Zanussi ZCG61246XA User manual

EN
ZCG61246XA
User Manual
Cooker
EG

Contents
Safety information 2
Safety instructions 4
Product description 6
Before first use 8
Hob - Daily use 9
Hob - Hints and tips 10
Hob - Care and cleaning 10
Oven - Daily use 11
Oven - Clock functions 13
Oven - Using the accessories 13
Oven - Hints and tips 14
Oven - Care and cleaning 17
Troubleshooting 19
Installation 20
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read the
supplied instructions. The manufacturer is not responsible for any
injuries or damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and accessible
location for future reference.
Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
•This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts are hot.
•Children shall not carry out cleaning and user maintenance of
the appliance without supervision.
General Safety
•Only a qualified person must install this appliance and replace
the cable.
•This appliance is intended for use up to an altitude of 2000 m
above sea level.
2 www.zanussi.com

•This appliance is not intended to be used on a ships, boats or
vessels.
•Do not install the appliance behind a decorative door in order
to avoid overheating.
•Do not install the appliance on a platform.
•Do not operate the appliance by means of an external timer or
separate remote-control system.
•WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in fire.
•NEVER try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire blanket.
•CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
•WARNING: Danger of fire: Do not store items on the cooking
surfaces.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the glass door or the glass of hinged lids of the hob since
they can scratch the surface, which may result in shattering of
the glass.
•Metallic objects such as knives, forks, spoons and lids should
not be placed on the hob surface since they can get hot.
•Remove any spillage from the lid before opening. Let the hob
surface cool down before closing the lid.
•WARNING: The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching heating
elements. Children less than 8 years of age shall be kept away
unless continuously supervised.
•Always use oven gloves to remove or put in accessories or
ovenware.
•Before maintenance cut the power supply.
•Ensure that the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre or
similarly qualified persons to avoid an electrical hazard.
www.zanussi.com 3

•WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The use
of inappropriate guards can cause accidents.
Safety instructions
This appliance is suitable for the following
markets: EG
Installation
WARNING!
Only a qualified person must install
this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Follow the installation instruction supplied
with the appliance.
• Always take care when moving the appliance
as it is heavy. Always use safety gloves and
enclosed footwear.
• Do not pull the appliance by the handle.
• The kitchen cabinet and the recess must
have suitable dimensions.
• Keep the minimum distance from the other
appliances and units.
• Make sure that the appliance is installed
below and adjacent safe structures.
• Parts of the appliance carry current. Close
the appliance with furniture to prevent
touching the dangerous parts.
• The sides of the appliance must stay
adjacent to appliances or to units with the
same height.
• Do not install the appliance adjacent to a
door or under a window. This prevents hot
cookware to fall from the appliance when the
door or the window is opened.
Electrical Connection
WARNING!
Risk of fire and electrical shock.
• All electrical connections should be made by
a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical information on
the rating plate agrees with the power
supply. If not, contact an electrician.
• Always use a correctly installed shockproof
socket.
• Do not use multi-plug adapters and
extension cables.
• Do not let mains cables touch or come near
the appliance door, especially when the door
is hot.
• The shock protection of live and insulated
parts must be fastened in such a way that it
cannot be removed without tools.
• Connect the mains plug to the mains socket
only at the end of the installation. Make sure
that there is access to the mains plug after
the installation.
• If the mains socket is loose, do not connect
the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type fuses
removed from the holder), earth leakage trips
and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
• Fully close the appliance door, before you
connect the mains plug to the mains socket.
Gas connection
• All gas connections should be made by a
qualified person.
• Before installation, make sure that the local
distribution conditions (nature of the gas and
gas pressure) and the adjustment of the
appliance are compatible.
• Make sure that there is air circulation around
the appliance.
• The information about the gas supply is on
the rating plate.
• This appliance is not connected to a device,
which evacuates the products of
combustion. Make sure to connect the
4 www.zanussi.com

appliance according to current installation
regulations. Pay attention to requirements
regarding adequate ventilation.
Use
WARNING!
Risk of injury and burns.
Risk of electrical shock.
• This appliance is for household use only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings are
not blocked.
• Do not let the appliance stay unattended
during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance
door while the appliance is in operation. Hot
air can release.
• Do not operate the appliance with wet hands
or when it has contact with water.
• Do not use the appliance as a work surface
or as a storage surface.
WARNING!
Risk of fire and explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or heated
objects away from fats and oils when you
cook with them.
• The vapours that very hot oil releases can
cause spontaneous combustion.
• Used oil, that can contain food remnants,
can cause fire at a lower temperature than
oil used for the first time.
• Do not put flammable products or items that
are wet with flammable products in, near or
on the appliance.
• Do not let sparks or open flames to come in
contact with the appliance when you open
the door.
• Open the appliance door carefully. The use
of ingredients with alcohol can cause a
mixture of alcohol and air.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the
enamel:
– do not put ovenware or other objects in
the appliance directly on the bottom.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food in the
appliance after you finish the cooking.
– be careful when you remove or install
the accessories.
• Discoloration of the enamel has no effect on
the performance of the appliance.
• Use a deep pan for moist cakes. Fruit juices
cause stains that can be permanent.
• Do not keep hot cookware on the control
panel.
• Do not let cookware boil dry.
• Be careful not to let objects or cookware fall
on the appliance. The surface can be
damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Do not put aluminium foil on the appliance or
directly on the bottom of the appliance.
• Cookware made of cast iron, aluminium or
with a damaged bottom can cause
scratches. Always lift these objects up when
you have to move them on the cooking
surface.
• Provide good ventilation in the room where
the appliance is installed.
• Use only stable cookware with the correct
shape and diameter larger than the
dimensions of the burners.
• Make sure the flame does not go out when
you quickly turn the knob from the maximum
to the minimum position.
• Use only the accessories supplied with the
appliance.
• Do not install a flame diffuser on the burner.
• This appliance is for cooking purposes only.
It must not be used for other purposes, for
example room heating.
Care and Cleaning
WARNING!
Risk of injury, fire, or damage to the
appliance.
• Before maintenance, deactivate the
appliance.
Disconnect the mains plug from the mains
socket.
• Make sure the appliance is cold. There is the
risk that the glass panels can break.
• Replace immediately the door glass panels
when they are damaged. Contact the
Authorised Service Centre.
• Be careful when you remove the door from
the appliance. The door is heavy!
www.zanussi.com 5

• Fat and food remaining in the appliance can
cause fire.
• Clean regularly the appliance to prevent the
deterioration of the surface material.
• Clean the appliance with a moist soft cloth.
Only use neutral detergents. Do not use any
abrasive products, abrasive cleaning pads,
solvents or metal objects.
• If you use an oven spray, obey the safety
instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
• Do not clean the burners in the dishwasher.
Lid
• Do not change the specification of the lid.
• Clean the lid regularly.
• Do not open the lid, when there are spills on
the surface.
• Before you close the lid turn all burners off.
• Do not close the lid until the hob and oven
are completely cold.
• Glass lid can shatter, when heated (if
applicable).
• Keep the lid glass open, while the oven is in
operation (if applicable).
Internal light
• The type of light bulb or halogen lamp used
for this appliance is only for household
appliances. Do not use it for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect the
appliance from the power supply.
• Only use lamps with the same specifications.
Gas Grill
WARNING!
Risk of fire, explosion and burns.
• Do not leave the appliance unattended
during grilling. Accessible parts become hot.
• Keep children away when the grill is in use.
• Do not put the oven shelf with food on the
highest shelf level.
Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to discard the appliance
correctly.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Remove the door catch to prevent children
or pets from becoming trapped in the
appliance.
• Flat the external gas pipes.
Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
Product description
Cooker specification
Check the table to see your appliance's detailed
specification.
6 www.zanussi.com

Model denomination and PNC number
ZCG61246XA 943006299
Initial gas settings Natural gas X
LPG X
Additional gas injectors X
Hob integrated ignition on the control knob X
Hob ignition on the spark generator button
Oven integrated ignition on the control knob X
Oven ignition on the spark generator button
Hob thermocouple
Oven thermocouple X
Oven cleaning Enamel X
Catalytic
Pan support Enamel
Cast iron X
General overview
2 3 4 51
6
7
8
9
10
11
1
2
3
4
5
1Button for the turnspit
2Knob for the Minute Minder
3Knob for the grill
4Knob for the oven functions
5Button for the lamp
6Knobs for the hob
7Grill
8Lamp
9Turnspit hole
10 Fan
11 Shelf positions
www.zanussi.com 7

Cooking surface layout
1 2 3
5 4
1Auxiliary burner
2Steam outlet - number and position depend
on the model
3Semi-rapid burner
4Semi-rapid burner
5Triple Crown burner
Accessories
•Wire shelf
For cookware, cake tins, roasts.
•Baking tray
For cakes and biscuits.
•Turnspit
For roasting larger joints of meat and poultry.
•Storage compartment
The storage compartment is below the oven
cavity. To use the compartment, lift the lower
front door then pull it down.
WARNING!
The storage compartment can
become hot when the appliance
operates.
•Coffee pot (if applicable)
For coffee makers and small pans.
Before first use
WARNING!
Refer to Safety chapters.
Initial Cleaning
Remove all accessories from the appliance.
Refer to "Care and cleaning"
chapter.
Clean the appliance and the accessories before
first use.
Put the accessories back to their initial position.
Preheating
Preheat the empty appliance to burn off the
remaining grease.
1. Set the maximum temperature.
2. Let the appliance operate for approximately
1 hour.
WARNING!
Accessories can become hotter than
usual.
The appliance can emit an odour and smoke.
This is normal. Make sure that the airflow is
sufficient.
Let the oven cool down. Dampen a soft cloth
with warm water and a little mild washing-up
liquid and use this to clean the oven cavity.
8 www.zanussi.com

Hob - Daily use
WARNING!
Refer to Safety chapters.
Ignition of the hob burner
Always light the burner before you
put on the cookware.
WARNING!
Be very careful when you use open
fire in the kitchen environment. The
manufacturer declines any
responsibility in case of the flame
misuse.
The spark generator can start
automatically when you switch on
the mains, after installation or a
power cut. It is normal.
In the absence of electricity you can
ignite the burner manually.
Ignition of a the hob burner without the
thermocouple
• For all hobs without thermocouple first turn
the knob and then push the knob down.
Release knob when the burner lights.
• For integrated ignition on knob push the
knob for the hob down and turn it
counterclockwise to the maximum gas flow
position .
Keep the knob for the hob pushed for equal or
less than 10 seconds to let the thermocouple
warm up. If not, the gas supply is interrupted.
Adjust the flame after it is regular.
WARNING!
Do not keep the knob pushed for
more than 15 seconds. If the burner
does not light after 15 seconds,
release the knob, turn it into the off
position and try to light the burner
again after minimum 1 minute.
If after some tries the burner does
not light, check if the crown and its
cap are in the correct position.
If the burner accidentally goes out,
turn the knob to the off position and
try to light the burner again after
minimum 1 minute.
Burner overview
A
B
C
C
A
B
A. Burner cap
B. Burner crown
C. Ignition candle (if applicable)
www.zanussi.com 9

Turning the burner off
To put the flame out, turn the knob to the off
position .
WARNING!
Always turn the flame down or
switch it off before you remove the
pans from the burner.
Hob - Hints and tips
WARNING!
Refer to Safety chapters.
Cookware
WARNING!
Do not put the same pan on two
burners.
WARNING!
Do not put unstable or damaged
pots on the burner to prevent from
spill and injury.
CAUTION!
Make sure that pot handles are not
above the front edge of the cooktop.
CAUTION!
Make sure that the pots are placed
centrally on the burner in order to
get maximum stability and to get
lower gas consumption.
Diameters of cookware
WARNING!
Use cookware with diameters
applicable to the size of burners.
Burner Diameter of cook-
ware (mm)
Triple Crown 160 - 240
Semi-rapid 140 - 240
Auxiliary 120 - 180
Energy saving
• If it is possible, always put the lids on the
cookware.
• When the liquid starts to boil, turn down the
flame to barely simmer the liquid.
Hob - Care and cleaning
WARNING!
Refer to Safety chapters.
General information
• Clean the hob after each use.
• Always use cookware with clean bottom.
• Scratches or dark stains on the surface have
no effect on how the hob operates.
• Use a special cleaner applicable for the
surface of the hob.
• Wash stainless steel parts with water, and
then dry them with a soft cloth.
Cleaning the hob
•Remove immediately: melted plastic,
plastic foil, sugar and food with sugar. If not,
the dirt can cause damage to the hob. Take
care to avoid burns.
•Remove when the hob is sufficiently
cool: limescale rings, water rings, fat stains,
shiny metallic discoloration. Clean the hob
with a moist cloth and non-abrasive
detergent. After cleaning, wipe the hob dry
with a soft cloth.
• To clean the enamelled parts, cap and
crown, wash them with warm soapy water
and dry them carefully before you put them
back on.
Cleaning the spark plug
This feature is obtained through a ceramic
ignition candle with a metal electrode. Keep
these components well clean to prevent difficult
lighting and check that the burner crown holes
are not obstructed.
10 www.zanussi.com

Pan supports
The pan supports are not resistant
to washing in a dishwasher. They
must be washed by hand.
1. Remove the pan supports to easily clean
the hob.
Be very careful when you
replace the pan supports to
prevent the hob top from
damage.
2. After you clean the pan supports, make sure
that they are in correct positions.
3. For the burner to operate correctly, make
sure that the arms of the pan supports are
aligned with the centre of the burner.
Periodic maintenance
Speak to your local Authorised Service Centre
periodically to check the conditions of the gas
supply pipe and the pressure adjuster, if fitted.
Oven - Daily use
WARNING!
Refer to Safety chapters.
Oven Functions
Oven function Application
Off position The appliance is off.
MIN -
240°C Heat settings Range of temperature adjustment.
Grilling To grill flat food in the middle of the grill. To make toast.
Oven fan To thaw frozen food.
To use the fan in combination with the gas oven burner
ignite the gas oven and turn the knob for the grill clock-
wise to activate the fan.
Oven lamp To illuminate the oven interior.
To use this function, press the button for the lamp.
Turnspit To spit roasting meat.
MIN -
240°C Gas Multifunction To cook several different dishes at the same time. To cook home-made syrup, dry mushrooms or fruit.
Ignition of the oven gas burner
CAUTION!
When turning on the oven burner
the oven door must be opened.
CAUTION!
Make sure that the lid is opened.
When using the oven the lid has to
be opened to avoid over-heating.
www.zanussi.com 11

Oven safety device:
The gas oven has a thermocouple. It
stops the gas flow if the flame goes
out.
1. Open the oven door.
2. Ignite the oven gas burner.
• For integrated ignition on the control
knob turn the knob for the oven
functions counterclockwise to the
maximum heat settings and push it to
light the burner.
Keep the knob for the oven functions
pushed for 15 seconds or less to let the
thermocouple warm up. If not, the gas flow
is interrupted.
Manual ignition of oven gas burner
In case of absence of the electricity you can
ignite the oven burner without an electrical
device.
1. Open the oven door.
2. Hold the flame near the hole in the bottom
of the oven cavity.
3. At the same time push the knob for the
oven functions and turn it counterclockwise
to the maximum gas flow position.
4. When the flame comes on, keep the knob
for the oven functions pushed on the
maximum gas flow position for 15 seconds
or less to let the thermocouple warm up.
Do not keep the knob for the oven
functions pushed for more than 15
seconds. If the oven burner does not
light after 15 seconds, release the
knob for the oven functions, turn it
into off position, open the oven door
and try to light the oven burner again
after minimum 1 minute.
After igniting the oven gas burner
1. Release the knob for the oven functions.
2. Close the oven door.
3. Turn the knob for the oven functions to set
the necessary heat setting.
Control the flame trough the holes in the bottom
of the oven.
Turning off the oven burner
To put out the flame, turn the knob to the off
position .
Using the grill
CAUTION!
Always keep the appliance door
closed when the grill operates.
Do not put the meat directly on the
tray or pan.
CAUTION!
Do not put the meat on the highest
shelf level. There is a risk of fire.
1. Open the oven door.
2. Ignite the grill burner.
• For manual ignition hold a flame near the
grill burner holes. Push and turn the
knob for the grill to the flame position.
Hold the knob pushed down.
• For integrated ignition on the control
knob push and turn the knob for the grill
to the flame position.
3. Hold the knob for the grill pushed for
approximately 15 seconds.
4. Release the oven control knob.
The grill temperature can be adjusted. To
lower the temperature turn the knob for the
grill counterclockwise.
If the grill does not come on or if it
accidentally goes out release the knob for
the oven functions and turn it to the Off
position. Open the oven door. After one
minute, try to light the grill again.
5. Preheat the grill for 5 to 10 minutes.
6. Put the oven shelf with the meat on shelf
position 3.
7. Put a baking tray or roasting pan below, on
shelf position 2, to collect the juices.
If there is temporarily no power supply open the
oven door hold a flame near the grill burner
holes and turn the lnob for the gas to the flame
position.
12 www.zanussi.com

Turning off the grill burner
To put out the flame, turn the knob to the off
position .
Oven - Clock functions
Minute Minder
This function has no effect on the
operation of the appliance.
Turn the knob for the timer as far as it goes,
then turn it to necessary time period.
After the time period is completed, an acoustic
signal sounds.
Oven - Using the accessories
WARNING!
Refer to Safety chapters.
Inserting the accessories
Wire shelf:
Put the shelf on the correct shelf position. The
front and back bars should be placed upwards.
Make sure the shelf does not touch the back
wall of the oven.
Tray:
Do not push the baking tray all the
way to the back wall of the cavity.
This prevents the heat from
circulating around the tray. The food
may be burnt, especially in the rear
part of the tray.
Put the tray or deep pan on the shelf position.
Make sure it does not touch the back wall of the
oven.
Using the turnspit
WARNING!
Be careful when you use the
turnspit. The forks and the spit are
sharp. There is a risk of injury.
WARNING!
Use oven gloves when you remove
the turnspit. The turnspit and the grill
are hot. There is a risk of burns.
CAUTION!
The maximum weight permitted on
the turnspit is 4.5 kg.
A B C
D
A. Support hook
B. Forks
C. Spit
D. Handle
The support hook is installed in the
top of the oven cavity.
You can leave the support hook in
the oven, when the turnspit is not
active.
1. Open the oven door.
2. Put the turnspit handle into the spit.
3. Put the baking tray on the lowest shelf level.
4. Snap out one end of the support hook from
the oven ceiling A and let it hang on the
other end.
www.zanussi.com 13

A
5. Install the first fork on the spit, then put the
meat on the turnspit and install the second
fork.
Make sure that the meat is in the middle of
the spit.
6. Use the screws to tighten the forks.
7. Put the tip of the spit into the turnspit hole.
Refer to "Product description" chapter.
8. Put the front part of the spit on the support
hook.
9. Remove the turnspit handle.
10. Light the grill.
Refer to "Oven - Daily use" chapter.
11. Press the turnspit button .
12. Make sure that turnspit rotates.
13. Close the oven door.
The turnspit does not stop if you open the
oven door.
When meat is ready press the turnspit button.
Turn off the grill. Install the turnspit handle.
Carefully remove the turnspit and the roasting
pan from the oven.
Oven - Hints and tips
WARNING!
Refer to Safety chapters.
The temperature and baking times in
the tables are guidelines only. They
depend on the recipes and the
quality and quantity of the
ingredients used.
General information
• The appliance has five shelf positions. Count
the shelf positions from the bottom of the
appliance floor.
• The appliance has a special system which
circulates the air and constantly recycles the
steam. With this system you can cook in a
steamy environment and keep the food soft
inside and crusty outside. It decreases the
cooking time and energy consumption to a
minimum.
• Moisture can condense in the appliance or
on the door glass panels. This is normal.
Always stand back from the appliance when
you open the appliance door while cooking.
To decrease the condensation, operate the
appliance for 10 minutes before cooking.
• Clean the moisture after each use of the
appliance.
• Do not put the objects directly on the
appliance floor and do not put aluminium foil
on the components when you cook. This can
change the baking results and cause
damage to the enamel.
Baking
• Your oven may bake or roast differently to
the appliance you had before. Adapt your
14 www.zanussi.com

usual settings (temperature, cooking times)
and shelf positions to the values in the
tables.
• The manufacturer recommends that you use
the lower temperature the first time.
• If you cannot find the settings for a special
recipe, look for the one that is almost the
same.
• You can extend baking times by 10 – 15
minutes if you bake cakes on more than one
shelf position.
• Cakes and pastries at different heights do
not always brown equally at first. If this
occurs, do not change the temperature
setting. The differences equalize during the
baking procedure.
• With longer baking times, you can deactivate
the oven approximately 10 minutes before
the end of the baking time and then use the
residual heat.
When you cook frozen food, the trays in the
oven can twist during baking. When the trays
become cold again, the distortions are gone.
Baking cakes
• Do not open the oven door before 3/4 of the
set cooking time is up.
• If you use two baking trays at the same time,
keep one empty level between them.
Cooking meat and fish
• Use a deep pan for very fatty food to prevent
the oven from stains that can be permanent.
• Leave the meat for approximately 15 minutes
before carving so that the juice does not
seep out.
• To prevent too much smoke in the oven
during roasting, add some water into the
deep pan. To prevent the smoke
condensation, add water each time after it
dries up.
Cooking times
Cooking times depend on the type of food, its
consistency, and volume.
Initially, monitor the performance when you
cook. Find the best settings (heat setting,
cooking time, etc.) for your cookware, recipes
and quantities when you use this appliance.
Cooking tables
The time does not include
preheating.
Casseroles
Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Lasagna1) 1.5 - 2.5 180 45 - 50 2
Cannelloni
1)
1.5 - 2.5 180 45 - 50 2
Potato gratin
1)
1.5 - 2.5 190 55 - 60 2
Macaroni oven
1)
1.5 - 2.5 195 40 - 45 2
Kebab Hala 1.5 - 2.5 195 45 - 50 2
1) Preheat the oven for 10 minutes.
www.zanussi.com 15

Meat & Poultry
Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Sheep 1.5 - 2.0 210 90 - 120 2
Chicken 1.0 - 1.8 240 90 - 1001) 2
Duck 1.8 - 2.5 240 90 - 120 2
Goose 2.5 - 3.0 240 100 - 160 2
Rabbit 1.0 - 1.5 195 90 - 120 2
Beef 1.2 - 1.8 210 90 - 120 2
1) Turn over after 45 minutes.
Fish
Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Pike 0.8 - 1.5 180 60 - 80 2
Dorade 0.4 - 0.7 180 40 - 60 2
Trout 0.5 - 1.0 180 25 - 30 2
Pizza
Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Thin
1)
1.0 - 1.2 210 20 - 25 2
Thick
1)
1.4 - 1.5 240 20 - 25 1
Calzone
1)
1.4 - 1.5 210 25 - 30 2
1) Preheat the oven for 10 minutes.
Cakes
Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Flat cake
1)
0.6 - 1.0 170 25 - 30 2
Flat cake
1)
1.2 - 2.0 170 22 - 30 2 and 4
Sponge cake 1.0 - 1.5 150 110 - 115 2
16 www.zanussi.com

Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Feter Mshalted
1)
1.0 - 1.5 195 30 - 35 2
Salty cake
1)
1.0 - 1.2 195 50 - 60 2
Yeast cake
1)
1.0 - 1.5 195 45 - 50 2
1) Preheat the oven for 10 minutes.
Grilling
Food Quantity (kg) Grill position Time (min) Shelf position
Sheep chops1) 0.7 - 1.2 half 20 - 25 3
Ribs
1)
1.0 - 1.2 half 45 - 60 3
Burgers
1)
2.0 - 2.5 max. 15 - 20 3
Mackerel
1)
1.2 - 1.5 half 20 - 25 3
Toast browning
1)
0.3 - 0.5 max. 5 - 7 3
Toast Hawai
1)
0.5 - 1.0 max. 15 - 20 3
1) Preheat the oven for 5 minutes.
Revolving frying
Food Quantity (kg) Grill position Time (min) Shelf position
Sheep on skewer 1.5 - 2.0 max. 100 - 120 Turnspit
Chicken on skew-
er 1.2 - 1.8 max. 95 - 105 Turnspit
Oven - Care and cleaning
WARNING!
Refer to Safety chapters.
Notes on cleaning
• Clean the front of the appliance with a soft
cloth with warm water and a cleaning agent.
• To clean metal surfaces, use a dedicated
cleaning agent.
• Clean the appliance interior after each use.
Fat accumulation or other food remains may
result in a fire.
• Clean stubborn dirt with a special oven
cleaner.
www.zanussi.com 17

• Clean all accessories after each use and let
them dry. Use a soft cloth with warm water
and a cleaning agent.
• If you have nonstick accessories, do not
clean them using aggressive agents, sharp-
edged objects or a dishwasher. It can cause
damage to the nonstick coating.
Stainless steel or aluminium appliances
Clean the oven door with a damp
cloth or sponge only. Dry it with a
soft cloth.
Do not use steel wool, acids or
abrasive materials as they can
damage the oven surface. Clean the
oven control panel with the same
precautions.
Cleaning the oven door
The oven door has two panels of glass installed
one behind the other. To make the cleaning
easier remove the oven door.
WARNING!
The oven door can close if you try to
remove the internal panel of glass
when the door is still assembled.
Do not lose the screws.
1. Open the door fully and hold the two door
hinges.
2. Lift and turn the levers on the two hinges.
3. Close the oven door to the first opening
position (halfway). Then pull forward and
remove the door from its seat.
4. Put the door on a soft cloth on a stable
surface.
5. Use a screwdriver to remove 2 screws from
bottom edge of door.
1
1
6. Use a spatula made of wood or plastic or
equivalent to open the inner door. Hold the
outer door, and push the inner door against
the top edge of the door. Lift the inner door.
22
3
7. Clean the oven door with water and soap.
Clean inner side of the door. Dry the oven
door carefully.
When the cleaning is completed, install the
glass panels and the oven door. To install the
oven door, do the above steps in the opposite
sequence.
44
5
5
6
18 www.zanussi.com

Replacing the lamp
Put a cloth on the bottom of the interior of the
appliance. It prevents damage to the lamp glass
cover and the cavity.
WARNING!
Danger of electrocution! Disconnect
the fuse before you replace the
lamp.
The lamp and the lamp glass cover
can be hot.
1. Deactivate the appliance.
2. Remove the fuses from the fuse box or
deactivate the circuit breaker.
The back lamp
1. Turn the lamp glass cover counterclockwise
to remove it.
2. Clean the glass cover.
3. Replace the lamp with a suitable 300 °C
heat-resistant lamp.
4. Install the glass cover.
Troubleshooting
WARNING!
Refer to Safety chapters.
What to do if...
Problem Possible cause Remedy
There is no spark when you try to
activate the spark generator. The hob is not connected to an electrical supply or it is connec-
ted incorrectly.
Check if the hob is correctly con-
nected to the electrical supply.
Refer to the connection diagram.
There is no spark when you try to
activate the spark generator. The fuse is blown. Make sure that the fuse is the cause of the malfunction. If the
fuse is blown again and again,
contact a qualified electrician.
There is no spark when you try to
activate the spark generator. Burner cap and crown are placed incorrectly. Place the burner cap and crown correctly.
The flame ring is uneven. Burner crown is blocked with
food residues. Make sure that the injector is not blocked and the burner crown is
clean.
The burners do not work. There is no gas supply. Check the gas connection.
The appliance makes noises. Some metal parts of the appli-
ance expand and contract when
they heat up or cool down. The
noises are normal.
The flame colour is orange or yel-
low. The flame can look orange or yel- low in some areas of the burner.
This is normal.
The lamp does not operate. The lamp is defective. Replace the lamp.
Steam and condensation settle
on the food and in the cavity of
the oven.
You left the dish in the oven for
too long. Do not leave the dishes in the oven for longer than 15 - 20 mi-
nutes after the cooking process
ends.
www.zanussi.com 19

Problem Possible cause Remedy
The oven does not heat up. The necessary settings are not
set. Make sure that the settings are correct.
The turnspit does not rotate. The turnspit is not correctly in-
stalled into the turnspit hole. Refer to "Using the turnspit".
It takes too long to cook the
dishes or they cook too quickly. The temperature is too low or too high. Adjust the temperature if neces- sary. Follow the advice in the
user manual.
Service data
If you cannot find a solution to the problem
yourself, contact your dealer or an Authorised
Service Centre.
The necessary data for the service centre is on
the rating plate. The rating plate is on the front
frame of the appliance cavity. Do not remove
the rating plate from the appliance cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
Installation
WARNING!
Refer to Safety chapters.
Location of the appliance
You can install your freestanding appliance with
cabinets on one or two sides and in the corner.
Keep a distance of about 1 cm
between the appliance and the back
wall to make sure that the lid opens.
For minimal distances for fitting check the table.
A
C
D
D
B
Minimum distances
Dimension mm
A400
