Zanussi ZOU 851 User manual

ELECTRIC OVEN
ÇËÅÊÔÑÉÊÏÓ
ÖÏÕÑÍÏÓ
ZOU 851
INSTRUCTION BOOKLET
ÏÄÇÃÉÅÓ ×ÑÇÓÇÓ
GR
All manuals and user guides at all-guides.com
all-guides.com

2
This appliance complies with the following
E.E.C. Directives:
- 73/23 - 90/683 (Low Voltage Directive);
- 89/336 (Electromagnetical Compatibilit Directive);
- 93/68 (General Directives)
and subsequent modifications.
ENGLISH
These warnings are provided in the interest of safet . You MUST read them carefull before installing or using the appliance.
Important Safety Information
Installation
 It is mandator that all operations required for the
installation are carried out b a qualified or competent
person, in accordance with existing rules and
regulations.
 It is dangerous to alter the specification in an wa .
 Once ou removed all packaging from the appliance,
ensure that it is not damaged and the electric cable is
in perfect conditions. Otherwise, contact our dealer
before proceeding with the installation.
Child Safety
 This appliance has been designed to be operated b
adults and children under supervision. Young children
MUST NOT be allowed to tamper with the controls or pla
near or with the oven.
 Accessible parts of this appliance ma become hot
when it is in use. Children should be KEPT AWAY until it
has cooled.
During use
 This appliance has been designed for cooking edible
foodstuff onl and MUST NOT be used for an other
purposes.
 Ensure that all control knobs are in the OFF position
when not in use.
 Should ou connect an electrical tool to a plug near
this cooking appliance, ensure that electric cables are
not in contact with it and keep them far enough from
the heated parts of this appliance.
If the appliance is out of order, disconnect it from the
electric suppl .
Do not leave untensils containing foodstuffs, e. g. fat
or oil in or on the appliance. This could cause damage
in case the appliance is inadvertentl switched on.
 Alwa s place the dripping pan in position to collect fat
when using the grill or when cooking meat. Pour a little
water into the dripping pan to avoid smoke and
unpleasant smells.
 Alwa s use oven gloves to remove pans from the oven.
 For h giene and safet reasons, this appliance should
be kept clean at all times. A build-up of fats or other
foodstuff could result in a fire.
 Disconnect the appliance from the electrical suppl ,
before carr ing out an cleaning or manteinance work.
Some parts of the appliance are covered b a shock-
proof plastic film. Remove this film before using the
oven.
This appliance is meant to operate with a single-
phased connection to 230V electrical suppl . An
eventual 400V poliphasic connection without earth
wire will destro the oven and the hob, if fitted.
 The manufacturer disclaims any responsability
should all the safety measures not be carried out
Service
 Under no circumstances should ou attempt to repair
the appliance ourself. Repairs carried out b
unexperienced persons ma cause injur or serious
malfunctioning. Refer to our local Service Centre.
Alwa s insist on genuine spare parts.
Environmental Information
 After installation, please dispose of the packaging with
due regard to safet and the environment.
 When disposing of an old appliance, make it unusable,
b cutting off the cable.
Guide to Use the instructions
The following s mbols will be found in the text to guide
ou throughout the Instructions:
Safet Instructions
Step b step instructions for an operation
Hints and Tips
Environmental information
F
MANUFACTURER: ELECTROLUX ZANUSSI S.p.A.
Viale Bologna, 298
47100 FORLÌ (Ital )
It is most important that this instruction book
is be retained with the appliance for future
reference Should the appliance be sold or
transferred, always ensure that the book is left
with the appliance in order that the new
owner can get to know the functions of the
appliance and the relevant warnings
All manuals and user guides at all-guides.com

3
OVEN DOOR PROTECTION DEVICE (stainless
steel models) All our appliances compl with the
European Safet Standards. Nevertheless, in order
to ensure the highest safet level, and avoid little
children to be exposed to the heat when the appliance
is operated, it is possible to fit a special protection
device to the oven door. This device can be purchased
in our Service Force Centres, specif ing the relevant
code (35791) and the Product No. shown on the
rating plate. Fitting instructions are provided with the
kit package.
Contents
For the User For the Installer
Description of the Oven
1. Control panel
2. Control knobs for the hotplates
3. Thermostat control light (°C)
4. Thermostat control knob
5. Oven control light
6. Oven function control knob
7. Grill
8. Oven light
9. Oven fan
10. Rating plate
10
8
7
9
1
4
5
26
3
Important Safety Information
Description of the Oven 3
Operation 4
When the oven is first installed 5
Electronic programmer 6
Using the oven 8
Cooking Tables 9
Cooking Tables 10
Cleaning and maintenance 11
Technical Assistance 1
Something not working... 1
Technical Data 13
Installation 13
Electrical connection 14
All manuals and user guides at all-guides.com

4
Fig 2 FO 2673
Oven function control knob
(Fig 1)
Oven Light - The oven light will be on without an
cooking function
Conventional cooking - The heat comes from both
the top and bottom element, ensuring even heating
inside the oven.
Top heating element - The heat comes from the
top of the oven onl .
Bottom heating element - The heat comes from
the bottom of the oven onl .
Inner grill element onl - can be used for grilling
small quantities.
Double Grill - The full grill element will be on.
Thermal Grilling - This function offers an alterna-
tive method of cooking food items, normall
associated with conventional grilling. The grill
element and the oven fan operate together,
circulating hot air around the food. When using
this function, select a maximum temperature
of 200°C
Fan cooking - This allows ou to roast or roast and
bake simoultaneousl using an shelf, without
flavour transference.
Defrost Setting - This setting is intended to assist
in thawing of frozen food.
Thermostat control knob (Fig 2)
Turn the thermostat control knob to select temperatures
between 50°C and 250°C (MAX).
Thermostat control light (°C)
Once the oven temperature has been selected, the
temperature light will come on and remain on until the
oven has reached the correct setting; after that, it will go
on and off with the thermostat, showing how the tempe-
rature is being maintained.
Oven control light
It will come on ever time an heating element is set on
operation.
Fig 1 FO2672
Operation
50
MAX
100
150
200
0
All manuals and user guides at all-guides.com

5
The Safety Thermostat
This oven is provided with a safet thermostat. In case of
malfunctioning of the main thermostat, and consequent
over-heating, the safet device will stop the power suppl
to the appliance. If this happens, call our local Service
Centre. Under no circumstances should ou attempt to
repair the appliance ourself.
The Cooling Fan for the Controls
This oven is provided with a cooling fan, meant to keep the
front panel, the knobs and the oven door handle cool. This
fan ma run on after the oven or grill is switched off, until
a normal temperature is reached.
Before cooking for the first time, carefull wash
the oven accessories.
Once the oven has been installed:
a) set the thermostat knob to MAX;
b) switch the oven function control knob to conventional
cooking ( );
c) allow the oven to run empt for approximatel 45
minutes;
d) open a window for ventilation.
During this time, an unpleasant odour ma be emitted.
This is absolutel normal, and is caused b residues of
manufacturing.
Repeat this operation for the grill and fan cooking function.
Once this operation is carried out, let the oven cool down,
then clean the oven cavit with a soft cloth soaked in warm
soap water.
FO 2161
Fig 4
To open the oven door, always catch the
handle in its central part (Fig 7)
When the oven is first installed
Hotplate control knobs
The Control Knobs for the hotplates (Fig. 3) can be found
on the oven control panel. The energ regulator of the
hotplates can be set b means of a 7-position control
knob:
0=Off
1= Minimum
3= Maximum
The intermediate positions give an increasing heating
power.
Carefully supervise cookings with oil or fats,
since these types of food can result in a fire,
when over-heated
FO 2745
Fig 3
0
3
2
1
All manuals and user guides at all-guides.com

6
Using the oven
Conventional cooking
Turn the oven function control knob to the relevant
s mbol ( ) and set the thermostat knob on the required
temperature.
If ou need more heat from the top or the bottom of the
oven, turn the oven function control knob to (top
heating element onl ) or (bottom heating element
onl ).
Fan cooking
Turn the oven function control knob to the relevant
s mbol ( ) and set the thermostat knob on the required
temperature. The fan behind the back panel circulates
heated air into the oven.
If ou need to cook more than one dish in the fan oven at
the same time, place the shelves on the first and third
position from the bottom (fig. 5). If ou are cooking onl
one dish in the fan oven, use the lower positions, as this
will give ou better results.
Grilling
Turn the oven function control knob to the relevant
s mbol ( or ) and set the thermostat knob on the
required temperature. With the setting , ou will
obtain even heating on the whole surface of the dish.
When grilling meat or fish, spread a little oil on them and
alwa s place them on the oven grid. The shelf level
depends on the thinckness of the food.
Alwa s place the dripping pan at the lowest level, with
some water in it, to avoid smoke and unpleasant smells.
Thermal grilling
Turn the oven function control knob to the relevant
s mbol ( ) and set the thermostat knob on the required
temperature. When using this cooking function,
select a maximum temperature of 200°C
The full grill element and the oven fan operate alternatel ,
circulating hot air around the food. The need to check and
turn food is reduced. With the exception of toast and rare
steaks, ou can thermal grill all the foods ou would
normall cook under a conventional grill.
Defrosting
Turn the oven function control knob to the relevant
s mbol ( ) and set the thermostat knob on the OFF
position (s mbol : l). The oven fan operates without
heat and circulates the air, at room temperature, inside
the oven.
 The temperatures inside the oven can reach 250°C.
Alwa s ensure that ou are using oven proof baking
tra s, oven dishes, etc. Fig 5
Always cook with the oven door closed
4
3
2
1
Fan cooking
 Do not place pans, biscuit pans or aluminium foil
directl on the base of the oven. This could cause a
heat build-up which could affect the performance of the
oven and damage the oven enamel.
 Carefull supervise cookings with fats or oil, since
these t pes of foodstuff can result in a fire, if over-
heated. For the same reason, be careful when placing
or removing food in the oven, not to let an fat or oil fall
on the oven base. If this happens, carefull clean the
oven to avoid unpleasant smells or smoke.
Hints and Tips on Cooking
Fish and Meat
You can place meat in oven proof dishes, or directl on
the oven shelf. In this case, remember to place the
dripping pan in the first position from the bottom with
some water in it. The dripping pan will avoid the falling
of melted fat on the oven base.
White meat, poultr and fish in general, need a medium
temperature cooking (between 150 and 175 °C). If ou
need to cook red meat (slightl browned on the outside
and more gentl cooked in the inside), a higher tempera-
ture (between 200 and 250 °C) for a short time is
recommended.
Hints and Tips on baking
Cakes usuall need a medium temperature cooking,
between 150 and 200 °C.
A short oven pre-heating (about 10 minutes) is
recommeded when cooking cakes or baking. Once the
cooking has been started, keep the oven door closed
during all the cooking time, and check the cooking results
through the oven door glass.
Hints and Tips on grilling
If ou need to grill meat or fish, place them directl on
the shelf after spreading a little oil on them. In the grill
function, heat comes onl from the top element. Therefore,
ou need to adjust the cooking level depending on meat
or fish's thickness. Alwa s remember to place the dripping
pan in the lower position with some water in it.
FO 0351
All manuals and user guides at all-guides.com
all-guides.com

7
temp.
Cakes
Whipped up kneading 2 180 2 (1 and 3)* 160 45 ~ 60
Leavened kneading 2 180 2 (1 and 3)* 160 20 ~ 35
Shortbread dough 2 180 2 (1 and 3)* 160 20 ~ 30
Butter-milk cheese cake 1 175 2 150 60 ~ 80
Apple cake 1 180 2 (1 and 3)* 160 40 ~ 60
Strudel 2 175 2 (1 and 3)* 150 60 ~ 80
Jam-tart 2 180 2 (1 and 3)* 160 45 ~ 60
Small cakes 2 180 2 (1 and 3)* 160 15 ~ 25
Biscuits 2 180 2 (1 and 3)* 160 10 ~ 20
Meringues 2 100 2 (1 and 3)* 100 90 ~ 120
Bread and Pizza
1000 White bread 1 200 2 175 45 ~ 60 1 piece
500 R e bread 2 200 2 175 30 ~ 45 In bread pan
500 Bread rolls 2 200 2 (1 and 3)* 175 20 ~ 35 8 rolls
250 Pizza 1 220 2 (1 and 3)* 200 20 ~ 35 In baking pan
Flans
Pasta flan 2 200 2 (1 and 3)* 175 40 ~ 50
Vegetable flan 2 200 2 (1 and 3)* 175 45 ~ 60
Quiches 2 200 2 (1 and 3)* 175 35 ~ 45
Lasagne 2 200 2 175 45 ~ 60
Meat
1000 Beef 2 200 2 175 50 ~ 70 On grid
1200 Pork 2 200 2 175 100 ~ 130 On grid
1000 Veal 2 200 2 175 90 ~ 120 On grid
1500 English roast beef 2 220 2 200 50 ~ 70 On grid
1200 Lamb 2 200 2 175 110 ~ 130 Leg
1000 Chicken 2 200 2 175 60 ~ 80 Whole
4000 Turke 2 200 2 175 210 ~ 240 Whole
1500 Duck 2 175 2 160 120 ~ 150 Whole
3000 Goose 2 175 2 160 150 ~ 200 Whole
1200 Hare 2 200 2 175 60 ~ 80 Cut in pieces
Fish
1000 Whole 2 200 2 (1 and 3)* 175 40 ~ 60 2 fishes
800 Fillets 2 200 2 (1 and 3)* 175 30 ~ 40 4 fillets
Fan Oven
Conventional Cooking NOTES
WEIGHT
(GR.)
Cooking
time
minutes
°C
temp.
Level
4
3
2
1
Conventional and fan cooking
TYPE OF DISH
NOTE:
Cooking times do not include pre-heating time. We
reccomend a short oven pre-heating (about 10 minutes)
before baking or cooking pizza.
(*) If ou need to cook more than one dish at the same
time, we recommend ou to place them on the levels
quoted between brackets.
The times given in the table are intended as a guide onl .
Onl experience will enable ou to determine the correct
setting to suit our personal requirements.
Cooking Tables
Level
4
3
2
1
°C
All manuals and user guides at all-guides.com

8
Steaks 4 800 4 max 10 8
Chops 4 600 4 max 12 8
Sausages 8 500 4 max 10 6
Chicken (cut in pieces) 6 800 3 max 30 20
Kebabs 4 700 4 max 12 10
Chicken (breast) 4 400 4 max 13 10
Tomatoes 8 500 4 max 12 
Fish (fillets) 4 400 4 max 8 6
Sandwiches 4  4 max 8 
Toast 4  4 max 2~3 1
Upper
side
°C
temp.
PIECES WEIGHT
Quantit Cooking time
(minutes)
Lower
side
Grilling
TYPE OF DISH
Level
4
3
2
1
Type of dish Quantiy (gr ) Shelf level Temperature °C Time in minutes
from the bottom lower side upper side
Pork 1500 2 or 3 170 45 30
Roastbeef 1500 3 200 30 20
Chicken 1200 2 or 3 190 40 30
Kebabs 800 3 200 15 10
Fish (whole) 800 3 200 12 8
Cooking Tables
Grilling
When using the Thermal grill function, select a maximum temperature of 200°C
Thermal grilling
All manuals and user guides at all-guides.com

9
F
Cleaning and maintenance
General Cleaning
Before carrying out any cleaning or
manteinance work, always disconnect the
appliance from the electrical supply, and
allow it to cool down
 When using spray cleaning products, be careful not
to spread them on the heating elements or on the
thermostat sensor.
 Never use harsh abrasives, steel wool or cleaners
with bleach, as the could damage the enamel and
the oven door glass.
The Oven Cavity
The enamelled oven cavit is best cleaned whilst the oven
is still warm. It is advisable to wipe the oven over with a soft
cloth soaked in warm soap water after each use.
However, from time to time, it will be necessar to do a
more complete cleaning, using a proper oven cleaner.
In case of particularl tough stains, ou can use stainless
steel cleaning products or some warm vinegar.
If cooking fruits, some over-heated natual acids
can squeeze and settle on the oven enamel,
causing stains quite difficult to remove. This could
affect the enamel brightness, but it will have no
consequence on the oven performances. To avoid
these stains to be burnt out during the next
cooking, carefull clean the oven cavit after all
fruits cookings.
The Oven Door and its gasket
Before cleaning the oven door, we recommend ou to
remove it from the oven.
Proceed as follows:
a) open the oven door completel ;
b) find the hinges linking the door to the oven (fig. 7);
c) unlock and turn the small levers located on the two
hinges (fig. 7);
d) handle the door b its left- and right-hand sides, then
slowl turn it towards the oven until it is half-closed;
e) gentl pull the oven door off its site (fig.7);
f) place it on a stead plan.
Clean the oven door glass with warm water and a softh
cloth onl .
Once the cleaning is carried out, refit the oven door,
following the procedure in reverse.
The correct operation of the oven is ensured b a gasket
placed round the edge of the oven cavit .
 Periodicall check the condition of this gasket. If
necessar , clean it without using abrasive cleaning
products.
 If the gasket shows to be damaged, call ou local
Service Centre. Do not use the oven until it has been
repaired.
Fig 7 FO 0288
Fig 6
Replacing the Oven Light
Ensure the electricity supply is switched off
before carrying out this operation
The oven bulb has to compl to these features:
a) resistant to temperatures of 300 °C;
b) electric rate: 230 V - 50 Hz;
c) electric power rate: 25 W;
d) connection t pe: E 14.
To replace the bulb, proceed as follows (Fig. 8):
a) push in and turn the glass lid anticlockwise;
b) remove tha fault bulb;
c) replace it with a new one;
d) refit the glass lid;
e) switch on the electricit suppl .
FO 0287
Fig 8
All manuals and user guides at all-guides.com

10
SOLUTION
uCheck that both a cooking function and a temperature have
been selected
or
uCheck the appliance is wired in properl , and the socket
switch or the switch from the mains suppl to the oven are
ON.
uTurn the thermostat knob on a temperature
or
uTurn the oven function control knob on a function.
uTurn the oven function control knob on a function
or
uBu a new oven light bulb, asking for it to our local Service
Centre and replace it b following the instruction provided in
this booklet.
uRefer to the contents of this booklet, especiall to the chapter
"Using the Oven".
uLeave dishes inside the oven no longer than 15-20 minutes
after the cooking is completed.
SYMPTOM
nThe oven does not come on
nThe oven temperature light does not come on
nThe oven light does not come on
nIt takes too much time to finish the dishes, or
the are cooked too fast.
nSteam and condensation settle on the food and
the oven cavit .
If the appliance is not working correctly, please carry out the following checks, before contacting your local
Service Centre
f after the checks listed in the previous chapter, the
appliance still does not work correctl , contact our
local Service Centre, specif ing the t pe of
malfunctioning, the appliance model (Mod.), the product
number (Prod. No.) and the serial number (Ser. No.)
marked on the identification plate.
This plate is placed on the front external edge of the oven
cavit .
Original spareparts, certified b the product
manufacturer and carr ing
this s mbol are onl available
at our Service Centre and
authorized spareparts shops.
Something not working...
Technical Assistance
These built-under ovens can be combined with the
following hob models (50 Hz - 230V):
- ZMF 2105
- ZMFW 2305
- ZME 2005
- ZK 630
- ZC 6675
Total ating of combined appliances
Oven + Hob 9,9 kW
Fig 9
SER. NO.
Mod.
PROD. NO.
SER. NO.
MOD.
PROD. NO.
TYPE
All manuals and user guides at all-guides.com

11
Recess dimensions
Height 59,5 cm
Width 56,0 - 57,00 cm
Depth 55,0 cm
Oven cavity dimensions
Height 32,5 cm
Width 42,0 cm
Depth 39,0 cm
Volume 53 l
Technical Data
The following instructions are meant to a qualified
technician, in order to allow him carry out the
installation in compliance with the rules in force
The building-in and the electrical connection fo the
appliance must be carried out by a qualified and
authorized technician only
Building In
It is important that the dimensions and materials of the
surround or cabinet into which the oven will be built are
correct and will withstand a temperature increase.
A correct installation will have to ensure a proper protection
against contact with electric parts or merel functionall
isolated parts.
All the units meant to ensure protection have to be fitted
not to be taken awa without using an tool.
We recommed not to install the appliance near refrigerators
or freezer, since the heat could affect the performance of
these appliances.
Oven dimensions
The oven dimensions are shown in fig. 10.
Undertop Recess Dimensions
The recess must have the dimensions shown in Fig. 11.
Securing the Oven to the Cabinet
- Fit the appliance into the cabinet recess.
- Open teh oven door and secure the oven to the kitchen
cabinet with four wood screws, which fit the holes
provided in the oven frame (Fig.12).
When installing an electric plate hob over the oven, the
hob's electrical connection and the oven's one have to be
carried out separatel , for securit reasons and to let the
oven be taken off the unit easier, if necessar .
FO 2160
FO 0207
Fig 10
Fig 11
Installation
Heating elements ratings
Bottom heating element 1000 W
Top heating element 800 W
Full Oven (Top+Bottom) (1000 + 800) 1800 W
Simple Grill heating element 1750 W
Double Grill heating element 2550 W
Oven rear heating element 2000 W
Convection fan 30 W
Cooling fan 25 W
Oven lamp 25 W
Voltage tension 230/400 V 3N ~ 50Hz
Maximum power rating (230V - 50Hz) 2600 W
FO 0039
Fig. 12
All manuals and user guides at all-guides.com
all-guides.com

12
Before the appliance is connected:
1) check that the main fuse and the domestic installation
can support the load;
2) check that the power suppl is properl earthed in
compliance with the current rules;
3) check the socket or the double pole switch used for
the electrical connection can be easil reached with
the appliance built in the forniture unit.
This appliance is supplied without connection cable. A
suitable one must be fitted, in compliance with the electric
suppl rate. Onl the following cable t pes must be used:
H07 RN-F, H05 RN-F, H05 RR-F, H05 VV-F, H05 V2V2-F
(T90), H05 BB-F. A suitable plug, able to carr the load
specified on the rating plate, must be fitted to the cable.
The plug has to be fitted in a proper socket.
If connecting the appliance directl to the electric
s stem, a double pole switch must be installed between
the appliance and the electricit suppl , with a minimum
gap of 3 mm. between the switch contacts and of a
t pe suitable for the required load in compliance with
the current rules. The earth wire must not be interrupted
b the double switch pole.
The connection cable has to be placed in order that, in
each part, it cannot reach a temperature 50 °C higher
than the room temperature.
After the connection is carried out, test the heating
elements for about 3 minutes.
Connection to terminal block
This appliance is provided with a 6 poles terminal block
(Fig. 13) set to operate with a 400 V three-phase
electrical suppl with neutral wire. To adapt the the
terminal block to a different electrical suppl , carr out
the connection as shown in Fig. 14. The earth wire must
be connected to terminal marked . Once the
connection is carried out, fit the cable into the the cable
clamp.
Electrical connection with the
hob
This oven can be connected to hobs indicated in the
"Technical Assistance" section. The socket for connecting
the hob is located at the top of the oven cabinet. The
hobs come complete with connecting leads for the hot
plates/heat areas and ground cable; these leads feature
plug-in connectors. Connection of the hob to the oven is
carried out b plugging-in these connectors to the cor-
responding oven socket.
The plug-to-socket connection design is such as to
prevent possible wrong plugging-ins.
The manufactu e disclaims any
esponsability should all the safety
measu es not be ca ied out.
FO 0584
Fig 14
FO 0330
Fig 13
230V 3~ 1 2 3 4 5
L1 L2 L3 PE
230V 1~ 1 2 3 4 5
L1 N PE
400V 2N~
1 2 3 4 5
L1 L2 N PE
400V 3N~
1 2 3 4 5
L1 L2 L3 N PE
lectrical connection
All manuals and user guides at all-guides.com
