Zap ACC200 User manual

Quick Start Guide - qACC200-202, qACC250-253 Copyright 2021 System Q Ltd
1
Slim & Compact Exit Buttons
Zap is a registered trademark of System Q Ltd
ACC200-202, ACC250-253 - Quick Start Guide
Exit Buttons
This guide covers the slim exit buttons which are made from zinc
alloy with a matt finish. Their slim footprint means they can fit
most locations and come supplied with their own back box.
This guide also coversthe compact exit buttons, just 53mmwide
with a built-in back box. The options available also include the
LED illuminated ACC253 model.
User Information
· There are no user serviceable parts, opening or attempting to repair the product will void the warranty.
· Do not install or use the device if the wires connected are damaged or have been subjected to water
ingress.
· Shut off all power to the access control system before wiring this device.
· Maintain a clean and safe environment at all times.
Definition
NO (Normally Open) - This is a contact which remains open (as default) until activated, during the "active" state
the contact provides a closed circuit and starts conducting.
NC (Normally Closed) - Is the opposite of a NO contact. The contact will remain closed (as default) until
activated, during the "active" state the circuit breaks and stops current flow.
Setup Example
Exit buttons are used in access control
systems to provide a momentary contact
signal to the access controller to open a
magnetic lock.
This example shows a "Fail-safe"
scenario. When the exit button is
pressed the access control power
supply then releases power from the
lock, and if power is lost then the
lock also releases.
Wire in NO or NC depending on the
access controller used and also on
the required state of the lock during
a "Fail-safe" or "Fail-secure" scenario.

Quick Start Guide - qACC200-202, qACC250-253 Copyright 2021 System Q Ltd
2This symbol indicates that equipment must not be mixed with general household waste. For treatment, recovery and recycling please return to your local designated
WEE/CG0783SS collection point as defined by your local council.
All specifications are approximate. System Q Ltd reserves the right to change product specifications or features without notice. Whilst every effort is
made to ensure that these instructionsare complete andaccurate, System Q Ltd cannot be held responsible for any losses, no matter how they arise,
from errors or omissionsin these instructions,or the performance or non-performance of the equipment refered to.
Slim & Compact Exit Buttons
Zap is a registered trademark of System Q Ltd
Connections - ACC200
For operation with a door accesscontrol panel and lock, the exit button is
provided with NO/COM terminals.
Connections - ACC202, ACC250-252
For operation with a door access control panel and lock, the exit button
button is provided with NC or NO and COM connection wires.
Connections - ACC253
For operation with a door accesscontrol panel and lock, the exit button is
provided with NC or NO.
The ACC063 also has a built in blue LED which requires 12V DC (not supplied
with the product).
Troubleshooting
If the exit button is not activating the lock then there is likely a shorted wire, open circuit or some other failed
device in the circuit.
To identify where the fault is, each wired connection in the circuit needs to be tested; working from the push
button progress through, including the keypad, the access controller, power supply and the magnetic lock.
If the fault is with the access control button then check the connection wires for continuity and for trapped
wires. Check for water ingress on the wired connections.Check the polarity in the power connections and
ensure the connections are connected to the proper terminals.
Specification
ACC200
ACC202
ACC250-252
ACC253
Construction
Zinc Alloy
Zinc Alloy
Zinc Alloy
Zinc Alloy
Terminals
NO/Common (Screw
Terminals)
NO/NC/Common
(Wires)
NO/NC/Common
(Wires)
NO/Common/ +12V
DC/ GND (Wires)
Rating
2A12V DC Max
2A12V DC Max
0.5-1A 12V DC Max
0.5-1A 12V DC Max
LED Colour
~
~
~
Blue LED
Dimensions
80 x 30 x 26mm
93 x 35 x 28mm
53 x53 x28mm
53 x53 x28mm
