ZBM MINI OTDR User manual
1
MINI OTDR
（
Optical Time-Domain Reflectometer
）
User Manual
1-700-500-717
https://www.zbm.co.il
1-700-500-717
https://www.zbm.co.il
2
Overview
Mini OTDR is the most portable test instrument in the industry. It adopts the OTDR technical
principles and integrates the powerful analysis software, which enables the OTDR fiber ranger
detect fiber faults location more accurate and easier.
Features
*Portable, rugged, lightweight; Easy to use.
*More accurate testing results and better repeatability.
*Automatic Pulse Width Control design to ensure a convenient operation.
*Easy to identify the faults location.
*Built-in visual fault locator (VFL), conveniently to find the faults in dead zone.
*Dust, water and shock proof, designed for field use.
*Long battery life, up to 5000 measurements operation.
*2.6 inch screen, data saves in SOR format.
Standard Accessory
1. MINI OTDR -----------------------1pc
2. SC adapter------------------------1pc
3. USB cable-------------------------1pc
4. User manual-----------------------1pc
5. Carrying bag-----------------------1pc
1-700-500-717
https://www.zbm.co.il
3
1. Specifications
Model
OT6109S
Wavelength
1310nm or 1550nm
Type of fiber
9/125um SM Fiber
Connector
FC,SC/PC
Dynamic Range
22dB
Pulse Width
5ns~ 8000ns,Auto
Measurement
m
Event blind zone
3m
Attenuation blind
10m
Range accuracy
±（1m+2×10-4×distance）
OPM
-50~+26dBm
850/1300/1310/1490/1550/1625nm
VFL
≥10mW
Optical Light Source
1550nm
Event Map Function
Yes
Power Supply
3pcs of Dry battery
Battery Work time
≥2000 times measure
Save Data
＞500
Work Temperature
-5~40℃
Save Temperature
-10~60℃
Humidity
0~85%（no condensation）
Net weight
300g
2.Buttons Description
1. : On / off key, when in power-on, short press switch to auto-off function ；long press about 3s off.
When the top right corner of LED show ，The instrument will automatically shut down for about 10
minus in the state of no key operation.
2. SCAN, Start OTDR module to test the fiber. Press about 6s, enter auto cycle test, press exit again.
3. ▲-View the previous measurement or choose previous option
4. ▼-View the next measurement or choose next option
5. ◄--View a measurement to the left or select an option to the left
6. ►-View a measurement to the right or select an option to the right
7. ENT select the confirm button or deselect
8. VFL light shows starting work
1-700-500-717
https://www.zbm.co.il
4
3. Keypad
5.Operations
1. Starting up, when clean the end face of fiber, connect the interface of OTDR, make the fiber and
instrument correctly connect
2. Press ENT setting parameter; pulse width choose auto. Continuous press ENT confirm and Exit parameter
setting or continuous press◄exit ; Press SCAN start to test and get the results. The theoretical value of
refractive index is 1.4677 at 1550nm. The pulse width is set according to the length of the measuring
fiber. Small the pulse width, short the measurement distance, if cannot confirm the fiber length，can
use 100ns,then choose the pulse width according to the measurement result curve; if short distance can
choose<500m, if long distance choose<40km.
The greater the gain, the stronger the signal that can be measured.
OTDR
OPM
VFL
USB Charging
Main Display
VFL Indicator
Button Operation
1-700-500-717
https://www.zbm.co.il
5
3. Measurement results as follows:
(1) Total number of events;
(2) Event Number;
(3) Event type (reflection event);
(4) Event distance;
(5) The loss value from the starting point to that point;
(6) Incident loss per kilometer;
(7) Event connection point loss,
(8) Battery symbol, automatic shutdown symbol;
(9) Main menus;
(10) View curve;
(11) Zoom in or out the curve;
(12) Curve suspend;
(13) Switch the A/B coordinate;
(14) Save data icon;
(15) Set the options icon.
1-700-500-717
https://www.zbm.co.il
6
6. Curve Analysis
Users could check the state of the fiber through analyzing the testing curve.
(1)(2)(3) Connect point of the fiber.
(4) Fiber end-face.
7. iLOM(Event Map)
The function can be tested automatically by one key, and the information of the length of the link,
the type of event point and the position of breakpoint can be displayed in a graphical form. The result is
easy is clear and easy to understand
1-700-500-717
https://www.zbm.co.il
7
8. OPM
This function is used to test the power of optical signal and insertion loss of various devices and
optoelectronic components. It can identify and measure the frequency of 270/3301k/2kHz frequency
optical signal.
9. VFL Function
Connect fiber to VFL port, select VFL in menu, then you could see optical light(650nm) in breakpoint or fiber
end-face.
Note: Do not see the light directly with your eyes! It is harmful to your eyes.
1-700-500-717
https://www.zbm.co.il
8
10.Laser
11. Data Saving
Press ENT button to save the testing data after testing. The ENT button is used to SAVE, READ and EXIT.
MINI OTDR could save more than 500pcs data.
12. Data Processing
1. Copy JWMINI OTDR TRACE file to your computer (files will be provided with testers or users could contact
seller for the file). Click USB driver.exe and install USB driver software.
2. After installing the driver software, connect the tester to computer with USB, click MINI OTDR.exe in the
file and then the tester will be ready.
1-700-500-717
https://www.zbm.co.il
9
Connect the tester and derive curve data, and then users can enlarge curve to see details and print testing
report.
13. Power Supply
JOTDR use 3pcs Alkaline battery to supply power, please change the battery when power is low. Please
remove the battery if the tester is not used for long time.
1-700-500-717
https://www.zbm.co.il
10
Maintenance
1. Always keep the connector ports of your power meter are clean.
2. Once not in use, make sure the dust-proof cap is placed properly over the optical ports.
3. Try to use only the adaptor supplied, or will damage the tester.
4. Temperature may affect the tester, so do not put the tester in sunshine for long.
Quality Warranty
We do not recommend to repair OTDR in field.
1) We warrant that MINI OTDR will be free from defects in material and workmanship for a period of 18
months. The date will be started from the date of goods shipment. If any defectives happened due to
quality problems of the product during the warranty period, we promise to repair or replace free of
charge. This warranty is limited to defects in workmanship and material.
2) OTDR repairing does not cover damages from below condition:
1. Repairing without our authorization.
2. Wrong or abnormal operation.
1-700-500-717
https://www.zbm.co.il
