ZBT Z2101AX-T User manual

Shenzhen Zhibotong Electronics Co., LTD
第1页 共 14 页
Product model: Z2101AX-T
Version: V1.0
Editor: Mr.He

Shenzhen Zhibotong Electronics Co., LTD
第2页 共 14 页
contents
1 Overview---------------------------------------------------------------------3
1.1 Brief overview --------------------------------------------------------------3
1.2 Reference standards -------------------------------------------------------3
2 Product image ----------------------------------------------------------------4
3 Main features of the product----------------------------------------------- 5
4 Hardware function ----------------------------------------------------------5
4.1 Introduction to Hardware Interface ------------------------------------5
4.2 Indicator function introduction ------------------------------------------5
4.3 Introduction to the hardware platform ---------------------------------6
5 Power supply and power consumption description ---------------------6
6 Introduction to WIFI wireless parameters ------------------------------- 6
6.4 WIFI 2.4G ------------------------------------------------------------------6
6.2 WIFI 5.8G ------------------------------------------------------------------7
8 Introduction to structural parameters and accessories ------------------8
9 Product working environment requirements -----------------------------8
10 Software configuration information -------------------------------------8

Shenzhen Zhibotong Electronics Co., LTD
第3页 共 14 页
1 Summary
1.1 Brief overview
This document describes the electrical characteristics, RF performance, dimensions and
application environment of the Z2101AX. Under the introduction of this document, end users
or developers can quickly understand the hardware functions of Z2101AX.
Z2101AX is a 5G/4G+WIFI6 home CPE router. It accesses the Internet through 5G/4G mobile
communication dial-up or 1000Mbps WAN port, and then shares the Internet network through
wireless WiFi 6 and 1000Mbps wired LAN.
1.2 Reference standards
Relevant standard specifications:
USB3.0/USB2.0 bus standard
PCI- Express bus standard
SIM/USIM interface standard
IEEE802.11n/g/b/a/ac/ax
IEEE802.3/802.3u/802.ab
PCI Express M.2 Specification Rev1.1
5G/4G mobile communication standard, which is determined by the selected 5G/4G mobile
communication module

Shenzhen Zhibotong Electronics Co., LTD
第4页 共 14 页
2 Product Picture

Shenzhen Zhibotong Electronics Co., LTD
第5页 共 14 页
3 Main features of the product
Using MT7621A scheme, MIPS dual-core CPU, the main frequency is up to 880MHZ
Using independent WIFI6 chip, MT7905D and MT7975D, the rate is up to 1800Mbps
Using high-speed 256MB DDR3, with 16MB Nor Flash
1WAN+3LAN 1000M adaptive network port, support auto flip (Auto MDI/MDIX)..
Support "one-key flashing mode", that is, long press the reset button to enter the
rescue flashing mode...
Built-in M.2/Mini-PCIE standard interface (choose one of the two), which can be
used to connect to 5G/4G mobile communication modules
External standard SIM card (large card) interface and built-in eSIM (QFN-8
6mmx5mm) card interface, support SIM/USIM card
External high-gain WIFI antenna, wireless signal 360 degrees without dead angle
4 Hardware function
4.1 Introduction to the hardware interface
Ports
WAN* 1, 1000Mbps(Auto MDI/MDIX)
IEEE 802.3/802.3u/802.ab
LAN*3, 1000Mbps(Auto MDI/MDIX)
IEEE 802.3/802.3u/802.ab
SIM slot
Spring type SIM slot*1, QFN-8(6mmx5mm) eSIM*1, Support
SIM/USIM
Power adapter
DC5.0*2.1MM slot
Button
Reset button* 1, MESH button*1
Antennas
Onmidirectional External 5dbi 2.4G antennas*2
Onmidirectional External 5dbi 5.8G antennas*2
Onmidirectional External 5dbi 5G/4G antennas(5G antennas* 4, 4G
antennas*2)

Shenzhen Zhibotong Electronics Co., LTD
第6页 共 14 页
4.2 Introduction to indicator lights
MESH LED
1. The red light is on during the boot process, the boot is complete, the red light
is off and the green light is on
2. Press the mesh button to enter the mesh pairing state, the green light flashes
once a second, and the other lights are off
3. The main equipment network is normal, the green light and blue light are on
at the same time (cyan)
The slave device MESH is successfully connected, and the distance is longer, the
green light and the red light are on at the same time (orange), the distance is
suitable for the green light and the blue light is on at the same time (cyan)
WAN LED
When connecting the WAN ports, the LED light will be always on, and
the LED will be flashing when there is data communication
LAN1 LED
When connecting the LAN ports, the LED light will be always on, and
the LED will be flashing when there is data communication
LAN2 LED
When connecting the LAN ports, the LED light will be always on, and
the LED will be flashing when there is data communication
LAN3 LED
When connecting the LAN ports, the LED light will be always on, and
the LED will be flashing when there is data communication
4G/5G LED
When insert SIM card, the LED light will be always on, and the LED
will be flashing when there is data communication
POWR LED
when the power supply is normal, the power indicator is always on, and
it won’t be on when the power supply is abnormal.
4.3 Introduction to the hardware platform
Processor
MT7621A MIPS Dual Core CPU, 880MHZ main frequency
WIFI chipset
MT7905D+MT7975D IEEE 802.11n/g/b/a/ac/ax, max speed
up to 1800Mbps
RAM
DDR3 256MB
Flash
Nor Flash 16MB
NAND Flash

Shenzhen Zhibotong Electronics Co., LTD
第7页 共 14 页
4.4 Introduction to hardware watchdog function
This hardware product is designed with a hardware watchdog function. The hardware watchdog
will automatically turn on after power-on, and detect the heartbeat level output by the routing
system that jumps once per second. If the routing system itself fails (such as a crash), it will also
Naturally, the heartbeat level can no longer be output. At this time, if the hardware watchdog does
not detect the heartbeat level within 120 seconds, it will shut down itself for 15 seconds and then
restart the entire system.
When the routing system is operating normally, but the 5G/4G module dialing is abnormal, the
routing system will control the power supply of the 5G/4G module through GPIO and let the
module automatically restart to fix the 5G/4G dialing abnormal problem.
Hardware watchdog specific functions
Routing system is abnormal
Module dialing abnormal
Restart the whole system
Only restart the module
5 5G/4G mobile communication function
This product has a built-in M.2/MiniPCIE interface, which can be used to expand
5G/4G mobile communication functions. The built-in M.2/PCIE interface supports
USB3.0 and USB 2.0 buses. 5G mobile communication supports NSA or SA, and
which frequency bands are specifically supported by the selected 5G module. At
present, this product has completed the joint debugging with Fibocom's FM150 series
modules.

Shenzhen Zhibotong Electronics Co., LTD
第8页 共 14 页
6 Power supply and power consumption description
Testing Condition
Minimu
m
Rating
Maximum
Working
voltage(V)
T A = 25°C
9
12
35
Absolute
operating
voltage(V)
T A = 25°C
8
36
Working
Currency(A)
VIN=12V ，T A =
25°C
0.3
0.9
1.5
Please use the ZBT standard power adapter to supply power to this product. If you do
not use the ZBT standard power supply, please supply power to this product in strict
accordance with the above power specifications and parameters, otherwise the
product will be damaged. If the battery or vehicle power supply is used for power
supply, please make anti-static and anti surge countermeasures.
7 Introduction to WIFI wireless parameters
7.1 WIFI EVM standard
Mode description
index parameter
EVM
standard(dBm)
802.11B 11Mbps
≤-1 5 dB
802.11G 54 Mbps
≤-25 dB
802.11N HT20@ MCS7
≤-28 dB
802.11N HT40@ MCS7
≤-28 dB
802.11AC VHT20@ MCS8
≤-30 dB

Shenzhen Zhibotong Electronics Co., LTD
第9页 共 14 页
802.11AC VHT40@ MCS9
≤-32 dB
802.11AC VHT80@ MCS9
≤-32 dB
802.11AX HE20@MCS 11
≤-35 dB
802.11AX HE40@MCS 11
≤-35 dB
802.11AX HE80@MCS 11
≤-35dB

Shenzhen Zhibotong Electronics Co., LTD
第10 页 共 14 页
7.2 WIFI 2.4G
Compatible with IEEE 802.11 b/g/n/ac/ax, supports 20MHz, 40MHz, modulation method
1024-QAM / OFDMA, adopts 2T2R MU-MIMO antenna technology, and the highest connection
rate is up to 573.5Mbps. The following is an explanation of 2.4G WIFI's power frequency,
receiving sensitivity, and transmitting power.
Instraction
Maximum
Value
Rating
Minimum
Value
Working
Frequency(MHz)
2484
2412
Receiving
sensitivity(dBm)
802.11B 11Mbps
-86
-87
-88
802.11G 54 Mbps
-69
-71
-73
802.11N HT20@ MCS7
-67
-69
-71
802.11N HT40@ MCS7
-65
-67
-69
802.11AC VHT20@ MCS8
-63
-65
-67
802.11AC VHT40@ MCS9
-61
-63
-65

Shenzhen Zhibotong Electronics Co., LTD
第11 页 共 14 页
802.11AX HE20@MCS11
-62
-64
-66
802.11AX HE40@MCS11
-60
-62
-64
Transmit
power(dBm)
802.11B 11Mbps
22
21
20
802.11G 54 Mbps
20
19
18
802.11N HT20@ MCS7
19
18
17
802.11N HT40@ MCS7
19
18
17
802.11AC VHT20@ MCS8
18
17
16
802.11AC VHT40@ MCS9
18
17
16
802.11AX HE20@MCS11
17
16
15
802.11AX HE40@MCS11
17
16
15

Shenzhen Zhibotong Electronics Co., LTD
第12 页 共 14 页
7.3 WIFI 5.8G
Compatible with IEEE 802.11 a/ac/ax, supports 20MHz, 40MHz, 80MHz, modulation
method 1024-QAM / OFDMA, adopts 2T2R MU-MIMO antenna technology, and the highest
connection rate is up to 1201Mbps. The following is an explanation of the power frequency,
receiving sensitivity, and transmitting power of 5.8G WIFI.
Instraction
Maximum
Value
Rating
Minimum
Value
Working
Frequency(MHz
)
5825
5180
Receiving
sensitivity(dBm)
802.11G 54 Mbps
-69
-71
-73
802.11N HT20@ MCS7
-67
-69
-71
802.11N HT40@ MCS7
-65
-67
-69
802.11AC VHT20@
MCS8
-63
-65
-67
802.11AC VHT40@
MCS9
-61
-63
-65
802.11AC VHT80@
MCS9
-59
-61
-63
802.11AX HE20@MCS 11
-57
-59
-61
802.11AX HE40@MCS 11
-55
-57
-59
802.11AX HE80@MCS 11
-53
-55
-57
Transmit
power(dBm)
802.11G 54 Mbps
20
19
18
802.11N HT20@ MCS7
19
18
17
802.11N HT40@ MCS7
18
17
16
802.11AC VHT20@
18
17
16

Shenzhen Zhibotong Electronics Co., LTD
第13 页 共 14 页
MCS8
802.11AC VHT40@
MCS9
17
16
15
802.11AC VHT80@
MCS9
16
15
14
802.11AX HE20@MCS 11
18
17
16
802.11AX HE40@MCS 11
17
16
15
802.11AX HE80@MCS 11
16
15
14
8 Introduction to structural parameters and accessories
weight
（KG）
TBD
Enclosure
Size
L*W*H=160mm*93mm*31.9mm
color
Black
Accessories
Power adapter
12V/2A 1PCS
User manual
1PCS
certificate
1PCS
Ethernet cable
Cat 5 network cable 1PCS

Shenzhen Zhibotong Electronics Co., LTD
第14 页 共 14 页
9 Product working environment requirements
Working
temperature
0℃ - 40℃
Storage
temperature
-40℃ - 70℃
Working
humidity
10% - 90%RH, Non condensing
Storage
humidity
5% - 90%RH,Non condensing
10 Software configuration information
Default IP
192.168.1.1
username/password
root/admin
2.4G SSID
WIFI6-XXXXXX (x is the last 6 bits of MAC address), default no
password
5.8G SSID
WIFI6-5G-XXXXXX (x is the last 6 bits of MAC address), default no
password
The above is the general default configuration information of the product. The WiFi SSID using
our OS firmware or openwrt firmware may be different, but the default IP and web login name and
password of the product remain unchanged. Please refer to the product description for other
detailed software functions.
