HP A-MSR20 Router Series
Installation Guide
Abstract
This document guides you through installation of HP A Series products, including installing the device,
connecting to the network, hardware management, and troubleshooting.
Part number: 5998-1411
Software version: CMW520-R2207P02
Document version: 6PW100-20110810

Legal and notice information
© Copyright 2011 Hewlett-Packard Development Company, L.P.
No part of this documentation may be reproduced or transmitted in any form or by any means without
prior written consent of Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
HEWLETT-PACKARD COMPANY MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS
MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for errors contained
herein or for incidental or consequential damages in connection with the furnishing, performance, or use
of this material.
The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

iii
Contents
Product overview······························································································································································ 1
A-MSR20-20 panel views ················································································································································1
A-MSR20-21 panel views ················································································································································2
A-MSR20-40 panel views ················································································································································2
Preparing for installation················································································································································· 4
Safety recommendations ··················································································································································4
Installation site requirements ···································································································································4
Cooling······································································································································································5
Lightning protection··················································································································································5
Rack-mounting requirements····································································································································6
Installation tools·································································································································································6
Pre-installation checklist ····················································································································································7
Installing the router ·························································································································································· 9
Installation prerequisites ···················································································································································9
Installation flowchart······················································································································································ 10
Installing the router························································································································································· 11
Installing the router on a workbench··················································································································· 11
Mounting the router in a 19-inch rack ················································································································ 11
Grounding the router ············································································································································ 13
Installing interface modules·································································································································· 15
Connecting interface and power cables ····················································································································· 17
Connecting an Ethernet cable······························································································································ 17
Connecting the console cable and setting terminal parameters ······································································ 17
Connecting the AC power cord··························································································································· 21
Verifying the installation················································································································································ 21
Starting up and configuring the router ························································································································ 21
Powering on the router ········································································································································· 21
Configuring basic settings for the router············································································································· 23
Installing and upgrading internal modules and FRUs································································································24
Opening and removing the chassis cover··················································································································· 24
Locating internal modules·············································································································································· 26
Installing and removing a VPM module······················································································································· 29
Installing a VPM module······································································································································· 29
Removing a VPM module ····································································································································· 30
Installing and removing a VCPM or ESM module······································································································ 30
Installing a VCPM or ESM module ······················································································································ 31
Removing a VCPM or ESM module ···················································································································· 32
Installing and removing a CF card······························································································································· 32
Installing a CF card··············································································································································· 32
Removing a CF card ············································································································································· 33
Troubleshooting······························································································································································34
Power supply failure ······················································································································································ 34
Fan failure······································································································································································· 34
Configuration system problems ···································································································································· 34
No terminal display ·············································································································································· 35
Garbled terminal display ····································································································································· 35
No response from the serial port························································································································· 35

iv
Password loss ································································································································································· 35
User password loss ··············································································································································· 35
Super password loss ············································································································································· 36
Interface module, cable, and connection failure ········································································································ 37
Support and other resources ········································································································································38
Contacting HP ································································································································································ 38
Subscription service ·············································································································································· 38
Related information························································································································································ 38
Documents······························································································································································ 38
Websites ································································································································································ 38
Conventions ···································································································································································· 39
Appendix A Technical specifications···························································································································41
Appendix B LEDs····························································································································································42
A-MSR20-20 LEDs·························································································································································· 42
A-MSR20-21LEDs ··························································································································································· 43
A-MSR20-40 LEDs·························································································································································· 44
Appendix C Slot arrangement and interface numbering ··························································································46
Slot arrangement···························································································································································· 46
Interface numbering······················································································································································· 46
Index················································································································································································48

1
Product overview
This chapter discusses the chassis panels of the HP A-MSR20 Router Series models listed in Table 1. The
chassis panel views shown may differ slightly from the actual panels.
Table 1 HP A-MSR20 Router Series models
J#
Type
JF283A
A-MSR20-20
JD663B
A-MSR20-21
JF228A
A-MSR20-40
A-MSR20-20 panel views
Figure 1 A-MSR20-20 front panel
123
(1) PWR LED
(2) SYS LED
(3) ESM LED
Figure 2 A-MSR20-20 rear panel
1 2
3456789
10
(1) SIC slot 2
(2) SIC slot 1
(3) CF card slot
(4) USB port
(5) AUX port
(6) Console port
(7) Ethernet WAN ports
(ETH0 and ETH1)
(8) Power switch
(9) Power receptacle
(10) Grounding screw

2
A-MSR20-21 panel views
Figure 3 A-MSR20-21 front panel
123
(1) PWR LED
(2) SYS LED
(3) ESM LED
Figure 4 A-MSR20-21 rear panel
1 2
3456789
1011
(1) SIC slot 2
(2) SIC slot 1
(3) CF card slot
(4) USB port
(5) AUX port
(6) Console port
(7) Ethernet WAN ports
(ETH0 and ETH1)
(8) Ethernet LAN ports
(ETH2 to ETH9)
(9) Power switch
(10) Power receptacle
(11) Grounding screw
A-MSR20-40 panel views
Figure 5 A-MSR20-40 front panel
1 2 3
456
(1) Console port
(2) Power switch
(3) Power receptacle
(4) AUX port
(5) USB port
(6) CF card slot

3
Figure 6 A-MSR20-40 rear panel
1 2
3456
(1) SIC slot 4
(2) SIC slot 3
(3) Ethernet WAN ports
(ETH0 and ETH1)
(4) SIC slot 1
(5) SIC slot 2
(6) Grounding screw

4
Preparing for installation
This chapter discusses safety, site, and rack-mounting requirements, as well as the tools and accessories
needed for installation.
Safety recommendations
WARNING!
Before installation and operation, read all of the safety instructions in the Compliance and Safety
Guide supplied with your router.
General safety recommendations follow:
Turn off all power and remove all power cables before opening the chassis.
Unplug all power and external cables before moving the chassis.
Before installation, locate the emergency power switch so that you can shut off power immediately if
necessary.
Always wear an ESD-preventive wrist strap when installing the device.
Do not stare into an open optical interface. The light can cause permanent eye damage.
Use a good grounding system. This is essential for reliable operation.
Confirm that the resistance between the chassis and the ground is less than 1 ohm.
Installation site requirements
This section provides information about temperature and humidity, cleanness, and air quality
requirements.
Table 2 Temperature and humidity requirements
Temperature
Relative humidity
0°C to 40°C (32°F to 104°F)
5% to 90%
Table 3 Dust concentration limit in the equipment room
Substance
Concentration limit (particles/m3)
Dust particles
≤ 3 x 104
(No visible dust on desk in three days)
NOTE:
Dust particle diameter ≥ 5 µm

5
Table 4 Harmful gas concentration limits in the equipment room
Gas
Maximum concentration (mg/m3)
SO2
0.2
H2S
0.06
NH3
0.05
Cl2
0.01
Cooling
Air flows through the A-MSR20 from left to right, as shown in Figure 7.
Figure 7 A-MSR20 ventilation
To prevent overheating:
Provide adequate clearance for air flow.
Provide at least 10 cm [3.94 in] ventilation space around the router's air intake and outlet vents.
For heat dissipation and device maintenance, the front and rear of the rack should be at least
0.8 m (2.62 ft) away from walls or other devices.
The equipment room ceiling height should be no less than 3 m (9.84 ft).
Make sure the site has an adequate cooling system.
Lightning protection
To protect the router from lightning:
Make sure the grounding cable of the chassis is grounded properly.
Make sure the grounding terminal of the AC power receptacle is grounded properly.
Install a lightning arrester at the input end of the power supply.
Install a lightning arrester at the input end of outdoor signal lines (for example, E1/T1 line) to which
the router’s interface modules are connected.

6
Rack-mounting requirements
Before rack-mounting a switch, make sure the rack meets the following requirements:
Size. The rack must be appropriately sized to hold the switch.
Ventilation. HP recommends that you mount a switch in an open rack. If you mount a switch in a
closed rack, provide an adequate heat dissipation system. With either type of rack, there must be
enough space around the switch's left and right panels for unimpeded airflow and heat dissipation.
Sturdy support. The rack must provide steady, secure support for the switch and accessories.
Installation tools
Accessories supplied with the router
Power cord
Console cable
Grounding cable
Mounting brackets
User-supplied tools and equipment
Phillips screwdriver P1 –100 mm, P2 –150 mm, and P3 –250 mm
Flat-bladed screwdriver P4 –75 mm
Screws with different specifications
Meters and equipment such as HUB, terminal, and multimeter
ESD-preventive gear, including gloves or wrist strap, mat or other work surface, and antistatic bags

7
Pre-installation checklist
Table 5 Pre-installation checklist
Item
Requirements
Yes No
Installation
site
Ventilation
There is a minimum clearance of 10 cm (3.9 in) around
the router chassis intake and exhaust vents for heat
dissipation.
The installation site ventilation system is adequate.
Temperature
0°C to 40°C (32°F to 104°F)
Relative humidity
5% to 90% (noncondensing)
Cleanness
Dust concentration ≤ 3 × 104 particles/m3
ESD prevention
The equipment and floor are properly grounded.
The equipment room is dust-controlled.
Humidity and temperature are maintained at proper
levels.
Wear an ESD-preventive wrist strap when inspecting or
handling a circuit board.
Place any removed memory module, CF card, or
interface module face-up on an antistatic workbench or
in an antistatic bag.
Touch only the edges, not any electronic components,
when inspecting or handling a memory module, CF
card, or interface module.
EMI prevention
Take measures to protect the power system from the
power grid system.
Keep the protection ground of the router as far away
from the grounding device or lightning protection
grounding device as possible.
Keep the router far away from radio transmitters, radar,
and high-frequency or high-voltage devices.
Use electromagnetic shielding when necessary.
Lightning protection
The grounding cable of the chassis is grounded
properly.
The grounding terminal of the AC power receptacle is
grounded properly.
A port lightning arrester is installed. (Optional)
A power lightning arrester is installed. (Optional)
A signal lightning arrester is installed at the input end
of an external signal cable. (Optional)
Electricity safety
Install a UPS.
In case of emergency during operation, switch off the
external power switch.
Workbench
The workbench is stable.
The workbench is grounded properly.

8
Item
Requirements
Yes No
Rack mounting
Install the router in an open rack if possible. If you
install the router in a closed cabinet, make sure that the
cabinet is equipped with a good ventilation system.
The rack is sturdy enough to support the weight of the
router and accessories.
The size of the cabinet is appropriate for the router.
The front and rear of the cabinet are at least 0.8 m
(31.50 in) away from walls or other devices.
Safety
precautions
The router is far away from any sources of heat or moisture.
The emergency power switch in the equipment room is identified and
accessible.
Tools
Installation accessories supplied with the router are ready.
User-supplied tools are ready.
Reference
Documents shipped with the router are available.
Online documents are available.

9
Installing the router
WARNING!
To avoid injury, do not touch bare wires, terminals, or parts with high-voltage hazard signs.
NOTE:
The barcode on the router chassis contains important product information that you must provide to HP Support
before returning a faulty router for service.
The HP tamper-proof label attached to a mounting screw on the router chassis must be kept intact. Before
opening the chassis cover, contact HP Support for authorization; if you do not, you take full responsibility for all
operation and maintenance failures.
This chapter provides instructions for installing the router on a workbench or mounting it in a 19-inch rack.
Installation prerequisites
You have read "Preparing for installation" carefully.
All requirements in "Preparing for installation" are met.

10
Installation flowchart
Figure 8 shows two ways to install your router:
Install the router on a workbench.
Install the router in a 19-inch rack.
Figure 8 A-MSR20 router installation flowchart
Start
Connect the PGND cable
Install interface modules
Verify the installation
Connect interface cables
Power on the router
Operating properly? Power off the router
Troubleshoot the router
End
Yes
No
Connect the router to a
console terminal
Connect the power cable
Install the router to a
specified position?
Check the workbench Install a 19-inch rack
Install the router to a rack
Install the router to a
workbench

11
Installing the router
When installing the router:
Reserve a space of 10 cm (3.9 in) around the router for heat dissipation.
Do not place heavy objects on the router.
Installing the router on a workbench
To install the router on a workbench:
1. Make sure the workbench is clean, stable and properly grounded.
2. Place the router upside down on the workbench and attach the rubber feet to the four round holes
in the chassis bottom.
3. Place the router upright on the workbench.
Mounting the router in a 19-inch rack
A-MSR20-20/A-MSR20-21 router
CAUTION
Mounting brackets can support only the weight of the router. To avoid damaging the router, do not
place any objects on it.
Figure 9 Rack-mounting the A-MSR20-20/A-MSR20-21 router
1 2
43
To mount the router in a 19-inch rack, as shown in Figure 9:
1. Determine where to attach the cage nuts to match the mounting bracket holes.
2. Attach the cage nuts to the rack posts.
3. Attach the front mounting brackets, shown in Figure 10, to the sides of the router.
4. Mount the router in the rack horizontally by fastening the mounting brackets to the rack with
rustproof panhead screws that meet installation requirements.

12
Figure 10 A-MSR20-20/A-MSR20-21 mounting brackets
1 2
(1) Left front mounting bracket
(2) Right front mounting bracket
A-MSR20-40 router
CAUTION
Mounting brackets can support only the weight of the router. To avoid damaging the router, do not
place any objects on it.
Figure 11 Rack-mounting the A-MSR20-40 router
21
3 4
65
To install the router in a 19-inch rack, as shown in Figure 11:
1. Attach the rear mounting brackets, shown in Figure 12, to the rack.
a. Determine where to attach the cage nuts to match the mounting bracket holes.
b. Attach the cage nuts to the rack posts.
c. Attach the rear mounting brackets to the rack.
2. Attach the front mounting brackets, shown in Figure 12, to the sides of the router.

13
3. Screw two weight-bearing screws into the appropriate holes, one on the left side and one on the
right side of the router. These screws will rest on the top edges of the rear mounting brackets.
4. Position the router so that the weight-bearing screws fit securely over the top edges of the rear
mounting brackets.
5. Secure the router fastening the front mounting brackets to the rack with rustproof panhead screws
that meet installation requirements.
Figure 12 A-MSR20-40 front and rear mounting brackets
1 2 3 4
(1) Left front mounting bracket
(2) Right front mounting bracket
(3) Left rear mounting bracket
(4) Right rear mounting bracket
Grounding the router
WARNING!
Connecting the router grounding cable correctly is crucial for protecting the router from lightning and
EMI.
The grounding resistance should be less than 5 ohms.
If the router is mounted in a 19-inch standard rack, the rack must be properly grounded.
You can ground the router in one of the following ways, depending on the grounding conditions at the
installation site:
Ground the router to a properly grounded grounding strip.
Ground the router to a grounding conductor buried in the earth.
Grounding the router to a grounding strip
To connect the grounding cable, as shown in Figure 13:
1. Remove the grounding screw from the rear panel of the router chassis.
2. Put the OT terminal of the supplied grounding cable on the grounding screw.
3. Use a screwdriver to fasten the grounding screw, with the grounding cable OT terminal attached,
to the grounding screw hole.

14
Figure 13 Connecting the grounding cable to the router chassis
1
(1) OT terminal
4. Attach the other end of the grounding cable to the grounding strip, as shown in Figure 14.
Figure 14 Connecting the grounding cable to a grounding strip
1
2
3
45
(1) Hex nut
(2) Grounding cable
(3) Bare metal part
(4) Grounding post
(5) Grounding strip
Grounding the router to a buried grounding conductor
If the installation site has no grounding strips but offers the option of grounding to earth, hammer a 0.5 m
(1.64 ft) or longer angle iron or steel tube into the earth to serve as a grounding conductor, as shown in
Figure 15.

15
Figure 15 Grounding the router to a grounding conductor buried in the earth
1
23
(1) Earth
(2) Joint
(3) Angle iron
Installing interface modules
The router provides SIC slots. On some models, you can remove a slot divider to combine two side-by-
side SIC slots into one DSIC slot, as shown in Table 6.
Table 6 A-MSR20 SIC and DSIC slots
Model
Slot arrangement
A-MSR20-20
SIC 1SIC 2
A-MSR20-21
SIC 1SIC 2
A-MSR20-40
SIC 2 SIC 1DSIC 2
SIC 4 SIC 3DSIC 4
—SIC slot
—DSIC slot

16
Installing a SIC interface module
Figure 16 Installing a SIC interface module
1 2
3
To install a SIC interface module, as shown in Figure 16:
1. Power off the router and remove the power cord.
2. Using a Phillips screwdriver, remove the screws on the filler panel, and then remove the filler panel.
3. Push the SIC interface module into the SIC slot along the slide rails until it is firmly seated.
4. Using a flat-blade screwdriver, tighten the captive screws to fasten the SIC interface module to the
router.
Installing a DSIC interface module
Figure 17 Installing a DSIC interface module
1 2
43
To install a DSIC interface module, as shown in Figure 17:
1. Power off the router and remove the power cord.
2. Using a Phillips screwdriver, remove the screws on two side-by-side SIC filler panels, and loosen
the captive screw on the slot divider.
3. Remove the filler panels and pull out the slot divider.
4. Push the DSIC interface module into the DSIC slot until it is firmly seated.
5. Using a flat-blade screwdriver, tighten the captive screws to secure the module.
6. Save the filler panels and slot divider for future use.
