Zebex Z-2121 series User manual

Portable Data Collector
Z-2121 series ( Version 1.00)
User’s Manual
ZEBEX INDUSTRIES INC.
WWW.ZEBEX.COM

ZEBEX INDUSTRIES INC.
Subject Version Date Page
Z-2121 series User’s Manual 1.00 2010/11/15 2 / 39
Editorial Record
Version Date of edited Page Content
1.0 2010/11/15 1-39 1st Edition

ZEBEX INDUSTRIES INC.
Subject Version Date Page
Z-2121 series User’s Manual 1.00 2010/11/15 3 / 39
Table of Contents
Preface
About This Manual.................................................................................................5
Symbols used in this manual...............................................................................5
Copyright................................................................................................................6
Safety Information.................................................................................................6
Laser Safety ...........................................................................................................6
Safety Operation....................................................................................................7
Federal Communication Commission (FCC) Statement ....................................8
Unpacking
Package Contents..................................................................................................9
Optional Parts ......................................................................................................10
Cradle package .....................................................................................................10
Purchaseable accessories..................................................................................10
General Guide......................................................................................................11
Getting Start
Inserting the Battery............................................................................................12
Remove the Battery...……...................................................................................13
Charging the Battery...........................................................................................14
Charging by cable ................................................................................................14
Charging by cradle ...............................................................................................14
Charging the Battery Separate in the Cradle……..………………………………16
PC System Requirements ...................................................................................17
Connecting To PC................................................................................................17
Connecting via USB Cradle................................................................................17
Connecting the Z-2070 directly via USB cable..................................................18
About The Product ..............................................................................................19
Prerequisites........................................................................................................21
Specifications ......................................................................................................22
Start to operate the Z-2121
Fimware Operstion and Start Guide….…………………… ............ …………….23
0. Power-on Screen
0.1. User Reset…………………………………………………………….. 23
0.2. System Manual……………………………………………………….. 24
1. Run Task Function…………………………………………………………... 25
2. Task Utility Function…………………………………………………… …... 25
2.1. File Status Function…………………………………………….…... 26
2.2. Data Format Function....……………………………………….…... 26
2.3. Delete Data Function……………………………………………….. 27
2.4. Delete Task Function……………………………………………….. 27
3. Setup Function………………………………………………………………. 28
3.1. Basic Setup Function………………………………………………. 28
3.1.1. Backlight & LCD Contrast Function

ZEBEX INDUSTRIES INC.
Subject Version Date Page
Z-2121 series User’s Manual 1.00 2010/11/15 4 / 39
3.1.1.1. Back Light Function…………………………………….. 29
3.1.1.2. LCD Contrast Function…………………………………. 29
3.1.2. Beep Volume Function…………………………………………. 29
3.1.3. Auto Power Off Function………………………………………. 30
3.2. System Setup Function………………………………………………. 30
3.2.1. Communication Function……………………………………… 31
3.2.1.1. Communication Parameter Function………………… 31
3.2.1.2. On Line Upload Function………………………………. 32
3.2.1.3. Timeout Value Function………………………………… 32
3.2.2. System Timer Function………………………………………… 33
3.2.3. ID/PN/Date Mode Function…………………………………….. 33
3.2.3.1. Device ID Function………………………………………. 34
3.2.3.2. Password Function……………………………………… 34
3.2.3.3. Date Mode Function…………………………………….. 35
3.3. Barcode Setup Function………………………………………………35
3.3.1. Basic Set Function……………………………………………….36
3.3.2. Advance Set Function…………………………………………...36
3.3.3. Pre/Postamble Function…………………………………………36
4. Auto Scan Operation……………………………………………………………37
5. Bootload Function………………………………………………………………38

ZEBEX INDUSTRIES INC.
Subject Version Date Page
Z-2121 series User’s Manual 1.00 2010/11/15 5 / 39
Preface
About This Manual
Thank you for your purchase of the ZEBEX Z-2121 Portable Data
Collector. ZEBEX Z-2121 product is at the forefront of data collector
technology, and this manual will provide the necessary information on
the many and varied options available to you.
The Z-2121 product is a compact, ergonomic, modular and durable
data collector. It is designed for easy upgrade with an integrated BT
communication, 1D barcode scanner and vibration. The design is ideal
for the mobile worker as it simple and easy to use anywhere along a
supply chain.
Symbols used in this manual
A triangular shape indicates you should exercise
caution.
A circle shape indicates something you should not to
do.
A black circle indicates something you must to do.
A note symbol indicates you the information that is
important and you should be observed.

ZEBEX INDUSTRIES INC.
Subject Version Date Page
Z-2121 series User’s Manual 1.00 2010/11/15 6 / 39
Copyright
ZEBEX Industries Inc. makes no warranty of any kind with regard to
this material. Including but not limited to the imply warranties of
merchantability and fitness for a particular purpose. ZEBEX Industries
Inc. shall not be liable for errors contained herein or for incidental
consequential damages in connection with the furnishing,
performance or use of this product.
ZEBEX Industries Inc. will be under no liability in respect of any defect
arising from fair wear and tear, willful damage, negligence, abnormal
working conditions, failure to follow the instructions and warnings, or
misuse or alteration or repair of the products without written approval.
No part of this document may be reproduced, transmitted, stored in a
retrieval system, transcribed or translated into any language or
computer language in any form or by any means electronic,
mechanical, magnetic, optical, chemical, manual or otherwise, with
express writ- ten consent and authorization.
We reserve the right to make changes in product design without
reservation and without notification. The material in this guide is for
information only and is subject to change without notice.
ZEBEX is a registered trademark of ZEBEX INDUSTRIES INC.
© Copyright 2009 ZEBEX.
Safety Information
Your safety is of the utmost importance so please observe and follow
the following guidelines that allow you to use the scanner in a safe
and responsible way.
Laser Safety
The Z-2121 series Portable Data Collector complies with safety
standard IEC825-1(1993) for a Class 2 laser product. It also complies
with U.S.21CFR1040 as applicable to a Class II laser product. Avoid
staring at direct laser light as the laser beam may hurt your eyes.
LASER BEAM
Never look directly into the laser beam.
Doing so can cause serious eye damage.

ZEBEX INDUSTRIES INC.
Subject Version Date Page
Z-2121 series User’s Manual 1.00 2010/11/15 7 / 39
Safety Operation
WARNING
Disassembly and Modification
Never try to disassemble or modify the device in any way. All
servicing should be carried out be qualified Zebex personnel or
Zebex- approved engineers.
Interior Parts and Components
Never touch interior high voltage parts or components. Doing
so creates the danger of electrical shock.
Drop and Knock the Device
Be careful when using the device; do not drop or knock the
device as irreversible damage to the unit may occur.
Extreme temperature
Do not operate the device under extreme temperature.
Battery and Charger
The use of third-party battery or charger may either damage the
device or shorten the life of the device.
CAUTION
Dropping and Damage
Should the drop the device and damage it, immediately turn off
the power and contact your original dealer or an authorized
ZEBEX service provider. Continued use creates the danger of
fire and electrical shock.
Abnormal Conditions
Should the device become hot or start to emit smoke or an
original dealer or an authorized ZEBEX service provider.
Continued use creates the danger of fire and electrical shock.
Foreign Objects
Should any foreign matter ever get into the device, immediately
turn off the power and contact your original dealer or an
authorized ZEBEX service provider. Continued use creates the
danger of fire and electrical shock.
Moisture
Keep the device away from vases, planters, cups, glasses and
other containers of liquid. Also keep it away from metal. Water
and metal getting into the device creates the danger of fire and
electrical shock.

ZEBEX INDUSTRIES INC.
Subject Version Date Page
Z-2121 series User’s Manual 1.00 2010/11/15 8 / 39
Federal Communication Commission (FCC)
Statement
15.21
You are cautioned that changes or modifications not expressly
approved by the part responsible for compliance could void the user’s
authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in the accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions: This device may
not cause interference;
This device must accept any interference, including interference that
may cause undesired operation of the device.
FCC RF Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. End users must follow the specific
operating instructions for satisfying RF exposure compliance. This
transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.

ZEBEX INDUSTRIES INC.
Subject Version Date Page
Z-2121 series User’s Manual 1.00 2010/11/15 9 / 39
Unpacking
Package Contents
u
Z-2121 series AC Adapter
Portable Data Terminal
RS-232 DB9 (F) Cable Battery Pack

ZEBEX INDUSTRIES INC.
Subject Version Date Page
Z-2121 series User’s Manual 1.00 2010/11/15 10 / 39
Optional Parts
Cradle package
RS-232 Docking Cradle USB Docking Cradle
AC Adapter
Purchaseable accessories
USB Cable Main Battery
RS-232 DB9 (F) Cable USB AC Adapter
ACAdapter
