Zed-3 GA90 User manual

GA90
Modual Gateway
User’s Manual
Manual Part Number 96-00559-00
Zed-3
501 Valley Way
Milpitas CA 95035
USA
[phone]
http://www.zed-3.com

Notice
The information contained in this document is subject to change without notice.
Zed-3 makes no warranty of any kind with regard to this material, including, but not limited
to, the implied warranties of merchantability and fitness for a particular purpose. Zed-3 shall
not be liable for errors contained herein or for incidental or consequential damages in
connection with the furnishing, performance, or use of this material.
Zed-3 assumes no responsibility for the use or reliability of interconnected equipment that is
not furnished by Zed-3.
This document contains proprietary information which is protected by copyright. The
contents of this manual and the associated software are the property of Zed-3, and all rights
are reserved. No part of this document may be photocopied, reproduced, stored in any
computer format, translated to another language, or publicly displayed without the prior
written consent of Zed-3.
The information contained herein has been prepared by Zed-3 solely for use by Zed-3’ss
employees, agents, and customers. Dissemination or use of the information or concepts
contained herein to or by other parties is prohibited without prior written consent from Zed-3.
Zed-3, the Zed-3 logo, the Zed-3 mark,GA90 , CN2x2, CN2x4, SE150, SE150P, SE150+, SE150,
SE500, and SEME are trademarks of Zed-3 and may be registered trademarks in certain
countries. All other names may be trademarks or registered trademarks of their respective
owners.
Revision History
Manual Release Firmware Vision Release Date
1.0 0.8.11.0 23 February 2009

GA90 Modular Gateway User’s Manual 1
Contents
Product Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Product Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3 Basic Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4 Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Device Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Installation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Preparations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Installation Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Web Management System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Web Management System Main Interface . . . . . . . . . . . . . . . . . . . . . . . . 11
3.3 Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1 System Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2 Line Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3 Active Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4 Call Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.5 T1/E1 State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Line Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.1 IP Line. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.2 FXS Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.3 FXO Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.4 T1/E1 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.1 Matching Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.2 Routing Matching Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.3 Route. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.4 Alter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.5 Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.6 Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.7 System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.1 Change Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

2 GA90 Modular Gateway User’s Manual
Contents
7.2 Network Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.3 Time Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.1 System Reboot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.2 Reset to Default. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.3 Config Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.4 Auto Attendant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.5 Upgrade Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.6 Diagnostic Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

1. Product Introduction
1
Chapter 1
Product Introduction
1.1 Product Introduction
Zed-3 GA90 is a Modular Gateway which has prefect performance, rich interfaces, and supports
interface cards plug. GA90 supports multitype interface cards, such as FXO, FXS, IP, T1/E1 card,
can be connected to VoIP and PSTN network, allows calls freely transfer between these
interfaces, fully meeds the various requirements of communication and business extension for
enterprises. GA90 permits flexible call routing and call restricting to provide users calling strategy
based on their own requirements. The web-based management platform dramatically reduces
complication of users' operations.
GA90 are compatible with most SIP-based IP-PBX and traditional telephony system. When there
is no PBX, it can be deployed alone or in a group. This product can connect to local PSTN network
directly for its support of most countries and areas' telephone agreements. Zed-3 sells GA90 and
privides technical support across the world.
1.2 Technical Specifications

2
GA90 Modular Gateway User’s Manual
1.3 Basic Features
•Support SIP, meet RFC3261 standard, be compatible with most SIP-based IP-PBXs.
•Support flexible SIP calling, support interconnection with other SIP devices like IP-PBX by
register or Unregister ways.
Specifications Description
System capacity
•Up to 8 FXSx4 ports
•Up to 8 FXO4 ports(loop start)
•Up to 1 T1/E1 x4 port
•Any combination of interface cards
•90 simultaneous calls
Hardware
specification
•1 LCD screen
•1 reset button
•4 extended slots
Interface card
capacity
•4 extended slots
•Available interface card types:
- 8 ports FXO interface card
- 8 ports FXS interface card
- 1 port E1/T1 interface card
Network interface •1 10/100M LAN port
•1 10/100M WAN port
Voice capacity
•Codec: G.711 A-Law/U-Law, G.729, G.723.1
•Comfortable noise, silence supclickion, echo cancellation,
delay jitter/ lost-packet compensation
•DTMF Relay: In-band DTMF Relay, RFC-2833, SIP INFO
Physical
characteristics
•Dimesion: 1.5U 19# rack
•Weight: 5.3kg
•Power: AC-DC power adapter
- Input: ATX PS, AC 100 ~ 240 V @ 47 ~ 63 Hz
- Output: DC-5V
•power consumption: Max.80 Watt
Operating
environment
•Operating temperature: 10 ~ 40 °C(50 °F ~ 104 °F)
•Storage temperature: 0 ~ 50 °C(32 °F ~ 122 °F)
•Humidity: 5 ~ 85 %

1. Product Introduction
3
•Modular interface, including FXS, FXO and T1/E1 interface cards.
•support mix-plug of interface cards
•Support flexible secondary dialing and DID function
•Support flexible call routing, freewill transfer between any two interfaces.
•Flexible call restriction.
•Support caller ID transfer
•Powerful number transform includes head-trim, tail-trim, replacement, and number segment
ways.
•General calling strategy management: you may set call schedules based on different time
segments.
•Cascade and extend capacity in a Unregister way
•Plenty system monitor: line status, current call, CDR, system status etc.
•Easy-use of web configuration and management system
•Powerful safety management: upload/download configurations, fireware update, disaster
recovery etc.
1.4 Profile
1.4.1 Appearance
1.4.2 Front View
Figure 1-1 GA90 appearance

4
GA90 Modular Gateway User’s Manual
•LCD indicator on the front panel of GA90 for system status.
•4 extended slots which can hold 8FXO cards , 8FXS card and E1/T1 interface cards.
Each 8FXO and 8FXS interface card has eight anolog voice channels, each channel has
corresponding LCD indicator-for channecl's status. After startup, indicator is on when that
channel is used after off-hook. light is off when the channel is idle.
1.4.3 Back View
All ports are on the back panel of GA90, the interface type and descriptions are:
•WAN port: connect to IP network via this port.
•LAN port: connect to PC or other devices via this port.
•Reset button: reset the configuration to factory defaults (includes network configuration).
click it for 6 seconds when system is running
•Power Port: connect to power adapter.
Figure 1-2 GA90 front panel
Figure 1-3 GA90 back panel

2. Device Installation
5
Chapter 2
Device Installation
Unpack the unit and verify shipment content with the packing list :
•One GA90 equipment.
•One power cable.
•One Ethernet cable.
•One electronic mannual CD.
•Accessories package: 2 GA90 fixers, 8 M3 screws for fixing on GA90, 6 M6 screws for fixing
on 19# rack.
Note: If there is any missing or damage, contact the seller or Zed-3 sales immediately and save
all packages for the repackaging if need.
2.1 Installation Requirements
2.1.1 Power Requirements
•Power-off before installation, dismantlement or movement.
•The electric outlet shall be installed near the equitment and shall be easily accessible in case
of emergency.
2.1.2 Anti-static Requirements
•If the device's power line need to be put outside, take necessary anti-static action please.
•Anti-static Requirements
- Static will damage the circuit or the whole machine seriously if static exceed the limitation,
so make sure the ground bus well enough.

6
GA90 Modular Gateway User’s Manual
- Static inside body will result in damage too, so please wear anti-static wristband if you
have.
2.1.3 Environment Requirements
2.1.3.1 Basic Conditions
Keep the GA90 equipment in a room which has proper control of temperature and humidity, watch
out the conductivity of the shelf. Too high or too low humidity will cause short circuit or fire. At the
same time, the conductive property of rack is also considerable.
Place the equipment on a rack (if possible) which is near stable and liable power in an anti-fire,
anti-humidity, anti-dust, and anti-thief room.
2.1.3.2 Temperature, Humidity, and Illumination
Suggestions:
•Temperature: 0 ~ 40
•Relative humidity: 5~ 95RH without coagulation
•Illumination: light, 500 ~750 lx, light enough for operations.
High humidity will affect the insulating efficiency of insulating materials and also cause the rust of
metals. Low humidity will make insulating gasket shrink, loose the fixed bolts, and scrape up
static. Long period of high temperature will accelerate components' aging, lower the reliability and
reduce the useful time dramatically.
2.1.3.3 Air Quality
The air particulate may enter the equipment through ventholes. Too much dust will cause
short-circuit, so the suggestion is less than 180mg/m3. In machinery room, printer and
Photocopiers shall be placed away from the power provider in case of floating particulate. Please
put it in the diagonal corner.
Keep the room clean, for the dust will cause static and bad connections between little
components
2.1.3.4 Ventilation Requirements
There are thermal discharge holes in the back and side side, so keep more than 100mm from
other stuffs for thermal discharging.
2.1.3.5 Safety
There must be some safety precautions like securities or other effective anti-thief actions. The
lightning rod is well connected to the ground, the ground bus' diameter must be more than 5mm.
For seismal zones, there must be anti-earthquake measurements, like fixed balustrade for the
rack.
