ZvRemote

ZvKeyboard

ZvReceiver

User’s Guide

Contents

Welcome............................................... 3

ZvReceiver ............................................4-5

ZvRemote............................................6-18

ZvRemoteataglance .................................... 7

Installaon ............................................8-9

Using ZvRemote ......................................10-17

Tips and Troubleshoong ................................ 18

ZvKeyboard..........................................19-25

Installaon ..........................................20-21

Using ZvKeyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22-23

Sengs ............................................... 24

Tips and Troubleshoong ..............................24-25

Compliance and FCC Statement ........................... 26

ZeeVee Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27-29

Welcome

Thank you for your purchase. This guide

provides operang instrucons for

ZvRemote, ZvKeyboard, and ZvReceiver.

For more informaon on any of our

products, visit www.zeevee.com.

ZvReceiver ZvReceiver

ZvReceiver wirelessly communicates with both the

ZvRemote and ZvKeyboard, and converts their inputs

to commands sent to your computer using a USB

connecon. ZvReceiver can be paired with up to eight

ZvRemotes or ZvKeyboards for simultaneous control

from dierent locaons in your home.

1. Connect buon

Used to “pair” ZvReceiver with ZvRemote

and/or ZvKeyboard.

2. Blue indicator lamp

Indicates commands received from

ZvKeyboard or ZvRemote.

3. Yellow indicator lamp

Blinks when the connect buon was pressed,

indicang that it is waing to be paired.

Installaon

Plug ZvReceiver into a USB port on computer,

as shown. (Not required if adding ZvRemote to

a computer with exisng ZvReceiver.)

“Pair” ZvReceiver

See page 9 for instrucons on pairing ZvReceiver

with ZvRemote.

See page 21 for instrucons on pairing

ZvReceiver with ZvKeyboard.

ZvRemoteZvRemote

ZvRemote

ZvRemote uses long range radio frequency (RF) technology to control your computer

from nearly anywhere in your house. It contains a touchpad mouse, mulmedia keys

(e.g. play/pause), 5-way navigaon keys, numeric keypad, and other shortcut keys, if

you have a ZvBox.

ZvRemote communicates with the computer via ZvReceiver, an RF receiving unit. If

your computer doesn’t have an exisng ZvReceiver installed (ZvReceiver is included

with ZvBox systems), you’ll need to purchase one. Downloading Zviewer soware on

the computer enables addional special features on ZvRemote, detailed below.

Power

buons Mode

buons

Mouse

Navigaon

and control

buons

Window

control

buons

Zviewer

Launch

Buon

Numeric and

text keypad

ZvRemote ZvRemote

Mode Buons

Pressing a mode buon tells the remote which

device you want to control.

ZV: Sets remote to control computer.

TV1, TV2, TV3: Selects which TV or system

is controlled (or the “acve” TV), which is

selected by pressing TV1, TV2, or TV3.

For example, TV1 could be in the family room,

TV2 in the oce, and TV3 in the bedroom.

Install Baeries

Insert AA baeries in compartment on back, as shown.

“Pair” ZvRemote with ZvReceiver

ZvRemote must be “paired” with ZvReceiver in order

to communicate with it. Normally, when you rst

install the baeries in ZvRemote, it automacally

pairs with ZvReceiver (if ZvReceiver is plugged into

the computer). If necessary, you can manually pair

the two:

1. On ZvReceiver press the “connect” buon and a

yellow light will blink

2. On ZvRemote, press and hold the and but-

tons unl a blue light ashes on ZvReceiver.

ZvRemote ZvRemote

Power and AV Buons

TV : Turns acve TV on/o.

PC : Sends “sleep” command to the computer. The computer’s power sengs determine eect.

Raise or lower volume on the acve TV.

Mutes the acve TV.

Channel up/down: PC command, funcon varies by applicaon running on your computer.

Using ZvRemote

ZvRemote is designed to control a computer,* and

with addional programming through ZvBox it can

conrol up to three TVs (or sound systems connected

to TVs).

To program ZvRemote to control your TVs or other

devices, visit:

www.zeevee.com/support

ZvRemote

Touchpad and Mouse Buons

1. Touch Pad: Used for cursor movement.

2. Vercal Scrollbar: Drag ngerp up or down

to scroll in the acve window.

3. Le/Right Mouse Buons

ZvRemote

Navigaon Buons

Keyboard arrow keys

OK (to select)

Keyboard “enter” key

Window Controls*

Press repeatedly to sort through

open windows

Minimize acve window

Maximize acve window

Close acve window and applicaon

ZvRemote

Media Controls

Control popular media applicaons like Zviewer and

Media Center. Funconality of these buons may

vary depending on the applicaon being run.

ZeeVee is working closely with many websites to

add the ability to control the playback of their media

with keys like Play, Pause, and Full Screen. Zviewer

will tell you which controls are acve as you visit

each website.

Pause

Record

Rewind

Skip back

Play

Stop

Fast forward

Skip forward

“Back” buon

ZvRemote

Navigaon and Control Buons*

Zoom in/out of applicaon

Full-screen mode

Opens Zviewer* for easy access

to online programming:

Show informaon

Guide

On-screen keyboard*

ZvRemote

Numeric Keypad

Aer installing Zviewer soware,* the numeric

keypad allows “triple-tap” text entry. Enter text

as if text-messaging on a cell phone.

To enter this mode, press the “INPUT” key (an

on-screen keyboard pops up).

Press “INPUT” again to exit triple-tap mode.

*Download Zviewer soware for free at

www.zeevee.com.

0-9 Buons: Enter numbers or

leers in applicaon

CLEAR:

“Escape” (esc)

key on a

keyboard

ENTER:

“Enter” on

a keyboard

Tips and Troubleshoong

1. ZvRemote is unresponsive.

• Ensure that the baeries are properly installed.

• ZvRemote’s touchpad is designed to “sleep” when not in use, in order to save baeries. Press the

ZV mode buon to “wake” ZvRemote when you’re ready to use it.

2. ZvRemote works intermiently or yellow LED blinks.

• Ensure that the antenna on ZvReceiver is screwed in ghtly.

• Posion ZvReceiver dierently; keep it away from objects made of metal or stone, which reduce

operang range.

• Replace ZvRemote’s baeries.

• Out of range of ZvReceiver. Try moving closer to your computer.*

3. ZvRemote’s LED ashes yellow aer a key press but nothing happens.

• ZvReceiver is not installed or acve. Ensure ZvReceiver is plugged into the USB port of your computer.

• Out of range of ZvReceiver. Try moving closer to your computer.*

*If range problems persist, adding a USB extender may solve the problem. Get more informaon on USB

extenders at www.zeevee.com/support.

ZvRemote

ZvKeyboard

ZvKeyboard lets you control your computer from across the house; perfect when the computer’s output is

routed to distant displays, or when a convenonal wireless keyboard can’t reliably reach the computer.

Surf the web, compose e-mail, or use the media controls for playback of video or music–ZvKeyboard makes

it easy, from wherever you happen to be!

ZvKeyboard uses Radio Frequency technology to communicate with the computer via ZvReceiver. If your

computer doesn’t have an exisng ZvReceiver installed (ZvReceiver is included with ZvBox systems), you’ll

need to purchase one. Go to www.zeevee.com to purchase a

ZvReceiver.

Downloading and installing Zviewer soware enables

addional special features on ZvKeyboard, detailed on the

following pages.

Go to www.zeevee.com to download Zviewer for free.

ZvKeyboard

Installaon

Insert baeries:

Open the baery compartment on the 1.

back of ZvKeyboard by pushing in the two

tabs and pulling up on the cover.

Insert four AA baeries as shown.2.

Replace baery compartment cover.3.

On/O switch:

The keyboard enters “sleep” mode to when not

in use. But to conserve baeries when you are

not using it for long periods of me, turn o

keyboard when you are done using it.

ZvKeyboard

Installaon

Install ZvReceiver:

See pages 4-5.

“Pair” ZvKeyboard with ZvReceiver:

ZvKeyboard must be “paired” with ZvReceiver in

order to communicate with it. Normally when

you rst turn on ZvKeyboard and press any key, it

automacally pairs with ZvReceiver. If necessary,

you can manually pair the two:

On ZvReceiver press the “connect” buon 1.

and a yellow light will blink.

Ensure ZvKeyboard has baeries and the 2.

switch on back is “on.”

On ZvKeyboard, press and hold the3.

“connect” buon on back of keyboard unl a

blue light ashes on ZvReceiver.

ZvKeyboard

1. Mouse buons and scroll wheel: For easy up/

down navigaon

2. Media Keys: Control playback in popular media

applicaons like Zviewer and Media Center

3. Track ball: For precise mouse control

321 4

Using ZvKeyboard

4. Browser buons

 “Back” and “Forward” commands

on popular internet browsers

Go to browser’s home page

Opens Zviewer (if installed on

computer) for online video

Acvates full-screen mode in

many applicaons

Zoom in or out of acve window

in many applicaons

ZvKeyboard

Sengs

Sengs for pointer speed, keyboard buon repeat speed, etc., are adjustable from the control panel on your

computer, just as with any other keyboard and mouse.

Tips and Troubleshoong

If ZvKeyboard doesn’t work, ensure that the baeries are fresh and installed correctly, and that the on/o

switch on the back of ZvKeyboard is set to “on.”

The logo buon on the boom row of the keyboard is non-funconal except when using the keyboard

with a computer connected to a ZvBox, or with a computer that has Zviewer soware installed. In those

cases the Zv buon brings up Zviewer, a free user interface for easy access to online video. Visit

www.zeevee.com to download Zviewer.

To conserve baery power, turn ZvKeyboard o when not in use for long periods. Note: you may have to re-

pair it with ZvReceiver when you turn the keyboard back on.

Tips and Troubleshoong

If the keyboard works intermiently:

• Ensure that the antenna on ZvReceiver is screwed in ghtly.

• Posion ZvReceiver dierently; keep it away from objects made of metal or stone, which reduce

operang range.

• Replace ZvKeyboard’s baeries.

If range problems persist, adding a USB extender may solve the problem. See www.zeevee.com for more details.

For more assistance see our web site at www.zeevee.com/support, or call us at 1-877- 4ZEEVEE.

ZvKeyboard

Important Ergonomic Informaon

Long periods of repeve moon using an improperly set up workspace, incorrect body posion, and poor work habits may be associated with

physical discomfort and injury to nerves, tendons, and muscles. If you feel pain, numbness, weakness, swelling, burning, cramping, or sness in

your hands, wrists, arms, shoulders, neck, or back, see a qualied health professional.

FCC Statement

FCC Compliance and Advisory Statement: This hardware device complies with Part 15 of the FCC rules. Operaon is subject to the following two condi-

ons: 1) this device may not cause harmful interference, and 2) this device must accept any interference received including interference that may cause

undesired operaon. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protecon against harmful interference in a residenal installaon. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed or used in accordance with the instrucons, may cause harmful interference to radio

communicaons. However there is no guarantee that interference will not occur in a parcular installaon. If this equipment does cause harmful inter-

ference to radio or television recepon, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures: 1) reorient or relocate the receiving antenna; 2) increase the separaon between the equip-

ment and the receiver; 3) connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected; 4) consult the dealer

or an experienced radio/TV technician for help. Any changes or modicaons not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment. Where shielded interface cables have been provided with the product or specied addional

components or accessories elsewhere dened to be used with the installaon of the product, they must be used in order to ensure compliance with

FCC regulaons.

Compliance and FCC Statement ZeeVee Limited Warranty

Limited One Year Warranty

ZeeVee warrants your ZeeVee Equipment against defects in materials and workmanship for a period of one year from the date of purchase. ZeeVee’s lim-

ited warranty extends only to the original end user purchaser or any person receiving the ZeeVee Equipment as a gi from the original end user purchaser

and to no other purchaser or transferee. All warranes implied by law, including any implied warranes of merchantability and tness for a parcular

purpose, are expressly limited to the duraon of this express limited warranty. Some States do not allow limitaons on how long an implied warranty lasts,

so the above limitaon may not apply to you.

EXCLUSIVE REMEDY FOR ZEEVEE EQUIPMENT

At the opon of ZeeVee, the ZeeVee Equipment will be repaired or replaced with a new, repaired or refurbished product (whichever ZeeVee deems as nec-

essary) if it becomes defecve or inoperave. If ZeeVee cannot reasonably repair or replace the ZeeVee equipment then ZeeVee may, at its sole discreon,

refund the original purchase price or the current retail price of the ZeeVee equipment. If ZeeVee chooses to repair or replace the ZeeVee equipment, or to

refund the purchase price, this will be the exclusive remedy. With the excepon of any warranes implied by the law of any state of the USA, this express

limited warranty is exclusive and in lieu of all other warranes, guarantees, agreements and similar obligaons of ZeeVee.

THE ABOVE WARRANTIES ARE SUBJECT TO ALL CONDITIONS LISTED BELOW:

You must have proof of purchase to receive warranty service. A sales receipt or other document showing that you purchased the ZeeVee Equipment is

considered proof of purchase.

Warranty coverage begins the day you purchase the ZeeVee Equipment.

All ZeeVee Equipment, including replacement products, are covered only for the original warranty period. When the warranty on the original product

expires, the warranty on the replacement product also expires.

If we determine that the problem is not covered under the limited warranty, we will nofy you and inform you of service or replacement alternaves that are

available to you on a fee basis.

In the case of a paid repair: at the opon of ZeeVee, the ZeeVee Equipment will be repaired or replaced with a new, repaired, refurbished, or comparable

product (whichever ZeeVee deems as necessary).

(connued on next page)

ZeeVee Limited Warranty

WHAT THESE WARRANTIES EXCLUDE

Your warranes do NOT cover:

Labor charges for installaon or set-up of the ZeeVee Equipment.

Repairs or replacement due to misuse, accident, lightning damage, unauthorized repair, or other causes not within the control of ZeeVee.

Any modicaons or other changes to the ZeeVee Equipment, including but not limited to soware or hardware modicaon in any way other than as expressly

authorized by ZeeVee, will void these limited warranes. Except in the case of hardware or soware provided by ZeeVee, installing modicaons, “hacks,” or

ulizing service access or “back doors” will void these limited warranes.

Recepon or transmission problems caused by signal condions, Internet connecon problems, or any other communicaon systems outside the unit.

Expendable accessories included in ZeeVee Equipment such as baeries.

Any ZeeVee Equipment that has been modied or adapted to enable it to operate in any country other than the country for which it was designed, manufac-

tured, approved, and/or authorized.

Any ZeeVee Equipment that has altered or missing serial numbers.

Any ZeeVee Equipment that has been opened or otherwise tampered with

Problems that are directly caused as a result of using any third party accessories, parts or components.

MAKE SURE YOU KEEP…

Please keep your sales receipt and any other documentaon showing proof of purchase. Also, keep the original box and packaging material in case you

need to return your ZeeVee Equipment.

(connued on next page)

ZeeVee Limited Warranty

TO GET WARRANTY SERVICE

Warranty service will be provided by ZeeVee. If you believe you need service for your ZeeVee Equipment, please contact ZeeVee by calling our

Customer Care Center at (877)-4ZeeVee; (877)-493-3933. If it is determined that the product needs to be returned for service or exchange, you will

receive a Return Material Authorizaon (“RMA”) number. Our agents will help you through the process through which you can return the product.

ZeeVee is not responsible for Customer products received without an RMA number and may reject such products.

TO GET OUT-OF-WARRANTY SERVICE

To obtain out-of-warranty service for your ZeeVee Equipment, please contact ZeeVee by calling our Customer Care Center at (877)-4ZeeVee; (877)-493-

3933 for informaon on the possibility of and any costs for repair or replacement of out-of-warranty products. No agent, company, dealer, distributor,

or person is authorized to change, modify, or extend the terms of these warranes in any manner.

LIMITATION OF LIABILITY
