Zeliox Compact Instruction Manual
Installing
Guide
Zeliox Compact
ENGLISH
3
1. Stand Alone
Follow these steps for correct installation
WARNING:
• Do not place the Zeliox Compact upside down or on its back.
1. Screw the 4 legs in place
at marked positions.
2. See User & Installation
Manual page 25 for further
instructions.
3. Zeliox Compact is
ready for use.
4
2. Aluca
Follow these steps for correct installation
WARNING:
• Do not place the Zeliox Compact upside down or on its back.
1. All cables should be
prepared and routed
according the local
regulations.
2. Remove the drawer
from the cabinet.
3. Place the adapter
plate ZEL-MKS-024
inside the drawer and
mark the hole positions.
5
4. Drill 4 holes size 7mm at
the marked positions.
5. Place 4 claw nuts M6 at
the marked positions.
6. Mount the adapter plate
ZEL-MKS-024 at the bottom
of the Zeliox Compact with
3 bolts.
6
7. Place the Zeliox Compact
with adapter into the drawer.
8. Mount the 4 bolts at
the marked positions.
9. Place the drawer into
the rails connecting the
assembly to the cabinet.
10. See User & Installation
Manual page 25 for further
instructions.
11. Connect the cables to
the Zeliox Compact.
7
12. Gently close the drawer
until it clicks in place.
13. The Zeliox Compact is
ready for use.
8
3. Bott
Follow these steps for correct installation
WARNING:
• Do not place the Zeliox Compact upside down or on its back.
1. All cables should be
prepared and routed
according the local
regulations.
2. Remove the drawer from
the cabinet.
3. Place adapter ZEL-MKS-020
inside drawer and check the
spacing around the plate,
this should be equal.
9
4. Place 4 claw nuts M6 at
the marked positions.
5. Mount the adapter plate
ZEL-MKS-020 at the bottom
of the Zeliox Compact.
6. Mount the 4 bolts at
the marked positions.
10
7. Place the drawer into
the rails connecting the
assembly to the cabinet.
8. See User & Installation
Manual page 25 for further
instructions.
9. Connect the cables to
the Zeliox Compact.
10. Gently close the drawer
until it clicks in place.
11. The Zeliox Compact is
ready for use.
11
4. Servicesystem
Follow these steps for correct installation
WARNING:
• Do not place the Zeliox Compact upside down or on its back.
1. All cables should be
prepared and routed
according the local
regulations.
2. Remove the drawer
from the cabinet.
3. Place adapter ZEL-MKS-020
inside drawer and check the
spacing around the plate,
this should be equal.
12
4. Place 4 claw nuts M6 at
the marked positions.
5. Mount the adapter plate
ZEL-MKS-024 at the bottom
of the Zeliox Compact with
3 bolts.
6. Mount the 4 bolts at
the marked positions.
13
7. Place the drawer into
the rails connecting the
assembly to the cabinet.
8. See User & Installation
Manual page 25 for further
instructions.
9. Connect the cables to
the Zeliox Compact.
10. Gently close the drawer
until it clicks in place.
11. The Zeliox Compact is
ready for use.
14
5. Sortimo
Follow these steps for correct installation
WARNING:
• Do not place the Zeliox Compact upside down or on its back.
1. All cables should be
prepared and routed
according the local
regulations.
2. Remove the drawer from
the cabinet.
3. Place adapter ZEL-MKS-020
inside drawer and check the
spacing around the plate,
this should be equal.
15
4. Place 4 claw nuts M6 at
the marked positions.
5. Mount the adapter plate
ZEL-MKS-024 at the bottom
of the Zeliox Compact with
3 bolts.
6. Mount the 4 bolts at
the marked positions.
16
7. Place the drawer into
the rails connecting the
assembly to the cabinet.
8. See User & Installation
Manual page 25 for further
instructions.
9. Connect the cables to
the Zeliox Compact.
10. Gently close the drawer
until it clicks in place.
11. The Zeliox Compact is
ready for use.
17
6. Different brands
Follow these steps for correct installation
WARNING:
• Do not place the Zeliox Compact upside down or on its back.
1. All cables should be prepared and routed according the local
regulations.
2. Use the measurements for
placing the Zeliox Compact.
The 4 mounting holes should
be located according to
drawing, 7mm round. The
minimum required space
around the Zeliox is shown
as solid line.
3. Make sure the air intake and
outlet are free. Use M6 bolts.
4. Place 4 spacers (5mm) in
between the surface and
the underside of Zeliox
Compact.
5. Make sure the cable section
and the Earth Leakage
Switch at the back of the
Compact are serviceable,
and the cables do not kink.
6. See User & Installation
Manual page 25 for further
instructions.
7. Connect the cables to the
Zeliox Compact.
8. Zeliox Compact is
ready for use.
303
385
249
385
54
505
365
2735
60
60
60
60
35
81
Front Zeliox Compact
Back Zeliox Compact
18
Notes
19
Notes
20
