Zencontrol zc-blind User manual

Dimensions
Mounting options Independently mounted control for surface mounting
Mounting centres 470 / 150 mm
Dimensions 197 / 500 / 57 mm
Product range
Order code Description
zc-blind Full feature blind controller
Installation
Remove the product from the box and inspect it for any damage. If you
believe the product to be damaged or otherwise unsound, do not install
the product. Please pack it back into its box and return it to the place of
purchase for replacement.
If the product is satisfactory, proceed with the installation:
1 Ensure safety warnings are adhered to.
2 Mount the unit as shown in g 1 or g 2 using the appropriate
fasteners (not included).
3 Wire terminal I/O and secure using provided cable clamps or M20
cable glands as per the wiring diagram in g 3.
4 Connect starter leads to output channels
per wiring diagram in g 4-6.
1
Safety information
■This product must only be installed by a licensed electrician.
■Before commencing installation or servicing turn off and isolate all
supply circuits.
■Risk of accidental contact with live parts. Do not energise with product
open or disassembled.
■There are no user serviceable parts, attempting to service any part of the
product will void the warranty
■DALI is not SELV and as such should be treated as LV.
■As the installer, it is your responsibility to ensure you comply to all
relevant building and safety codes. Refer to application standards for the
relevant rules.
■When the installation is complete, leave this manual with the building’s
owner for future reference.
■Each circuit must be protected by a MCB rated at 16 A or less
Blind controller zc-blind
Surface mount
2
Rod mount
Up to 15 mm
threaded rod
M6 fastener
x4
x4
Specications
Supply voltage 230 V ~ 50 Hz
DALI supply current 235 mA
Output rating Maximum 250 mA
Guaranteed supply 235 mA
Terminal capacity Mains 1 - 4 mm2
Digital I/0 0.5 - 2.5 mm2
Lighting circuits 3
Load per circuit 10 A
Motor channels 4
Load per channel 375 W / 1/2HP
1.6 A inductive load
Operating temperature 0 to 45°C
Material PC
Classication Class I
197
500
57
57
470
150
170 mm
= 3 - 5 core
Recommended cable clearance
200 mm
= 6 core

Circuit 3
phase 3
Cable sadles
M20 gland
Circuit 1
Circuit 2
phase 2
Circuit 1
phase 1
zc-room
zc-plug-6w
Wire preparation
6 - 7 mm
1 - 2.5 mm2
Wire preparation
8 - 9 mm
1 - 4 mm2
Wire preparation
5 - 6 mm
0.5 - 2.5 mm
2
Motor 1
*
**
******
TPS cable
Up to 1.5 mm2
TPS cable
Alternative wiring for
single circuit operation
TPS cables
Cable sadles
Ethernet
Digital
output
relay
*
SELV
inputs
*
M20 gland
Blind motor
Switch
DA
DA
L1 (fwd)
N
L1 (rev)
L1
E
N
L2
DALI
DALI
Switched live
Earth
Neutral
Permanent live
L1
E
N
L2
DALI
DALI
Switched live
DALI
DALI
Blind motor
L1 (fwd)
N
L1 (rev)
L1
E
N
L2
DALI
DALI
Switched live
Earth
Neutral
Permanent live
L1
E
N
L2
DALI
DALI
Switched live
Motor 2
Motor 3
Motor 4
Circuit 2
Circuit 3
Information is subject to change without notice, E&OE Last updated 19 / 11 / 19 0553116_V 1.0
© zencontrolzencontrol.com
Wiring diagram Plug wiring
3 5
6
4
For more information
on compliant software
see our website
zencontrol.com
Notice
7
Conguration
Dip switch settings
Sensor delay Absence / presence
A B C D
10 min Presence Reserved for later use
15 min Absence
20 min
30 min
On Off
Blind motor
Blind motor and switch
First channel (side 1)
First channel (side 1)
Second channel (side 2)
Second channel (side 2)
