Z-EACC-DAB2Z-EACC-DAB2
INSTALLATION MANUAL
EN
DAB+ WINDOW MOUNT ANTENNA

2 3
CAUTION
● TheDAB+windowmountantennahasbeendevelopedexclusivelyforuseinsidethevehicle.
● Theantennamustnotadvereslyaffectthedriver’seldofvision.
● Ifyourvehicleisequippedwithasideairbag,theantennamustnotinterferewiththeairbagfunctionsin
anyway.
● Theantennamustnotbeinstalledonmovableglasssurfacessuchasthesidewindowsorrearwindow.
● Donotbendordamagethewindowmountantenna.
● TheZENECsystemshouldbeinstalledbyanauthorisedspecialistdealer.
 Specicknowledgeandtoolsarerequiredforinstallation.Incorrectinstallationcandamagethevehicle
andtheZENECsystem.
●Plasticlevertool
●Optional:cross-headscrewdriver(Phillips)
●Optional:flat-bladescrewdriver
●Optional:Torxscrewdriver(T20)
●Glasscleaner
●Cableties
NOTE
● Thestrengthofsignalreceptionmaybeimpairedifyouinstalltheantennaoninfraredreectiveglass,
thermalinsulationglass,oronsurfacescoveredwithreectivelm.
● Thesignalstrengthalsodecreasesiftheantennaoverlapswithanotherantenna,orifitisnearawindow
heatingwire.
● IfyouhaveanyquestionsorproblemswiththeZENECsystem,pleasecontacttheretailerwhereyou
purchasedit.
TOOLS REQUIRED
No. Item Quantity
1WindowMountAntenna 1
SUPPLIED ITEMS
WORKING OUT THE INSTALLATION POSITION OF THE ANTENNA
Installingtheantennaontheleft-handside Installingtheantennaontheright-handside
(A)=Ceramicline(B)=Magneticearthingstrap
Installation:
1. RemovetheA-pillarcoverinyour
vehicle.Thecoverissecuredwith
specialclips.
  Ascrewisusuallyconcealedbehinda
coverintheupperareaoftheA-pillar.
  Youcancarefullyprisethecoveroff
withaplasticwedgeoraflat-head
screwdriver.
CAUTION
● Ifyourvehicleisttedwithaside
airbag,youmustleavetheignition
switchedoffforthedurationof
theinstallation,andproceedwith
extremecaution.
2. Cleantheselectedadhesiveareaon
thewindscreenusingtheglasscleaner.
  Waituntiltheglasssurfacehasdried
completely.
3. Removetheprotectivefilmfromthe
windowmountantenna(No.1)and
attachitsoitisflushwiththeceramic
line.
  Paycloseattentiontotheinstallation
positionoftheantenna,whichis
explainedatthebeginningofthe
manual.
1
3
2
min. 150 mm
min. 150 mm
A
B
B

4 5
4. Carefullyrubthewindowmount
antenna(No.1)ontothewindscreento
ensurethatitisaffixedsecurely.
5. Takethemagneticearthingstrapand
attachitontotheA-pillar(metalpart).
  Leavesufficientspacefortheearthing
strapsoyoucaninstalltheA-pillar
coveragainlaterwithoutanyproblems.
8. Reattachyourvehicle’sA-pillarcoverin
itsoriginalposition.
  Ensurethatyoudonotdamagethe
earthingstrap.
9.  (Nopicture)
  ConnecttheDABantenna(SMB
connector)toyourDABradio.
10. (Nopicture)
  Startup:Turnonyourradioandactivate
theDAB+antennavoltage(12V)inthe
settings.
  Onceconnected,performaDAB+search
onyourradio.
7. Usecabletiestoattachtheantenna
cabletotheexistingwiringharnessesin
thevehicle.
ATTENTION
● Payparticularattentiontoen-
surethatyoudonotadversely
affectthefunctionoftheairbag
inanyway.
4
5
6
7
8
6.  Routetheantennacabledownwards
alongtheA-pillar,alongthedashboard
andintotheradiobay.

Technicalmodificationsexcepted.Noliabilityacceptedforprintingerrors. ©Copyright2023·RevC/copydeadline:Q2-2023 ·English
Product Description
Compactuniversalrodtypeantennawithadhesivemounting:Themagnetpillprovidesforafastandsimple,
non-invasivecarbodygroundreference.Goodreceptionperformanceforthisparticulartypeofantennaisthe
secondadvantage.
Key Features
• ActiveDAB+antennaforeasymountingontheinnersideofthewindshield
• 90°SMBantennaconnector(f),3.0mcablelength
• Groundconnectionoftheantennatothevehicleusingasmallmagnet
• ESDprotected
Technical Specifications
Receptionfrequencyrange: BandIII,174~240MHz(noL-Bandcoverage)
Antennaimpedance:  50Ohm
Antennagain:   16dB±2dB
Operatingvoltage:  9~16V
Currentconsumption@12V: 10mA
Powerconsumption@12V: 120mW
Operating / receiving frequency
ThisproductcontainsanamplifiermoduleforthefrequencyspectrumreceivedbytheantennainbandIII,from
174-274MHz.
Radio Frequency Exposure Information
ThisdevicecomplieswithEUrequirements(2014/53/EUArticle3.1a)tolimitexposureofthegeneralpublicto
electromagneticfieldsforhealthprotection.
Donotusethedeviceinlocationswherewirelessdevicesarenotallowed.
ZENECcannotguaranteethataccidentsordamagewillnotoccurduetoimproperuseofthedevice.Usethis
productwithcareandatyourownrisk.
Conformity with radio equipment
Hereby,ACRBrändli+VögeliAGdeclaresthatthetypeofradioequipmentZ-EACC-DAB2complieswiththe
2014/53/EUDirective.ThefulltextoftheEUDeclarationofConformityisavailableatthefollowingInternet
address:http://www.zenec.com(seelink"ProductConformityDocuments"inthefooterareaofthepage).
Recycling Notes
ThisproductbearsthesymbolforselectivesortingofWasteElectricalandElectronicEquipment(WEEE).
ThismeansthatthisproductmustbetreatedinaccordancewithEuropeanDirective2012/19/EUinorderto
berecycledordismantledtominimizeitsimpactontheenvironment.Theuserhasthechoicetohandoverhis
producttoacompetentrecyclingorganizationortotheretailerwhenanewelectricalorelectronicdeviceis
purchased.
UKAuthorisedRepresentative
(forauthoritiesonly)
ProductIP(UK)Ltd.
8,NorthumberlandAv.
LondonWC2N5BY
MADE IN CHINA
Manufacturer:ACRAG∙Bohrturmweg1∙CH-5330BadZurzach∙Switzerland
LegalrepresentativeinEU:ACRS&VGmbH∙Industriestraße35∙D-79787Lauchringen∙Germany
www.zenec.com
