ZERO-X ZXM-AC5 User manual

Waterproof 4K UHD Action Camera
USER MANUAL
ZXM-AC5

3
CONTENTS
1.0 INTRODUCTION............................................................................... 6
2.0 ABOUT THE ZXM-AC5 .................................................................... 6
3.0 WHATS IN THE BOX......................................................................... 7
4.0 COMPONENTS................................................................................. 7
5.0 GETTING STARTED ...............................................................................7
5.1 CHARGING THE BATTERY .................................................................9
5.2 MICRO SD CARD COMPATIBILITY..................................................10
5.3 TOUCH SCREEN COMPONENTS ...................................................10
5.4 POWERING ON YOUR ZXM-AC5.................................................... 10
5.5 FORMAT YOUR MICRO SD CARD...................................................11
6.0 ZXM-AC5 CONTROLS AND FUNCTIONS...................................... 12
6.1 POWER ON/OFF BUTTON .............................................................. 12
6.2 SHOOT/RECORD BUTTON .............................................................12
6.3 The MODE BUTTON.........................................................................12
6.4 ACCESSING SYSTEM SETTINGS..................................................... 13
6.5 SETTING THE TIME........................................................................... 13
6.6 SETTING THE DATE FORMAT .........................................................14

4
6.7 SETTING THE DATE.......................................................................... 15
6.8 AUTO POWER OFF...........................................................................16
6.9 WiFi.......................................................................................................17
6.10 WiFi INFORMATION ......................................................................... 18
6.11 RE-SET WiFi .......................................................................................19
6.12 ROTATE IMAGE .................................................................................20
6.13 DVR MODE ........................................................................................ 21
6.14 SCREEN SAVER..................................................................................22
6.15 LED INDICATOR ................................................................................23
6.16 KEYPAD TONE................................................................................... 24
7.0 PICTURE & VIDEO SETTINGS ........................................................ 25
7.1 VIDEO MODE ....................................................................................26
7.2 SLOW MODE..................................................................................... 28
7.3 LOOP MODE .....................................................................................30
7.4 LAPSE MODE.....................................................................................32
7.5 PHOTO MODE ..................................................................................34
7.6 AUTO MODE .....................................................................................36
7.7 BURST MODE ....................................................................................38

5
7.8 TIMER MODE..................................................................................... 40
7.9 PLAYBACK MODE ............................................................................. 42
8.0 RESTORE DEFAULT SETTINGS....................................................... 43
9.0 FIRMWARE VERSION ..................................................................... 44
10.0 INSTALLING AND USING THE ZX-ACTION APP .......................... 45
11.0 MANUAL STEPS FOR CONNECTING TO THE ZX-ACTION APP... 45
11.1 ZX-ACTION APP ................................................................................46
11.2 SAVING PHOTOS AND VIDEOS VIA THE APP............................... 47
11.3 REMOTE PHOTO/RECORD VIA THE APP ......................................48
11.4 ADJUSTING SETTINGS VIA THE APP .............................................48
12.0 WARRANTY TERMS & CONDITIONS............................................. 49

6
1.0 INTRODUCTION
Thank you for purchasing a ZXM-AC5 action camera. Please read through
this User Manual before attempting to use the ZXM-AC5.
FEATURES
• 4K UHD Recording
• 2.0” LCD Display Screen
• Waterproof without protective case up to 10 metres underwater
2.0 ABOUT THE ZXM-AC5
The Zero-X ZXM-AC5 shoots footage with dynamic realism, where action
is effortlessly captured into moments you can keep. The ZXM-AC5 comes
with a range of included accessories to create fully immersive footage. To
learn more about our extended accessory range and for details on stockists,
please visit the Zero-X website.
www.zero-x.com.au | www.zero-x.co.nz.
Please note, the ZXM-AC5 is waterproof to a depth of up to 10 metres / 1
atmosphere without its waterproof case.
A waterproof case is also included with the ZXM-AC5 to use as a protective
case during action sports (it is more protective if the camera is dropped
on a hard surface), and also if you want to submerge the camera up to 30
metres underwater.

7
3.0 WHATS IN THE BOX
4.0 COMPONENTS
5.0 GETTING STARTED
1 x ZXM-AC5 Action Camera
1 x USB Charging & Data Cable
1 x Waterproof Casing
1 x Bike Mount
2 x Quick Release Mounts
2 x 3M Adhesive Mounts
3 x 3 Way Mounts
1 x Frame Mount
4 x Straps
1 x Helmet Base
1 x Adaptor Mount
1 x Metal Tether
2 x 3M Adhesive Pads
1. Power On/Off Button
2. Shoot/Record Button
3. Mode Button
4. HDMI Port &
Charging Port
5. Battery & Micro SD
Card Slot Access
1
3
2
5
4

8
CAUTION:
Before using your action camera please ensure you read and understand the following
product and safety precautions.
• Do not use the ZXM-AC5 without water proof case deeper than 10M.
• Do not use the ZXM-AC5 with the waterproof case in water deeper than 30M.
• Always check the waterproof case seal is clean and free of debris prior to use in water.
• Do not attempt to open the ZXM-AC5 or modify it in any way. If the ZXM-AC5 has
been tampered with the warranty will be void. Maintenance and repairs should only be
performed by Zero-X.
• Only recharge the ZXM-AC5 battery using the supplied USB cable.
• Do not use the ZXM-AC5 in temperatures that exceed 55°C.
• Do not drop, crush, pierce, bend, deform, microwave, incinerate or shoot the ZXM-AC5.

9
BATTERY WARNING
Always charge the ZXM-AC5 using the provided USB Cable. If the ZXM-AC5 is not charged
as directed in this manual, the battery may become damaged and fail.
• Never dismantle the ZXM-AC5 or expose the internal battery cell.
• Do not dispose of the ZXM-AC5 in fire.
• Please dispose of the ZXM-AC5 mindfully and observe local regulations, especially in
regards to the safe disposal of the internal battery. Check your local recycling facility for
more information.
• Only use a certified 5V 1.5A USB charger to charge the ZXM-AC5. Using non certified
chargers could potentially damage the ZXM-AC5, or the ZXM-AC5 battery and void the
warranty.
• Do not let the battery charge overnight.
• If the ZXM-AC5 seems to still need charging after three hours, temporarily remove it from
its charger as the battery may overheat. Let it cool down for 30 minutes and try charging
again.
5.1 CHARGING THE BATTERY
We recommend that you fully charge your ZXM-AC5 before use. A full
charge will take approximately 3.0 hours using a 5V 1.5A Charger.

10
5.2 MICRO SD CARD COMPATIBILITY
The ZXM-AC5 requires a Micro SD Card (not included) to save the
files. We recommend you use a maximum 128GB, UHS Class 3 or
higher Micro SD Card from a well known brand.
NOTE: There is only one correct way to insert the Micro SD Card into your ZXM-AC5. It
should easily slide in. Do not force the card into the slot as it may damage the unit
and the card.
5.3 TOUCH SCREEN COMPONENTS
5.4 POWERING ON YOUR ZXM-AC5
To power ON your ZXM-AC5 follow the below steps:
1. Insert the battery into the unit.
2. PRESS and hold the ON/OFF BUTTON on the side of the unit
until the start up screen appears.
1
2 3 4
765
1. Current Mode
2.
Micro SD Card Inserted
3. Microphone ON
4. Battery Level
5. Playback
6. Mode Selection
7. Settings

11
5.5 FORMAT YOUR MICRO SD CARD
Before you start using the ZXM-AC5, we recommend that you format
the Micro SD card. You are able to format the Micro SD card using the
ZXM-AC5. The instructions on how to do this are listed below:
1. If you are currently in VIDEO MODE and RECORDING, you
will need to PRESS the SHOOT/RECORD BUTTON to end the
recording first.
2. Once the ZXM-AC5 is fully charged insert your Micro SD Card into
the correct slot (see the “4.0 COMPONENTS”).
3. PRESS the ON/OFF BUTTON on the side of the unit to turn ON
the ZXM-AC5.
4. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.
5. PRESS the tab on the left side of the screen. The current
section tab will be highlighted blue.
6. Scroll down the list by swiping from bottom to top until you reach
FORMAT SD CARD. PRESS on this option.
7. You will be prompted with the options FORMAT and CANCEL.
PRESS on the option that you require. Your Micro SD card will now
format.
NOTE: Formatting the Micro SD card will permanently erase all data stored on the Micro
SD card. Be sure to back up all saved data prior to formatting.

12
6.0 ZXM-AC5 CONTROLS AND FUNCTIONS
6.1 POWER ON/OFF BUTTON
The ON/OFF BUTTON is located at the side of the ZXM-AC5. This is
used to turn ON/OFF the unit.
The ON/OFF BUTTON is also used to change between the Video/
Photo in preview interface, the Video Settings, Photo Settings,
General Settings and Exit in setting menu. It also serves as the back
button when you are in the navigation settings.
6.2 SHOOT/RECORD BUTTON
The SHOOT/RECORD BUTTON is located on right side on top of the
ZXM-AC5. This button is used to shoot images and also record videos
(start and stop videos).
The SHOOT/RECORD BUTTON is also used to access the navigation
SETTINGS MENUS, select menu items, and confirm your selection.
6.3 THE MODE BUTTON
The MODE BUTTON is located on the top of the ZXM-AC5 on the left
side. This button is used to access the navigation SETTING MENUS
and to scroll down in the setting menu.

13
6.4 ACCESSING SYSTEM SETTINGS
You can access system settings when using any of the camera modes.
1. If you are currently in VIDEO MODE and RECORDING, you
will need to press the SHOOT/RECORD BUTTON to end the
recording first.
2. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.
6.5 SETTING THE TIME
To set the correct time on your ZXM-AC5, follow the below steps
once your unit is turned ON. You can set the time and date in separate
settings.
1. If you are currently in VIDEO MODE and RECORDING, you
will need to press the SHOOT/RECORD BUTTON to end the
recording first.
2. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.
3. PRESS the tab on the left side of the screen. The current
section tab will be highlighted blue.

14
4. Scroll down the list by swiping from bottom to top until you reach
TIME SETTING. PRESS on this option. The time settings screen
will pop up.
5. You will be prompted to fill in the current hour, minute and
seconds. Navigate by pressing either the hour, minute and second
on the screen. To change the numbers, PRESS the UP and DOWN
ARROWS on the screen until you reach the required number.
6. Once you have adjusted the time, confirm by pressing the TICK on
the screen in the top right corner. The time will now be updated.
NOTE: The option which is bold and black is the active selection. Non active
options are grey. The time is 24 hour and is set as HH:MM:SS.
6.6 SETTING THE DATE FORMAT
The ZXM-AC5 has 3 date formats you can choose from, including how
the date is displayed. The options are YYYY/MM/DD, MM/DD/YYYY
and DD-MM-YYYY. The ZXM-AC5 default setting is DD/MM/YYYY.
To change follow the below steps:
1. If you are currently in VIDEO MODE and RECORDING, you
will need to press the SHOOT/RECORD BUTTON to end the
recording first.
2. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop-up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.

15
3. PRESS the tab on the left side of the screen. The current
section tab will be highlighted blue.
4. Scroll down the list by swiping from bottom to top until you reach
DATE FORMAT. PRESS on this option. The DATE FORMAT
SETTINGS screen will pop up.
5. PRESS on the option that you prefer. The DATE FORMAT will now
be updated.
6.7 SETTING THE DATE
To set the correct date on your ZXM-AC5, follow the below steps. You
set the time and date in separate settings.
1. If you are currently in VIDEO MODE and RECORDING, you
will need to press the SHOOT/RECORD BUTTON to end the
recording first.
2. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.
3. PRESS the tab on the left side of the screen. The current
section tab will be highlighted blue.
4. Scroll down the list by swiping from bottom to top until you reach
DATE SETTING. PRESS on this option. The DATE SETTING
screen will pop up.

16
5. You will be prompted to fill in the current year, month and day.
Navigate through by pressing on either year, month and day on
the screen. To change the numbers PRESS the UP and DOWN
ARROWS on the screen until you reach the required number.
6. Once you have adjusted the date, confirm this by pressing the
tick on the screen in the top right corner. The time will now be
updated.
6.8 AUTO POWER OFF
The auto power OFF function is designed to help extend the battery
life of the ZXM-AC5. The ZXM-AC5 will automatically POWER OFF
after a selected period of inactivity (3, 5, 10 MINUTES and OFF). The
ZXM-AC5 is factory defaulted to 3 MINUTES. To change this setting,
follow the below steps:
1. If you are currently in VIDEO MODE and RECORDING, you
will need to press the SHOOT/RECORD BUTTON to end the
recording first.
2. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.
3. PRESS the tab on the left side of the screen. The current
section tab will be highlighted blue.

17
4. Scroll down the list by swiping from bottom to top until you reach
AUTO POWER OFF. PRESS on this option. The AUTO POWER
OFF SETTINGS screen will pop up.
5. You can scroll through the options by swiping up and down on the
screen. PRESS on the option that you prefer. The setting will now
be updated.
6.9 WIFI
The ZXM-AC5 comes with inbuilt WiFi, allowing you to easily access
your footage and photos through your smartphone. The ZXM-AC5
default setting is OFF. For more information, see ‘11.1 ZX-ACTION
APP.’ To change this setting, follow the below steps:
1. If you are currently in VIDEO MODE and RECORDING, you
will need to press the SHOOT/RECORD BUTTON to end the
recording first.
2. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.
3. PRESS the tab on the left side of the screen. The current
section tab will be highlighted blue.
4. Scroll down the list by swiping from bottom to top until you reach
WIFI. You will notice a box on the right of screen with TURN OFF
next to it. PRESS on this box. The WiFi is now activated.

18
5. To exit out of WIFI MODE, PRESS the UP BUTTON.
NOTE: When WiFi is connected to your smartphone, you cannot use the
functions on the ZXM-AC5 via the camera however you can manage
functions via the app in this mode. You can also use your smartphone
as a wireless recording monitor when in WiFi mode. You can control
functions via the ZXM-AC5 camera again once you have finished
using the functions of the ZX-ACTION APP and disconnect from your
smartphone.
6.10 WIFI INFORMATION
If you need to find out the connection name and password of the ZXM-
AC5 WiFi ID, you can find this in the WiFi information section. To access
this, follow the below steps:
1. If you are currently in VIDEO MODE and RECORDING, you
will need to press the SHOOT/RECORD BUTTON to end the
recording first.
2. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.
3. PRESS the tab on the left side of the screen. The current
section tab will be highlighted blue.
4. Scroll down the list by swiping from bottom to top until you reach
WIFI INFORMATION. PRESS on this option to see the WiFi ID
information.

19
5. WiFi information will have WIFI ID and WIFI PASSWORD. The
WiFi Name will be ZXM-AC5_XXXX ( XXXX will be unique to every
action camera) Password: 1234567890
6.11 RE-SET WIFI
If you need to re-set ZXM-AC5 WiFi connection, follow the below steps:
1. If you are currently in VIDEO MODE and RECORDING, you
will need to press the SHOOT/RECORD BUTTON to end the
recording first.
2. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.
3. PRESS the tab on the left side of the screen. The current
section tab will be highlighted blue.
4. Scroll down the list by swiping from bottom to top until you reach
RESET WIFI. PRESS on this option.
5. You will be prompted to confirm or cancel. PRESS on the option
you require. If you PRESS confirm, the WIFI will be re-set.

20
6.12 ROTATE IMAGE
You have the ability to flip the image vertically (upside down) when
you are using the ZXM-AC5, by turning on this function. The ZXM-AC5
default setting is OFF. To change this setting, follow the steps:
1. If you are currently in VIDEO MODE and RECORDING, you
will need to press the SHOOT/RECORD BUTTON to end the
recording first.
2. PRESS the BUTTON on the bottom right of the back screen,
this will open up the SETTINGS MENU. A pop up with two locks
and arrows may appear. Swipe from left to right. You may need to
PRESS the BUTTON again.
3. PRESS the tab on the left side of the screen. The current
section tab will be highlighted blue.
4. IMAGE ROTATION is the first option on the settings menu. You
will notice there is a small box with TURN OFF next to it. PRESS
the box to activate this function. It will now say TURN ON. The
camera image will now be flipped vertically (upside down).
