Zeroplus LAP-C Pro User manual

LAP-C Pro
LOGIC ANALYZER
Quick Start Guide
English

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
2
Index
0. Precautions
1. Introduction
1.1. Preface
1.2. About document
1.3. Product Introduction
1.4. Package Content
1.5. System Requirements
1.6. Product Specifications
2. Installation and Setup
2.1. Software Installation
2.2. Hardware Setup
2.3. Quick Start the Software
2.4. Operating Environment and Maintenance
3. Contact ZEROPLUS

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
3
0. Precautions
Users are advised to carefully review this section to avoid potential
hazards to people, this product and other products connected to it.
To protect the instrument and the Device under Test (DUT), grounding
is required during signal acquisition.
Follow the “Operating environment” recommendations from Table 2:1.
Protect the logic analyzer from static discharge.
Avoid direct impacts and rough handling.
The logic analyzer is a pollution degree 2 instrument.
Normally only dry, non-conductive pollution occurs. Occasionally a
temporary conductivity that is caused by condensation must be
expected. Temporary condensation occurs only when the product is out
of service.
Do not place heavy objects on the logic analyzer.
As a Class A product, the LAP-C Pro may cause radio interference.
Do not disassemble the logic analyzer as this will void the warranty and
may affect its operation.

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
4
1. Introduction
1.1.Preface
This Quick Start Guide presents the Zeroplus* logic analyzer, its
operation and software. The purpose of the Quick Start Guide is to help
users understand and get familiar with the operations of the instrument and
the software. Throughout the document, the instrument software is referred
to as ZP-Logic and the instruments as LAP-C Pro.
Users are welcome to give us feedback by email or telephone. Thank
you for purchasing our logic analyzer.
* Zeroplus and ZP are abbreviation of Zeroplus Technology Co., Ltd.
1.2.About document
This Quick Start Guide is organized as follows: First, the characteristics
of the logic analyzer are presented, followed by installation and setup
procedures.
NOTE：The updated software UI might differ from the illustrations
herein.

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
5
1.3.Product Introduction
The LAP-C Pro is a multi-purpose PC-based logic analyzer. It has the
largest memory capacity for the channels, higher sampling rate and more
advanced functions.
But the LAP-C Pro is not only about GHz and Gb/Mb. The extensive
protocol library consisting of more than 129 protocol decoders, direct
streaming to disk, channel folding, user-friendly software and a host of other
functions make efficient debugging.
1.4.Package Content
All items contained in the package are listed in Table 1:1。. If any of
the items is missing or damaged, please contact your distributor as
soon as possible.

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
6
Item
LAP-C Pro
LAP-C Pro
Detail
Channels
16ch
32ch
Logic Analyzer
1
1
USB flash drive
(software)
1
1
2 x 5 pin Probe (short)
2
4
10cm
2 x 5 pin Probe (long)
2
4
25cm
1 pin Probe (gray)
4
4
25cm
1 pin Probe (black)
1
1
25cm
Clip-on connector
20
40
USB 3.0 cable;
PC-to-LAP-C Pro
1
1
A to B type;
1.5 m
Table 1:1 LAP-C Pro package content

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
7
1.5.System Requirements
1.5.1. Operating System Requirements
The ZP-Logic supports operating systems for Microsoft only. See Table
1: 2 below for a list of supported operating systems. Please contact our
Technical Support team if you have questions about past operating
systems.
Supported OS
Versions
Windows 10
32- and 64-bit (Recommended)
Windows 8.1
32- and 64-bit (Recommended)
Windows 7
32- and 64-bit
Table 1:2 Supported operating systems

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
8
1.5.2. Hardware Requirements
Item
Value
Type
CPU
2 GHz
Minimum
Memory
RAM
4 GB
Minimum
RAM
8 GB
Recommended
Hard disk
80 GB
Minimum
Interface
USB 3.0
Recommended
support
USB 2.0
Recommended
compatibility
Display
Display size
17”
Recommended
Display resolution
1,024 x 768
Minimum
Display card
8 Mb SDRAM
Recommended
Table 1:3 PC hardware requirements and recommendations

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
9
1.6.Product Specifications
1.6.1. Product Photo
Figure 1-1 Top view of the LAP-C Pro

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
10
1.6.2. Specifications
Item
Characteristic
Supported operating
systems
See Table 1:
Acquisition Channels
16 or 32
Interface
USB 3.0 (2.0 compatible)
Sampling Frequency
Internal (Timing)
2 GHz
External (State)
250 MHz (Dual-edge)
Memory/channel
4, 8, 16, 32, 64 , 128, 256, 512Mb or 1Gb
Trigger
Trigger Channels
16 or 32
Trigger Events
Pattern / Edge / Pulse-width / Interval (Time)
Trigger Delay
Yes
Trigger Sequence Levels
256
Trigger Pass
1-65,535
Trigger Voltage
4 simultaneous levels;
1 for each of the 4 ports
Auxiliary Cursors
250
Protocol Triggers (HW)
I2C, I2S, SPI, SVID, UART, CAN2.0B
Software functions
Languages
English, Chinese (Traditional), Chinese
(Simplified)

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
11
Wavefrom & UI
customization
Modify the appearance of channels, menus,
traces, windows etc
State List & Waveform
View
Present the samples as a list of 1s and 0s or
as a waveform
DSO Connection
Connect to and import signals from DSOs
Files Comparison
Compare 2 files to quickly see the difference
Navigator
Instantly navigate the distant parts on the
waveform
Memory View
See the memory status; read/written each
address
Packet List
Breakdown of all packets in list form
Statistics
Table view the numbers & periods, satisfied
conditions etc
Find Results
Set conditions, and look for the information
which meets the requirements
Real-time Signal Activity
Live view of the activity of probe
Protocol Decoders
More than 129 free, built-in protocol
decoders
Miscellaneous
Power
USB 5 V
Dimensions
125 x 92 x 25 mm
Certifications
FCC/CE/WEEE/RoHS/REACH
Table 1:4 LAP-C Pro specifications

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
12
NOTE：The external sampling frequency requires the shortest probe,
or the ground wire can be added to each channel with twisted.
1.6.3. Available Models
Model
Channels
Memory depths available
LAP-C Pro
16
64 and 128Mb /channel
LAP-C Pro
32
64, 128, 256, 512Mb or 1GMb /channel
Table 1:5 LAP-C Pro Available memory depths
1.6.4. Electrical Specifications
Item
Power Supply
Working Voltage (DC)
USB 5V
Working Current (MAX)
0.6A
Working Power (MAX)
3W
Table 1:6 LAP-C Pro power specifications
NOTE：Voltages that exceed the Working Voltage may damage the
LAP-C Pro.

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
13
1.6.5. Probe Specifications
The following input channels are also available for the LAP-C Pro.
Item
Description
Signal Type
Single-ended
Channels (Max)
32 Signal + 4CK
Input Impedance
200 kohm
Capacitance
7 pF
Input Bandwidth (Max)
250 MHz
Trigger Level
User-defined
Trigger Level Range
-6 to 6 V
Trigger Level Resolution
10mV / STEP
Reference Level Accuracy
±100mV+5%Vth
Input DC V (Max)
±30 V
Table 1:7 LAP-C Pro input channel specifications
NOTE：The Input Bandwidth (Max) requires the shortest probe, or
the ground wire can be added to each channel with twisted.

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
14
1.6.6. Overview of Port
Figure 1-2 shows the overview of port of the LAP-C Pro
Figure 1-2 LAP-C Pro, Overview of Port

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
15
Port
Number
Description
Signal in
Channels
32/16
USB connections to probes for signal
acquisition
CLK IN
4/2
External clock input for State mode
acquisitions
T_O
1
Send output signal upon triggering
T_I
1
Trigger in
Pattern
Generate
4
Output pattern
USB
1
Connection to the PC;
both USB 3.0 and 2.0 are supported
EXPAND
1
Reserved
Table 1:8 LAP-C Pro, Overview of Port

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
16
In Fingure 1-3, cables are connected to the LAP-C Pro ports listed
above.
32-signal in channel ports are on the left side of the product.
Figure 1-3 Cable connections to the LAP-C Pro

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
17
2. Installation and Setup
2.1. Software Installation
NOTE: For users who have internet access, we recommend that you
download the latest version of the ZP-Logic software from our website:
www.zeroplus.com.tw/logic-analyzer_en/
Close all other programs and connect the logic analyzer to the PC via USB.
Connect the flash drive for ZP-Logic Software activation.
Open the Setup.exe file manually.
The dialog box will be shown as Figure 2-1.
Figure 2-1 Main installation window

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
18
Choose the Application Setup as the option will install both the software and
the instrument driver.
The Driver Setup is for driver reinstallation.
Before the installation starts, the user will be asked to read the License
Agreement carefully. “I accept the terms of the license agreement” must
be checked to continue. Next, enter User and Company names to
continue.
Click “Next” throughout the installation to install the standard version is
recommended, but options for customizing the installation are also available
for the user.
Upon completion, the user will be prompted to restart the computer.

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
19
2.2. Hardware Setup
Connect the probe to the instrument; see Figure 2-2
Figure 2-2 Probe connected to the LAP-C Pro
Connect the LAP-C Pro to the PC using the USB. The power lamp
(in Figure 2-3) turns on when the power is been supplied.
Figure 2-3 Probe and USB cable connection

LAP-C Pro Logic Analyer | Quick Start Guide | www.zeroplus.com.tw
20
2.3. Quick Start the Software
1. Memory Capacity: Determine the amount of data to be acquired per
channel
2. Sampling Rate: Determine how often the samples are taken
3. Column of Trigger: 6 trigger conditions include <Don't Care>, <High>,
<Low>, <Rising Edge>, <Falling Edge> and <Either Edge>
4. Trigger Level: Set up with 4 different Trigger Levels (Port A, B, C and D)
at a time
5. Signal capture: Capture the sample with using Sampling setting and
Trigger condition
6. Display All: Show all data in the waveform view
