Manual
Surface Texture Meter PCE-RT 10
Version 1.0
Date of creation: 21.04.2016
Date of last change: 04.05.2016

Manual
2
Contents
1Introduction .............................................................................................................3
2Safety notes.............................................................................................................3
3Specification............................................................................................................4
4System description.................................................................................................5
4.1 Measurement unit....................................................................................................................... 5
4.2 Delivery content.......................................................................................................................... 5
4.3 Measuring procedure.................................................................................................................. 6
4.3.1 Preparations................................................................................................................................... 6
4.3.2 Perform measurements ................................................................................................................. 7
4.3.3 Set the measurement length.......................................................................................................... 7
4.3.4 Calibration...................................................................................................................................... 7
4.3.5 Set Cutoff length ............................................................................................................................ 7
4.4 Notes .......................................................................................................................................... 7
4.4.1 General Notes................................................................................................................................ 7
4.4.2 Standards....................................................................................................................................... 7
4.4.3 Travel length .................................................................................................................................. 8
4.4.4 Recommended length of the cutoff frequency............................................................................... 8
5Battery replacement................................................................................................8
6Disposal...................................................................................................................9
7Contact.....................................................................................................................9
7.1 PCE Instruments UK .................................................................................................................. 9
7.2 PCE Americas ............................................................................................................................ 9

Manual
3
1 Introduction
Thank you for purchasing a surface texture meter from PCE Instruments.
The surface texture meter PCE-RT 10 is a small, light device with a very simple navigation. Despite the
fact that the device functions on a very complex and elaborated level, the measurement results can be
gained very easily and in a comfortable way. Due to a high insensitivity the device has a long lifetime.
This device is calibrated according to ISO, DIN, ABSI and JIS standards. The surface texture meter can
be applied for various mechanical manufacturing processes as controlling equipment. The device
indicates all calculated measurement results on its LCD display at any time. In order to measure the
roughness of a surface, the sensor has to be placed onto the surface. Subsequently, the sensor moves
smoothly in the lead on the surface. Now the device will calculate the measuring values. Thus the
indicated values are a result of the sensor's movement, while it is induced with electricity. The fast DSP
processing supports quick measurements results, which are then shown on the surface texture meter's
display. If the instrument is not used for five minutes, it will turn itself off automatically.
2 Safety notes
Please read this manual carefully and completely before you use the device for the first time. There is no
warranty of damages or injuries caused by non-observance of the manual.
- The instrument may only be used as described in this manual. If it is not used in the described
way it may cause injuries or break.
- Only use the device in the prescribed ambient conditions. Protect it from direct sunlight, fluids and
high humidity.
- The instrument may only be used by qualified personnel and repaired by PCE Instruments
personnel.
- Do not place the instrument on the user interface since scratches may appear on the interface.
- Do not make any technical changes on the device.
- The appliance should only be cleaned with a damp cloth / use only pH-neutral cleaner.
- Only use the tester with dry hands.
- The instrument can only be used with and replaced by accessory supplied by PCE Instruments.
- The measuring instrument cannot be used in explosive atmospheres.
- If the tester is not used for a longer period of time the batteries should be taken out of the device
in order not to damage it.
This user's handbook is published from PCE Instruments without any guarantee.
We expressly point to our general guarantee terms, they can be found in our general terms of business.
If you have any questions please contact PCE Instruments.

Manual
4
3 Specification
Measurement range
Ra
0.05 ... 10 µm / 1 ... 400 µinch
Rz
0.02 ... 100 µm / 0.78 ... 40 µinch
Measurement accuracy
General
±10 %
Fluctuation on display
Max. 6 %
Resolution
measurement range < 10 µ
0.001 µ
measurement range < 100 µ
0.01 µ
measurement range ≥ 100 µm
0.1 µ
Sensor
Measuring type
Induction principle
Radius of sensor
10 µm
Material of sensor
Diamond
Measuring force of sensor
16 mN (1.6gf)
Sensor angle
90 °
Vertical radius of probe head
48 mm
Measurement speed
Sampling length: 0.25
Vt = 0.135 mm/s
Sampling length: 0.8
Vt = 0.5 mm/s
Sampling length: 2.5
Vt = 1 mm/s
Returning
Vt = 1 mm/s
General Technical Specifications
Maximum hub
2.5 mm / 0.5 inch
Limit of frequency length
0.25 mm / 0.8 mm / 2.5 mm optical
Units
Rz, Ra
Display
4-digit LCD display, with background lights
Maximum surrounding temperature
0 ... +50 °C
Maximum surrounding air humidity
< 80%
Diameters
140 x 52 x 48 mm
Weight
280 g

Manual
5
4 System description
4.1 Measurement unit
1. Calibration mode
2. Measured value
3. Position indicator
4. Chosen parameter
5. Parameter button / Up
6. Calibration button
7. Power on / off
8. Battery level
9. Measurement unit
10. Cutoff frequency
11. Start button
12. Cutoff frequency button
13. µm / µinch button / Down
4.2 Delivery content
1 x Surface texture meter PCE-RT 10
1 x Calibration plate
1 x User’s manual
1 x Screwdriver

Manual
6
4.3 Measuring procedure
4.3.1 Preparations
1. Switch on the device to check the battery level
2. The device will automatically set the conditions of the last measurement. Because of that all
settings should be checked properly.
3. In order to check the settings the parameter button needs to be pressed.
4. Check if the cutoff frequency is set correctly. If that is not case, press the cutoff frequency button.
To set the correct length of the cutoff frequency, refer to the table “Recommended length of the
cutoff frequency” within this manual.
5. Press the µm / µinch button to check the correctness of the measuring units.
6. Clean the surface you want to measure in order to avoid faulty measuring results.
7. The device needs to be placed correctly on the surface. This is shown in the figure below. If it is
not set up correctly the measured results may be faulty.
8. The sensor of the instrument needs to be placed on the surface in an angle of 90 °.
Wrong
Correct
Wrong

Manual
7
4.3.2 Perform measurements
Press the Start button when all preparations are made. The display shows “- - - -“ while the measurement
is made. After the selected area has been detected the probe only moves backwards to the position from
where measurements are started. After this point has been reached, the measured value is displayed on
the screen. Now it is possible to view the results in Ra or Rz by simply pressing the Parameter button.
4.3.3 Set the measurement length
The measurement length is set by making use of the Calibration button. Press the Calibration button until
the display shows “LEN”. You can now choose length “1” and “2” by pressing the Up or Down button. The
settings can be saved by pressing the Start button.
4.3.4 Calibration
To calibrate the device, press the Calibration button. “CAL” will show up in the display. Now place the
device on the calibration plate and press the Start button. The display will show a result after
measurement has been made. You can now adjust value according to the reference value on the
calibration plate. To do so, use the Up / Down button. When the correct value has been set, switch the
device off and on again.
4.3.5 Set Cutoff length
To set the cutoff length the Cutoff button simply needs to be pressed. You can choose between 2,5 mm,
0,25 mm and 0,8 mm.
4.4 Notes
4.4.1 General Notes
???
???
4.4.2 Standards
- ISO 4287
- DIN 4768
- JIS B601
- ANSI B46.1

Manual
8
4.4.3 Travel length
L = Length of the sampling
n = amount of the sampling length
I x n = Length of the calculation
4.4.4 Recommended length of the cutoff frequency
Ra (µm)
Rz (µm)
Cutoff frequency length (mm)
>5 … 10
>2,5 … 5
>20 … 40
>10 … 20
2,5
>1,25 … 2,5
>6,3 … 10
0,8
>0,63 … 1,25
>3,2 … 6,3
>0,32 … 0,63
>1,6 … 3,2
>0,25 … 0,32
>2,25 … 1,6
0,25
>0,20 … 0,25
>0,16 … 0,20
>1,0 … 1,25
>0,8 … 1,0
>0,125 … 0,16
>0,1 … 0,125
>0,08 … 0,1
>0,63 … 0,8
>0,5 … 0,63
>0,4 … 0,5
>0,063 … 0,08
>0,05 … 0,063
>0,04 … 0,05
>0,32 … 0,4
>0,25 … 0,32
>0,2 … 0,25
>0,032 … 0,04
>0,025 … 0,032
>0,02 … 0,025
>0,16 … 0,2
>0,125 … 0,16
>0,1 … 0,125
5 Battery replacement
The batteries need to be replaced, when indicated on the display. Open the battery lid and replace them
by four new AA-batteries (1,5 V each).

Manual
9
6 Disposal
For the disposal of batteries, the 2006/66/EC directive of the European Parliament applies. Due to the
contained pollutants, batteries must not be disposed of as household waste. They must be given to
collection points designed for that purpose.
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use them or
give them to a recycling company which disposes of the devices in line with law.
If you have any questions, please contact PCE Instruments.
7 Contact
If you have any questions about our range of products or measuring instruments please contact PCE
Instruments.
7.1 PCE Instruments UK
By post:
PCE Instruments UK Ltd.
Units 12/13 Southpoint Business Park
Ensign Way, Southampton
Hampshire
United Kingdom, SO31 4RF
By phone:
02380 987 030
7.2 PCE Americas
By post:
