Zest 4 Leisure LOGCHEST User manual

ASSEMBLY INSTRUCTIONS
Size 1800 mm x 725 mm x 875 - 800 mm ( W x D x H )
(Please note chest height with lid open is 1500mm)
Item code LOGCHEST
Please retain these instructions
Zest4leisure
08458902357 [e-mail]

Log Chest
1800mm x 725mm x 875 - 800mm (W x D x H)
Pack Contents Fixings
20no 60mm Screws
2no Pre Drilled Side Wall Panels (A) 14no 30mm Screws
1no Pre Drilled Back Wall Panel (B) 2no T - Hinges
1no Pre Drilled Front Wall Panel (C)
1no Base Panel (D) Tools Required
1no Top Panel (E) Posidrive #2 Screwdriver
Assembly requires 2 persons.
The Log Chest should be positioned on a level base to ensure that the top /
hinged panel operates correctly.
Assembly Instructions
1) Locate 8no 60mm screws into the pre drilled holes on the framing of Side
Panels (A) and 2no 60mm screws into the base framing on Back Panel (B) and
Front Panel (C), as shown in diagram 1 (S = Location of Pre drilled screw holes,
the arrow shows direction of fix). Secure Side Panels (A) to Back Panel (B)
using a posidrive #2 screwdriver. The cladding on the side panel should overlap
the ends of the cladding on the rear panel, and the base timbers of the panels
should be level.
2) Repeat the procedure for attaching Front Panel (C), ensuring the cladding on
the side panels overlap the ends of the cladding on the front panel, and the base
timbers of the panels should be level.
3) Locate the wall panel assembly onto Base Panel (D), ensuring the wall panels
are flush with the perimeter of the base panel. Secure the wall panel assembly
down to the base panel using 8no 60mm screws.
4) Prior to attaching the hinges, please ensure that Top Panel (E) is orientated
as shown in Diagram 2. Position the hinges on the two innermost framing
timbers on the underside of Top Panel (E) as shown in Diagram 1. The hinge pin
(ie the pivot point of the hinge should be positioned 38mm in from the rear outer
edge of the top panel (See diagram 3) . Attach using 4no 30mm screws per
hinge (See Diagram 1). Position Top Panel (E) onto the assembly and, ensuring
the overhangs are equal, attach the hinged top panel (E) to the outer face of the
Back Wall Panel (B) using 6no 30mm screws i.e. 3no screws per hinge (See
Diagram 3).
The Log Chest assembly is now complete.

Diagram 2
Front
E
Diagram 1
A
A
B
C
E
D
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
A
A
B
D
E
C
S = Location of Pre drilled screw holes (arrow shows direction of fix).
Diagram 3
