ZETR 13 User manual

WWW.ZETR.COM.AU / [email protected]
13 INSTALLATION MANUAL / 13-FRE / 161221
FLUSH FIRE RATED ENCLOSURE


TOOLS REQUIRED

COMPATIBLE PRODUCT INDEX
PRODUCT




SKU














 


 


 


 


 


 




 





 












WARNING
DANGER
ATTENTION
13-FRE MUST BE INSTALLED IN CONJUCTION WITH 13-FMA/AMA



WWW.ZETR.COM.AU / [email protected]
13 FLUSH FIRE RATED ENCLOSURE / 13-FRE
CONTINUE INSTALLATION FROM STEP 5 OF
THE ‘13-AMA INSTALLATION GUIDE’
Insert the fire rated enclosure into the hole cut-
out. Lightly tap the staples into the wall so the
enclosure sits flush

dovetail washers contained in the mounting
assembly allowing the inner shroud to freely
move back and forth within the mesh frame.
INSTALLATION GUIDE
1
4
5

thread through the fire rated enclosure.
ATTENTION We recommend that the hole
cut-out in your substrate is laser, waterjet or

results. N.B. Consult your substrate fabricator
for best results.
PRE-FABRICATION
POST-FABRICATION
2
Insert the mounting assembly into the fire
rated enclosure and fasten to the fire resistant
plasterboard.
6
Using a mechanical fastener secure the fire
rated shroud and mounting assembly to the
back side of your substrate.
N.B. Consult your substrate fabricator or
contractor for best fastening method.
4
CONTINUE INSTALLATION FROM STEP 5 OF
THE ‘13-FMA INSTALLATION GUIDE’
Align the centre of the template provided to the
centre of where you’d like to install your outlet/
switchgrid. Once aligned, mark both left and
right hole centres.
1

centre point.

N.B. Ensure these are tangential with the top
and bottom of these holes

mounting assembly and thread through the
hole cut-out.
3

bending them back and forth with pilers.
3
PLASTERBOARD
12.5mm
2


