ZETRON 15P User manual

ZETRON
Model 15P Field Programmable
Multi-Format Encoder
Operating Manual
Part No. 025-9235E.1
Copyright © by Zetron, Inc.
All Rights Reserved

Table of Contents
1. INTRODUCTION
GENERAL DESCRIPTION....................................................................................... 1-1
MODEL 15P FIELD PROGRAMMABLE VS. THE MODEL 15B ......................... 1-2
USING THIS MANUAL............................................................................................ 1-3
2. SPECIFICATIONS
SIGNALING FORMATS........................................................................................... 2-1
Two-Tone........................................................................................................ 2-1
Reach............................................................................................................... 2-1
Five/Six-Tone ................................................................................................. 2-2
DTMF ............................................................................................................. 2-2
2805/1500 Hz.................................................................................................. 2-2
HSC (Hexadecimal Sequential Code)............................................................. 2-2
Custom Two-Tone .......................................................................................... 2-3
Custom DTMF ................................................................................................ 2-3
POCSAG (Digital Numeric Display Format)................................................. 2-3
NEC (Digital Tone Only And Numeric Display Formats) ............................. 2-4
Motorola GOLAY (Digital Numeric Display Format)................................... 2-4
Motorola METRO (Digital Tone-Only Format)............................................. 2-4
Custom Stack (Fixed Stack Pages) ................................................................. 2-4
SPECIAL FEATURES ............................................................................................... 2-5
ELECTRICAL SPECIFICATIONS ........................................................................... 2-6
PHYSICAL ................................................................................................................. 2-6
3. OPERATION
POWER-ON ............................................................................................................... 3-1
KEYPAD .................................................................................................................... 3-1
CONFIGURATION.................................................................................................... 3-1
FRONT PANEL DISPLAY........................................................................................ 3-2
PLACING A PAGE.................................................................................................... 3-2
Format Selection ............................................................................................. 3-2
Pager Number .................................................................................................3-3
Message .......................................................................................................... 3-3
Autopage ......................................................................................................... 3-3
Autoscroll........................................................................................................ 3-4
Strapped Digits ...............................................................................................3-4
Keypad Stack Entry ........................................................................................3-4
Custom Stacks (Fixed Stack Pages)................................................................ 3-5
Talk ................................................................................................................. 3-6
Paging Sequence ............................................................................................. 3-6
Repage............................................................................................................. 3-7
Busy Channel.................................................................................................. 3-7
Continuous Transmit Mode ............................................................................3-8
OPTIONAL SERIAL PORT ...................................................................................... 3-8

Table of Contents
(Continued)
Power-Up Test ................................................................................................ 3-8
Operation ........................................................................................................ 3-9
Special Keys ................................................................................................... 3-9
CRT Paging Examples....................................................................................3-10
4. INSTALLATION
OPENING THE ENCODER ...................................................................................... 4-1
WIRE ROUTING ....................................................................................................... 4-1
GROUNDING ............................................................................................................ 4-1
POWER SUPPLY....................................................................................................... 4-1
AUDIO OUTPUT....................................................................................................... 4-1
DIGITAL OUTPUT.................................................................................................... 4-2
MICROPHONE CONNECTION ............................................................................... 4-2
PUSH-TO-TALK........................................................................................................ 4-2
DIGITAL MODE........................................................................................................ 4-3
EXTENDING THE TALK TIME ..............................................................................4-3
ALPHA PAGING ....................................................................................................... 4-3
SERIAL CRT INTERFACE....................................................................................... 4-4
INTERFACE CONNECTOR ..................................................................................... 4-4
Jumpers ........................................................................................................... 4-7
ADJUSTMENTS ........................................................................................................ 4-7
Audio Test Mode ............................................................................................4-7
Binary Test Mode ........................................................................................... 4-8
DTMF Output Test ......................................................................................... 4-8
EXCEPTIONS ............................................................................................................ 4-8
CABLE OPTIONS...................................................................................................... 4-8
5. PROGRAMMING
OVERVIEW ............................................................................................................... 5-1
PROGRAMMING SYSTEM PARAMETERS.......................................................... 5-3
System Programming Example....................................................................... 5-4
Station ID Characters...................................................................................... 5-5
Example .............................................................................................. 5-6
PROGRAMMING PAGING FORMATS .................................................................. 5-7
About the Custom Calls Formats.................................................................... 5-7
Two-Tone........................................................................................................ 5-8
Programming Example ....................................................................... 5-8
Five-Tone........................................................................................................ 5-10
DTMF Format................................................................................................. 5-11
HSC Format .................................................................................................... 5-12
Reach Format.................................................................................................. 5-13
2805 Format.................................................................................................... 5-14
Alert Tones ..................................................................................................... 5-15
Custom Two-Tone Format.............................................................................. 5-16

Table of Contents
(Continued)
Brief Summary.................................................................................... 5-17
Programming Example ....................................................................... 5-17
POCSAG Format ............................................................................................ 5-21
NEC Format.................................................................................................... 5-22
GOLAY (GSC) Format................................................................................... 5-23
Metro-PageBoy Format .................................................................................. 5-23
Custom DTMF Format ................................................................................... 5-24
Brief Summary.................................................................................... 5-24
Programming Example ....................................................................... 5-25
Custom Stack-Page Format (Fixed Stack)...................................................... 5-28
Programming Example ...................................................................... 5-30
Important Things to Remember When Programming Stacks ............. 5-33
6. REPAIR
IN CASE OF DIFFICULTY....................................................................................... 6-1
SELF-TEST ................................................................................................................ 6-1
OUTPUT TESTS ........................................................................................................ 6-2
Audio Test Mode ............................................................................................ 6-2
Binary Test Mode ........................................................................................... 6-2
DTMF Output Test ......................................................................................... 6-3
FAULT IDENTIFICATION....................................................................................... 6-3
MODEL 15P TOP LEVEL PARTS LIST .................................................................. 6-4
MODEL 15P MULTI-FORMAT ENCODER (702-9855B)...................................... 6-5
Parts List ......................................................................................................... 6-5
Schematic........................................................................................................ 6-7
Silkscreen........................................................................................................ 6-9
MODEL 15P SERIAL PORT PARTS LIST .............................................................. 6-10
MODEL 15P SPARE PARTS LIST........................................................................... 6-10
MODEL 15P SERIAL PORT CONNECTIONS........................................................ 6-11
7. QUICK REFERENCE
UNDERSTANDING THE TWO-TONE CODING SYSTEM .................................. 7-1
The Reeds........................................................................................................ 7-1
Tone Groups.................................................................................................... 7-1
Motorola and GE Tone Group Frequencies.................................................... 7-1
Two-Tone Timing........................................................................................... 7-2
Code Plans ...................................................................................................... 7-2
Pager Capcode ................................................................................................ 7-3
Example .......................................................................................................... 7-3
Summary ......................................................................................................... 7-3
Motorola and GE Code Plans ......................................................................... 7-4
5/6-TONE FREQUENCIES AND TIMINGS ............................................................ 7-5
5/6-Tone Format ............................................................................................. 7-5
DTMF TONE PAIR FREQUENCIES........................................................................ 7-6

Table of Contents
(Continued)
HSC TONE FREQUENCIES AND TIMINGS.......................................................... 7-7
HSC Format .................................................................................................... 7-7
REACH ENCODING PLAN...................................................................................... 7-12
Zetron Tone Groups for REACH Encoding ................................................... 7-12
REACH Code Plan .........................................................................................7-13
REACH Tone Timing ..................................................................................... 7-13
POCSAG DIGITAL FORMAT.................................................................................. 7-14
NEC DIGITAL FORMAT (D2/D3) ........................................................................... 7-15
MOTOROLA GOLAY DIGITAL FORMAT ............................................................ 7-16
MOTOROLA METRO DIGITAL FORMAT ............................................................ 7-17
PROGRAMMING FUNCTIONS LOG...................................................................... 7-18
CUSTOM CALLS MEMORY REQUIREMENT WORKSHEET ............................ 7-22
CUSTOM STACK MEMORY REQUIREMENT WORKSHEET............................ 7-23
MODEL 15P CONFIGURATION SHEET................................................................ 7-24
CUSTOMER FEEDBACK FORMS
CHANGE INFORMATION

WARRANTY STATEMENT
Zetron's warranty is published in the current Zetron United States Price Book.
LIMITATION OF LIABILITY
Zetron makes no representation with respect to the contents of this document and/or the
contents, performance, and function of any accompanying software and specifically
disclaims any warranties, expressed or implied, as to merchantability, fitness for purpose
sold, description, or quality.
Further, Zetron reserves the right to revise this document or the accompanying software and
to make changes in it from time to time without obligation to notify any person or
organization of such revisions or changes.
This document and any accompanying software are provided “as is.” Zetron shall not under
any circumstances be responsible for any indirect, special, incidental, or consequential
damages or losses to the buyer or any third party arising out of or connected with the buyer’s
purchase and use of Zetron’s products or services.
COPYRIGHT
This publication is protected by copyright by Zetron, Inc. and all rights are reserved
worldwide. This publication may not, in whole or in part, be copied, photocopied,
reproduced, translated, or reduced to any electronic medium or machine-readable form
without prior written consent from Zetron, Inc.
The software in this product is copyrighted by Zetron, Inc. and remains the property of
Zetron, Inc. Reproduction, duplication, or disclosure is not permitted without prior written
consent of Zetron, Inc.
TRADEMARKS
Zetron is a registered trademark of Zetron, Inc.
All other product names in this document are trademarks or registered trademarks of their
respective owners.

FEDERAL COMMUNICATIONS COMMISSION (FCC) REGULATIONS
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his or her own expense.
Changes or modifications not expressly approved by the manager of Zetron’s compliance
department can void the FCC authorization to operate this equipment.
Repair work on this device must be done by Zetron, Inc. or a Zetron authorized repair
station.

1. INTRODUCTION
GENERAL DESCRIPTION................................................................................1-1
MODEL 15P FIELD PROGRAMMABLE VS. THE MODEL 15B ..................1-2
USING THIS MANUAL.....................................................................................1-3

Section 1. Introduction
1-2
MODEL 15P FIELD PROGRAMMABLE VS. THE MODEL 15B
The Model 15P is an ideal encoder in most circumstances. The added flexibility of
programmability provides a superior solution to growing or changing paging needs, without
downtime. It can provide an advantage to dealers where an inventory of configurable or
programmable paging encoders enables the quickest possible response to customer requests.
However, the Model 15P is not completely identical to the Model 15B encoder that preceded it.
The following list is provided for those who have experience with the Model 15B in order to
help them decide if the 15P can be used to replace the 15B in their application.
1. As required by a particular installation, Model 15Bs can be preconfigured to provide
automatic Morse code station ID. With this feature, the radio site will send the Morse
Code station identification signal at 15 or 30 minute intervals. The Model 15P can be
programmed in the field to do a Morse Code Station ID, however, the time interval is
fixed at 15 minutes only.
2. Plectron or custom calls are 2-tone pages that use nonstandard tones or reeds and
sometimes nonstandard tone timings. Tone frequencies, timing, and individual
capcodes for the Model 15B must be specified when ordering. These parameters may
be changed only by factory reprogram, not by the user. The Model 15P supports this
kind of paging with a format called CUSTOM TWO TONE, which can hold up to
111 custom pages. The capcode numbers assigned to these pages can be one to four
digits long and are totally independent (i.e.: the programmer in the field is not locked
into any predetermined numbering scheme set by Zetron).
3. Fixed-stack pages available on the Model 15B are a factory programmed group of
capcodes that are sent out as a string of pages with the pressing of a single button.
The Model 15P can also support fixed stack pages, however, there are some
important differences between it and the 15B. The Model 15P supports fixed stack
paging by having a paging format called Custom Stack. This format is assigned a
leading digit in the same way other paging formats are. The individual stacks are
assigned an identifying number when they are entered, and then the capcodes for that
stack are entered. The stack numbers can be from one to four digits in length, so in
order to send a fixed stack page in the Model 15P you enter a leading digit for the
Custom Stack format plus the stack number.
The Model 15P can also support calling a fixed stack page using a single key press.
The Custom Stack format must be assigned to multiple leading digits, and one stack
can be created under each of these leading digits that does not have a number
assigned to it.

Section 1. Introduction
1-3
Each stack page in the Model 15P can hold approximately ten pager cap codes. If a
larger number of pages is needed in a stack, the encoder will allow you to string
stacks together by placing the number of another fixed stack in the last capcode
position of the first stack. The number of entries that can be programmed for a stack
depends upon the memory used by each entry, however, ten entries per stack is
approximately correct.
4. The Model 15P has a new format, not found in the 15B, called Custom DTMF. This
format supports DTMF code strings up to 10 digits in length. The pager capcodes and
timing are independently assignable for each page.
USING THIS MANUAL
This manual is divided into seven sections, both to group similar topics together and to make it
easy to find information quickly once you start using the encoder. The sections are:
1. Introduction A brief description of the Model 15P and its capabilities.
2. Specifications An organized listing of the capabilities and specifications of the
encoder.
3. Operation This section describes the use of the encoder once it has been
installed and programmed. It covers how variations in
programming can effect the operation of the unit.
4. Installation This section covers the interfacing of the encoder to its radio
equipment and how to make proper level adjustments to ensure
optimum performance while paging.
5. Programming This section provides in-depth explanations and examples of how
to configure both the system and individual paging format
parameters.
6. Repair This section contains a list of the Error codes and their meaning. It
also contains the parts list and schematics for the unit.
7. Quick Reference This section contains specific background information on the
various paging formats supported by the Model 15P. It includes
tables of tone frequencies and timings for the analog formats, as
well as capcode and message format information for the digital
display formats. This section is to be used as resource when
programming the unit.

2. SPECIFICATIONS
SIGNALING FORMATS....................................................................................2-1
Two-Tone.................................................................................................2-1
Reach........................................................................................................2-1
Five/Six-Tone ..........................................................................................2-2
DTMF ......................................................................................................2-2
2805/1500 Hz...........................................................................................2-2
HSC (Hexadecimal Sequential Code)......................................................2-2
Custom Two-Tone ...................................................................................2-3
Custom DTMF .........................................................................................2-3
POCSAG (Digital Numeric Display Format)..........................................2-3
NEC (Digital Tone Only And Numeric Display Formats) ......................2-4
Motorola GOLAY (Digital Numeric Display Format)............................2-4
Motorola METRO (Digital Tone-Only Format)......................................2-4
Custom Stack (Fixed Stack Pages) ..........................................................2-4
SPECIAL FEATURES ........................................................................................2-5
ELECTRICAL SPECIFICATIONS ....................................................................2-6
PHYSICAL ..........................................................................................................2-6

2-1
2. SPECIFICATIONS
SIGNALING FORMATS
Two-Tone
Standard Motorola and GE Tone Groups and Code Plan
Call Capacity: 100 call (first/second tones from one standard tone group each)
1000 call (one standard code plan)
Configurations: User Programmable
Tone Groups
(100-call): Motorola 1,2,3,4,5,6,10,11,A,B,Z; GE A,B,C; or special
Code Plan
(1000-call): Motorola B,C,D,E,F,G,H,J,K,L,M,N,P,Q,R,S,T,U,V,W,Y,MT;
General, Modified General, General Alternate;
GE X,Y,Z; or special
Tone Timing: Field Programmable
1st /Gap/ 2nd / Group Call
1.0 / 0 / 3.0 / 8.0 (GE std, Mot std Tone+Voice)
1.0 / 0 / 3.0 / 6.0 (NEC-B)
1.0 /0.3/ 3.0 / 6.0 (NEC-A)
1.0 / 0 / 1.0 / 4.0 (NEC-C)
0.5 / 0 / 0.5 / 3.0 (NEC-L)
0.4 / 0 / 0.8 / 8.0 (Motorola Tone Only)
0.4 / 0 / 0.8 / 4.0 (NEC-M)
0.4 / 0 / 0.4 / 3.0 (NEC-D)
Diagonal Tone: None (group call) or standard tone group diagonals
Diagonal Tone Placement: First Tone or Second Tone
Reach
Call Capacity: 100/1000 call and group call
Configurations: Field Programmable
Tone Timing: 1st /Gap/ 2nd / Group Call
0.2 / 0 / 0.2 / 1.4 (Reach Fast)
2.0 / 0 / 0.7 / 4.5 (Reach Slow)
Group Call: 10 group calls or individual calls

Section 2. Specifications
2-2
Five/Six-Tone
Call Capacity: Full format capacity of 100,000 calls
Configurations: Field Programmable
Preamble: Optional
Addressing: Single, Dual (using even numbered pages for 1st address, odd
for 2nd address), or selectable by function digit
Tones/Timing: EIA, CCIR, ZVEI, or EEA
DTMF
Call Capacity: 1, 2, 3, 4, 5, 6, 7, or 8 digits
Configurations: Field Programmable
Tones: All 16 tone pairs available from keypad
Timing: Programmable tone duration and gap duration
2805/1500 Hz
Call Capacity: 3, 4, 5, 6, 7, or 8 digits
Configurations: Field Programmable
Tone Freq.: 1500 or 2805 Hz
Timing: 10 pps
HSC (Hexadecimal Sequential Code)
Call Capacity: Full format capacity of 100,000 calls in 10 service blocks. Full
group calling capacity.
Configurations: Field Programmable
Functions: 9 pager control functions
10 message/data functions
All call pager muting
All call service range enable/disable
All call battery saving, 0-60 second automatic repeat cycle
Messages: Up to 23 numeric characters of formatted data with talk request

Section 2. Specifications
2-3
Custom Two-Tone
Call Capacity: Up to 111 independently programmable capcodes, actual
capacity depends on memory used by other custom formats.
Configurations: Field programmable for each capcode
Tones: Any tone between 250.0 Hz and 3500.0 Hz
Timing: Programmable A and B tone duration and gap duration, range
is from 0.000 to 9.999 seconds. Single tone pages made by
setting the Gap and B tone to zero duration.
Capcodes: Independently assignable, up to four digits in length.
Alert tones: Any one of the four available Alert tones can be assigned to
follow each capcode.
Custom DTMF
Call Capacity: Up to 141 independently programmable capcodes, actual
capacity depends on memory used by other custom formats.
Configurations: Field programmable for each capcode
Capcode: Independently assignable, up to four digits in length.
Page Length: Up to 10 DTMF digits for each capcode.
Tones: All 16 DTMF tone pairs available from keypad
Timing: Programmable tone duration and gap duration
POCSAG (Digital Numeric Display Format)
Call Capacity: Full format capacity of 2,097,152 calls
Configurations: Field Programmable
Functions: 4 beep/tone alerts strappable
Messages: Up to 20 numeric characters
Up to 255 alphanumeric characters (when RS232 port option is
used for message entry)
Data Rates: 512, 1200, and 2400 baud
Talk Enable: 0-60 seconds talk time

Section 2. Specifications
2-4
NEC (Digital Tone Only And Numeric Display Formats)
Call Capacity: Full format capacity of 100,000 calls (Tone only) and
1,000,000 calls (Numeric display)
Configurations: Field Programmable
Tone Only: When using 5 digits of address
Display: When using 6 digits of address. Messages of up to 20 numeric
characters.
Motorola GOLAY (Digital Numeric Display Format)
Call Capacity: Full format capacity of 1,000,000 calls with battery preamble
digit
Configurations: Field Programmable
Functions: 10 beep Alert/voice/data combinations
Messages: Up to 12 numeric characters
Up to 128 alphanumeric characters
Motorola METRO (Digital Tone-Only Format)
Call Capacity: Full format capacity of 1,000,000 calls
Custom Stack (Fixed Stack Pages)
Call Capacity: Up to 41 fixed stacks available, each with user assigned
capcode. Each stack can hold approximately 10 pager
capcodes, actual capacity depends on memory used by other
custom formats. See “Custom Stacks (Fixed Stack Pages)” in
Section 3.
