Zetronix zClock-1000 User manual

HD DVR Alarm Clock
zClock-1000
User Manual

Table of Contents
Preface and Quality Assurance
Operation Instructions
I. Basic Instructions
II. Basic Operation
III. Diagram
IV.Product Introduction
V. Detailed Operation
VI. File storage & Playback
Technical specifications
Troubleshooting
Included Accessories
Warranty from Zetronix Corp.
Preface
This manual will guide you how to use the product. It also provides the necessary
related to the product, such as the information for operating and handling. You are
recommended to read the Instructions carefully and understand all contents herein
operating. Please save the Manual Instructions for your future reference.
Product Assurance
This product is with FCC and CE certificate and had inspected by the authorized
where was found to comply with the recommended indexes. User is under our safety

assurance when operating this product.

Operation Instructions
I. Basic functions
1. 5 buttons: HR, MIN, SET, LIGHT, TALK/SNZ;
2. The time & minute is displayed in the 3.5 bit LCD panel. Time-showing system of 12
hours and 24 hours is available;
3. Multiple rings of choice: Beep, cock, etc. 5 melodies options.
4. The time alarm will be triggered every 10 minutes if the clock is on the snooze function.
It can alarm a maximum of 6 times.
5. The choice of two “On-the-hour “ alarm functions;
6. The ring of “Beep” will be become louder generally, and will last 1 minute;
7. If adopting the melody as the ring, the clock will alarm when the melody ends.
II. Basic Operation
When turning the power on, the whole LCD will display; after the ring of a melody ends, the
clock will display time;
1. Press “Set” button under the Time mode using the following sequence (the display will
flash simultaneously):Time setting  Alarm setting  On-the-hour alarm setting
2. Press “HR” button under the Time Setting mode to set hour, and “MIN” button to set
minute;
3. Press “HR” button under the Alarm Setting mode (Symbol: ) to set hour, and “MIN”
set minute. Press “SNZ” button when alarming, the clock will re-alarm every 10 minutes,
send alarm by 6 times at most;
4. Under the On-the-hour Alarm Setting mode (the symbol of alarm and the on-the-hour
flash): It will open and close the function (Symbol: ) by pressing the “HR” button, Set
alarm by using the time from 7:00am to 9:00pm (Symbol: ); You can activate or
alarm ring by pressing “MIN” button (Symbol: ).
5. Under the Time Mode and if the “HR” button is pressed, it will shift the hour system
(12/24 hour system); by pressing “MIN” button, it will select the alarm ring.
6. Under any modes, it will turn the background light off by pressing the “LIGHT” button.
7. Under any mode, it will report the time by pressing the “TALK” button.

III. Diagram
Ti
1. Alarm Clock
Time-telling
button
Rotational
cover
MicroSD Memory card
Camera Lens
Off Position
On Position
Electronic Clock Function
Buttons
IR Receiver
2. Remote
control
IR
Transmitter
Power button
Motion Activated Video
Sound recording
Take a photo
USB Port
Video Record

IV. Product Introduction
This product is a high-resolution 30 frames-per-second (640X480, 1280*960) remote
video surveillance clock, with an external TF Card. As a multifunctional high-tech
product, the device is available with multiple functions, such as: video, sound recording,
video recording, photo taking, cyber chat, electronic alarm clock and file storage; with
the high-capacity battery, it can last for about 12 hours continuous video recording, or
25 hours of audio recording; also the device saves the high-resolution video with 2
million pixels, sound and file automatically, The device is designed with the multiple
languages support for telling the time. The MicroSD interface supports up to 32GB of
storage. Also included is an easy to use and compact remote control. With the best
imperceptibility, this product will be as your ideal assistant to prevent theft or to gather
evidence.

V. Detailed Operation
1. Turning on the unit: Open the rotational cover at the right side, insert the TF card
and turn “ON” to get ready.
2. Remote Control: Use the remote controller to aim to the receiver of the clock and
press to start. When the blue lamp is on, the clock is in the stand by mode.
3. Record Video: Press to start recording video. After the blue lamp flashes 3
times and then turns off, the DVR Clock is recording. Stop by pressing, the unit will save
the video file and return to the “standby mode” , and the blue lamp will come on (the default
time length for video recorded is 20 minutes).
4. Record Audio: Press button to start audio recording; after the blue lamp flashes
3 times and turns off, the zClock-100 is recording. Press again, the clock will save the
sound file and return to the “standby mode” , the blue will light on (the default time length
for sound recorded is 20 minutes);
5. Taking Photographs: Press button to start in photo mode. The unit will take a
photo by pressing the again. When pressing this button, the blue lamp will flash; after
taking the photo, it will return to the stand by.
6. Motion Activated Video Mode: Press button to start in motion activated video
mode, then the blue lamp will flash quickly. If a moving object is detected, the blue lamp will
flash slowly two times and the device will be start recording video. If there is no moving
object to be detected, the blue lamp will return to “Quick-flash: and stay in motion detection
mode (the default length for the video file is 3 minutes);
7. Turning off the unit: Press button to will turn the device off and the blue lamp
will turn off.
8. External Drive: When the switch is “ON”, insert the USB cable and then press
button on the remote control, the device will access to the removable-disc mode.
9. PC camera function: Please install the driver software which is included in the
Compact Disc before operating; Turn on the device by pressing on the remote
controller when the device is “ON”, insert USB cable to connect the computer; this time, it
will change into PC CAM mode
10. Charging: Place the chief switch to “OFF” position, insert USB adapter, and the red
lamp will turn on; when it is fully charged, the red lamp will be off. You can also charge it by
connecting the device to a computer ( Please use only the adapter provided with the

device; if the device is getting hot or while charging, please disconnect the adapter's power
source);
11. Reset: If the product stops working or responding under illegal operation or other
unclear reasons, please turn the switch of the device to “OFF” position, and then to “ON”
position. It will reset the product accordingly;
12. When the battery is low, the blue lamp will keep flashing, or the screen display will be
unclear. If so please charge it immediately. When charge starts running out, media files will
be saved automatically;
13. Recorder date: Run the writertime file (included in CD) when the camera is connected to
computer. The program will use the time from your computer.
14. File update: please install “Network Installer” from the installation disc; use the remote
control to open the clock, then insert the USB cable for 10 seconds; afterwards, the
computer will open the interface automatically; click “Program Upgrade”, it will open a
dialogue box; click “Update”.
When ①DRAM Timing, select 0X35
When ②DRAM Size, select “8M”; press “OK” to upgrade; several minutes later, press
“Confirm” button.
15. When the program is lost, please install the software which is saved in the Compact Disc,
and then click “STK02NU Program Upgrading Tool”, then click “Update”;
Under  DRAM Timing, select 0X35
Under  DRAM Size, select “8M”; press “OK” to upgrade; several minutes later, press “Confirm”
button.

VII. File storage and Playback
When finishing video-recording and other operations, please place the switch to “ON”
position, connect the clock to your computer by USB cable, and press on the
remote controller; copy the file or cut and paste it to the your computer to play; or you
can remove the TF card and use the card reader to read the data inside. The Media player
/ KM player is recommended.
Precautions
Application conditions: Please abide by the related national laws and regulations strictly; it is prohibited to use
the product for illegal purpose, otherwise you must be responsible for the consequences.
Software upgrade: In order to keep the device available and for better performance, the manufacturer shall
improve the product software continuously. The device is designed to update by user itself, please claim the
latest software and upgrading method towards your local dealer.
Working temperature: Please use the device only at the room temperature; never use the device at the
temperature that human body feels unconformable.
Working humidity: Please use the device only in the environmental humidity suitable for living; keep the device
far away from the humid or wet environment. This device is not water-proof.
Video luminance: Please use the device when the sufficient luminance is available; do not aim the camera
USB data cable
Computer’
s USB port

lens to the sun or other intensive light source; otherwise it may damage the optical apparatus;
Cleanliness requirement: Please do not use the device in a dusty environment; otherwise it may cause the lens
or other parts to attach with dirt and effect video quality. A lens wiping paper or glass cloth can be used to
clean.
Other precautions:
This device is a sensitive electronic product; please avoid intensive impact, shock, intense magnetic fields or
high electro-static environments.
Technical Specifications
Pixel
2.0 Mega pixel
Resolution
640*480、1280*960
Video format
AVI
Frame number
30fps
Vision angle
72°
Induction photographing
6 meters for Straight-line distance
Minimal illumination
1LUX
Battery capacity
2200MA
Continuous recording time
Over 12 hours
Remote operating distance
19.7 feet
Scope for sound recording
131 feet2
Power consumption
130MA / 3.7V
Storage temperature
-4~176 F
working temperature
14 ~ 140 F
working humidity
15~85% RH
Type of memory card
Mini SD card
Capacity of memory card
32GB maximally
Player software
Media player / KM player
USB Interface
USB1.1/2.0
Operating system
WIN 2000/ XP / Visat32 / 7
Time consumed of storage
1GB/40 minutes
Charging time
About 4 hours
This product can only be allowed to comply the authorized power sources with the following marks, i.e.:
UL mark / American Power Certification
CE mark / UN Power Certification
CCC mark / Chinese Power Certification
BS mark / British Power Certification
C-TICK mark / Australian Power Certification

GS mark / German Power Certification
PSE mark / Japanese Power Certification
Note:
The A/C adapter may experience an increase in temperature on the surface during operation. This is an expected
phenomenon. When not in use, please remove the adapter from the power socket as a safety precaution.

Troubleshooting
Trouble
Troubleshooting
Can not turn on
Remove the insulator
lock of Power, please charge accordingly;
Battery is not contacting well, re-start
Can not charge the electricity
Replace the battery or adapter
Blue light flashes rapidly
re-start camera, low-power charging reminder, delete
redundant files from the card, put in TF Card or
replacing TF Card.
Remote controller is hard to use
Align with the receiverʼs head, remove the insulator
of remote controller, replace battery or wait for
reading the card
Cannot connect with computer
Replace the data cable or computer
Clockʼs screen flashes or character is displayed
incompletely
Charging
Sound is recorded with noise or video is not clear
Charging, replace TF card
Other problems
Please contact local seller
Included Accessories
Compact Disc A/C Wall Charger
USB Data Cable Instruction Manual

Limited Warranty from Zetronix Corp.,
Zetronix Corporation (“Zetronix”) warrants this product against defects in material or
workmanship as follows:PRODUCT: Zetronix will repair this product with new or refurbished parts, free of charge, for
a period of one (1) year from the date of original purchase in the event of a defect in
materials or workmanship. REPAIRS: Zetronix will repair or replace defective parts used in
the repair or replacement of this product with new or refurbished parts, free of charge, for
a period equal to the remainder of the original limited warranty period on the original
product, or for 60 days after the date of the repair or replacement, whichever is longer. This
warranty is extended only to the original purchaser. Proof of purchase in the form of a bill of
sale or receipted invoice, which is evidence that the unit is within the warranty period, must
be presented to obtain warranty service. To obtain warranty service, you must take this
product, or deliver the product freight prepaid, in either its original packaging or packaging
affording an equal degree of protection, to Zetronix Corporation. See below for additional
information. This warranty only covers failures due to defects in materials and
workmanship, which occur during normal use. The warranty does not cover damages which
occurred in shipment, cosmetic damage, damage that is attributable to acts of God, failures
which are caused by products not supplied by the warrantor, or failures which result from
accident, misuse, abuse, neglect, mishandling, faulty installation, misapplication, improper
installation, operation or maintenance, alteration, modification, introduction of sand,
humidity or liquids, line power surge, improper voltage supply, lightning damage, or
subjecting the product to operating/environmental conditions in excess of the maximum
values or below the minimum values set forth in the applicable specifications, or products
serviced by anyone other than Zetronix. This warranty is invalid if the factory-applied serial
number has been altered or removed from the product. This warranty does not cover
products sold AS IS or WITH ALL FAULTS. This warranty excludes consumable parts such as
batteries and power supplies.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED ABOVE. REPAIR OR REPLACEMENT
AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER.
MYVU SHALL NOT BE LIABLE FOR LOST PROFITS, LOST SALES, LOSS OF USE OF THE
PRODUCT, OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS
AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE AND TITLE, ARE LIMITED TO THE APPLICABLE WARRANTY
PERIOD SET FORTH ABOVE.
Imitation of liability
SELLER SHALL HAVE NO LIABILITY FOR ANY CLAIM, LOSS, DAMAGE OR EXPENSE OF ANY
KIND, INCLUDING FOR LOST PROFITS, SPECIAL, INDIRECT, CONSEQUENTIAL, EXEMPLARY OR
INCIDENTAL DAMAGES, WITH RESPECT TO THE SELECTION, QUALITY, CONDITION,
MERCHANTABILITY, SUITABILITY, FITNESS, OPERATION, PERFORMANCE, OR THE USE,
MAINTENANCE OR REPAIR OF THE PRODUCTS EVEN IF SELLER OR BUYER HAS BEEN ADVISED
OF THE POSSIBILITY THEREOF. THE PRICE STATED HEREIN WAS ARRIVED AT IN
CONSIDERATION FOR LIMITING SELLERS WARRANTIES AND LIABILITY AS PROVIDED HEREIN.Some states do not allow the exclusion or limitation of incidental or consequential damages,
or allow limitations on how long an implied warranty lasts, so the above exclusions or
limitations may not apply to you. This warranty gives you specific legal rights and you may
also have other rights, which vary from state to state.
If a problem with this product develops during or after the warranty period, please contact:
Zetronix Corporation,
