Zeversolar ComBox User manual

Contents
~ 1~
Contents
1. About this Manual .....................................................................................3
1.1 Scope of Application...................................................................................................................3
1.2 Target Reader.................................................................................................................................3
1.3 Abbreviations ..................................................................................................................................3
2.Introduction................................................................................................4
2.1 Product Overview.........................................................................................................................4
2.2 Function and Feature .................................................................................................................4
2.3 Scope of Application...................................................................................................................4
2.4 Scope of Delivery .........................................................................................................................5
2.5 Environment and Attention.....................................................................................................5
2.6 Safety Symbols.............................................................................................................................5
3.Mounting.....................................................................................................6
3.1 Preparation.......................................................................................................................................6
3.2 Assemble the ComBox..............................................................................................................6
4.Connect to Internet.................................................................................... 7
4.1 Connecting via Ethernet............................................................................................................7
4.2 * Connecting via WiFi ................................................................................................................. 8
5.Web Server .............................................................................................. 10
5.1 Visiting the Web Server ..........................................................................................................10
5.2 Home .................................................................................................................................................. 11
5.3 Ethernet ............................................................................................................................................11
5.4 Advanced.........................................................................................................................................12
5.5 *Wireless....................................................................................................................................... 20
6.Solarcloud ................................................................................................22
6.1 Account Registration ...............................................................................................................22
6.2 Create a PV plant.......................................................................................................................24
6.3 Browse PV plant ........................................................................................................................26
6.4 Add a ComBox.............................................................................................................................26
6.5 PV Plant Sharing ........................................................................................................................27
6.6 Configuration Report................................................................................................................27
6.7 Mobile device Monitoring.......................................................................................................28

Contents
~2~
7. Trouble Shooting..................................................................................... 30
7.1 LED Indication of Network Interface ..............................................................................30
7.2 FAQ..................................................................................................................................................... 31
8.Technical Parameters............................................................................. 32
9.Disposal ................................................................................................... 33
10. ContactUs .............................................................................................. 34

About this Manual
~ 3~
1. About this Manual
This manual contains a detailed description of the ComBox, including precautions,
methods of installation and operating instructions.
The specifications described in this document apply to the current version of the
product. We reserve the right to make changes or update our product to
introduce new functions and overall improvements. This specification is subject
to change without prior notice. Please contact Zeversolar to confirm the latest
revision.
1.1 Scope of Application
This manual applies to the ComBox firmware version 15430-408R+15429-407R
and later versions.
1.2 Target Reader
This manual is intended for authorized skilled installers, who have knowledge of
electrical safety. Safety warnings can be found in section 2.6. Please read this
manual carefully before installing.
1.3 Abbreviations
Table 1-1: Abbreviations
Abbreviation
Designation
E-Today
Daily Energy
E-Total
Total Energy
LAN
Local Area Network
WAN
Wide Area Network
WLAN
Wireless Local Area Network
DHCP
Dynamic Host Configuration Protocol
DNS
Domain Name Server
PV
Photovoltaic
Pac
Alternating Current Output Power

Introduction
~4~
2. Introduction
The monitoring system plays an important role in the PV plant. Users can view
the PV Plants power generation data and fault information to avoid unnecessary
loss of power and non-scheduled downtime. Users can also maximize the
energy generating efficiency according to power generating data and report.
ComBox has two versions: ComBox and ComBox WiFi.
2.1 Product Overview
The ComBox is an integrated monitoring device, which can be installed inside the
inverter, and collects the inverter’s data and events in the PV plant. When an
Internet connection is present, the ComBox will upload the collected data to the
Solarcloud to facilitate on-line web monitoring and data analysis. The system
structure shows in Fig. 2-1.
Fig.2-1: System structure
2.2 Function and Feature
PV Plant monitoring via the Solarcloud
Remote monitoring via Ethernet or WiFi
Power Management Capability
Support Micro SD card save data
Integrated memory
Online firmware updating
2.3 Scope of Application
ComBox can be installed in the following inverters:
Zeverlution 1000S-3000S
Zeverlution 3000SE-3680SE

Introduction
~ 5~
The sections marked with a * apply to the WiFi version.
2.4 Scope of Delivery
The details information about Scope of Delivery please refer to the ComBox
Quick Installation Guide.
2.5 Environment and Attention
The ComBox operational ambient temperature is -25 °C to 75 °C.
2.6 Safety Symbols
Please pay attention to the following safety symbols in the manual:
Information
Provides information about installation or use.
Notice
Indicates the instructions must be followed in the correct order
to prevent problems.
Warning
Indicates the instructions must be followed in order to prevent
serious problems or injuries.

Mounting
~6~
3. Mounting
3.1 Preparation
Table 3-1: Preparation
Type
Requirements
Quantity
Network
cable
1. Comply with the standards for structured cabling
according to EIA/TIA-568.
2. Shielded Ethernet cable (CAT-5E or higher).
3. UV resistant if used outdoors.
Max. 100m
3.2 Assembling the ComBox
3.2.1Electrical Checks
Risk of lethal electric shock when opening the inverter may cause death or
serious injury. Therefore before assembly, ensure that the inverter is isolated
from all sources of AC and DC power (see inverter Installation Guide).
Electrostatic discharge can damage the inverter. Please ground yourself before
touching components by touching the protective conductor (PE) or a non-coated
part of the inverter enclosure.
1. In order to ensure safety, before assembly, please
read the inverter user manual carefully.
2. Assembly is strictly prohibited when the inverter
connected to electricity or is in operation.
3.2.2 Assembly
For details regarding mounting please refer to the ComBox Quick Installation
Guide.

Connecting to the Internet
~ 7~
4. Connecting to the Internet
The ComBox requires an Internet connection in order to provide remote
monitoring via Ethernet or WiFi.
The ComBox uses network port #6655 and #80 to communicate with the
Solarcloud. Both of these two ports must be opened otherwise the ComBox
cannot connect to the Solarcloud and upload data.
If the IP address of the ComBox is different from the network
segment assigned by the router,
Troubleshooting:
1. Make sure the DHCP service of router has been activated if
ComBox use DHCP function.
2. Check the connection between the ComBox and the router.
3. Check whether the ComBox was using a fix IP address.
4. If the ComBox cannot obtain an IP address from the router,
it will use 169.254.1.100 or 0.0.0.0
4.1 Connecting via Ethernet
The ComBox is connected to the Ethernet by simply connecting the Ethernet
cable from the router to the Ethernet port. The connection between the ComBox
and the Internet is shown in Fig. 4-1.
Fig. 4-1: Network connection
The ComBox obtains an IP address from the router via DHCP automatically and
displays it on the LCD of the inverter. The time it takes to connect to the Internet
depends on the network communication conditions. At the same time the router
needs to support DHCP services and the DHCP services must be activated if the
ComBox has been set up to use the DHCP function.

Connecting to the Internet
~8~
4.2 * Connecting via WiFi
If users use the ComBox’s WiFi to connect the router for remote monitoring, the
connection diagram is shown in Fig. 4-2.
World wide web
Wireless Router
WLAN
Inverter
WiFi
Fig. 4-2: WiFi connection
In order to achieve remote monitoring reliably, the following steps must be
taken.
Step1: Power on the inverter, which will also power ComBox, and use a mobile
device or laptop to search for the wireless access point (AP) of the Combox WiFi.
A new AP of ZEVERSOLAR -XXXX is displayed, Select this AP to connect. The
password is “zeversolar”. As shown in Fig. 4-3.
Fig. 4-3 WiFi connection page
1. "XXXX" stands for the last four digits in the Registry ID of
the Combox.
Step2: Start the web browser and enter http://160.190.0.1. The internal website
opens.
Step3: Select the wireless page and select a wireless local network in the area
to connect. The Password/Security Key dialog box opens, as shown in Fig. 4-4.

Connecting to the Internet
~ 9~
Fig. 4-4 connect to router
Step4: Enter the password of the wireless local network that you wish to
connect to. Do not enter the password of the router.
Step5: After approximately one minute the WiFi of the ComBox will connect to
the wireless local network. The status indicator on the Wireless page should
display the icon, as shown in Fig. 4-5.
Fig. 4-5 WiFi Connection Instructions

Web Server
~10~
5. Web Server
The ComBox has an integrated internal web server. The running state of the
inverter can be checked from the internal web server page. You can also enable
some advanced functions such as output power limitation and adjusting the
inverters safety parameters
The interface structure of the built-in web server is shown in Fig. 5-1.
Fig. 5-1: Structure of the web server
5.1 Visiting the Web Server
There are two ways to visit the internal web server of the ComBox: via Ethernet
or via WIFI (if the ComBox is equipped with the WiFi module).
5.1.1 Visiting via Ethernet
Input the IP address of the ComBox (shown on the inverter’s LCD) in the
browser’s address bar. For example, if the IP address shown on the inverter is
192.168.10.13, then enter 192.168.10.13 in the browser’s address bar and press
the Enter key to open the web page, as shown in Fig. 5-2.
5.1.2*Visiting via WiFi
You also can visit the web page via WiFi, please refer to section 4.2. Once you
are wirelessly connected to the ComBox, input“160.190.0.1”in the browser’s
address bar, press the Enter key to display the internal web page of ComBox, as
shown in Fig. 5-2.

Web Server
~ 11 ~
Fig. 5-2: ComBox Web Server
5.2 Home
This page shows the information and state of the ComBox. It also shows the
state of the inverter. See Fig. 5-2.
If the inverter is working normally, it shows a green icon; otherwise the red
icon will be shown.
5.3 Ethernet
Clicking the “Ethernet” tab will open the Ethernet page. On this page you can set
the Ethernet port parameters. You can set the ComBox using a static IP address
or obtaining the IP address automatically.

Web Server
~12~
Fig. 5-3: Ethernet page
5.4 Advanced
The Advanced web page shows the advanced settings of the ComBox, Such as
the power management and safety setting.
In addition, the firmware of the ComBox and Inverter can be upgraded from this
webpage.
5.4.1 Power Management
The ComBox will regulate the active power of inverter according to value of the
installed PV module capacity or the installed inverter capacity or the energy
meter reading, which are set by the user. Enter the fit to values in Fig. 5-4.
a) Active Power Limit
There are two modes of active power limitation can be selected and five values
need to set.
Fig. 5-4: Set Active Power Limitation Method
The following ways will introduce how to configure the two types of power
limitation.

Web Server
~ 13 ~
Based on the installed Solar DC capacity
In this method the AC output of the PV system will not exceed a set percentage
of the installed solar DC capacity. For example, if a 20 % limitation on a 1,5 kWp
PV system connected to an Eversol TL2000 (2 kWac inverter) has been set then
the AC output will not exceed 1.2 kWac.
The Fig.5-5 shows the system diagram of power limitation based on the
installed solar DC capacity
Fig. 5-5 System diagram based on the installed solar DC capacity
For this method position 1 in Fig. 5-6 should be ticked.
For correct operation of this method there are three parameters that must be
entered, please refer to Fig. 5-6:
Item a –installed solar DC capacity of PV system in Wp;
Item b –total inverter AC capacity of PV system in W;
Item c –Limitation value of solar DC capacity in %.
Click “OK” button in bottom-right of this web page to ensure the setting
parameters take effect.

Web Server
~14~
The Fig. 5-6 Set parameters based on the installed solar DC capacity
The “output power” value is value a multiplied by value c when P >= a*c,
Table 5-1: The indicator of the Item
Parameter
Definition
a
The combined peak power of the PV array (Wp)
b
The sum of the rated powers of all inverters in the
PV plant (Wac)
c
The Percentage of output power limitation based
on parameter a
P
The sum of the real time output power of all
inverters in the PV plant
Parameter b: This parameter is the key value of power limitation, please ensure
that it is correct
Based on the Installed Inverter AC Capacity
In this method the AC output of the PV system will not exceed a set percentage
of the installed inverter AC capacity regardless of the installed DC capacitay. For
example, if a 20 % limitation on a 2 kWp PV system connected to an Eversol
TL2000 (2 kWac inverter) has been set then the AC output will not exceed 1.6
kWac.
Fig. 5-7 is shows the system diagram of power limitation based on the installed
AC (inverter) capacity
For this method position 2 in Fig. 5-7, should be ticked.
For correct operation of this method there are two parameters that must be
entered, please refer to Fig. 5-7:
Item b –total inverter AC capacity of PV system in W;
Item d –Limitation value of AC capacity in %.
Click the “OK” button in bottom-right of this web page to ensure the setting
parameters take effect.

Web Server
~ 15 ~
The Fig. 5-7 Set parameters based on the installed solar DC capacity
The “output power” value is value b multiplied by value d when P >= b*d
Table 5-2: The indicator of the Item
Parameter
Designation
b
The sum of the rated power of all inverters in the PV
plant (Wac)
d
The percentage of power output limitation based on
parameter b
P
The sum of the real time output power of all inverters
in the PV plant
Parameter b: This parameter is the key value of power limitation. Please ensure
that it is correct
b) Reactive Power Limit
There are four modes of reactive power limitation can be selected.
Cos(phi) fix mode: In this mode, the ComBox will regulate the reactive
power of inverter according to the Cos(phi) value which is set by the user.
Enter the Cos(phi) value and choose the phase as shown in Fig.5-8.
Fig. 5-8: Cos(phi) fix mode
Cos(phi) variable mode: In this mode, the ComBox will produce a curve
according to the “P/Pn”, “Cos(phi)” and the phase of points 1,2,3 and 4, and
will regulate the reactive power according to this curve, as shown in Fig. 5-
9.

Web Server
~16~
Fig. 5-9: Cos(phi) variable mode
0.95
0.4 0.6 0.8
P/Pn
Cosφ
1
0.2
0.95
Leading
Lagging
Fig. 5-10: Cos(phi) variable Cure
Q fix mode: In this mode, the ComBox will regulate the reactive power of
the inverter according to the Q value which is set by the user. You need to
input the Q value and choose the phase as shown in Fig. 5-11.
Fig. 5-11: Q fix mode
Q variable mode: In this mode, the ComBox will produce a curve according
to the “U/Un”, “Q value” and phase position of points 1,2,3 and 4, and will
regulate the reactive power according to this curve, as shown in Fig. 5-12.

Web Server
~ 17 ~
Fig. 5-12: Q variable mode
0.50
1.00 1.04 1.08
U/Un
Q
1
0.96
0.50
Leading
Lagging
1.12
Fig. 5-13: Q variable Cure
To cancel the output power limit function untick the checkbox and click the “OK”
button.
Please ensure that the inverter supports the Output Power Limit
function.
5.4.2 Safety Setting
The ComBox also supports setting the safety parameters of the inverter.
Choose the safety standard and then set the protect threshold below. And press
the “OK” button.

Web Server
~18~
Fig. 5-14: Safety Parameters
5.4.3 Updating Firmware
The ComBox can update the firmware of itself, and can also update the
firmware of the connected inverter.
The ComBox can distinguish the update file type and update it automatically.
Update ComBox firmware
Enter the Advanced page and click the “choose file” button and select the new
firmware of ComBox and then click the “OK” button to update.

Web Server
~ 19 ~
Fig. 5-15: Update Firmware
Update inverter firmware
Enter the Advanced page and click the “choose file” button and select the new
firmware of inverter and then click the “OK” button to update. It similar the Fig. 5-
15, but you should choose the relevant inverter firmware file.
5.4.4 Restart
Enter the Advanced page of the ComBox and click the “OK” button at the Restart
section to restart the device.
Fig. 5-16: Restart the device
