zewa 11115 User manual

1
Model:11115
Infrared Thermometer
User Manual
Manual Version: 1.1
Issuing Date: 2020/11

2
Introduction
Thank you for choosing the Dual-mode Digital Infrared Thermometer.
The infrared thermometer can be used to read the body temperature by
measuring the ear and forehead temperature, which is suitable for adult
and children (ear test mode only for the child above 3 months).
Please read the instructions carefully before using the product and put it
in a safe and secure place for reference.

Contents
1. Advantages of the infrared thermometer..................................................1
2. Necessary safety instructions....................................................................2
3.Instructions for product designs................................................................. 3
4.How to measure the forehead temperature.............................................. 4
5.How to measure the ear temperature........................................................ 4
6.Instructions for display and operation........................................................6
7.Cleaning and Disinfection........................................................................... 8
8.Maintenance................................................................................................. 2
9. Replace the battery.....................................................................................2
10.Troubleshooting......................................................................................... 2
11. Technical specifications........................................................................... 5
12. After-sale service...................................................................................... 6
13. Security type..............................................................................................7
14. Authorized European Representative:................................................... 7
15. Symbols..................................................................................................... 7
16.Declaration..................................................................................................8
17. Appendix A: EMC Information-Guidance and Manufacture’s
Declaration....................................................................................................... 8

1
1. Advantages of the infrared thermometer
Dual-mode design (forehead temperature and ear temperature),you can
take body temperature by detecting the infrared ray given off by the
forehead or eardrum. The measuring range of the thermometer in
forehead /ear mode is between 32.0°F - 212.0°F (0 °C- 100 °C) .
The product consists of ABS plastics, temperature sensor, Infrared
temperature measuring element, microcomputer controlled circuit, LCD ,
backlight and buzzer.
Convenient for use
● Special ergonomic design to facilitate operation.
● No inconvenience would be caused to your daily life. It’s available for
measurement when your child is sleeping.
● It provides comfortable user experience compared with anal
thermometer for children, fast reading and simple operation compared
with mouth thermometer.
Memory recall
A maximum of 20 previous readings is available to help you track the
changes of your body temperature.
Safe and hygienic
● Compared to mercury thermometer, there is no danger of breaking the
glass or swallowing mercury.
● It is totally safe for children use.
Fever warning
When the reading exceeds 37.5℃/99.5℉, this product shall warn the
user that he/she may have a fever by 7 rapid and short beeps with LCD
flicker.(For normal forehead temperature, the signal is long beep with
LCD no flicker)
Extensive clinical data of hospital
The cooperation with designated hospitals is subjected to precise clinical
verification, with the support of extensive clinical data and professional
medical experts.
Application scope
The thermometer takes human body temperature for clinical or home use.
It applies to all age groups who are suffering from a fever.

2
Operating principle
The infrared temperature sensor detects infrared energy emitted by the
eardrum. A built-in lens focuses the collected energy, which is then
converted into a temperature reading by the thermopiles and
measurement circuits.
2. Necessary safety instructions
● Take care of the temperature probe lens, which is fragile.
● The device is not a continuous monitoring device.
● The device is not waterproof. Please do not douse it into water or
other liquids. Cleaning and disinfection procedure shall be in accordance
the instructions specified in [Cleaning and Disinfection]
● Do not try to repair the product if it is damaged. Please contact the
nearest Zewa Customer Service.
● The device consists of precision parts with high quality. Please
prevent the product falling off.
●Operating Conditions:
Temperature: 10

C to 40

C
Humidity: 15-95% RH, non-condensing
Atmospheric pressure: 86kPa to 106kPa
●Storage and Shipping Conditions:
Temperature: - 20C to 55C
Humidity: 0-95% RH, non-condensing
Atmospheric pressure: 50kPa to 106kPa

3
●Battery Installation:
Put the two AAA batteries into battery
compartment in correct polarities.
Install the battery cover along the arrow.
Notes:
☆If you are using the thermometer for the
first time, Please pull out the insulation piece.
☆Battery polarities should be correctly installed. Otherwise, damage
may be caused to the device.
☆Please put in or remove batteries in right order, or may cause damage
to the device bracket.
☆Please remove the batteries if the thermometer will not be used for a
long time.
Warnings
● Please keep this infrared thermometer out of children
● Medical assistance can’t be replaced by the use of infrared
thermometer
● The infrared thermometer is not waterproof, Keep it away from water.
3.Instructions for product designs
(1) Probe cover (put the cover on when using forehead mode)
(2) Probe (take off the cover when using ear mode)（applied part)
(3) Forehead mode
(4) LCD display
(5) Ear mode
(6) Battery cover

4
Display description
1. Ambient temperature
2. Ready for measurement
3. Ear mode
4. Head mode
5.

C / °F
6. Low power indicator
7. Memory mode
8. Temperature value
4.How to measure the forehead temperature
1. With the sensor/probe cover attached, position the thermometer at the
center of the forehead, just above the eyebrow, with a distance of 1-3cm.
2. Press and release the HEAD button.The temperature will be displayed
on the screen instantly.
5.How to measure the ear temperature
1. Gently remove the sensor/probe cover to reveal the ear probe.

5
2. Insert the ear probe into the ear canal.
3. Press and release the EAR button. The reading will be displayed on
the screen instantly.
Note:
Children under 1 year: Pull the ear straight back.
Children aged 1 year to adult: Pull the ear up and back.
In order to avoid the inaccuracy:
(1) Please make sure that there is no dirt on the temperature sensor
(2) Please make sure that the device only be used in room, and there is
no strongly conversation of wind.
(3) Before you measure the forehead temperature, there shall be no
water or any shade on the forehead.
(4) Before you measure the ear temperature, please clean the ear canal
first.
(5) Please make sure that there is no intense emotion and movement
before measuring.
(6) If thermometer is transferred from one condition to another which has
different ambient temperature, it is suggested to deposit for more than 30
minutes, and please follow the rule (2).
(7) If the user is transferred from one condition to another which has
different ambient temperature, it is suggested to have a rest for more
than 10 minutes, and please follow the rule (2).
(8) Do not hold thermometer for long time as it is highly sensitive to heat.
Connecting the thermometer to an APP
The thermometer has a built-in Bluetooth module and can be connected
to a smartphone by using the Bluetooth wireless technology. View the
measurement data in real time by using mobile phone software. The
software automatically saves the measurement which helps view the
temperature change in real time.

6
6.Instructions for display and operation
LCD
display
Operational method and instruction
for displays
Sound and backlit
1.Measurement of forehead
temperature:
Position the thermometer at the center
of the forehead above the eyebrow.
With the thermometer touching the
forehead, press and release the HEAD
button. The temperature will be
displayed on the LCD screen.
2.Measurement of ear temperature:
Insert the thermometer ear probe into
the ear canal. Press and release the
EAR button. The temperature will be
displayed on the LCD screen.
3. To measure again, simply press the
HEAD/EAR button accordingly.
When the
temperature is
between 32.0°F/
0°C and 99.5°F/
37.5°C, there will be
a long beep and a
green backlit will be
displayed for 3
seconds.
When the
temperature is
between
99.6°F/37.6°C and
107.9°F/42.2°C,
there will be 7 short
beeps and the
reading will flicker
with a red backlit for
3 seconds. This
indicates that the
subject may have a
fever. Please
consult your doctor
if you are not sure.
Forehead measurement mode
Eardrum measurement mode
The measured value exceeds
212 °F/100°C.
3 short beeps with a
red backlit for 3
seconds.

7
The measured value falls below
32.0°F/0°C.
3 short beeps with a
red backlit for 3
seconds.
Inquiry for memory data, Storing 20 temperature
readings
LCD
display
Operational method and instruction
for displays
Sound and backlit
Press and hold EAR button for 3-6
seconds and the LCD will display “- - -”
with the M signal blinking.
None
Press button EAR again and the LCD
will display the number ‘1’ with the M
signal. After 1 second, the measured
temperature with the mode of
measurement icon will be displayed.
Note that this is the latest reading.
To recall the next recorded reading,
press button EAR again. The number
‘2’ with the M signal will be displayed.
After 1 second, the measured
temperature with the mode of
measurement icon will be displayed.
Repeat to recall earlier recordings (up
to 20 total) if necessary.
None
The LCD will display “- - -” with the M
signal blinking if there is no test data.
None
°C/°F conversion
LCD
display
Operational steps
Sound and backlit
When the thermometer is off, press and
hold the EAR button for 6-9 seconds.
The screen will display “- - - ” with “M” at
the bottom right. Continue to hold the
button until “- - -°C/°F” appears on the
screen. Release the EAR button and
None

8
the “- - -°C/°F” temperature unit will
start to blink. Press the EAR button
again within 5 seconds to change the
temperature unit to your choice.
Error message & Low voltage
LCD screen will display “Er1” when
ambient temperature exceeds
104.0°F/40.0°C or drops below
50.0°F/10.0°C.
3 short ticks and red
backlit for 3
seconds.
LCD screen will display “ErC” if there is
EEPROM data reading error or the
calibrating process is not finished.
Please contact your supplier.
3 short ticks and red
backlit for 3
seconds.
Low-voltage signal when the battery
voltage is below 2.5V±0.1V. Please
replace battery.
None
Power Off Mode
The thermometer will power off automatically in10 seconds.
Attention:
● Electromagnetic interference: thermometer contains sensitive
electronic component and shall not be used under the condition with
electromagnetic interference,( such as the place nearby the mobile
phones and microwaves )
● Please dispose the used products and batteries in accordance with
local regulation requirements when the products and batteries are not
available.
● Please take out the battery if the device is not used for a long time.
7.Cleaning and Disinfection
Cleaning
1) Clean the temperature probe with a soft
cloth. Clean the lens of the temperature
probe with a cotton swab.
2) Wipe the thermometer body with a
slightly damp soft cloth, and gently dry the
body with a piece of tissue paper.

9
Keep water off the lens during the cleaning process. Otherwise, the
lens may be damaged.
The lens may be scratched if it is cleaned with a piece of tissue
paper, resulting in inaccurate readings.
Do not clean the thermometer with corrosive cleansers. During the
cleaning process, do not touch the lens using hard objects, immerse any
part of the thermometer into liquid, or allow liquid to enter the
thermometer.
Disinfection
1) Disinfect the thermometer body and the area around the
temperature probe with a cloth slightly moistened with 75% medical
alcohol.
Do not use hot steam or ultraviolet radiation for disinfection.
Otherwise, the thermometer may be damaged or quickly aged.
8.Maintenance
1) After each use, clean the temperature probe as described in
"Cleaning and Disinfection".
2) Store the thermometer in a dry, dust-free, and well-ventilated place.
Ensure that the thermometer is not exposed to sunlight. Ensure that
the storage and transportation environments meet the requirements
3) Check whether safety risks exist on a regular basis.
4) Remove the batteries if the thermometer will not be used for more
than two months.
9. Replace the battery.
Slide the battery cover off along the marked direction. Put the two AAA
batteries into the compartment correctly.
Remove the batteries if the thermometer will not be used for more than
two months.
10.Troubleshooting
Symptom
Possible Cause
Solution
The thermometer
The battery level is
Use new batteries of

10
Symptom
Possible Cause
Solution
fails to power on.
extremely low.
the same model or
specifications.
Polarities of the
batteries are reversed.
Ensure that the
batteries are correctly
installed according to
the polarity symbols in
the battery
compartment.
The thermometer is
faulty.
If the warranty period
does not expire,
contact Zewa or a local
distributor.
Only the battery
symbol is
displayed after the
thermometer
power on.
The battery level is low.
Use new batteries of
the same model or
specifications.
"Er1" is displayed.
The ambient
temperature is lower
than 10°C (50.0°F) or
higher than 40°C
(104°F).
Take a measurement
under an ambient
temperature between
10°C (50.0°F) and
40°C (104°F).
"ErC" is displayed.
An error occurs when
data is being read from
or written into the
memory, or the
temperature correction
is not complete.
Contact Zewa.
The temperature
reading is lower
than the typical
body temperature
The lens of the
temperature probe is
dirty.
Clean the lens using a
cotton swab.
The distance between
Move the thermometer

11
Symptom
Possible Cause
Solution
range.
the temperature probe
and the target is too
long.
closer to the target.
The thermometer is not
used within 30 minutes
after being taken from a
cold environment.
Wait for more than 30
minutes after the
thermometer is moved
into the measurement
environment.
The temperature
reading is higher
than the typical
body temperature
range.
The temperature probe
is faulty.
Contact Zewa.

12
11. Technical specifications
Items
Standards
Model
Infrared Ear Forehead Thermometer
Temperature units
℃/℉, adjustable
Measurement range
Forehead temperature mode:0.0℃-100.0℃/32.0F
– 212.0 F
Ear temperature mode:0.0℃-100.0℃/32.0F –
212.0 F
Accuracy
(Laboratory)
±0.2℃/±0.4F(36℃-39℃/96.8℉-102.2℉)
±0.3/±0.5℉(less than 36 °C (96.8°F) or more than
39 °C (102.2 °F)
Accuracy (Clinical)
±0.3°C (±0.6°F)
Display resolution
0.1℃/0.1℉
Measuring site
Ear canal, Forehead (keep distance 1~3 cm from
forehead)
Reference body site
Armpit
Mode of operation
Adjusted mode
Measure time
About 1 second
Latency Time
About 1 second
Measuring distance
Forehead temperature:1-3cm
Sound
volume≧50 db (the perpendicular distance from dB
Volume sensor to thermometer is 10cm )
Automatic shutdown
function
10s±1s
Low-voltage display
function
The product shall display low-voltage signal if the
voltage is below 2.5V±0.1V.

13
Memory function
Memorize 20 groups of measured temperature.
Power supply
Internal power supply
Operating voltage
DC 3V
Battery
AAA ×2
The date of
production
See the label
Life
2 years
Battery life
Alkaline dry battery for around 20000 measurements
The infrared thermometer has been tested and conforms to the standard
ASTM E1965-98. ASTM laboratory accuracy requirements in the display
range of 96.8°F to102.2°F (36°C-39°C) for ear canal IR thermometers is
±0.4°F (±0.2°C). Note that for mercury-in-glass and electronic
thermometers, the requirement per ASTM Standards E667-86 and
E1112-86 is ±0.2°F (±0.1°C).
12. After-sale service
The device is under warranty for one year since the date of acquisition.
Application for repairing should be presented during the warranty period.
The damage caused by improper use is not under the warranty scope.
Batteries and packaging are not under warranty scope either.
After-sale service:
Zewa, Inc.
12960 Commerce Lakes Dr. # 29
Fort Myers, FL 33913
E-mail：[e-mail]
Website: www.zewa.com
Phone: [phone]

14
13. Security type
The signal indicates that the thermometer is type BF applied part.
14. Authorized European Representative:
N/A
15. Symbols
Symbol
Description
Type BF applied part.
Attention must be paid.
The action is prohibited.
Information about a manufacturer, such as name and
address.
Date of manufacture.
Consult the instructions for use.
This product complies with the MDD93/42/EEC
requirements.
Waste electrical materials should be sent to a
dedicated collection point for recycling.Must contact
its local authorities to determine the proper method
of disposal of potentially bio hazardous parts and
ACCESSORIES.
IP22
Degree of protection against ingress of water and
particulate matter
Warning
A personal injury or thermometer damage may occur
if the thermometer is not correctly used.
Attention
Inaccurate reading or thermometer damage may
occur if the thermometer is not correctly used.

15
16.Declaration
EMC of this product complies with IEC60601-1-2 standard.
The materials which the user can come into contact have no toxicity
and no action on tissues comply with ISO10993-1, ISO10993-5 and
ISO10993-10.
17. Appendix A: EMC Information-Guidance and
Manufacture’s Declaration
CAUTION:
● Infrared Thermometer needs special precautions regarding EMC
and needs to be installed and put into service according to the EMC
information provided for in the ACCOMPANYING DOCUMENTS.
● Portable and mobile RF communications equipment can affect
Infrared Thermometer
● The Infrared Thermometer should not be used adjacent to or
stacked with other equipment.
Guidance and manufacturer´s declaration – electromagnetic
emission –for all EQUIPMENT AND SYSTEMS
Guidance and manufacturer´s declaration – electromagnetic emission
The Infrared Thermometer is intended for use in the electromagnetic
environment specified below. The customer or the user of the Infrared
Thermometer should assure that it is used in such an environment.
Emissions
test
Compliance
Electromagnetic environment - guidance
RF emissions
CISPR 11
Group 1
The Infrared Thermometer uses RF
energy only for its internal function.
Therefore, its RF emissions are very low
and are not likely to cause any
interference in nearby electronic
equipment.
RF emissions
CISPR 11
Class B
The Infrared Thermometer is suitable for
use in all establishments, including
domestic establishments and those
directly connected to the public
low-voltage power supply network that
supplies buildings used for domestic
purposes.

16
Guidance and manufacturer's declaration – electromagnetic
immunity –for all EQUIPMENT and SYSTEMS
Guidance and manufacturer´s declaration – electromagnetic immunity
The Infrared Thermometer is intended for use in the electromagnetic
environment specified below. The customer or the user of the Infrared
Thermometer should assure that it is used in such an environment.
Immunity test
IEC
60601
test level
Compliance
level
Electromagnetic
environment- guidance
Electrostatic
discharge
(ESD)
IEC 61000-4-2
±6 kV
contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be
at least 30 %.
Power
frequency
(50/60 Hz)
magnetic
field
IEC 61000-4-8
3 A/m
3 A/m
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Guidance and manufacturer´s declaration – electromagnetic
immunity –for EQUIPMENT and SYSTEM that are not
LIFE-SUPPORTING
Guidance and manufacturer´s declaration – electromagnetic immunity
The Infrared Thermometer is intended for use in the electromagnetic
environment specified below. The customer or the user of the Infrared
Thermometer should assure that it is used in such an environment.
Immunity test
IEC
60601
test level
Compliance
level
Electromagnetic
environment -
guidance
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz
to 2.5
GHz
3 V/m
Portable and mobile RF
communications quipment
should be used no closer to
any part of the
Infrared Thermometer,
including cables, than the
recommended separation

17
distance calculated from the
equation applicable to the
frequency of the transmitter.
Recommended separation
distance
where p is the maximum
output power rating of the
transmitter in watts (W)
according to the transmitter
manufacturer and d is the
recommended separation
distance in metres (m).b
Field strengths from fixed
RF transmitters, as
determined by an
Electromagnetic site
survey,a should be less than
the compliance level in each
frequency range.b
Interference may occur in
the vicinity of equipment
marked with the following
symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic is
affected by absorption and reflection from structures, objects and people.
a. Field strengths from fixed transmitters, such as base stations for radio
(cellular/cordless) telephones and land mobile radios, amateur radio, AM and
FM radio broadcast and TV broadcast cannot be predicted theoretically with
accuracy. To assess the electromagnetic environment due to fixed RF
