zewa 11110 Installation and maintenance instructions

Getting
Started
Infrared Thermometer

STEP 1
Device Setup
Insert 2 x AAA batteries into bottom
of the unit.
Part Descriptions:
1. Temperature Sensor
2. Start Button
3. Setting Button
4. Batteries
1
3
2
4
Pg. 1

Press the Start button to change
the temperature unit and the
Setting button to continue.
The time format is ashing (12H or
24H format). Press the Start
button to change or the Setting
button to continue.
The hour is ashing. Press the
Start button to change or the
Setting button to continue.
Program Date and Time
After installing the batteries, the temperature
unit is ashing. Follow these steps to program
the thermometer.
STEP 2
Pg. 2

Note: For additional details on how to
program the thermometer, please refer to the
instruction manual.
The minutes are ashing. Press the
Start button to change or the
Setting button to continue.
The year is ashing. Press the Start
button to change or the Setting
button to continue.
The month is ashing. Press the
Start button to change or the
Setting button to continue.
The day is ashing. Press the Start
button to change or the Setting
button to continue.
When completed the thermometer
will turn OFF.
Pg. 3

STEP 3
4 Position Rotating Temperature
Sensor
This unique temperature sensor allows it to
turn in 4 directions.
Towards the user for self
measurement.
Towards another person to take
their measurement.
Straight up to take a
measurement for another person
or an object (if in object mode).
Straight down (closed position)
which turns the thermometer off.
Pg. 4

1. Rotate the temperature sensor to the
appropriate position, the display will turn
ON.
2. Aim the thermometer at the center of the
forehead with a distance of less than 2"
but do NOT touch the forehead.
3. Press the Start button to take a reading.
4. When done, rotate the temperature sensor
downwards and the display will turn OFF.
Note: If the thermometer was too far way from
the forehead, the word FAR is shown on the
display. Take another reading that is closer than
2" from the forehead.
STEP 4
Take a measurement.
Pg. 5

My reading is off by several degrees.
Check if the thermometer is in object mode.
Make sure you are not touching your forehead
when taking a measurement.
My device does not turn ON.
Change the batteries (use a brand new set of
batteries).
Rotate the temperature sensor to an ON
position.
For additional FAQ’s, please visit our website
at www.zewa.com
Frequently Asked Questions
Pg. 6

Zewa Inc.
12960 Commerce Lakes Dr. # 29
Fort Myers, FL 33913
Toll Free: 888-993-3592
www.zewa.com
Warranty Registration
To register your warranty, visit us online at:
www.zewa.com
For a detailed description of your warranty,
please refer to the instruction manual.
