ZIGBEE 68904 User manual
ZIGBEE BATTERY MOTOR OPERATING
MANUAL
ZIGBEE BATTERY MOTOR OPERATING
MANUAL
ZIGBEE BATTERY MOTOR OPERATING
MANUAL
Remote: P541-16
Version: 2.0 Date: Dec,15, 2021
68904
CONTENTS
Motor Parameters 7
Reset and Re-pair 8-19
FAQ 20-21
Alexa&Voice Control 4-6
Remote Control 1-3
CONTENTS
Motor Parameters 7
Reset and Re-pair 8-19
FAQ 20-21
Alexa&Voice Control 4-6
Remote Control 1-3
CONTENTS
Motor Parameters 7
Reset and Re-pair 8-19
FAQ 20-21
Alexa&Voice Control 4-6
Remote Control 1-3
REMOTE CONTROL
REMOTE CONTROL
REMOTE CONTROL
P541-16
CR2032(3V)CR2032(3V)
Setting Button
Setting Button
Setting Button
3
V
L
i
t
h
u
i
m
C
E
L
L
+
CR2032
3V(CR2032)
+
Lithuim Cell
CR2032
3V
sc
3
V
L
i
t
h
u
i
m
C
E
L
L
+
CR2032
We have finished the basic program setting of the blind.
You can control the blind via a remote controller directly
after you receive the blind.
We have finished the basic program setting of the blind.
You can control the blind via a remote controller directly
after you receive the blind.
We have finished the basic program setting of the blind.
You can control the blind via a remote controller directly
after you receive the blind.
INSTALL BATTERY｜INSTALL BATTERY｜INSTALL BATTERY
Megnetic Holder
Megnetic Holder
Megnetic Holder
x2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Up｜Up｜Up
Stop｜Stop｜Stop
Down｜Down｜Down
—Channel +Channel
Channel “1-16”
Control max 16 blinds separately
Channel “1-16”
Control max 16 blinds separately
Channel “1-16”
Control max 16 blinds separately
Channel “ ”
Group Control
Channel “ ”
Group Control
Channel “ ”
Group Control
Remote control range
Remote control range
Remote control range
Rolling
Rolling
114ft(35m)
590ft(180m)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Shade jogs x1
Shade jogs x1
Shade jogs x1
ALEXA&VOICE CONTROL
ALEXA&VOICE CONTROL
ALEXA&VOICE CONTROL
HOW TO CONNECT TO ALEXA
HOW TO CONNECT TO ALEXA
HOW TO CONNECT TO ALEXA
Step 1
The below 5 types Alexa moudles can connect to shades directly
but others types need a hub.:
The below 5 types Alexa moudles can connect to shades directly
but others types need a hub.:
The below 5 types Alexa moudles can connect to shades directly
but others types need a hub.:
Echo Plus(2.Gen.) Echo Studio Echo (4th Gen) Echo Show 10
(3rd Gen) Echo Show
(2nd Gen)
Press and hold for 3s
Press and hold for 3s
Press and hold for 3s
Please say
“Alexa, discover my devices”
“OK”
12
3
Quickly press for x4
Quickly press for x4
Quickly press for x4
Please check if the top and bottom limit can work normally before
connecting to alexa.
Please check if the top and bottom limit can work normally before
connecting to alexa.
Please check if the top and bottom limit can work normally before
connecting to alexa.
x1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Step 2
Please say
Alexa, open blind A to 50%.
Alexa, close blind B to 60%.
Please say
If you have two or more blinds:
If you use the echo4, please refer to the below instructions:
If you use the echo4, please refer to the below instructions:
If you use the echo4, please refer to the below instructions:
If you have two or more blinds:
If you have two or more blinds:
SET DEVICE NAME
SET DEVICE NAME
SET DEVICE NAME
First device
Voice control｜Voice control｜Voice control
1
First blind
Second blind
First device
2 3 4
Please say
Alexa, open blind A to 50%.
Alexa, close blind B to 60%.
Congratulations！
Now you can free control the blind via Alexa voice command！
Congratulations！
Now you can free control the blind via Alexa voice command！
Congratulations！
Now you can free control the blind via Alexa voice command！
Please set their name separately. For example: blind A, blind B.
Please set their name separately. For example: blind A, blind B.
Please set their name separately. For example: blind A, blind B.
Alexa, open the blind to 1~100%.
Alexa, close the blind to 1~100%.
Alexa, open blind A to 50.
Alexa, close blind B to 60.
Alexa, open the blind.
Alexa, close the blind.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Step 3
“Alexa, Open the blind to 5 %”
Tips for Shangri-la blinds
Tips for Shangri-la blinds
Tips for Shangri-la blinds
. Depending on the different blinds length，same voice command (like 5%) will cause
different filtering angles.
. Please try to adjust the filtering angle as you need with voice command.
. Depending on the different blinds length，same voice command (like 5%) will cause
different filtering angles.
. Please try to adjust the filtering angle as you need with voice command.
. Depending on the different blinds length，same voice command (like 5%) will cause
different filtering angles.
. Please try to adjust the filtering angle as you need with voice command.
Short Shade
Short Shade
Short Shade
Middle Shade
Middle Shade
Middle Shade Long Shade
Long Shade
Long Shade
CONTROL THE BLIND VIA ALEXA ROUNTINE
CONTROL THE BLIND VIA ALEXA ROUNTINE
CONTROL THE BLIND VIA ALEXA ROUNTINE
2
1
3
90%
60%
30%
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Congratulations！
Now you can free control the blind via Alexa rountine!
Congratulations！
Now you can free control the blind via Alexa rountine!
Congratulations！
Now you can free control the blind via Alexa rountine!
7
8
10
45
6
9
You can add multiple blinds here.
You can add multiple blinds here.
You can add multiple blinds here.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Reset button
Reset button
Reset button
Minimum 8 hours
Flash Red
Flash Red
Flash Red
Minimum 8 hours
Minimum 8 hours
The Motor will change to Dot moving automatically when it's almost out of power.
The Motor will change to Dot moving automatically when it's almost out of power.
The Motor will change to Dot moving automatically when it's almost out of power.
1 .Please full charge the motor for more than 10 hours before the first use.
2.After fully charged, shade can be used for 3-6 months depending on the frequency of use.
1 .Please full charge the motor for more than 10 hours before the first use.
2.After fully charged, shade can be used for 3-6 months depending on the frequency of use.
1 .Please full charge the motor for more than 10 hours before the first use.
2.After fully charged, shade can be used for 3-6 months depending on the frequency of use.
USB Charger
5V2A（Not included）
USB Charger
5V2A（Not included）
USB Charger
5V2A（Not included）
Solar Panel (Optional)
Solar Panel (Optional)
Solar Panel (Optional)
Charging
Charging
Charging
Full Charge
Full Charge
Full Charge
MOTOR PARAMETERS
MOTOR PARAMETERS
MOTOR PARAMETERS
Solid Red
Solid Red
Solid Red
Solid Green
Solid Green
Solid Green
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
x1
HOW TO POWER ON/OFF
HOW TO POWER ON/OFF
HOW TO POWER ON/OFF
Power on｜Power on｜Power on：
Power off｜Power off｜Power off：
Flash red light x1
Flash red light x1
Flash red light x1
Press and hold for 7s
Press and hold for 7s
Press and hold for 7s
x1 x3
Press for 2s
Press for 2s
Press for 2s
Shade jogs x1
Shade jogs x1
Shade jogs x1
Flash red light x1
Flash red light x1
Flash red light x1
Flash red light x3
Flash red light x3
Flash red light x3
x1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
HOW TO CHANGE UP/DOWN DIRECTION
HOW TO CHANGE UP/DOWN DIRECTION
HOW TO CHANGE UP/DOWN DIRECTION
1
2
Press and hold for 5s
Press and hold for 5s
Press and hold for 5s
Press for 1s
Press for 1s
Press for 1s
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Press and hold for 5s
Press and hold for 5s
Press and hold for 5s
1
Press for 1
Press for 1
Press for 1
2
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
DOT MOVE CONTINUOUS MOVE
DOT MOVE CONTINUOUS MOVE
DOT MOVE CONTINUOUS MOVE
Shade jogs x1
Shade jogs x1
Shade jogs x1
If you want to run the shade to a exact position, you can switch to dot move mode.
If you want to run the shade to a exact position, you can switch to dot move mode.
If you want to run the shade to a exact position, you can switch to dot move mode.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
HOW TO DELETE LIMIT POSITION
HOW TO DELETE LIMIT POSITION
HOW TO DELETE LIMIT POSITION
The top limit position cannot be deleted.
The top limit position cannot be deleted.
The top limit position cannot be deleted.
Press and hold for 7s
Press and hold for 7s
Press and hold for 7s
1s later
6s later
2
1
Please run the blind to the position you want
to delete.
Please run the blind to the position you want
to delete.
Please run the blind to the position you want
to delete.
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Shade jogs x1
Shade jogs x1
Shade jogs x1
21
HOW TO SET TOP LIMIT POSITION
HOW TO SET TOP LIMIT POSITION
HOW TO SET TOP LIMIT POSITION
Press for 1s
Press for 1s
Press for 1s
The up limit point
The up limit point
The up limit point
1
2
3
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
Step 1-3 should be programmed continuously in a short time.
Step 1-3 should be programmed continuously in a short time.
Step 1-3 should be programmed continuously in a short time.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
HOW TO SET BOTTOM LIMIT POSITION
HOW TO SET BOTTOM LIMIT POSITION
HOW TO SET BOTTOM LIMIT POSITION
2
1
The down limit point
The down limit point
The down limit point
3
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
Step 1-3 should be programmed continuously in a short time.
Step 1-3 should be programmed continuously in a short time.
Step 1-3 should be programmed continuously in a short time.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
SET THE FAVORITE POSITION
SET THE FAVORITE POSITION
SET THE FAVORITE POSITION
Please move the shade to your favorite running
position (except fully open and fully closed)
Please move the shade to your favorite running
position (except fully open and fully closed)
Please move the shade to your favorite running
position (except fully open and fully closed)
Press for 1
Press for 1
Press for 1
Press for 1
Press for 1
Press for 1
Press for 2
Press for 2
Press for 2
3
1
2
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
HOW TO REMOVE A CHANNEL
HOW TO REMOVE A CHANNEL
HOW TO REMOVE A CHANNEL
Press for 1s
Press for 1s
Press for 1s
2
1
Press and hold for 5s
Press and hold for 5s
Press and hold for 5s
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
The remote "b" is now paried with the blind as remote "a".
The remote "b" is now paried with the blind as remote "a".
The remote "b" is now paried with the blind as remote "a".
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
Press and hold for 5s
Press and hold for 5s
Press and hold for 5s
Press for 1
Press for 1
Press for 1
a
b
ba
a
HOW TO ADD NEW REMOTE "b"
HOW TO ADD NEW REMOTE "b"
HOW TO ADD NEW REMOTE "b"
x1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
HOW TO RESET THE MOTOR
HOW TO RESET THE MOTOR
HOW TO RESET THE MOTOR
Press and hold for 5s
Press and hold for 5s
Press and hold for 5s
Press and hold for 7s
Press and hold for 7s
Press and hold for 7s
1s later
6s later
1
2
x2
Shade jogs x2
Shade jogs x2
Shade jogs x2
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
HOW TO RE-PAIR WITH MOTOR
HOW TO RE-PAIR WITH MOTOR
HOW TO RE-PAIR WITH MOTOR
Press for 1s
Press for 1s
Press for 1s
1
Press for 1s
Press for 1s
Press for 1s
2
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
x1
Shade jogs x1
Shade jogs x1
Shade jogs x1
shade up
shade up
shade up
Test motor running direction
Test motor running direction
Test motor running direction
* Dot press Dot moving
* Deep press Standard moving
* Dot press Dot moving
* Deep press Standard moving
* Dot press Dot moving
* Deep press Standard moving
shade down
shade down
shade down
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
Table of contents
