Zip IP-CAM530 User manual

ZIP-CAM - Vol 2 / Version 2
www.ZipNVR.com
Instruction
Manual
Add more to your CCTV!...
...zippy to fit & zippy to learn!
...IP Camera manual
IP-CAM530 / 535 / 570 / 800 / 815 / 870 / 880 / 910 / 920 / 930 Models

2Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com
Introduction
The Zip IP cameras are available in either ultra-clean looking Diamond white or a beautiful
gloss black finish. When surveyed, people preferred on the whole white cameras internally
and black cameras externally, so that's what we manufactured!
High resolution 4MP output using the latest H265 compression means you get stunning
images but minimise bandwidth and storage requirements.
Built in Smart-PoE means you can power the cameras directly from the Zip PoE NVR (or other
PoE devices) for a really easy and neat installation.
Video Analytical features built into the cameras include line crossing, missing object
detection and basic face detection. These features do work without the ZipNVR but to
get the maximum out of them you need the ZipNVR too so you can record and search
activations.
Plug and play with the ZipNVR, they couldn't be easier to fit.
“add more to your CCTV”.
Zip IP cameras are designed for installation by a professional CCTV installer, for
further support, please contact:

Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com 3
Contents
Anti-vandal Varifocal Domes 4
Anti-vandal Deep Bases 5
Mini Fixed Dome 6
Mini Fixed Eyeball 7
Midi Fixed Eyeball 8
Varifocal Eyeballs 9
Fixed All-In-One 10
Varifocal All-In-Ones 11
Universal Deep Bases 12
How To Connect To A Non-PoE NVR 14
How To Connect To A PoE NVR 16
How To Connect A Camera’s Audio 17
How To Connect A Camera’s Alarm Inputs/Outputs 18
Extra Resources 19
Have You Seen Our Easy Camera Configuration Tool?
Zip Finder is our handy FREE PC software for
discovering and configuring IP cameras on
your network.
It’s ideal for non-PoE installs and problem
solving issues such as forgotten or unknown
IP Addresses.
For your FREE software download just visit
ZipNVR.com
Have You Seen Our Easy Camera Configuration Tool?

4Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com
Anti-vandal Varifocal Domes
IP-CAM530 Connections IP-CAM535 Connections
Specification
Onvif Version 2.6
Compression H.265 / H.264
Resolution Up To 5 Mega Pixel
Lens 2.8-12mm Varifocal
Day/Night Mechanical IR Cut
O Filter
IR LEDs x40
IR Range Up To 40M
Lux 0 (With IR On)
Use IP66 For External Use
Dimensions Ø146mm x 115mm
Mounting
2 3
Loosen the three Torx screws in
the upper housing and lift off
(Torx key supplied).
1
Screw through the camera’s
base and into the mounting
surface using the screws and
wall plugs provided.
Once the camera is positioned.
Replace the upper housing and
fasten the three Torx screws.
RJ45 Socket
(Weather-proof cap supplied)
RJ45 Socket
(Weather-proof cap supplied)
2.1mm DC Socket
2.1mm DC Socket
Audio In Phono Socket (pg. 17)
Audio Out Phono Socket (pg. 17)
Camera Reset Button
Analogue Video Test BNC Socket
Alarm In / Out (pg. 18)
 Up to 5MP Resolution
 Built in PoE
 2.8-12mm Varifocal lens
 40x IR LEDs / 40m range
 Motorised Zoom with
Auto Focus
 Alarm + Audio In/Out
 Micro SD Recording
+ Motorised Option

Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com 5
Anti-vandal Deep Bases
Wall & Ceiling Mounting Pole & Wall Bracket Mounting
1
First you’ll need to fix the camera to the base as
shown in “Wall & Ceiling Mounting” steps 2 and 3.
Before you start
remove the upper
housing as shown in
“Mounting” step 1.
The anti-vandal deep bases
offer extra room for easy
termination and to disguise
cabling and connections
for a neat finish.
They are designed for use
with the IP-CAM530/353
anti-vandal domes so they
fit perfectly.
Code:
IP-BASE002B (Black)
Code: IP-BASE002W (White)
A practical way to get the
ideal viewing angle. As well
as a wall bracket there are
200mm, 300mm and 500mm
ceiling brackets available.
Code: IP-BRKT005B (Wall)
Code: IP-BRKT005W (Wall)
Code: IP-BRKT250B (200mm)
Code: IP-BRKT250W (200mm)
Code: IP-BRKT350B (300mm)
Code: IP-BRKT350W (300mm)
Code: IP-BRKT550B (500mm)
Code: IP-BRKT550W (500mm)
3
Tighten the three
Torx screws in the
upper housing
(Torx key supplied).
x3
1
Screw through
the four holes in
the bottom of the
base and into the
mounting surface
using the screws
and wall plugs
provided.
Mark the fixing holes on
the mounting surface.
Drill and insert the four
anchor bolts provided.
With the bracket over
the anchor bolts, place
a washers, split ring
and then screw a nut
on to each exposed
thread to secure.
2
Screw the deep base
on to the end of the
ceiling/wall bracket.
Lock the base in-place
using the small slotted
grubs screws supplied.
When ceiling mounting
the mounting plates
is attached to the
opposite end of the
pole in the same way.
x4 x4
2
Screw through the
camera’s base and
into the deep base
using the short flat
screws provided.
x4

6Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com
Mini Fixed Dome
Connections
Specification
Onvif Version 2.6
Compression H.265 / H.264
Resolution Up To 5 Mega Pixel
Lens 3.6mm Fixed
Day/Night Mechanical IR Cut
O Filter
IR LEDs x12
IR Range Up To 10M
Lux 0 (With IR On)
Use IP66 For External Use
Dimensions Ø119mm x 65mm
Mounting
123
Loosen the four screws in the
upper housing and lift off.
Remove the two black screws
in the base of the camera and
lift the camera module off the
fixing plate.
Screw through the four slots
in the fixing plate and into the
mounting surface using the
screws and wall plugs provided.
RJ45 Socket
(Weather-proof cap supplied)
2.1mm DC Socket
 Up to 5MP Resolution
 Built in PoE
 3.6mm Fixed lens
 12x IR LEDs with up to
10m range
 Just 65mm Tall

Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com 7
Mini Fixed Eyeball
Connections
Specification
Onvif Version 2.6
Compression H.265 / H.264
Resolution Up To 5 Mega Pixel
Lens 3.6mm Fixed
Day/Night Mechanical IR Cut
O Filter
IR LEDs x18
IR Range Up To 30M
Lux 0 (With IR On)
Use IP66 For External Use
Dimensions Ø90mm x 85mm
Mounting
123
Hold the base then unscrew the
collar to release the eyeball. Lift
the collar and eyeball off the
base.
Screw through the three
holes in the base and into the
mounting surface using the
screws and wall plugs provided.
Position the camera as required
then screw the collar back onto
the base while holding the
camera in-place.
RJ45 Socket
(Weather-proof cap supplied)
2.1mm DC Socket
 Up to 5MP Resolution
 Built in PoE
 3.6mm Fixed lens
 18x IR LEDs with up to
30m range
 Compact Size just
Ø90mm

8Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com
Midi Fixed Eyeball
Connections
Specification
Onvif Version 2.6
Compression H.265 / H.264
Resolution Up To 5 Mega Pixel
Lens 3.6mm Fixed
Day/Night Mechanical IR Cut
O Filter
IR LEDs x1 High Power
IR Range Up To 30M
Lux 0 (With IR On)
Use IP66 For External Use
Dimensions Ø126mm x 100mm
Mounting
123
Twist the collar covering the
fixing plate to unlock it then
lift off.
Remove the small screw
holding the locking plate in
place and then slide out the
locking plate.
Screw through the three
holes in the base and into the
mounting surface using the
screws and wall plugs provided.
RJ45 Socket
(Weather-proof cap supplied)
2.1mm DC Socket
 Up to 5MP Resolution
 Built in PoE
 3.6mm Fixed lens
 1x High Power IR LED
with up to 30m range
 Compact Size just
Ø90mm

Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com 9
Varifocal Eyeballs
IP-CAM870 Connections IP-CAM880 Connections
Specification
Onvif Version 2.6
Compression H.265 / H.264
Resolution Up To 5 Mega Pixel
Lens 2.8-12mm Varifocal
Day/Night Mechanical IR Cut
O Filter
IR LEDs x2 IR Arrays
IR Range Up To 40M
Lux 0 (With IR On)
Use IP66 For External Use
Dimensions Ø151mm x 115mm
Mounting
123
Twist the collar covering the
fixing plate to unlock it then
lift off.
Remove the small screw
holding the locking plate in
place and then slide out the
locking plate.
Screw through the three
holes in the base and into the
mounting surface using the
screws and wall plugs provided.
RJ45 Socket
(Weather-proof cap supplied)
RJ45 Socket
(Weather-proof cap supplied)
2.1mm DC Socket
2.1mm DC Socket
Audio In Phono Socket (pg. 17)
Audio Out Phono Socket (pg. 17)
Camera Reset Button
Analogue Video Test BNC Socket
Alarm In / Out (pg. 18)
 Up to 5MP Resolution
 Built in PoE
 2.8-12mm Varifocal lens
 2x IR Arrays / 40m range
 Motorised Zoom with
Auto Focus
 Alarm + Audio In/Out
 Micro SD Recording
+ Motorised Option

10 Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com
Fixed All-In-One
Connections
Specification
Onvif Version 2.6
Compression H.265 / H.264
Resolution Up To 5 Mega Pixel
Lens 3.6mm Fixed
Day/Night Mechanical IR Cut
O Filter
IR LEDs x2 High Power
IR Range Up To 60M
Lux 0 (With IR On)
Use IP66 For External Use
Dimensions
(h)79.5mm x (w)82mm x
(d)140mm (ex bracket)
Mounting
1 2
Screw through the three holes in the base of the
bracket and into the mounting surface using the
screws and wall plugs provided.
Using the Allen Key supplied loosen the three
locking screws on bracket. The camera can then
be positioned as required. When finished tighten
the locking screws to secure the camera.
RJ45 Socket
(Weather-proof cap supplied)
2.1mm DC Socket
 Up to 5MP Resolution
 Built in PoE
 3.6mm Fixed lens
 2x High Power IR LEDs
with up to 60m Range
 Cable Managed Bracket
 Compact Size just
Ø90mm

Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com 11
Varifocal All-In-Ones
Specification
Onvif Version 2.6
Compression H.265 / H.264
Resolution Up To 5 Mega Pixel
Lens 2.8-12mm Varifocal
Day/Night Mechanical IR Cut
O Filter
IR LEDs x2 High Power
IR Range Up To 60M
Lux 0 (With IR On)
Use IP66 For External Use
Dimensions
(h)88.5mm x (w)88mm x
(d)141mm (ex bracket)
Mounting
1 2
Screw through the three holes in the base of the
bracket and into the mounting surface using the
screws and wall plugs provided.
Using the Allen Key supplied loosen the three
locking screws on bracket. The camera can then
be positioned as required. When finished tighten
the locking screws to secure the camera.
IP-CAM920 Connections IP-CAM930 Connections
RJ45 Socket
(Weather-proof cap supplied)
RJ45 Socket
(Weather-proof cap supplied)
2.1mm DC Socket
2.1mm DC Socket
Audio In Phono Socket (pg. 17)
Audio Out Phono Socket (pg. 17)
Camera Reset Button
Analogue Video Test BNC Socket
Alarm In / Out (pg. 18)
 Up to 5MP Resolution
 Built in PoE
 2.8-12mm Varifocal lens
 2x IR LEDs / 60m range
 Motorised Zoom with
Auto Focus
 Alarm + Audio In/Out
 Micro SD Recording
+ Motorised Option

12 Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com
Universal Deep Bases
IP-CAM570 - Fixing Guide IP-CAM815 - Fixing Guide
IP-CAM910/920/930 - Fixing Guide
The universal deep bases are designed to fit the majority of the Zip
camera range. They make installation and maintenance much easier as
all connections are made inside the base. There are wall/ceiling mount
and pole mount options available in black or white.
Mount the camera as shown on
page 6 .
However on step 3, use the flat screws provided
with the base to secure the camera to the base
rather than the mounting surface.
Mount the camera as shown on page 8 .
However on step 3, use the flat screws provided
with the base to secure the camera to the base
rather than the mounting surface.
Use the flat screws provided with the base to
secure the camera to the base rather than the
mounting surface.
IP-CAM870/880 - Fixing Guide
Mount the camera as shown on page 9 .
However on step 3, use the flat screws provided
with the base to secure the camera to the base
rather than the mounting surface.

Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com 13
Universal Deep Bases
Wall & Ceiling Mounting Pole & Wall Bracket Mounting
1
First you’ll need to fix the camera to the base as
shown in “Wall & Ceiling Mounting” steps 2 and 3.
The universal deep bases
offer extra room for easy
termination and to disguise
cabling and connections
for a neat finish.
They are designed for
use with most of the Zip
range so you know it’ll be
a prefect fit.
Code:
IP-BASE001B (Black)
Code: IP-BASE001W (White)
A practical way to get the
ideal viewing angle. As well
as a wall bracket there are
200mm, 300mm and 500mm
ceiling brackets available.
Code: IP-BRKT001B (Wall)
Code: IP-BRKT001W (Wall)
Code: IP-BRKT200B (200mm)
Code: IP-BRKT200W (200mm)
Code: IP-BRKT300B (300mm)
Code: IP-BRKT300W (300mm)
Code: IP-BRKT500B (500mm)
Code: IP-BRKT500W (500mm)
3
Fix the camera to
the deep base as
described on the
opposite page.
Mark the fixing holes on
the mounting surface.
Drill and insert the four
anchor bolts provided.
With the bracket over
the anchor bolts, place
a washers, split ring
and then screw a nut
on to each exposed
thread to secure.
2
Screw the deep base
on to the end of the
ceiling/wall bracket.
Lock the base in-place
using the small slotted
grubs screws supplied.
When ceiling mounting
the mounting plates
is attached to the
opposite end of the
pole in the same way.
1
Screw through
the four holes in
the bottom of the
base and into the
mounting surface
using the screws
and wall plugs
provided.
x4 x4
x4
2
Thread the camera’s
cable through the
lid and through the
deep base. Screw
lid to the deep
base using the Hex
screws and Allen
key supplied with
the base.

14 Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com
How To Connect To A Non-PoE NVR
When connecting cameras to a non-PoE NVR, they are first connected to a network switch which is
in-turn connected to the NVR as shown below. The cameras are powered locally, from a PoE switch or
in-line with a PoE injector.
Router (Downlink)
Non-PoE
Network Switch
Non-PoE NVR
Switch Power
NVR Power
100m Max100m Max
100m Max (Uplink)
Non-PoE
IP Camera
Non-PoE
IP Camera
PSU PSU
From the Main Menu go to the Video menu and select Camera > IP Cameras .
1
Adding Cameras To A Non-PoE NVR
This is also the method used when connecting PoE cameras through a switch or non Zip IP cameras.

Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com 15
How To Connect To A Non-PoE NVR
Click Auto Assign IP to Camera(s) . In the dialogue box you will be asked to enter the User Name
and Camera Password for the camera(s) you are looking to add. If multiple cameras have the same
credentials they will all be added at the same time. Once entered click OK .
Zip IP Camera Default Credentials
- User Name: admin / Password: 777777
2
Finished! After a few seconds all successfully added cameras will display in the camera list. From
here you can also edit individual camera network settings if required without the need of a PC.
3

16 Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com
How To Connect To A PoE NVR
When connecting PoE cameras to a PoE NVR they are connected directly to one of the PoE ports on
the NVR as shown below. Non-PoE cameras can also be added in this way with the use of PoE splitters.
PoE IP
Camera
PoE IP
Camera
PoE IP
Camera
100m Max
100m Max
100m Max
100m Max
(Uplink)
NVR Power
PoE Splitter
12V DC
Non-PoE Network
Switch / Router
Router (Downlink)
O
ther Ethernet IP Devices (Downlink)
PoE NVR
100m Max
Non-PoE
IP Camer
a
Switch Power
Adding Cameras To A PoE NVR
From the Main Menu go to Setup > Network > Switch . Set the Switch Mode to “Auto Mode” , and
click Save . Wait a few seconds for the cameras to be discovered and that’s it, easy.
1
Note: If you’re connecting through a switch or non Zip IP cameras follow steps 1 to 3 on page 14.

Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com 17
How To Connect A Camera’s Audio
The pro motorised lens Zip IP cameras feature audio in and out (IP-CAM530, 880 and 930).
The audio input allows you to install a microphone at the camera location. The audio is then sent with
the camera’s image back to the NVR for video and audio recording.
The audio out is a useful feature as it lets you talk-back to site. A microphone is connected to the NVR’s
Line In and the audio is sent to the selected camera, through the audio out phono to a connected
loudspeaker. You can even talk-back through the Zip remote software and mobile apps.
How To Enable Audio Recording
From the Main Menu go to Video > Encoding > Mainstream . Select a camera with a microphone
connected from the Camera drop down list, tick the Audio check-box and click Save .
1
Note: The audio check-box will only be displayed if the selected camera has a microphone connected.
PoE IP
Camera
Microphone
At Camera
Microphone
At NVR
Line In
Loudspeaker
100m Max
PoE NVR
Camera Audio
Talk-back

18 Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com
How To Connect A Camera’s Alarm Inputs/Outputs
The pro motorised lens Zip IP cameras feature alarm in and out (IP-CAM530, 880 and 930).
The camera’s alarm inputs and outputs can be handled by the NVR in the same way as local alarms. The
camera’s alarm input can also be used to trigger local SD card recording in the camera itself. For more
information see the Zip IE browser manual (page 19).
How To Setup Alarm Handling
From the Main Menu go to Setup > Alarm . From the Alarm Input drop down list you can choose
the camera’s IP address as an alarm input when an alarm trigger is connected to the camera.
1
Set the Alarm Type to match that of the alarm trigger, Dwell Time , Audio Warning , Post
Recording time, alarm handling e.g. Send Email and which channel(s) you wish to record.
2
Click Alarm IO Scheduler to set the alarm schedule. The alarm will be active during the periods
marked in red. Finally click Trigger Alarm Out to automatically trigger an alarm output. Choose
one of the NVR’s local outputs or a camera’s alarm output by selecting the camera’s IP address.
3
PoE IP
Camera
Alarm Input
e.g. PIR
Alarm Output
e.g. VoiceO
Loudspeaker
100m Max
PoE NVR
Alarm Out - NO
Alarm In - Com
Alarm In - NO / NC
Alarm Out - Com
Alarm Connections

Get more from your Zip NVR with our Free CCTV tips at ZipNVR.com 19
Extra Resources
Zip NVR Quick Start Guide
The Zip NVR quick start
guide is full of helpful
information, diagrams
tips and how to guides to
get up and running with
your NVR.
Visit ZipNVR.com or scan
the QR for your copy.
NVR & Camera IE Browser Manual
The browser manual shows
you how to configure and
control your Zip NVR and
cameras through the
Windows Internet Explorer
internet browser.
Visit ZipNVR.com or scan
the QR for your copy.
Zip Camera Manual
You can also download a digital
copy of this very manual. Ideal
as a safeguard if this manual is
misplaced or maybe you’d like
a copy for somebody else.
Visit ZipNVR.com or scan
the QR for more copies.
Free Phone & Tablet Apps
Easy to use, Ideal for remote
monitoring. Search “
Zip
Vision ” or scan the QR code.
Android
iPhone
ZipNVR.com
The Zip NVR website is a great resource when in need of a little extra help and guidance. There’s
information on the cameras and NVRs, manuals, software, tools and support. Just visit www.ZipNVR.com

www.ZipNVR.com
© Copyright System Q Ltd 2019
All specications are approximate. We reserves the right to change
any product specications or features without notice. Whilst every
eort is made to ensure that these instructions are complete
and accurate, we cannot be held responsible in any way for any
losses, no matter how they arise, from errors or omissions in
these instructions, or the performance or non-performance of the
equipment that these instructions refer to.
WEE/CG0783SS
This symbol on the products and/or
accompanying documents means that used
electronic equipment must not be mixed
with general household waste. For treatment,
recovery and recycling please return this unit to
your trade supplier or local designated collection
point as dened by your local council.
Internal use only
For more information on the Zip
product range visit www.ZipNVR.com
or scan the QR code to the left.
Zippy by name...
...Zippy by nature!
ZipNVR.com
