Introduction
1.1 SEE995
The SEE995 has a motorised lens so that you can set the zoom and focus from the
DVR. With 4-in-1 technology design means you can set the output signal to either
TVI, CVI, AHD or CVBS.
Built in twin IR arrays provide 40m of night time vision to get 24/7 performance on
these new eyeballs.
This 5MP model is a perfect match for higher spec DVRs such as the new Zip Supa
DVR that can record in 5MP quality. Pick this model for finer detailing if your
business relies on its CCTV to protect employees or stock.
Tools & Handy Extras
· Screwdriver
· Drill
· 12V DC PSU
· Drill bits
· BNC Crimp Tool & BNCs
· RG59 Coax Cable
· Digital Multi-Meter
· LCD400K - CCTV Test monitor

24/10/2023
4
SEE995
ZipDVR.com
Connections & Dipswitches
The camera has a 2.1mm socket which requires 12V DC, use a regulated power
supply rated above the current draw of the camera.
The camera is polarity sensitive so connections must be correctly made.
The camera has a standard BNC connector for the 4-in-1 video output, the output can
be changed to AHD, CVIor CVBS if required.
Dipswitch 4-In-1 Technology
Selectable HD-TVI, HD-CVI, AHD and CVBS (Analogue) Output. As default the
camera is set to HD-TVI, however the output can be changed to AHD, CVIor CVBS
if required.
This output can be changed with the dip switches on the fly-lead of the camera.
Please note the “Output Mode” in the menu of the DVR won’t change the format, as
the dip switch overrides the output.
The dip switch configuration can be found below:-

© 2023 System Q Ltd
5
Index
ZipDVR.com
Mounting
5.1 Eyeball
A template is provided in the box for marking the hole positions for the fixing screws.

24/10/2023
6
SEE995
ZipDVR.com
Motorised Lens
To access the Motorised Lens via coaxitron:-
1. Click on the image in Live view
2. Click on the PTZ button at the bottom of the screen
3. Use Zoom + and - to zoom in and out, the camera should automatically focus
when Zoom +/- is released

© 2023 System Q Ltd
7
Index
ZipDVR.com
OSD Menu
Access to the camera menu is by Coaxitron. For the ZIP DVRs, ZIP Coaxitron is set
as default.
To access the Cameras Menu via coaxitron:-
1. Click on the image in Live view
2. Click on the PTZ button at the bottom of the screen
3. Click on the IRIS + / centre button to display the menu
Use the directional arrows to move up
and down through the menu.
Use the directional arrows left and right to
change the option.
Use IRIS + to select & enter that menu
option.

24/10/2023
8
SEE995
ZipDVR.com
7.1 5MP OSD Menu Motorised
AE
BRIGHTNESS
0 ~ 100 (Default 34)
EXPOSURE MODE
GLOBAL /
BLC
0 ~ 7 (Default 4)
RETURN
AF
AF MODE
SEMI / AUTO / MANUAL
ZOOM
- / +
FOCUS
- / +
BOOT MODE
SAVE POS / WIDE END / TELE END /
TDN AD
OPEN / CLOSE
FOCUS TRIGGER
SELECT (IRIS +)
LENS INIT
SELECT (IRIS +)
RETURN
AWB
MODE
PRO / GREYWORLD
RGAIN
0 ~ 100 (Default 50)
BGAIN
0 ~ 100 (Default 50)
DAY / NIGHT
MODE
EXT / COLOR / B/W
RETURN
IMAGE ENHANCE
CONTRAST
AUTO /
MANUAL
0 ~ 20 (Default 5)
SHARPNESS
AUTO /
MANUAL
0 ~ 20 (Default 3)
SATURATE
AUTO /
MANUAL
0 ~ 20 (Default 10)
3DNR
AUTO /
MANUAL
0 ~ 20 (Default 13)

© 2023 System Q Ltd
9
Index
ZipDVR.com
2DNR
AUTO /
MANUAL
0 ~ 20 (Default 19)
RETURN
VIDEO SETTING
HD
NO ADJUSTMENT SEE 4-IN-1 SWITCH
STANDARD
5MP 20 / 4MP 25 / 4MP 30 / 1080P 25 /
1080P 30 /
REBOOT & APPLY
RETURN
LANGUAGE
ENGLISH / SIMPLIFIED CHINESE / TRADITIONAL CHINESE /
RUSSIAN / SPANISH / FRENCH / POLISH / ITALIAN /
PORTUGUESE
WDR
OFF / ON
FUNC
PRIVACY
MODE
OFF / ON
AREA 0
CUSTOMISE
AREA 1
CUSTOMISE
AREA 2
CUSTOMISE
AREA 3
CUSTOMISE
COLOR
RED / GREEN / BLUE
TRANSPARENCY
OFF / ON
RETURN
RETURN
RESET
SAVE – EXIT
EXIT

24/10/2023
10
SEE995
ZipDVR.com
7.2 Key Menu Settings
Exposure Mode - AUTO / GLOBE / GLOBAL sets the required shutter speed for
the current light level. The shutter speed will automatically detect the required length
of time to keep the digital sensor exposed to light. FLK option sets the shutter speed
to stop synchronisation with lighting so that pulsing effect is minimised.
White Balance - Colour adjustment of the camera to be set up so objects appear a
natural colour. ATW / PRO (Automatic tracking white balance) continually tracks and
adjusts the white balance, making it suitable for use in cameras in which the image
content and lighting are subject to changes.
Day & Night - The camera can be set to colour or B&W mode or have it
automatically switch External is set as default, the switch between colour and black &
white is controlled by an external trigger In this a light dependent resistor.
DNR (Noice Reduction) - Noise Reduction is the process of removing noise from
the video signal by applying a digital filter. 2D noise reduction reduces noise in the
foreground of the image where as 3D noise reduction reduces noise in both the
foreground and the background of the image.
D-WDR - Digitally adjusts the exposure in areas of the frame to maintain optimum
levels in both the dark and bright areas of an image.
NOTE - Some models may not have D-WDR function.
Reset - Defaults the camera to factory settings. This setting helps when fault finding
issues with the camera to ensure all settings are defaulted.

© 2023 System Q Ltd
11
Index
ZipDVR.com
Troubleshooting
8.1 Camera Rebooting / Turning Off
A. Check the voltage to the camera (under load) using a digital multi-meter, if below
10.8V then move the power supplycloser to the camera.
B. For 12V DC cameras, only use regulated power supply rated above the current
consumption, so that the camera is always receiving the correct supply which is rated
above the current consumption.
C. Use thicker gauge copper cabling to reduce the voltage drop to the camera, using
thicker cable will reduce the resistance between the camera and the power supply
and therefore reduce the voltage dropped along the cable.
8.2 Poor Quality Images
A. Check the video format the DVR (digital video recorder), then set the camera to
the relevant video format – see the 4-In-1 Technology
B. If set to CVBS, then this is a low quality video output for legacy systems (analogue
- CVBS), when using a 2 MegaPixel DVR or above then use another video format,
like HD-TVI.
C. Reset the camera menu via Zip Coaxitron – OSD Menu
D. Check if the DVR (digital video recorder) supports the resolution of the camera.
8.3 Image is Black & White
A. Check the video format your DVR supports, then set the camera to the relevant
video format – see the 4-In-1 Technology
B. Reset the camera menu via Zip Coaxitron OSD Menu
D. Check if the DVR (digital video recorder) supports the resolution of the camera.
8.4 NCD / No Image Displayed on Recorder
A. Check the voltage to the camera (under load) using a digital multi-meter, if below
10.8V then move the power supplycloser to the camera.
B. For 12V DC cameras, only use regulated power supply rated above the current
consumption, so that the camera is always receiving the correct supply which is rated
above the current consumption.
C. Use thicker gauge copper cabling to reduce the voltage drop to the camera, using
thicker cable will reduce the resistance between the camera and the power supply
and therefore reduce the voltage dropped along the cable.
7
7

24/10/2023
12
SEE995
ZipDVR.com
D. Ensure that the BNC – BNC lead that is connected between the camera and DVR
has no shorts between the ground and the centre core (positive) or open circuits
along the centre core (positive) or open circuits along the ground.
General Maintenance
· Routinely clean the camera to prevent dust build up as this can effect the
performance of the camera. It is recommended to use a damp non-abrasive
microfibre cloth.
· Routinely check the connections for power and data to ensure no water ingress and
corrosion.
· Check that the cameras are firmly attached to the wall or mounting bracket.
· Check playback in the recorder to ensure the camera is recording and triggering
properly.

© 2023 System Q Ltd
13
Index
ZipDVR.com
Specification
10.1 SEE995
Resolution
5MP
Lens Type
2.8-12mm Motorised
Image Output
1 Volt Peak-Peak 75 ohm
Min.Illumination
0 Lux IR On
Day/Night
Mechanical (True Day-Night)
IR Range
40m
Input Voltage
12V DC
Current Consumption
500mA (IR On)
IP Rating
IP66
Video Connection
BNC Socket
Power Connection
2.1mm DC Socket
WDR
Yes
Finish
White/ Black
Build
Metal
Dimensions
135mm (Diameter) x127mm (Height)

24/10/2023
14
SEE995
ZipDVR.com
Conditions
11.1 General Company Disclaimer
All specifications are approximate. System Q Ltd reserves the right to change any
product specifications or features without notice. Whilst every effort is made to
ensure that these instructions are complete and accurate, System Q Ltd cannot be
held responsible in any way for any losses, no matter howthey arise, from errors or
omissions in these instructions, or the performance or non-performance of the
equipment that these instructions refer to.
11.2 WEEE Declaration
This symbol on the products and/or accompanying documents means that used
electronic equipment must not be mixed with general household waste. For
treatment, recovery and recycling please return this unit to your trade supplier or
local designated WEE/CG0783SS collection point as defined by your local
council.
11.3 Copyright
© Copyright 2023
Zip is a registered trademark of System Q Ltd, Chesterfield. Derbyshire. S40 2WB
