Zip IP-CAM890 User manual

© 2023 System Q Ltd
IP-CAM890
Instruction Manual
ZipNVR.com

IP-CAM890
I
© 2023 System Q Ltd
ZipDVR.com
Table of Contents
Part 1 Introduction 1
1 Key Features - IP-CAM890 ............................................................................................... 1
2 Essential Tools and ZipFinder ......................................................................................... 1
Part 2 Connections and Dimensions 2
1 IP-CAM890 ...................................................................................................................... 2
Part 3 Mounting and SD Card Installation 3
1 Eyeball ........................................................................................................................... 4
Part 4 Setup Options 5
1 PoE ZIP NVR ................................................................................................................... 5
2 Non-PoE ZIP NVR ............................................................................................................ 6
Part 5 How to Login via Browser 7
Part 6 Browser Menu Settings 9
Part 7 Extra Resources 10
1 ZipNVR.com Website .................................................................................................... 10
2 Adding IP Cameras to a ZIP recorder ........................................................................... 10
3 AI Setup ........................................................................................................................ 10
4 ZIP Firmware ................................................................................................................ 11
Part 8 General Maintenance 12
Part 9 Specifications 13
1 IP-CAM890 ..................................................................................................................... 13
Part 10 Conditions 14
Index 15

© 2023 System Q Ltd
1
Index
ZipDVR.com
Introduction
1.1 Key Features - IP-CAM890
Attractive Compact IP Eyeball with Face Recognition & Detection
2.8-12mm IP Eyeball With iSense
· ANPR Built-in
· Facial Recognition*
· Micro SD Card Slot
· Audio In - Audio Out
· Human Detect & Vehicle Detect
· Perimeter Intrusion Detect
· Line Crossing Detection
· Stationary Object Detect
· Cross Counting
· Facial Recognition*
· Crowd Density Detect
· Queues Length Detect
· 2.8-12mm Motor lens
· 5MP
· IR
· Perfect for ZIP NVR Kits
1.2 Essential Tools and ZipFinder
To install this product you will need:
· Laptop / Windows PC
· Screwdriver
· Drill
· Hammer
· ZIP NVR or DVR
· PoE Switch / 12V DC power supply
· Ethernet CAT5/5e/6 Cable
ZipFinder - IP Camera Configuration Tool
ZipFinder is a Windows PC software for
discovering
and configuring IP cameras a network.
Use ZipFinder on non-PoE installs, to help problem
solving issues such as forgotten or unknown
IP Addresses.
To download visit ZipNVR.com

04/05/2023
2
IP-CAM890
ZipDVR.com
Connections and Dimensions
2.1 IP-CAM890
Powering the camera
Option 1 - Power the camera from 12V DC (via the 2.1mm DC Socket), the current
consumption is 750mA.
The camera is polarity sensitive so connections must be correctly made.
Option 2 - Power the camera using a PoE 48V RJ45 Socket
When connecting ZIP PoE NVR plug the camera directly into the NVRs built in PoE
switch.
The camera should automatically become visible after being connected for
approximately 1 minute.

© 2023 System Q Ltd
3
Index
ZipDVR.com
Dimensions
*Dimensions Exclude Bracket
Mounting and SD Card Installation
For local recording on the camera itself an SD card must be installed.
Recording time will vary dependent upon: SD card size and encoding settings
32GB SD Card 31 hours
64GB SD Card 62 hours
128GB SD Card (MAX) 124 hours
256GB SD Card (MAX) 248 hours
The camera can be set to only record when triggered via motion detection, alarm
input or AIsmart, this maximises the recording time achievable.
Remove power from the camera when inserting / removing the SD card.

04/05/2023
4
IP-CAM890
ZipDVR.com
3.1 Eyeball
A template is provided in the box for marking the hole positions for the fixing screws.

© 2023 System Q Ltd
5
Index
ZipDVR.com
Setup Options
4.1 PoE ZIP NVR
When connecting to a ZIP PoE NVR plug the camera directly into the NVR's built in
PoE switch.
The camera should automatically become visible after being connected for
approximately 1 minute.
The 100m distance for a camera can be increased when the PoE Mode is set to
EPoE.
In the menu on a ZIP PoE NVR go to:-
Video > IP Channels > PoE Mode

04/05/2023
6
IP-CAM890
ZipDVR.com
4.2 Non-PoE ZIP NVR
When connecting cameras to a Non-PoE NVR, they are first connected to an
external network switch which is in-turn connected to the NVR as shown below.
See Extra Resources for more information on Adding IP Cameras manually to
a ZIP Recorder.
10

© 2023 System Q Ltd
7
Index
ZipDVR.com
How to Login via Browser
The AIsmart features can be configured in a ZIP recorder or directly in the browser
interface of the camera (standalone)
Only one smart detection feature can be enabled at any given time.
See the NVR or DVR manual for information on configuring these features
with a ZIP recorder.
Follow the steps below for configuring the settings directly in the camera via a
browser for standalone setup.
You will need...
· Windows Based PC/ Laptop connected to router/ PoE switch
· ZipVision Pro App on Mobile Device
· PoE Switch connected to Network/ Router
· Ethernet network cable
· ZipFinder software, available via this link below:-
www.softcctv.com/store/Item/Zip-Finder-IP-CCTV-Security-Camera-Discovery-Tool
NOTE If the PC being used is on a different IP range to the PC then add the IP range
of the camera to the PC using the below guide:-
PDF Version :- http://www.cctvmanuals.com/pdf/tips/How_to_add_an_IP_Range.pdf
HTML Version :-
http://www.cctvmanuals.com/tips/How_to_add_an_IP_Range/index.html
1. Plug the camera's RJ45 port with a network cable into a PoE switch

04/05/2023
8
IP-CAM890
ZipDVR.com
2. Using ZipFinder on a Windows Based PC/ Laptop Search and then tick the
camera
3. Select Net Mode = DCHP, then click Modify
4. Search again, to get the updated IP address.
5. Select the IP address of the camera, Internet Explorer will pop-up, and ask to
download and install the plug-in.
6. Download, install and follow the steps for the plug-in installation, then re-load the
browser by selecting the IP address again.
5. Login to the IP Camera, the default login details are:-
User Name
admin
Password
777777

© 2023 System Q Ltd
9
Index
ZipDVR.com
Browser Menu Settings

04/05/2023
10
IP-CAM890
ZipDVR.com
Extra Resources
7.1 ZipNVR.com Website
The Zip NVR has a range of information on the cameras and NVRs, manuals,
software, tools and support:-
www.zipdvr.com
7.2 Adding IP Cameras to a ZIP recorder
How to guide on Adding IP Cameras:-
www.zipdvr.com/howto/TIP459-How-To-Add-IP-Cameras.html
7.3 AI Setup
See the ZIP NVR full manual for more information on AIrecognition setup;
Full Instruction Manual
https://systemq.com/PDF/manual/xZIP4.pdf

© 2023 System Q Ltd
11
Index
ZipDVR.com
7.4 ZIP Firmware
Firmware for the zip products are available online:-
www.zipdvr.com/firmware.html
Compare the firmware in the product against that available online.

04/05/2023
12
IP-CAM890
ZipDVR.com
General Maintenance
· Routinely clean the camera to prevent dust build up as this can effect the
performance of the camera. It is recommended to use a damp non-abrasive
microfibre cloth.
· Routinely check the connections for power and data to ensure no water ingress and
corrosion.
· Check that the cameras are firmly attached to the wall or mounting bracket.
· Check playback in the recorder to ensure the camera is recording and triggering
properly.

© 2023 System Q Ltd
13
Index
ZipDVR.com
Specifications
9.1 IP-CAM890
Image Sensor
1/ 2.7” Progressive CMOS
Resolution
5MP 2880(H)×1620(V)
Lens Type
2.8-12mm Motorised
Shutter
1/5 ~ 1/20000s
Day/Night
Mechanical (True Day-Night)
Min. Illumination
0 (With IR On)
IR Range
Up to 40m
Digital Noise
Reduction
3D DNR
Video
Compression
H.264 / H.265
Video Bitrate
8Kbps ~ 8Mbps
Stream Options
Mainstream, SubStream & MobileStream
Smart Feature
Perimeter Intrusion, Line Crossing, Pedestrian and Vehicle
Detection, Facial Detection, Facial Recognition, Licence Plate
Detection
System
Compatibility
ONVIF (Profile S, Profile G, Profile T)
Connection
RJ45 10M / 100M Ethernet PoE
SD Card
Micro SD Card Slot (up to 256GB)
Audio (RCA)
1 Input / 1 Output
Input Voltage
PoE or 12V DC 750mA (PSU Required)
Consumption
9W Max
Operating
Temperature
From -30 to 55 deg°C
Backlight
Control
BLC / D-WDR
Use
IP66 For External Use
Framerate
25fps (@50hz) / 30fps (@60hz)

04/05/2023
14
IP-CAM890
ZipDVR.com
Conditions
All specifications are approximate. System Q Ltd reserves the right to change any
product specifications or features without notice. Whilst every effort is made to
ensure that these instructions are complete and accurate, System Q Ltd cannot be
held responsible in any way for any losses, no matter howthey arise, from errors or
omissions in these instructions, or the performance or non-performance of the
equipment that these instructions refer to.
This symbol on the products and/or accompanying documents means that used
electronic equipment must not be mixed with general household waste. For
treatment, recovery and recycling please return this unit to your trade supplier or
local designated WEE/CG0783SS collection point as defined by your local
council.
© Copyright 2020
NiteDevil is a registered trademark of System Q Ltd, Chesterfield. Derbyshire. S40
2WB
