ZIPPY H1U Series User manual

PRODUCTS MANUAL
Product Type：
Switching Power Supply
Model Name：
H1U/P1X SERIES
Rev.:A1
P/N:

INDEX
1.1 Introduction page 2
1.2 Packing page 2
1.3 Model Designation page 2
1.4 Features page 3
1.5 Pre-Installation page 3
1.6 Pin Assignment page 4~5
1.7 SPECIFICATIONS page 6 ~7
1.8 Operational Procedure page 8
1.9 Troubleshooting & Maintenance page 9
1.10 Technical Support Page 10
1

1.1 INTRODUCTION
First of all, thank you for purchasing H1U/P1X Series –power supply.
The H1U/P1X Series power supply offer a maximum 300 watts of output power.
The power unit’s size is compact and both power modules built one interior
40X20 m/m ball bearing DC fans. Total set has designed with 6 outputs including
+12V, +5V, +3.3V, -12V, -5V & +5VSB circuits
To really discover the power and easy in using these products, we recommend
that you read through this manual carefully.
1.2 PACKING
Your H1U/P1X box package should consist of the following:
(A) H1U/P1X *1
(B) Accessory pack *1
(C) Products’ manual *1
1.3 MODEL DESIGNATION
Model number identification:
H1U-6xxxP/P1X-6yyyP
H1U/P1X --- Model name
6--- For 6 DC outputs (5V/12V/-12V/-5V/3.3V/5VSB) for
ATX12V / EPS12V Spec.
xxx --- Total output power,150, 200, 250 (unit: watt)
yyy --- Total output power,200, 250, 300 (unit: watt)
P --- Active Power Factor Correction Design
2

1.4 FEATURES
Dimension :H1U - 155mm(D)×100mm(W)×40mm(H)
P1X - 190mm(D)×100mm(W)×40mm(H)
EN 61000-4-2(ESD) Criterion B, ±4KV by contact, ±8KV by air.All circuit
been designed in the power module
EN 61000-4-4(EFT) Criterion B, ±1KV.
EN 61000-4-5(SURGE) Criterion B, Line-Line ±1KV,Line-Earth ±2KV.
Remote sensing design
Meet FCC, CISPR EMI regulation
Space save design
One 40X20 m/m ball bearing DC fan
1.5 PRE-INSTALLATION
Before installing the H1U/P1X unit into the system chassis, please review the
following drawings page 4~ 9and find out the best way to match them.
3

1.6 Pin Assignment
Always check the socket and pin assignment (for devices such as motherboard, Hard Disk etc.)
before connecting the two heads.
4

5

1.7 SPECIFICATIONS
INPUT CHARACTERISTICS: H1U-6150/6200/6250P
A、INPUT CHARACTERISTICS：
1VOLTAGE：90～264VAC FULL RANGE
2 FREQUENCY：47～63HZ
3 INPUT CURRENT：4A(RMS) FOR 115VAC, 2 A (RMS) FOR 30VAC.
4 INRUSH CURRENT：65A MAX. FOR 115 VAC, 130A MAX. FOR 230 AC.
B、OUTPUT CHARACTERISTICS：
OUTPUT
OUTPUT CURRENT
REGULATION
OUTPUT RIPPLE &
VOLTAGE
MIN.
MAX.
LOAD
LINE
NOISE MAX. [P-P]
+5V
3
16/20/23
±5%
±1%
50mV (P-P)
+12V
2
9/12/16
±5%
±1%
120mV (P-P)
-12V
0.1
0.5
±10%
±1%
120mV (P-P)
-5V
0
0.2
±10%
±1%
50mV (P-P)
+3.3V
1
10/14/14
±5%
±1%
50mV (P-P)
+5Vsb
0.1
2
±5%
±1%
50mV (P-P)
REMARK: +5V AND +3.3V TOTAL OUTPUT MAX: 100W/130W/150W
C、SPECIFICATION
* TEMPERATURE RANGE：OPERATING 0℃～40℃, STORAGE -20℃~80℃
* HOLD UP TIME：16mS MIN. AT FULL LOAD & NOMINAL INPUT VOLTAGE
*EFFICIENCY：70% TYPICAL，AT FULL LOAD
* POWER GOOD SIGNAL：ON DELAY 100mS TO 500mS，OFF DELAY 1mS
* OVER POWER PROTECTION：110～150% MAX(Each Power Unit)
* OVER VOLTAGE PROTECTION: +5V→5.7~6.5V, +3.3V→3.7~4.3V, +12V→12.8~15V
* SHORT CIRCUIT PROTECTION: A short circuit placed on +5V,+3.3V,+12V output
* SAFETY: MEET UL62368, TUV EN-62368, CB IEC 62368
* DIMENSION: 155mm(D)×100mm(W)×40mm(H)
6

INPUT CHARACTERISTICS: P1X-6200/6250/6300P
A、INPUT CHARACTERISTICS：
1VOLTAGE：90～264VAC FULL RANGE
2 FREQUENCY：47～63HZ
3 INPUT CURRENT：4A(RMS) FOR 115VAC, 2 A (RMS) FOR 30VAC.
4 INRUSH CURRENT：65A MAX. FOR 115 VAC, 130A MAX. FOR 230 AC.
B、OUTPUT CHARACTERISTICS：
OUTPUT
OUTPUT CURRENT
REGULATION
OUTPUT RIPPLE &
VOLTAGE
MIN.
MAX.
LOAD
LINE
NOISE MAX. [P-P]
+5V
3
23
±5%
±1%
50mV (P-P)
+12V
2
12/16/20
±5%
±1%
120mV (P-P)
-12V
0.1
0.5
±10%
±1%
120mV (P-P)
-5V
0
0.2
±10%
±1%
50mV (P-P)
+3.3V
1
14
±5%
±1%
50mV (P-P)
+5Vsb
0.1
2
±5%
±1%
50mV (P-P)
REMARK: +5V AND +3.3V TOTAL OUTPUT MAX: 25A
C、SPECIFICATION
* TEMPERATURE RANGE：OPERATING 0℃～40℃, STORAGE -20℃~80℃
* HOLD UP TIME：16mS MIN. AT FULL LOAD & NOMINAL INPUT VOLTAGE
*EFFICIENCY：70% TYPICAL，AT FULL LOAD
* POWER GOOD SIGNAL：ON DELAY 100mS TO 500mS，OFF DELAY 1mS
* OVER POWER PROTECTION：110～150% MAX(Each Power Unit)
* OVER VOLTAGE PROTECTION: +5V→5.7~6.5V, +3.3V→3.7~4.3V, +12V→12.8~15V
* SHORT CIRCUIT PROTECTION: A short circuit placed on +5V,+3.3V,+12V output
* SAFETY: MEET UL62368, TUV EN-62368, CB IEC 62368
* DIMENSION: 190mm(D)×100mm(W)×40mm(H)
7

1.8 Operational Procedure
1. When removing four attached screws to install this product, please make sure not
removing fan or case screws by mistake.
2. Tighten four screws onto the computer case and double check for stability.
3. Check product specifications and calculate actual current requirements of each DC
voltage. Make sure these requirements fall within the minimum and maximum range of
power supply. If the current requirements are below the minimum load spec., the power
supply may not start up. If the current requirements are over the maximum load spec.,
our over protection circuitry will latch and shutdown the power supply.
4. Plug in power cord to the inlet of power supply.
H1U/P1X models have line power I/O rocker switch. Please set the switch to
“I”or “ON”to turn on line power.
Active Power Factor Correction (PFC) function is available for all power supply
models listed in this manual. The PFC function ensures maximum efficiency of
power usage to preserve energy and lower your electrical bills. It also
automatically adapts to a very wide range of AC line voltage: 100V to 240V AC.
(There are no manual switches for you to select AC input). This unique design
ensures you can use our power supplies anywhere in the world.
5. You can start up the power supply remotely by using “Remote on”.
8

1.9 Troubleshooting & Maintenance
SYMPTOM
COUNTERMEASURE
No power?
After plug main connector, such as 24-pin or 20-pin and aux.
connectors if needed, to motherboard socket, make sure AC
power cord gets AC line source that is on wall outlet, to this
product power supply. If AC power cord gets AC line source
through power bar or UPS, turn on these devices first.
Check I/O switch of power supply panel to “I”or “ON”.
Boot system from computer case I/O.
Check product specifications and calculate actual current
requirements of each DC voltage. Make sure these requirements
fall within the minimum and maximum range of power supply.
(i) If the current requirements are below the minimum load
spec., the power supply may not start up. Increase load. (ii) If
the current requirements are over the maximum load spec., our
over protection circuitry will latch and shutdown the power
supply. Reduce load or use larger capacity power supply.
The power supply could be latched by self-protection function
(e.g. “over voltage”, “over current”, “overload”). Remove the
power cord, wait for 20 seconds or more to discharge its
electricity, then plug in the power cord again, try to restart the
computer.
9

1.10 Technical Support
To best serve our customers, there are several services available to suite your needs:
1. For detailed products specification: please visit www.zippy.com
2. For technical enquiries: please send e-mail to [e-mail]
3. For RMA service: please prepare following items before calling RMA
department,
Proof of purchase (original dated receipt)
Product serial number (SER. NO.) (Refer to the label on product and
diagram below)
Product part number (P/N)
Product model
Detailed description of problems
Note:
Different distributors or resellers have their specific RMA terms and conditions;
please contact them for detailed information.
4. Please feel free to contact us via e-mail should you encounter any technical
problems beyond the scope of this user manual. Please visit www.zippy.com for
more detailed information.
10
