Ziton ZP2 Series User manual

ZP2 Series Installation
Manual
P/N 00-3251-501-0003-04 • ISS 04MAY15

Copyright
©
2015 UTC Fire & Security. All rights reserved.
Trademarks and
patents
ZP2
Series is a trademark of UTC Fire & Security.
Other trade names used in this document may be trademarks or
registered trademarks of the manufacturers or vendors of the
respective products.
Manuf
acturer
UTC CCS Manufacturing Polska Sp. Z o.o.
Ul. Kolejowa 24. 39
-100 Ropczyce, Poland
Authorized EU manufacturing representative:
UTC Fire & Security B.V. Kelvinstraat 7, 6003 DH Weert,
Netherlands
Version
REV
04b.
This document covers control panels with firmware version
3.5 or later.
Certification
European Union
directives
2004/108/EC (EMC directive). Hereby, UTC Fire & Security declares
that this device is in compliance with the essential requirements an
d
other relevant provisions of Directive 2004/108/EC.
2012/19/EU (WEEE directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the European
Union. For proper recycling, return this product to your local
supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that
cannot be disposed of as unso
rted municipal waste in the European
Union. See the product documentation for specific battery
information. The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, retu
rn the battery to your supplier or to a
designated collection point. For more information see:
www.recyclethis.info.
Contact information
For contact information, see www.utcfssecurityproducts.eu.

ZP2 Series Installation Manual i
Content
Important information ii
Chapter 1 Introduction 1
Product range 2
Product compatibility 3
Product overview 4
Chapter 2 Installation 15
Electrical safety 16
Cabinet and PCB layout 17
Cabinet installation 19
Connections 24
Chapter 3 Configuration and commissioning 35
Introduction 36
Maintenance level operation and configuration 39
Installer level operation and configuration 53
Commissioning 107
Chapter 4 Maintenance 109
Fire alarm system maintenance 110
Battery maintenance 111
Chapter 5 Technical specifications 113
Appendix A Default configurations 123
Appendix B PSTN country codes 125
Appendix C Menu maps 127
Appendix D Regulatory information 137
Index 139

ii ZP2 Series Installation Manual
Important information
Introduction
This is the installation manual for the ZP2 Series fire alarm, repeater, and
evacuation control panels. Read these instructions and all related documentation
entirely before installing or operating this product.
Firmware compatibility
Information in this document covers control panels with firmware version 3.5 or
later. This document must not be used as a guide to installation, configuration, or
operation of control panels with an earlier firmware version.
To check the firmware version of your control panel, see the Revision report in
the Reports menu.
Limitation of liability
To the maximum extent permitted by applicable law, in no event will UTCFS be
liable for any lost profits or business opportunities, loss of use, business
interruption, loss of data, or any other indirect, special, incidental, or
consequential damages under any theory of liability, whether based in contract,
tort, negligence, product liability, or otherwise. Because some jurisdictions do not
allow the exclusion or limitation of liability for consequential or incidental
damages the preceding limitation may not apply to you. In any event the total
liability of UTCFS shall not exceed the purchase price of the product. The
foregoing limitation will apply to the maximum extent permitted by applicable law,
regardless of whether UTCFS has been advised of the possibility of such
damages and regardless of whether any remedy fails of its essential purpose.
Installation in accordance with this manual, applicable codes, and the instructions
of the authority having jurisdiction is mandatory.
While every precaution has been taken during the preparation of this manual to
ensure the accuracy of its contents, UTCFS assumes no responsibility for errors
or omissions.
Advisory messages
Advisory messages alert you to conditions or practices that can cause unwanted
results. The advisory messages used in this document are shown and described
below.
WARNING: Warning messages advise you of hazards that could result in injury
or loss of life. They tell you which actions to take or to avoid in order to prevent
the injury or loss of life.

ZP2 Series Installation Manual iii
Caution: Caution messages advise you of possible equipment damage. They tell
you which actions to take or to avoid in order to prevent the damage.
Note: Note messages advise you of the possible loss of time or effort. They
describe how to avoid the loss. Notes are also used to point out important
information that you should read.

iv ZP2 Series Installation Manual

ZP2 Series Installation Manual 1
Chapter 1
Introduction
Summary
This chapter provides an introduction to your control panel, the main controls,
and the indicators.
Content
Product range 2
Product compatibility 3
Product overview 4
The user interface 4
Front panel controls and indicators 6
LCD controls and indicators 10
Acoustic indicators 12
Conditions 12

Chapter 1: Introduction
2 ZP2 Series Installation Manual
Product range
The series includes the fire alarm, repeater, and evacuation panels shown below.
Table 1: Fire alarm, repeater, and evacuation panels
Model
Description
ZP2
-E1(-S) [1] One-loop addressable fire and evacuation alarm control panel
ZP2
-E2(-S) Two-loop addressable fire and evacuation alarm control panel
ZP2
-ER(-S) Addressable fire and evacuation alarm repeater panel
ZP2
-F1(-S) One-loop addressable fire alarm control panel
ZP2
-F1-FB2(-S) One-loop addressable fire alarm control panel with fire routing and fire
protection controls
ZP2
-F1-SCFB(-S) One-loop addressable SS 3654 fire alarm control panel with fire routing
and fire protection controls [2]
ZP2
-F2(-S) Two-loop addressable fire alarm control panel
ZP2
-F2-PRT Two-loop addressable fire alarm control panel with internal printer
ZP2
-F2-FB2(-S) Two-loop addressable fire alarm control panel with fire routing and fire
protection controls
ZP2
-F2-FB2-PRT Two-loop addressable fire alarm control panel with fire routing and fire
protection controls and internal printer
ZP2
-F2-SCFB(-S) Two-loop addressable SS 3654 fire alarm control panel with fire routing
and fire protection controls [2]
ZP2
-F2-SCFB-PRT Two-loop addressable SS 3654 fire alarm control panel with fire routing
and fire protection controls and internal printer [2]
ZP2
-FR(-S) Addressable fire alarm repeater panel
ZP2
-FR-FB2(-S) Addressable fire alarm repeater panel with fire routing and fire protection
controls
ZP2
-FR-SCFB(-S) Addressable SS 3654 fire alarm repeater panel with fire routing and fire
protection controls [2]
[1] (
-S) indicates that large and small cabinet models are available. See Chapter 5 “Technical
specifications
” on page 113 for cabinet dimensions.
[2] Includes a fireman's key.
Repeater functionality
All control panels in a fire network can be configured for repeater functionality,
provided that they have a network board installed. For more information, see
“Firenet configuration” on page 56.
Fire routing and fire protection control and indication
In this document, information on control and indication for fire routing and fire
protection applies only to control panels that include those features.

Chapter 1: Introduction
ZP2 Series Installation Manual 3
Product compatibility
Products compatible with these control panels are listed in the supplied
compatibility list. Only those products specified in the compatibility list are
guaranteed to be compatible with these control panels. For further details contact
your local supplier.

Chapter 1: Introduction
4 ZP2 Series Installation Manual
Product overview
This topic provides an introduction to the control panel user interface, LCD,
operator controls, and indicators.
For a detailed overview of front panel controls and indicators, see “Front panel
controls and indicators” on page 6.
The user interface
Figure 1: Fire panel user interface (with fire routing and fire protection controls)
1
. Supply LED
2
. General Test LED
3
. General Disable LED
4
. General Fault LED
5
. Alarm LED
6
. LCD
7
. Sounder Delay button and LED
8
. Sounder Fault/Disabled/Test LED
9
. Programmable output group start/stop
button and LED
10
. Jog dial and function buttons
11
. Reset button and LED
12. Panel Silence button and LED
13. Sounder Start/Stop Button and LED
14. System Fault LED
15. Low Battery LED
16. Earth Fault LED
17. Supply Fault LED
18. Fire Protection Fault/Disabled/Test LED
19. Fire Protection Delay button and LED
20. Fire Protection On/Acknowledged button
and LED
21. Fire Routing Fault/Disabled/Test LED
22. Fire Routing Delay button and LED
23. Fire Routing On/Acknowledged button and
LED
See “Assigning an output group to a programmable button” on page 93 for more
information on configuring programmable buttons.

Chapter 1: Introduction
ZP2 Series Installation Manual 5
Figure 2: Evacuation panel user interface
1
. Supply LED
2
. General Test LED
3
. General Disable LED
4
. General Fault LED
5
. Alarm LED
6
. LCD
7
. Sounder Delay button and LED
8
. Sounder Fault/Disabled/Test LED
9
. Confirm button
10
. All Output Groups Start/Stop Button and
LED
11
. Programmable output group start/stop
buttons and LEDs
12
. Jog dial and function buttons
13. Reset button and LED
14. Panel Silence button and LED
15. Sounder Start/Stop Button and LED
16. System Fault LED
17. Low Battery LED
18. Earth Fault LED
19. Supply Fault LED
20. Fire Protection Fault/Disabled/Test LED
21. Fire Protection Delay button and LED
22. Fire Protection On/Acknowledged button
and LED
23. Fire Routing Fault/Disabled/Test LED
24. Fire Routing Delay button and LED
25. Fire Routing On/Acknowledged button and
LED
See “Assigning an output group to a programmable button” on page 93 for more
information on configuring programmable buttons.

Chapter 1: Introduction
6 ZP2 Series Installation Manual
Configuration options
Depending on your configuration, the labels for some interface buttons may
change. See Table 2 below.
Table 2: Configured changes to interface buttons and LEDs
Item
EN 54 NEN 2575
10
All Output Groups Start/Stop All Evacuation Start/Stop
11
Programmable output group start/stop Evacuation area sounders start/stop [1]
15
Sounder Start/Stop Fire Sounder Start/Stop
[1]
If the evacuation panel is operating in NEN 2575 mode, only sounder output groups can be
associated with the programmable start/stop buttons.
Front panel controls and indicators
Operational features described in this section are not available to all users. More
information on control panel operation and access restrictions can be found in
the topic “User levels” on page 36.
Common controls and indicators
The table below includes information for the common controls and indicators
available for fire, repeater, and evacuation panels.
Table 3: Common controls and indicators
Control/LED
LED colour Description
Supply LED
Green Indicates that the system is powered up.
General Test LED
Yellow Indicates that one or more features or devices are
being tested.
General Disable LED
Yellow Indicates that one or more features or devices are
disabled.
General Fault LED
Yellow Indicates a general fault. The fault LED for the
corresponding device or feature also flashes.
Alarm
LED Red Indicates a fire alarm.
A flashing LED indicates that the alarm was activated
by a detector. A steady LED indicates that the alarm
was activated by a manual call point.
Fire Routing
On/Acknowledged
button and LED
Red Cancels a previously configured delay as it counts
down and activates fire routing.
A flashing LED indicates that fire routing has been
activated. A steady LED indicates that the fire routing
signal has been acknowledged by the remote
monitoring equipment.

Chapter 1: Introduction
ZP2 Series Installation Manual 7
Control/LED
LED colour Description
Fire Routing Delay
button an
d LED
Yellow Enables or disables a previously configured fire routing
delay. Cancels a delay as it counts down and activates
fire routing.
A steady LED indicates that a delay is configured and
enabled. A flashing LED indicates that a delay is
counting (fire routing is activated when the configured
delay elapses or when the delay is cancelled).
The countdown for an active (counting) fire routing
delay or extended fire routing delay is also displayed on
the product LCD (see Figure 3 on page 10):
•When a fire routing delay is counting (and has not
been extended), the LCD displays FR in T1: xxx
sec.
•When an extended fire routing delay is counting
(investigation time), the LCD displays FR in
T2: xxx
sec.
Fire Routing
Fault/Disabled/Test
LED
Yellow Indicates a fire routing fault, disablement, or test.
A flashing LED indicates a fault. A steady LED indicates
a disablement or a test.
Fire Protection
On/Acknowledged
button and LED
Red Cancels a previously configured delay as it counts
down and activates fire protection.
A flashing LED indicates that fire protection has been
activated. A steady LED indicates that the fire
protection signal has been acknowledged by the remote
monitoring equipment.
Fire Protection Delay
button and LED
Yellow Enables or disables a previously configured fire
protection delay. Cancels a delay as it counts down and
activates fire protection.
A steady LED indicates that a delay is configured and
enabled. A flashing LED indicates that a delay is
counting (fire protection is activated when the
configured delay elapses or when the delay is
cancelled).
Fire Protection
Fault/Disabled/Test
LED
Yellow Indicates a fire protection fault, disablement, or test.
A flashing LED indi
cates a fault. A steady LED indicates
a disablement or a test.
Sounder Delay button
and LED
Yellow Enables or disables a previously configured sounder
delay. Cancels a delay as it counts down and activates
sounders.
A steady LED indicates that a sounder delay is
configured and enabled. A flashing LED indicates a
delay is counting (sounders are activated when the
configured delay elapses or when the delay is
cancelled).
Sounder
Fault/Disabled/Test
LED
Yellow Indicates a sounder fault, disablement, or test.
A flashing LED indicates a fault. A steady LED indicates
a disablement or a test.

Chapter 1: Introduction
8 ZP2 Series Installation Manual
Control/LED
LED colour Description
Programmable
start/stop
button and
LED
Yellow Starts or stops the the output group associated with the
programmable button.
A steady yellow LED indicates that the output group
associated with the button is active. A flashing yellow
LED indicates that a delay is counting (the output group
is activated when the configured delay elapses or when
the delay is cancelled).
Supply Fault LED
Yellow Indicates a power supply fault.
A flashing LED indicates a battery fault. A steady LED
indicates a mains or mains fuse fault.
Earth Fault LED
Yellow Indicates an earth isolation fault.
Low Battery LED
Yellow Indicates that the control panel is running on battery
power and that the remaining charge may be
insufficient to guarantee continued operation.
System Fault LED
Yellow Indicates a control panel system failure.
Sounder Start/Stop
button and LED
Red The LED indicates what happens when the button is
pressed.
If the LED is on
(flashing or steady), pressing the button
silences the sounders.
If the LED is off, pressing the button activates the
sounders (if the control panel status and operating
mode allow manual activation of sounders).
The LED also indicates the status of the sounders:
•
Steady indicates that sounders are active (or will be
activated shortly)
•Flashing indicates that a delay is counting
(sounders are activated when the configured delay
elapses or when the delay is cancelled)
•Off indicates that the sounders are off (or will be
deactivated shortly)
To prevent the immediate silencing of sounders when
an alarm is first reported, the Sounder Start/Stop button
may be temporarily blocked when a configured sounder
delay is counting down. For more information, see
“Sounders silence disable time” on page 102.
Depending on the size of the installation, processing
commands to start or stop sounders may take a few
seconds to travel through the system. This is why, for
example, the LED may be steady but sounders may not
initially be audible.
Panel Silence button
and LED
Yellow Silences the control panel buzzer.
A steady LED indicates that the buzzer has been
silenced.
Reset button and LED
Yellow Resets the control panel and clears all current system
events.
A steady LED indicates that the control panel can be
reset in the current user level.

Chapter 1: Introduction
ZP2 Series Installation Manual 9
Evacuation panel controls and indicators
The table below includes information for the additional controls and indicators for
evacuation panels.
Note: If the evacuation panel is operating in NEN 2575 mode, only sounder
output groups can be associated with the programmable start/stop buttons.
Table 4: Evacuation panel controls and indicators
Control/LED
LED colour Description
Confirm button
Confirms the starting or stopping of the output group
associated with a programmable button (when pressed
with the corresponding programmable button).
Confirms the starting or stopping of all output groups
associated with all programmable buttons (when
pressed with the All Output Groups Start/Stop button).
All Output Groups
Start/Stop button and
LED
Red Starts or stops all output groups associated with the
programmable buttons (when pressed with the Confirm
button).
A steady red LED indicates that all output groups
associated with the buttons are active. A flashing red
LED indicates that a delay is counting (the output
groups are activated when the configured delay elapses
or when the delay is cancelled).
Programmable
start/stop
buttons and
LEDs
Red/Yellow Starts or stops the the output group associated with the
programmable button (when pressed with the Confirm
button).
A steady red LED indicates that the output group
associated with the button is active. A flashing red LED
indicates that a delay is counting (the output group is
activated when the configured delay elapses or when
the delay is cancelled).
A flashing yellow LED indicates a fault. A steady yellow
LED indicates a disablement or a test.
Output group LED indications
The control panel can be configured to have several sounder, fire routing, or fire
protection output groups. Some groups may use the same indicators. When such
groups have the same status, that status is indicated. In the case of conflicting
status, the highest priority status is displayed.
Note: For evacuation panels, indications for output groups associated with the
programmable buttons use the corresponding programmable button LEDs.
The following examples illustrate this operation.
There are three sounder output groups, the first in fault status, the second in
delayed status, and the third in activated status. The sounder indications display
the fault status of the first group, the delay status of the second group, and the
activated status of the third group.

Chapter 1: Introduction
10 ZP2 Series Installation Manual
There are two fire routing output groups, the first is in activated status and the
second is in acknowledged status. The fire routing indication displays the
acknowledged status but not the activation status (the acknowledgement status
takes priority).
For more information on output groups, see “Output groups” on page 89.
LCD controls and indicators
Figure 3: LCD controls and indicators
1. Day/night mode indicator
2. System date and time (and active fire routing delay or extended fire routing delay countdown)
3. Control panel network status (stand-alone, networked, repeater)
4. Current alarm, fault, and condition events counter
5. Message display area
6. Soft keys (menu options linked to function buttons F1, F2, F3, and F4)
7. Jog dial
8. Function buttons F1, F2, F3, and F4
9. Local control panel ID (in a fire network)

Chapter 1: Introduction
ZP2 Series Installation Manual 11
Icons displayed on the LCD
Icons displayed on the LCD are shown below.
Table 5: LCD icons and descriptions
Icon
Description
Day mode (network)
This icon indicates that the primary sensitivity mode
setting for control panels in the fire network is day
mode.
Day mode (control panel)
This icon indicates that the
sensitivity mode for the local
control panel is day mode. Other control panels in the
fire network may have a different sensitivity mode
setting.
Night mode (network)
This icon indicates that the primary sensitivity mode
setting for control panels in the fire network is night
mode.
Night mode (control panel)
This icon indicates that the sensitivity mode for the local
control panel is night mode. Other control panels in the
fire network may have a different sensitivity mode
setting.
Fire alarms
The number beside this icon indicates the number of
zones with an active fire alarm. Alarm information for
the first and last zones to report an alarm is displayed in
the LCD message area.
Faults
The number beside this icon indicates the number of
active faults. Additional information is available by
pressing F1 (Show Events).
Conditions
The number beside this icon indicates the number of
active system conditions. Additional information is
available by pressing F1 (Show Events).
Stand-alone This icon indicates that the control panel is not
connected to the fire network.
Networked This icon indicates that the control panel is connected
to the fire network.
Repeater
This icon indicates that the control panel is configured
to operate as a repeater and is connected to the fire
network.
Detector alarm [1] This icon indicates a detector alarm.
Manual call point alarm [1] This icon indicates a manual call point alarm.
Manual call point alarm
(sprinkler) [1]
This icon indicates a manual call point alarm (sprinkler).
Manual call point alarm
(“hausalarm”) [1]
This icon indicates a manual call point alarm
(“hausalarm”). This is a local alarm with no fire routing
activation.
[1] These icons appear in the message display area with the notification details.

Chapter 1: Introduction
12 ZP2 Series Installation Manual
Indication of remote and local events on the LCD
The local control panel ID is always displayed on the LCD (see Figure 3 on page
10).
If your control panel forms part of a fire network, the event notification includes
the panel ID reporting the event as follows:
•If the panel ID matches the local ID, then the event relates to the local control
panel
•If the panel ID does not match the local ID, then the event is reported by the
remote control panel with the panel ID indicated
Repeater panels are installed only in fire networks and by default have a network
board installed. Fire alarm control panels must have a network board installed to
connect to a fire network.
Acoustic indicators
The control panel buzzer acts as an acoustic indicator to highlight system events.
Table 6: Control panel acoustic indicators
Indication
Description
The
buzzer sounds continuously Indicates a fire alarm or a system fault
The buzzer sounds intermittently (long tone) [1]
Indicates all other faults
The buzzer sounds intermittently (short tone) [1]
Indicates a condition
[1] A long tone is 50% ON and 50% OFF. A short tone is 25% ON and 75% OFF.
Conditions
A summary of system events logged as conditions is shown below.
Table 7: System events logged as conditions
Condition type
Description
Alert
A device is in alarm but the system is waiting for an
additional alarm event to confirm the zone alarm
Configuration device connected
A control panel configuration session is initiated via an
external device (PC, laptop, etc.)
Date and time not set
The system started but the date and time are not set
Disablements
A control panel feature or device is disabled
Event log full
The control panel event log is full
Extinguishing status [1]
Extinguishing is blocked, disabled, or has a fault
Extinguishing I/O device [1]
An extinguishing I/O device is active, being tested, is
disabled, or has a fault
Input activation
An input is activated (subject to configuration)

Chapter 1: Introduction
ZP2 Series Installation Manual 13
Condition type
Description
Loop device not configured
A loop device is detected that is not configured
Maximum conventional zones
exceeded in a network
The number of conventional zones in a fire network
exceeds the maximum allowed
Maximum loops exceeded in a
network
The number of loops in a fire network exceeds the
maximum allowed
New node in the fire network
A control panel has been added to the fire network
Output group activation
An output group is activated
Prealarm
A device (and corresponding zone) is in prealarm
Sounder, fire routing, and fire
protection delays
A sounder, fire routing, or fire protection delay is enabled or
disabled
Tests
A control panel feature or device is being tested
[1] These condition types only apply if an extinguishing panel is included in the fire network.
In addition to the above, the following system status events are also added to the
event log (but are not included in the control panel current events report).
Table 8: Other system status events added to the event log
Event
Description
Actions
An output group is activated or deactivated or a
programmable system command is executed (via the
Configuration Utility)
Conditions deactivation
A system condition is deactivated
General system events
The control panel is reset, the panel is silenced, a new date
and time is set, the system is initiated, etc.
Power supply
faults eliminated A previously logged power supply fault is resolved
Rules activation
A rule is activated [1]
User sessions
The date and time information for activation and termination
of user sessions
[1]
A rule consists of one or more states (combined by Boolean operators) that are configured to
trigger specific system actions after a specific confirmation time. Rules are created using the
Configuration Utility.

Chapter 1: Introduction
14 ZP2 Series Installation Manual
