Zline RWVZUD24CB User manual

User Manual
MONUMENT WINE &
BEVERAGE COOLERS
www.zlinekitchen.com

ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams
is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to
providing you an elevated experience in the heart of your home. With an endless selection of
features and finishes, our inspiration is your reality.

WARNING: This product can expose you to chemicals including nickel, which is known to the
State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury
designs and professional features into everyone’s homes. Because we continually strive to improve
our products, we may change specifications and designs without prior notice.

TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 1
OPERATION 8
CARE AND MAINTENANCE 10
TROUBLESHOOTING 12
WARRANTY 14

1
General Safety
IMPORTANT SAFETY INSTRUCTIONS
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury, or death.
WARNING
• Before beginning installation, please read and follow these important instructions for
the safety of your home and the people living in it. Always read and obey all safety
measures.
• It is recommended that installation and service be performed by a qualified installer.
The appliance should not be adjusted or repaired by anyone except properly
qualified service personnel.
• IMPORTANT: The installer should leave these instructions with the consumer who
should retain for local inspectors’ use and for future reference.
• The manufacturer will not be responsible for any damage to property or to persons
caused by incorrect installation, improper use of the appliance, or failure to heed the
warnings listed, and the warranty will be voided.
• The manufacturer reserves the right to make changes to its products when considered
necessary and useful, without affecting the essential safety and operating
characteristics.
• This appliance has been designed for non-commercial, domestic use only.
• Please observe all local, state, and national codes and ordinances. Please ensure the
appliance is properly grounded. The plug should always be accessible.
• Use this appliance only as described in this manual. Other uses not recommended
may cause fire, electric shock, or personal injury.
• This appliance is not intended for use by children unless they are adequately
supervised by a responsible person to ensure that they can use the appliance safely.
• Young children should be supervised to ensure that they never play with the
appliance.
• To protect against the risk of electric shock, never immerse the unit, cord, or plug in
water or spray with any cleaning product or other liquid.
• Unplug the appliance from the electrical outlet when not in use, when moving from
one location to another, and before cleaning.

2
IMPORTANT SAFETY INSTRUCTIONS
• To disconnect the appliance from power, grip the plug and pull it from the electrical
outlet. Never pull by the cord.
• Never operate the unit in the presence of explosive and/or flammable liquids or
fumes; doing so may create a fire hazard or explosion.
• Never install the unit or any of its parts near an open-flame, cooking, microwave, or
any other heating appliance.
• Never operate the unit with a damaged electrical cord or plug, if the product
malfunctions beyond simple troubleshooting measures, or if it is dropped or
damaged in any manner.
• The use of attachments not recommended by the manufacturer may be hazardous to
your safety.
• Never operate the unit if the door or cooling system is removed or damaged.
• A loose fit between the electrical wall outlet and plug may cause overheating and/
or a distortion of the plug. Contact a qualified electrician to replace loose or worn
electrical outlets.
• This appliance is CFC- and HFC-free and contains small quantities of isobutane
(R600a), an environmentally friendly coolant.
• You must ensure that the sealed cooling system is undamaged when installing the
appliance. If damaged, keep the product away from potential fire sources that may
cause it to catch fire and ventilate the room where the product is placed.
• Never use an appliance with a damaged cooling system. If system is damaged upon
arrival, contact ZLINE at 1-614-777-5004
• Ensure that the ventilation openings to and from a built-in wine cooler or beverage
cooler are never blocked or covered.
• No liability will be accepted for any damage caused by misuse of the appliance,
or as a result of repairs carried out by unqualified people. In this case, neither the
warranty nor any other liability claims will apply.
General Safety

3
IMPORTANT SAFETY INSTRUCTIONS
Never operate any other electrical appliance inside this unit.
WARNING
• Never attempt to repair or replace any part of your appliance unless it is specifically
recommended in this manual. All other servicing should be referred to a qualified
electrician, technician, or service provider.
• Ensure all access panels are appropriately installed before operating.
• It’s recommended to use two or more people to move and install the unit due to its
weight.
• Never clean the unit or its parts with flammable liquids. These fumes can create a fire
hazard or explosion.
• Never connect or disconnect the electric plug with wet hands.
• It’s recommended that a dedicated electrical circuit suitable for a NEMA 5-15 outlet
serving only your appliance be used; please ensure the outlet is easily accessible.
To reduce the risk of fire, electric shock or personal injury, unplug or
disconnect the appliance from the power supply before servicing.
WARNING
General Safety

4
SAVE THESE INSTRUCTIONS
This manual contains important information regarding the proper installation, use, and
maintenance of your beverage cooler and wine cooler. Following this manual will
ensure that your product will work at its peak performance and efficiency.
If you are experiencing problems, check the Troubleshooting Guide at the back of this
manual (pages 12-13). It lists causes of minor operating problems that you may solve
yourself.
DISPOSAL OF REFRIGERATION APPLIANCES
Dispose of your appliance packaging properly. Refrigeration equipment must be
properly disposed of in an environmentally-friendly manner. This applies to any old
appliances and to your new unit once it reaches the end of its service life.
Please ensure that old or worn appliances are rendered unusable before
disposal by removing the plug, cutting the power cable, and removing
or destroying any snap fastenings or bolts. This will prevent children from
locking themselves in the appliance (risk of suffocation) and endangering
their lives in any other way.
WARNING
• The cooling system, particularly the heat exchange located at the back/bottom of
the unit, must not be damaged during installation or when using the appliance.
• This product is not to be handled as normal household waste — it should be taken to
a recycling collection point for electrical and electronic goods.
• By correctly disposing of this product you are contributing to the protection of the
environment. Improper disposal endangers health and the environment.
• Further information about the proper recycling of the product may be obtained from
your local government agency or waste collection department.
BEFORE USING YOUR APPLIANCE
• Remove all exterior and interior packing materials.
• Before connecting the appliance to the electrical source, let it sit upright for
approximately 2 hours. This will reduce the possibility of malfunctions in the cooling
system caused by handling during shipping.
IMPORTANT SAFETY INSTRUCTIONS
General Safety

5
IMPORTANT SAFETY INSTRUCTIONS
• Prior to use, clean the interior surface with warm water using a soft cloth.
• The door on this appliance is designed so it may be opened from either the left or the
right side. The unit is delivered with the door opening on the left side and swinging
out to the right. Should you wish to open the door from the right, see the installation
manual.
INSTALLATION OF YOUR APPLIANCE
Do not store or install the appliance outdoors.
WARNING
• Wine coolers and beverage coolers are designed for either built-in or free-standing
installation.
• Place your unit on a floor that is strong enough to support it when it is fully loaded.
Please note the units weigh roughly 136 to 144 pounds when empty, so adjust
accordingly.
• To level your appliance, adjust the 4 legs by twisting clockwise or counter-clockwise
as needed until level.
• Install the appliance indoors and away from direct sunlight and sources of heat
(stove, heater, radiator, etc.). Sunlight may affect the acrylic coating, and heat
sources may increase electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly.
• Never install the unit in damp or overly humid areas.
• Any questions concerning power and/or electrical connection should be directed
toward a qualified electrician, technician, or service provider.
• The air vent located at the bottom front of the appliance must never be covered or
blocked in any way.
• The unit must be appropriately installed to all electrical connections in accordance
with state and local government codes.
• Please note that the cooler may experience decreased cooling efficiency if air flow is
restricted due to a fully loaded cabinet.
• Install the wine cooler or beverage cooler in a well-ventilated area where the
ambient temperature is above 50° F and below 90° F.
General Safety

6
IMPORTANT SAFETY INSTRUCTIONS
ATTENTION
• Never overload the unit’s cabinet.
• Do not open the door unless necessary.
• Never cover shelves with aluminum foil or any other material that may prevent air
circulation.
• It’s recommended to unplug the appliance if it sits empty for long periods. After
cleaning, leave the door ajar to allow air to circulate to avoid condensation, mold,
or odors from forming.
General Safety

7
IMPORTANT SAFETY INSTRUCTIONS
ELECTRICAL CONNECTION
Improper use of the grounded plug can increase the risk of electrical
shock. If the power cord is damaged, have it replaced by a qualified
electrician or authorized service provider.
WARNING
• This appliance must be properly grounded for your safety. The power cord provided
with this unit is equipped with a NEMA 5-15 plug that mates with standard NEMA
5-15 wall outlets to minimize the possibility of electrical shock.
• Never cut or remove the third-ground prong from the supplied power cord.
• Have a qualified electrician check the wall outlet and electrical circuit to ensure
the appliance is properly grounded. When a standard two-prong wall outlet is
encountered, it is your responsibility and obligation to have it replaced with a
properly grounded NEMA 5-15 wall outlet.
• To prevent injury, the electrical cord should be secured behind the appliance and not
left exposed or dangling.
• The appliance should always be plugged into its own dedicated NEMA 5-15 electrical
outlet. This provides the best performance while preventing overloading wiring circuits
that could cause a fire hazard from overheating.
• Have an electrician or qualified professional immediately repair or replace all power
cords that have become frayed or otherwise damaged. Never use a cord that shows
cracks or abrasion damage. When moving the appliance, be careful not to damage
the power cord.
• Never use your appliance with an extension cord unless this cord has been checked
and tested by a qualified technician or service person. The extension cord must be
a UL/CUL Listed, 3-wire grounding extension cord that has a grounding plug and
outlet and an electrical rating of 120 volts and at least 10 amps.
WARNING: We do not recommend using an extension cord. If one is
used on this appliance, it may void warranty.
WARNING
Electrical Connection

8
Controls
OPERATION
USING THE TOUCH CONTROL PANEL
Monument Beverage Cooler (RBV-US-24)
This beverage cooler has a temperature range from 34°F-50°F
Monument Wine Cooler (RWVUD24)
The temperature range of the upper zone is 39°F- 50°F.
The temperature range of the lower zone is 50°F- 68°F.
Power Button
Touch and hold this button for 3 seconds to power unit on or off.
Increase Temperature
Touch this button to increase the temperature by 1-degree increments.
Decrease Temperature
Touch this button to decrease the temperature by 1-degree increments.
Interior Light
After powering on the unit, touch the LED light button to turn on and off. The light will
take 2 seconds to turn on.
Temperature Zone Switch
Switch the temperature of the upper or lower zone by touching this button.
When the system is powered on for the first time, the system default setting is upper
temperature zone. Before temperature adjustment, you must first touch the temperature
zone switch key to select the zone to be set.
°F/°C Selector
Hold the Increase and Decrease Temperature buttons at the same time to
switch the display temperature.
Child Lock
Press the power button and light button at the same time for 3 seconds to lock and unlock.

9
Normal Sounds
OPERATION
If the unit is unplugged, loses power, or turned off, you must wait 3 to 5 minutes before
restarting. If you attempt to restart before this time delay, the appliance may not start and will
not keep the last set temperature.
Note: Beverage coolers and wine coolers are equipped with a temperature
memory function. If power is lost, the previous set temperature will be saved
and the appliance will return to this setting once power is restored.
The unit is designed with an automatic defrost system. However, on colder settings, some
frost may build up. Additionally, the more humid the ambient conditions, more frost may build
up depending on surrounding humidity. Keep the door closed and avoid opening the door
unnecessarily to minimize frost build-up.
If frost is preventing the door from closing properly, you may need to power the unit off until
the frost melts (possibly up to 24 hours). Use a soft absorbent towel to dry the unit.
Never attempt to remove frost with a sharp object.
WARNING
NORMAL SOUNDS
Refrigeration appliances may make unfamiliar sounds. This is common. Hard surfaces like
floors or walls can make sounds seem louder than they actually are. These sounds may be
caused by the following:
• Rattling noises may come from the flow of the refrigerant or the water line.
• Items stored on top of the beverage cooler may make noises. We do not recommend
storing anything on top of the appliance.
• The high-efficiency compressor located in the sealed cooling system may make a
pulsating or high-pitched sound.
• Water running from the cooling system’s evaporator to the water bin may make a
splashing sound.
• As each cycle ends, you may hear a gurgling sound due to refrigerant flowing in the
cooling system.
• You may hear air being forced over the cooling system’s condenser by the condenser fan.

10
Cleaning the Unit
CARE AND MAINTENANCE
CLEANING THE UNIT
Periodic cleaning and proper maintenance will ensure efficiency, top performance, and
long life of the unit.
INTERIOR CLEANING
1. Disconnect power to the unit.
2. Open the door and remove contents and shelves.
3. With a clean cloth, wipe down the interior of the unit.
4. Reinsert shelves and beverages.
5. Reconnect power to the unit.
EXTERIOR CLEANING
The door and cabinet may be cleaned with a mild kitchen-safe cleaner and lukewarm
water solution such as 2 tablespoons of baking soda to 1 quart of water. Do not use
solvent-based or abrasive cleaners. Use a soft sponge and rinse with clean water. Wipe
with a soft clean towel to prevent water spotting. Please note that stainless steel door
panels can discolor when exposed to chlorine gas and moisture. Clean stainless steel
with a cloth dampened with a mild kitchen-safe cleaner and warm water solution. Never
use an abrasive or caustic cleaning agent.

11
Energy Tips
CARE AND MAINTENANCE
POWER FAILURE
Most power failures are corrected within a few hours and should not affect the internal
temperature of your appliance if you minimize how often the door is opened. For longer
power outages, you need to take the proper steps to protect your contents.
MOVING YOUR BEVERAGE COOLER
• Remove all items.
• Securely tape down all loose items (shelves) inside your appliance.
• Turn the adjustable legs all the way up (clockwise) to the base to avoid damage.
• Tape the door shut.
• Be sure the appliance stays secure in the upright position during transportation. Also
protect outside of appliance with a blanket or similar item.
ENERGY SAVING TIPS
• The appliance should be located in the coolest area of the room, away from heat-
producing appliances, and out of direct sunlight.
• Ensure that the unit is adequately ventilated. Never cover air vents.
• Only open the door for as long as necessary.

12
Troubleshooting
TROUBLESHOOTING
POSSIBLE PROBLEM POSSIBLE CAUSE SOLUTIONS
The appliance does
not operate.
Not plugged in. Ensure the appliance is plugged in
and the power outlet has power.
The appliance is turned off. Turn on the appliance.
The circuit breaker tripped or has a
blown fuse.
Replace the broken fuse or reset the
breaker.
The appliance is not
cold enough.
Temperature control setting is too high. Adjust the set temperature.
External environment may be too warm
or humid.
Keep the appliance away from
sunshine or other heat sources.
The door is opened too frequently or for
long periods of time.
Close the door tightly and do not
open the door too frequently or for a
long period of time.
The door gasket is not sealed properly. Ensure the door gasket is not loose.
The cooler does not have sufficient
ventilation.
Read and follow the “Installation
Clearance Requirements” in the
installation manual.
The cooler has restricted air flow due to
too much storage.
Open space in the cabinet to allow
air flow.
The appliance turns on
and off frequently.
The room temperature is hotter than
normal.
Keep the appliance away from
sunshine or other heat sources.
The door gasket is not sealed properly. Ensure the door gasket is not loose.
The door is opened too frequently or for
long periods of time.
Close the door tightly and do not
open the door too frequently or for a
long period of time.
The cooler does not have sufficient
ventilation.
Read and follow the “Installation
Clearance Requirements” in the
installation manual.
The door is not closed completely Make sure the door is completely
closed.
The body of the
appliance is
electrified.
The unit is not properly grounded. Contact your local electrician to test
your electrical grounding system.

13
Troubleshooting
TROUBLESHOOTING
POSSIBLE PROBLEM POSSIBLE CAUSE SOLUTIONS
Frost is forming in the
appliance.
The environment is too humid.
The unit uses an ‘auto-defrost’
system; under certain conditions,
manual defrosting may be
required. If frost builds up, try
running the refrigerator on a
warmer temperature setting,
minimizing the number of times you
open the door, or unplugging the
unit to allow the frost to melt.
The ambient temperature is too low.
The door is being opened too frequently.
The appliance makes
too much noise.
The rattling noise may come from the flow
of the refrigerant, which is normal. As
each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in
the appliance.
This is a normal occurrence. The
high-efficiency compressor may
make a pulsating or high pitched
sound.
Contraction and expansion of the inside
walls may cause popping and cracking
noises.
Some popping or cracking noises
are normal. They are caused by
expansion and contraction of the
inside walls due to temperature
changes.
The unit is not level or is touching another
appliance.
Check the legs to ensure the unit
is level and that it is not in contact
with another appliance or furniture.
The door will not close
properly.
The appliance is not level. Make sure the appliance is on a
level surface.
The door gasket is not installed correctly. Make sure the door gasket is
properly installed.
The gasket is dirty. Clean the door gasket.
The shelves are out of position. Install the shelves correctly.

WARRANTY
COVERAGE
ZLINE Kitchen and Bath Monument Wine & Beverage Coolers have a two year parts and
service warranty and a five year parts warranty for a sealed cooling system. This is from the
original purchase date for the original purchaser of the product.
TERMS
This warranty applies only to the original purchaser of the product installed for normal
residential use. This is defined as a single-family, residential dwelling in a non-commercial
setting. Commercial settings include but are not limited to: schools, churches, hotels,
restaurants, vacation rentals such as Airbnb, day care centers, private clubs, fire stations,
common areas in multi-family dwellings, nursing homes, food service locations, and
institutional food service locations such as hospitals or correction facilities. This warranty
is non-transferable and will not be extended based on the date of installation. The
warranty applies only to products installed in the continental United States and the District
of Columbia. Warranty shall not apply and ZLINE Kitchen and Bath is not responsible
for damage resulting from negligence, improper maintenance, misuse, abuse, alteration
of or tampering with the appliance, accident, natural disaster, improper electric supply,
unauthorized service or repair, improper installation, or installation not in accordance with
the instructions contained in the manual or the local government codes.
WHAT IS NOT COVERED
1. Installation or start-up damages or problems caused by improper installation or use.
2. Damage related to unauthorized service or unauthorized parts.
3. Installation in any commercial or non-residential application.
4. Aesthetic damage, scratches, or natural wear caused by normal use.
5. Second-hand, open box products, or products purchased from an unauthorized retailer.

WARRANTY
NOTE: Please write down the model number and
serial number of your appliance. The model number
is located on the rating label on the back of your
unit. The serial number is located on the top center
of the interior on your appliance. Both are needed
to obtain warranty service. Do not remove
permanently affixed labels, warnings, or plates from
the product. This will void the warranty. You may
also consider attaching your receipt or proof of
purchase to this manual.
SERVICE
For warranty service, please contact our Customer Service team at
1-614-777-5004 or visit www.zlinekitchen.com/contact to utilize
our online Customer Experience Portal.
Need to purchase a part or accessory for your ZLINE product?
Visit www.zlineparts.com, ZLINE’s official parts distribution partner.

www.zlinekitchen.com
1-614-777-5004
[email protected]
1.3.2
