Zonet ZVS4204 User manual

TABLE OF CONTENTS
INTRODUCTION ......…….....…….......................................................... P2
PRODUCT FEATURES …..................................................................... P2
SPECIFICATIONS ....…...................................................................... P2
DISPLAY DIAGRAMS .…..................................................................... P3
HARDWARE INSTALLATION …............................................................ P4

- 2 -
Introduction
Zonet ZVS42 2 / ZVS42 4, 2/4-Port 4 MHz VGA Splitter is a boosting
device that duplicates the video signal from one source to 2 or 4 outputs.
It is ideal for monitors that are using analog signals. ZVS42 2 / ZVS42 4
extends the transmission distance up to 65m (21 ft) which makes it an
excellent for public broadcast systems.
It is capable to transmit multiple and high quality video signals to VGA,
SVGA, XVGA and Multi-sync monitors at a long distance without hassle.
Zonet ZVS42 2 / ZVS42 4 is the best choice.
Useful applications for the VGA Splitter include and not limited to:
•Financial Institutes: Remotely display of stock market information
•Educational purposes: Remotely display class lectures and
seminars to lecture halls and classrooms
•Business: Remotely display of presentation to other rooms, video
conferencing, and demonstrations
Features
•Duplicates Video Signals from 2 or 4 Computers
•Distance Transmission - up to 65 m (21 ft)
•Supports 4 MHz Bandwidths
•Supports VGA, SVGA, XVGA, and Multisync Monitors
•High Resolution Video - up to 23 X 144
Specifications
Operation and Storage parameters:
Operating Temperature: ~ 4 ˚C
32 ~ 1 4˚F
Storage Temperature: –2 ~ 6 ˚C
–4 ~ 14 ˚F
Humidity: ~8 % RH Non-condensing
VGA In Port
HDB 15 pin Male
VGA Out Ports
HDB 15 pin Female

- 3 -
isplay iagrams
Front View
PWR/SIG LE
Green – VGA Splitter is receiving power from the power adapter
Orange – VGA Splitter is transmitting video signals
Rear View
VGA in Port: VGA cable connects to the computer’s VGA output port
VGA out Ports: VGA cables connect to the monitors

- 4 -
Hardware Installation
Before you begin, make sure all devices are power-off.
NOTE: To prevent damage to your hardware due to ground potential
differences, make sure all devices (computer, monitor, and VGA Splitter)
are properly grounded during installation.
Zonet will not be responsible for any damaged caused in this way.
Connecting the VGA
1. Make sure that computer and monitors you are installing are powered
off.
2. Connect the VGA cable female end into the VGA splitter’s VGA In Port.
3. Connect the VGA cable male end into the computer’s VGA output port.
4. Connect the monitor cable(s) into the VGA Out Port.
5. Connect the provided power adapter to the power port.
6. Power on all devices.

- 5 -
FCC Certifications
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate
radio frequency energy, if it is not install and use in accordance with this
instruction, harmful interference to radio communication may caused.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment causes harmful interference to
radio or television reception, which determined by powering the equipment
on and off, user is advised to try correcting the interference by one or more
of the following measures:
•Reorient or relocate the placement of the unit.
•Increase the distance between the equipment and other devices.
•Connect the equipment to a different electrical outlet from other
devices.
•Consult the dealer or an experienced radio/TV technician for help.
•Shielded interface cables must be used in order to comply with
emission limits.
•Caution! Any change and/or modification to the device that is not
written approved by Zonet will void your authority to operate the
equipment and the warranty of the device.
•This device complies with FCC rules Part 15. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received, including
interference that may cause undesired operation.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to take
adequate measures.
Limited Warranty
Zonet offers limited warranty for its product only to the person or entity
who originally purchased the product from Zonet or from its authorized
resellers and/or distributors.
