Features:
Wireless-N Router
with Wireless Repeater, and Ethernet Client modes
Model 4403
Connects to your Cable Modem or ADSL Modem for shared Internet assess
Networks computers, phones, tablets, E-readers, and game stations that have WiFi®
capability or an Ethernet port
Includes Wireless Router, Wireless Repeater, and Ethernet Client modes
External detachable antenna enhances performance and flexibility
Advanced network security and easy setup
Connects to your Cable Modem, ADSL Modem, or WiMax® modem for shared Internet
access by up to 253 devices
Networks computers, phones, tablets, E-readers, game stations, and other devices
4 Ethernet ports allow direct connection of computers, game stations, HomePlug®
adapters, and other devices that have Ethernet.
Built-in WiFi compatible wireless-N router supports 802.11 n, g, and b
Wireless data speeds are up to 150 Mbps* even without compression.
Wireless range is typically up to 1,000 feet (304 meters) outdoors. Indoor range varies
depending on walls and other obstructions.
Wireless Router includes an advanced firewall and wireless security.
When not in Wireless Router mode, Model 4403 can be in Ethernet Client or Wireless
Repeater mode.
Ethernet Client mode adds powerful wireless capability to a computer, game station, or
other device that has an Ethernet jack.
Wireless Repeater mode can be used to extend the range of a wireless network.
Detachable external antenna provides high performance. Replacement by a larger
antenna is easy in the unlikely event that even longer range is needed.
1 year warranty and USA support from Zoom, a USA leader in communication products
since 1977

Model 4403
Wireless-N
Model 4403
©2011 Zoom Telephonics, Inc.,
207 South Street,Boston, MA 02111
Zoom is a registered trademark of
Zoom Telephonics,Inc. Wi-Fi is a
International
Headquarters
Zoom Telephonics, Inc.
207 South Street
Boston, MA 02111
USA
Tel: [phone]
Fax: [phone]
European
Sales/Support
Zoom Telephonics, Inc.
Centaur House
Ancells Business Park
Ancells Road
Fleet, Hants
GU51 2UJ UK
Tel: [phone]
Fax [phone]
Ventas América Latina
Zoom Telephonics Inc.
10237 Clubhouse Turn Rd.
Wellington, FL, 33449, USA
Tel. [phone]
Fax [phone]
email: [e-mail]
Website: www.zoomtel.com
OTCBB: ZMTP
4403 26411
Router
Specifications
Wireless standards - IEEE 802.11 b/g/n (Wireless LAN)
Wired network interfaces - Four 10/100 Mbps RJ45 Ethernet LAN ports with auto MDI/MDIX
- One 10/100 Mbps RJ45 Ethernet WAN port with auto MDI/MDIX
Product configurable as - Broadband router with integrated 4-port switch and (WDS
Wireless Distribution System) to support concurrent Internet access by up to
253 wired and wireless clients
or a
- Wireless access point for adding wireless access to a network
or a
- Repeater to extend the range of a wireless network
or an
- Ethernet client to create a wireless connection to an Ethernet - equipped
network client
Wireless security - 64/128 bit WEP (Wired Equivalent Privacy)
- WPA ( Wi-Fi Protected Access) and WPA2 with Pass Phrase
- WPS (Wi-Fi Protected Setup) button for easy security pairing
Management - Web-based user interface; remote login; backup/restore setting; SNMP
v1/v2; UPnP; IGD (Internet Gateway Device Protocol); Syslog; DDNS
Radio technology - 802.11b: Direct Sequence Spread Spectrum (DSSS)
- 802.11g: Orthogonal Frequency Division Multiplexing (OFDM)
- 802.11n: Orthogonal Frequency Division Multiplexing (OFDM)
Antenna - 2 dBi, removable, adjustable, omni-directional dipole antenna with reverse
polarity SMA plug
Wireless transmission rates - 1 Mbps to 150 Mbps
Wireless range - Indoors: up to 100 meters (328 feet) depending upon the environment
- Outdoors: up to 300 meters (984 feet) depending upon the environment
LED status indicators - Seven indicators showing:
Power and device status
Wide Area Network Link/Activity
Wired LAN Activity for each Ethernet port
Wireless LAN Activity
Wireless LAN frequencies - IEEE 802.11 b/g/n at 2.4000 to 2.4835 GHz
- US (FCC) channel 1 through 11
- Europe (ETSI) Channel 1 through 13
Router features - Stateful Packet Inspection (SPI); Virtual server; Special application; DMZ;
Super DMZ (IP pass-through); Denial of Service (DOS) detection and
protection; Static and dynamic routing; VPN pass-through (PPTP, L2TP, IPsec
tunneling); Parental controls
Dimensions (L X W X H) - 15.4 X 8.3 X 2.5 cm (6.1 X 3.3 X 1.1 inches) not counting antenna, when
vertical, the antenna tip is 10.1 cm (4 inches) above the case.
Antenna adds 4.8 cm (1.9 inches) to the depth of the product
Weight - 182 grams (6.42 ounces)
Power supply - Energy-saving external power supply, 100 to 240 VAC, 50/60 Hz
Temperature - Operating: 0
o
to 40
o
C (32
o
to 104
o
F)
- Storage: -10
o
to 70
o
C (14
o
to 158
o
F)
Humidity - 0% to 95% non-condensing
Transmit power (typical) - IEEE 802.11b: 17 dBm +/- to 1 dBm
- IEEE 802.11g: 14 dBm +/- to 1 dBm
- IEEE 802.11n: 14 dBm +/- to 1 dBm
Compliance FCC Part 15B and 15C, CE, RoHS
System requirements Configuration requires a computer with an Internet browser and either Wi-Fi
or an Ethernet port. Clients on the network must support TCP/IP
* 150 Mbps is the maximum wireless speed derived from IEEE Standard 802.11 specifications. Actual speeds will vary.
Package contents
- Wireless-N Router/Range
Extender/Client/Access Point
- Energy-saving switching power
cube, 100 to 240 VAC
- Ethernet cable
- Quick Start flyer in English
and Spanish
- CD with User Manual in English
and Spanish
