Zoomtak Telephonics 4300A User manual

BLUETOOTH 56K FAX MODEM
User’s manual
2.0
Model No.: 4300A, 4161A
Applicant: Zoom Telephonics, Inc.
Product Name: Bluetooth modem

REGULATORY STATEMENTS
FCC Certification
The United States Federal Communication Commission (FCC) and the Canadian
Department of Communications have established certain rules governing the use of
electronic equipment.
Part15, Class B
This device complies with Part 15 of FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interface, and
2. This device must accept any interface received, including interface that may cause
undesired operation. This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
♦Reorient or relocate the receiving antenna.
♦Increase the distance between the equipment and receiver.
♦Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
CAUTION:
1. To comply with FCC RF exposure compliance requirements, a separation distance of
at least 20 cm must be maintained between the antenna of this device and all persons.
2. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
FCC Caution: To assure continued compliance, any changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to operate this equipment.

Index
CHAPTER1
Introduction 1
CHAPTER2
Specifications 2
CHAPTER3
Product Shape 4
CHAPTER4
Bluetooth Modem Mode 6
CHAPTER5
Generic Modem Mode 38
CHAPTER6
How to use BTModemUtility 54
CHAPTER7
How to use Modem Country Region 64

1
1. Introduction
The Bluetooth 56K wireless modem is a 56K modem equipped with Bluetooth
function. It provides a standard V.92 Modem for WAN communication and access to
Internet. With a Bluetooth adapter, you can dial up to access the network via this
device wirelessly. Bluetooth technology brings you more freedom and mobility; it
allows you to mobilize your PC within the effective range of this Bluetooth modem.
Package Contents
•Bluetooth 56K Wireless Modem
•One AC adapter
•RJ-11 phone cable
•RS-232 Cable (DB-9pin)
•Quick Start Guide
•Driver CD (User's Manual inside)
Note:
If any of these items are missing from the retail package, contact your supplier
immediately.

2
2. Specifications
2.1. Features
V92 Modem
•ITU-T V.92 and K56flex
•V.34 (33.6 kbps), V.32 bis, V.32, V.22 bis, V.22, V.23, and V. 21; Bell
212A and 103
•Flow control and speed buffering
•Automatic format/speed sensing
•V.22bis fast connect
•One RS232 connecter for Host PC (DTE) interface
Bluetooth Function
•Wireless interface complies with Bluetooth Core Specification V1.1
•Main chip: CSR BlueCore 2
•Protocol: Bluetooth 2.4 GHz ISM band frequency hopping
•Output Power: Class 1 Bluetooth radio
•Data Rate: 723 kbps
•Special feature:
oModify bluetooth device name.
oEnable/disable authentication.
oChange pin code.
2.2. Specifications
•Communication software compatible AT command sets
•3.3V low power consumption
•Bluetooth or RS-232 (D-SUB9) interface Switch
•Provides LEDs for showing status information
2.3. Certification
•FCC Part 68, 15B , 15C and CE / LVD
2.4. Mechanical
•Dimension: 96 x64 x 22.1 mm (L x W x H)

3
2.5. Environment Operating Ranges
•Operation : 0 ~ 50℃, Humidity 10 ~ 90%
•Storage : -20 ~ 90℃, Humidity 10 ~ 90%
2.6. Power Consumption
•Operation: 175mA / 6V (Avg), 220mA/6V (Max)
•Standby: 52mA/6V
2.7. LED Indication
•Power LED: Power ON/OFF
•Link LED: Bluetooth Link
•ACT LED: Bluetooth Active
•OH LED: Off-Hook
•TX LED: Data Transmit
•RX LED: Data Receive
2.8. Driver Support
•Windows 98SE/ME/2000/XP
•Mac O.S 10.3 or above

4
3. Product Shape

5
1. Power LED indicator: Lights when the Bluetooth Modem powers on.
2. Link LED indicator: Lights when Bluetooth Modem is linked by a remote
device.
3. ACT LED indicator: Blinks when data is transferring via Bluetooth
connection.
4. OH LED indicator: Lights when Bluetooth Modem is dialing or gets
connected.
5. TX LED indicator: Blinks when Bluetooth Modem is transmitting data.
6. RX LED indicator: Blinks when Bluetooth Modem is receiving data.
7. Pin Code Reset Button: Resets the pin code back to the default value.
8. Antenna: Bluetooth 2.4GHz antenna.
9. RJ-11 Socket: PSTN (Telephone ) Line in for Modem.
10.Mode Switch: To select generic or Bluetooth Modem mode.
11.RS-232 connector: Connects to PC's COM port when it is in generic mode.
12.Power Jack: Power source connector.

6
4. Bluetooth Modem Mode
4.1. Getting Started
1. Turn the switch to "BT" side .
2. Connect the telephone line to the RJ-11 socket
3. Plug in the AC adapter to the power outlet.

7
4.2. How to dial-up under Widcomm Bluetooth Windows (BTW)
The Following procedures are using the Bluetooth software as reference
on how to use the Bluetooth Modem to access the Internet. The user
should follow accordingly based on the Bluetooth software in hand.
For Windows 98
1. Double click the "My Bluetooth Places" icon on the desktop. The
following window wills pop-up. Double click the "Find Bluetooth Devices"
icon.

8
2. Bluetooth software will start searching the surrounding remote devices.
Find the "Bluetooth Modem" icon and then double click on it.

9
3. The service start discovery.
4. Then windows will ask you a 4-digit PIN Code to pair with the Bluetooth
Modem. You can find the PIN Code on the bottom of your Bluetooth
modem. The default Pin code is “1111”.

10
5. Key in the PIN Code and click the "OK" button.
6. When Bluetooth Modem has been paired, it will show 3 services. Double
click on "Dial-up Networking on Bluetooth Modem" service icon.

11
7. When the connection is established, the service icon will change the color
to green.

12
8. If you are using the dial-up connection first time, the following window will
pop out. Type in the area code of your location, and then click the "Close"
button.
9. The "Connect To" window will auto pop-up. Please key in the user name,
the password, and the phone number. You can get the information form
your ISP (Internet Service Provider) and then click the "Connect" button.

13
10.The Bluetooth Modem starts dialing.
11.Once the connection is established you can run a web browser.

14
For Windows ME
1. Double click the "My Bluetooth Places" icon on the desktop. The
following window wills pop-up. Double click the "Find Bluetooth Devices"
icon.

15
2. Bluetooth software will start searching the surrounding remote devices.
Find the "Bluetooth Modem" icon and then double click on it.

16
3. The service start discovery.
4. Then windows will ask you a 4-digit PIN Code to pair with the Bluetooth
Modem. You can find the PIN Code on the bottom of your Bluetooth
modem. The default Pin code is “1111”.

17
5. Key in the PIN Code and click the "OK" button.
6. When Bluetooth Modem has been paired, it will show 3 services. Double
click on "Dial-up Networking on Bluetooth Modem" service icon.
