D-Link DSL-504T User manual

ADSL2/2+ MODEM ROUTER
DSL-504T
QUICK
INSTALLATION
GUIDE

DSL-504T
2
ENGLISH
CONTENTS OF
PACKAGING
CONTENTS
INSTALLATION CD
INCLUDES SET-UP WIZARD & TECHNICAL MANUALS
ADSL2/2+ MODEM ROUTER
DSL-504T
12V 1.25A POWER ADAPTER
ADAPTER
ETHERNET CABLE (RJ-45 CABLE)
CONNECT THE ROUTER TO YOUR PC DURING SET-UP
If any of these items are missing from your packaging contact
your reseller

DSL-504T 3
ENGLISH
PRODUCT
SET-UP
CD SET-UP WIZARD
English
SET-UP WIZARD CD
The CD contains all of the instructions required to set-up DSL-
504T
INSERT CD
Insert the CD into the CD drive of your computer. The set-up
wizard should start automatically. Make sure that your internet
connection is active. (Do not plug in DSL-504T yet)
SET-UP WIZARD
Select your language from the list of options and follow the
steps within the wizard to complete the set-up of DSL-504T
ADVANCED SET-UP (ACCESS VIA IP ADDRESS)
To congure DSL-504T manually (without the set-up CD) connect your computer to the DSL-
504T using the ethernet cable provided. Then connect the power cable on the DSL-504T. The
power light will display as solid green.
Then simply open a browser window and enter the IP address in the browser address eld:
IP ADDRESS: http://10.1.1.1
USERNAME: admin
PASSWORD: admin

DSL-504T
4
ENGLISH
TROUBLESHOOTING
SET-UP AND CONFIGURATION PROBLEMS
1. HOW DO I CONFIGURE MY DSL-504T ROUTER WITHOUT THE CD?
- Connect your PC to the router using an Ethernet cable.
- Open a web browser and enter the address http://10.1.1.1
- The default username is admin. The default password is admin.
- If you have changed the password and can not remember it, you will need to reset the router to
set the password back to admin.
2. HOW DO I RESET MY DSL-504T ROUTER TO FACTORY DEFAULT SETTINGS?
- Ensure the router is powered on.
- Press and hold the reset button on the rear of the device for 10 seconds.
Note: Resetting the router to factory default will erase the current conguration settings. To re-
congure your settings, log into the router as outlined in question 1, then run the Setup Wizard.
3. WHY CAN I NOT GET AN INTERNET CONNECTION?
For ADSL users please contact your ISP to make sure the service has been enabled/connected
by your ISP and that your ISP username and password is correct.
TECHNICAL SUPPORT
Australia:
Tel: [phone]
24/7(24Hrs, 7days a week) technical support
http://www.dlink.com.au
e-mail: [email protected]
New Zealand:
Tel: [phone]
24/7(24Hrs, 7days a week) technical support
http://www.dlink.co.nz
e-mail: [email protected]

DSL-504T 5
NOTES

DSL-504T
6
NOTES

DSL-504T 7
NOTES

Ver. 2.00(AU) 2009/05/15
WIRELESS NETWORK REMINDER
Wireless Network Name (SSID)
Wireless Network Password
