Mitsubishi Electric A2S-MODEM Instruction Manual

A
A2 2S S- -M MO OD DE EM M
D
DI IN N- -M MO OD DE EM M- -2 2
D
DE ES SK K- -M MO OD DE EM M- -2 2
U
US SE ER RS S H HA AN ND DB BO OO OK K
ISSUE 2
VERSION 2

i
A
A2 2S S, , D DI IN N, , D DE ES SK K- -M MO OD DE EM M- -2 2
FORWARD
This handbook is a programming and function description for the A2S, DIN and
DESK-2 range of modems with system program version 1.2x.
©LogiLink Ltd.2000
Unless Mitsubishi Electric Europe BV has accepted a contractual obligation in respect
of the permitted use of the information and data contained herein, such information
and data is provided without responsibility and Mitsubishi Electric Europe BV
disclaims all liability arising from its use.
All examples in this manual are used solely to promote understanding of how the
equipment works and its operation. Mitsubishi Electric Europe BV take no
responsibility if these examples are used in real applications.
Mitsubishi Electric Europe BV absolves itself of all responsibilities for damage and
injuries that may occur during installation or use of this equipment.
Mitsubishi Electric Europe BV absolves itself of all responsibilities for any type of
modification made to the equipment.

ii
Contents
FORWARD .............................................................................................................................................I
INTRODUCTION.................................................................................................................................. 1
SECTION 1 - MODEM STANDARDS AND COMPATIBILITY.................................................... 2
1.1 COMPATIBILITY ..............................................................................................................................2
1.2 WHAT YOU SHOULD HAVE IN YOUR PACKAGE.................................................................................2
1.3 WHAT TO DO NEXT..........................................................................................................................2
SECTION 2 – GETTING STARTED.................................................................................................. 3
2.1 INSTALLATION & REMOVAL ...........................................................................................................3
2.1.1 Installation – A2S Version......................................................................................................3
2.2.2 Removal – A2S Version..........................................................................................................3
2.1.3 Installation – DIN Version .....................................................................................................3
2.1.4 Removal –DIN Version...........................................................................................................3
2.2 CONNECTION AND WIRING .............................................................................................................3
2.2.1 Connection to a Link module (eg. A1SJ71C24-R2)...............................................................3
2.2.2 Connection to FX2N-232-BD.................................................................................................4
2.2.3 Connection to MAC 50/90 and E range of HMI’s..................................................................4
2.2.4 Connection to FX-232AW / FX0N-232ADP...........................................................................5
2.2.5 Connection to DESK Version.................................................................................................5
2.2.6 Wiring.....................................................................................................................................6
2.3 INITIAL CONFIGURATION.................................................................................................................6
SECTION 3 – USING THE ENHANCED FUNCTIONS .................................................................. 7
3.1 SETTING THE MODEM WITH TERMINAL SOFTWARE ........................................................................7
3.1.1 Connecting the Modem to a PC..............................................................................................7
3.1.2 Configuring the Modem..........................................................................................................7
Example 3-1 Protocol settings...............................................................................................................7
3.2 AUTOMATIC SIMULTANEOUS VOICE AND DATA.............................................................................8
3.2.1 Using Simultaneous Voice and Data with Other Modems......................................................8
3.3 ONLINE MAINTENANCE USING MITSUBISHI PLC PROGRAMMING SOFTWARE................................9
3.3.1 Making a Connection .............................................................................................................9
Example 3-2 Dialling ............................................................................................................................9
3.3.2 Terminating a Call .................................................................................................................9
3.3.3 Communicating with Mitsubishi PLC’s................................................................................10
3.3.4 Communicating with E series and MAC HMI’s...................................................................10
3.3.5 Transferring files from/to the HMI.......................................................................................11
3.3.6 Communicating with other makes of PLC controllers..........................................................11
Example 3-3 Transparent settings........................................................................................................12
3.4 SECURITY......................................................................................................................................13
3.4.1 Normal Operation................................................................................................................13
3.4.2 Installing the Access Codes..................................................................................................14
3.5 DIAL ON DEMAND ........................................................................................................................15
3.5.1 Setting Dial on Demand Commands ....................................................................................15
Example 3-4 Command Block Address setting...................................................................................16
3.5.2 Online Configuration ...........................................................................................................16
3.5.3 Contents of the command block............................................................................................17
3.5.4 Control and Status Register..................................................................................................17
3.5.5 Setting telephone numbers....................................................................................................19
Example 3-5 Setting Speed-Dial numbers...........................................................................................19
Example 3-6 Directory Dialling (PLC programming).........................................................................19
3.5.6 Setting fixed messages in the modem....................................................................................20
Example 3-7 Setting Messages from the PLC.....................................................................................20
3.6 WIDE AREA TELEMETRY (WAT)..................................................................................................21

iii
3.6.1 Setting the Start Address of WAT Information .....................................................................21
Example 3-8 Setting WAT addresses..................................................................................................21
3.6.2 Information in the WAT Header...........................................................................................22
Example 3-9 WAT settings in the PLC (Write Remote command).....................................................23
Example 3-10 WAT settings in the PLC (Read Remote command).....................................................23
3.7 WAT SETTINGS AND PROCEDURES BEFORE OPERATION...............................................................24
SECTION 4 – TROUBLESHOOTING ............................................................................................. 25
4.1 THE MODEM DOES NOT RESPOND TO COMMANDS..........................................................................25
4.2 THE MODEM DIALS BUT DOES NOT CONNECT..............................................................................25
4.3 THE MODEM DOES NOT DIAL, REPORTING “NO DIALTONE” ...................................................25
4.4 THE MODEM STOPS POLLING AFTER FIRST POLL .........................................................................26
4.5 POLLING OCCURS, BUT WILL NOT DIAL ON DEMAND...................................................................26
4.6 MODEM OCCASIONALLY HANGS-UP DURING WAT DATA EXCHANGE...........................................26
4.7 OCCASIONAL “RE-TRIES” OCCUR DURING PROGRAMMING/MONITORING.....................................26
SECTION 5 – AT COMMAND SET AND S - REGISTERS........................................................... 27
5.1 STANDARD COMMANDS................................................................................................................27
5.2 ECC COMMANDS..........................................................................................................................30
5.3 MNP 10 COMMANDS....................................................................................................................30
5.4 W-CLASS COMMANDS................................................................................................................30
5.5 FAX CLASS 1 ...............................................................................................................................30
5.6 FAX CLASS 2 ...............................................................................................................................30
5.7 VOICE/AUDIO COMMANDS ...........................................................................................................31
5.8 S-REGISTERS.................................................................................................................................32
5.9 UNIQUE AT COMMANDS...............................................................................................................33
SECTION 6 – SUPPORT SERVICE AND COMPLIANCE DETAILS......................................... 34
6.1 CUSTOMER SUPPORT.....................................................................................................................34
6.2 EUROPEAN COMPLIANCE INFORMATION.......................................................................................34
6.3 RINGER EQUIVALENCE NUMBER...................................................................................................34
6.4 APPROVED USAGE ........................................................................................................................34
SECTION 7 – TECHNICAL DETAILS............................................................................................ 35
7.1 MODEM SERIAL CONNECTIONS.....................................................................................................35
7.2 RECOMMENDED CABLE CONNECTIONS.........................................................................................35
7.2.1 A1SJ71C24-R2 Communications Module ............................................................................35
7.2.2 FX-232AW/AJ Communications Module..............................................................................36
7.2.3 PC Serial Port (9-way D-type).............................................................................................36
7.2.4 MAC / E-Range HMI’s.........................................................................................................36
7.3 LED FUNCTIONS...........................................................................................................................36
SECTION 8 – TECHNICAL SPECIFICATION.............................................................................. 37
8.1 RATED OPERATING LIMITS ...........................................................................................................37
SECTION 9 – ACCESSORIES AVAILABLE.................................................................................. 37
SECTION 10 – PLC PROGRAMMING EXAMPLE....................................................................... 38

1
A
A2 2S S, , D DI IN N, , D DE ES SK K- -M MO OD DE EM M- -2 2
INTRODUCTION
Your new modem is one of the most technologically advanced available. It combines
high-speed data, fax, voice and ASVD (Automatic Simultaneous Voice and Data)
functions in a single unit. The modem has been designed to complement the
Mitsubishi FX and A ranges of PLC’s, and provides a number of unique telemetry
features for handling data transfers between PLC’s.
The modem is capable of operating at data speeds of 33.6Kbps and has the ability to
store telephone numbers, fixed messages, etc.
This manual is divided into eleven sections covering (1) Modem Standards and
Compatibility, (2) Getting Started, (3) Enhanced Functions, (4) Troubleshooting,
(5) AT Command Set, (6) Support, Service and Compliance details, (7) Technical
Details, (8) Technical Specification, (9) Accessories, and (10) PLC Programming
Examples.
Please be sure to read section two carefully before installing your modem.

2
Section 1 - Modem Standards and Compatibility
1.1 Compatibility
Your modem is compatible with the following communications standards:
!V.34 (33600bps)
!V.32bis (14400bps)
!V.32 (9600bps)
!V.22bis (2400bps)
!V.22 (1200bps)
!Bell 212A (1200bps)
!Bell 103 (300bps)
!V.17 (14400bps FAX)
!V.29 (9600bps FAX)
!V.27ter (4800bps FAX)
!V.21 Channel 2 (300bps FAX)
!V.42 (error correction)
!MNP 2-4 (error correction)
!V.42bis (data compression)
!MNP 5 (data compression)
!Class 1 Fax Command Set
!Hayes AT Command Set
The modem has been designed to operate in all European Countries and complies with
standard TBR21.
1.2 What you should have in your package
A2S-MODEM
One A2S-MODEM module
One PC Utilities Software Diskette *
One Telephone Cable (BT – UK only)
One 24 Volt dc connector
One Modem to C24 Data Cable (MODEM-R2-CAB)
DIN-MODEM-2
One DIN-MODEM-2 module
One PC Utilities Software Diskette *
One Telephone Cable (BT – UK only)
DESK-MODEM-2
One DESK-MODEM-2 module
One PC Utilities Software Diskette *
One Telephone Cable (BT – UK only)
One 12 Volt UK Mains adapter
One PC to Modem RS232 9 way Cable (MODEM-PC9-CAB)
* Includes manual in PDF format and Windows Terminal application
If any of the above items are missing please contact your supplier
1.3 What to do next
If you do not wish to use any of the enhanced features available in your modem go
straight to section 2 (Getting Started).
If you wish to use some of the enhanced features; i.e. Access Code Protection, Dial
On Demand and Wide Area Telemetry, also read section 3 (Using the Enhanced
Functions)
If you experience problems go to Section 4 (Troubleshooting).

3
Section 2 – Getting Started
2.1 Installation & Removal
2.1.1 Installation – A2S Version
i) Locate in a vacant I/O position, preferably adjacent to the Comms Link
module (A1SJ71C24-R2/A1SJ71UC24-R2/A1SJ71QC24-R2).
ii) Insert the module mounting-hook into the slot below the chosen I/O position
on the A1S Base and push the top of the module forward until fully located.
iii) Secure the module with the retained mounting screw at the top.
NOTE: Installing the A2S-MODEM on the backplane does not connect to the Bus or
take power or occupy I/O addresses. To avoid loosing any I/O addresses, assign “S0”,
under Parameters in the PLC software, for that slot.
2.2.2 Removal – A2S Version
i) Unscrew mounting screw then tilt the module backwards against the
mounting hook until clear of the A1S Base connector.
ii) Lift upwards and remove the module hook clear of the slot.
2.1.3 Installation – DIN Version
i) Locate the top of the DIN rail clip onto the DIN rail and push the module
down until the clip is secure.
2.1.4 Removal –DIN Version
i) Lever the bottom of the module upwards until the clip releases and un-hook
from the top.
2.2 Connection and Wiring
2.2.1 Connection to a Link module (eg. A1SJ71C24-R2)
i) Connect the 9-pin to 9-pin cable type (MODEM-R2-CAB), between the
Data RS232 port on the front of the DIN-MODEM-2 or A2S-MODEM and
to the RS232 connector on the front of the A1SJ71C24-R2 link module.
ii) Connect the telephone lead provided by plugging in the RJ11 type plug into
the socket labelled LINE, making sure that the connector is properly latched.
iii) When simultaneous voice and data is required, connect a suitable handset or
headset by plugging into the socket labelled VOICE.
iv) Connect a 24V or 12V dc supply via the connector provided. The dc
polarity is not important as it is corrected within the MODEM.
AnS/QnS/A via C24 (R2)
RD
SD
CD
TR
CS
OH
VOICE
DATA
RS232
24V
OV
LINE
Modem-A2S
MODEM-R2-

4
2.2.1 continued
NOTE 1: Modems cannot be connected directly to the CPU programming port.
NOTE 2: Set the Link module to protocol 1, Write during run, 9600 baud, 8 data bits,
No parity, 1 Stop bit and Sum Check ON. Eg. MODE=1, SW04,05,07,08 &12 = ON,
all other switches OFF. After changing these switches turn the power to the PLC off
and back on alternatively reset the CPU.
2.2.2 Connection to FX2N-232-BD
i) Connect a 9-pin male to 9-pin female cable, type MODEM-FX2-CAB or
MODEM-PC9-CAB, wired to the schematic shown in Section 7, between
the Data RS232 port on the front of the MODEM and the serial port at the
top of the FX2N-232-BD plug-in module.
ii) Then follow the instructions in Section 2.2.1 ii) to iv) above
2.2.3 Connection to MAC 50/90 and E range of HMI’s
iii) Connect a 9-pin male to 9-pin female cable, type MODEM-MAC-CAB,
wired to the schematic shown in Section 7, between the Data RS232 port on
the front of the MODEM and PRINTER serial port at the back of the MAC
or E range terminal.
iv) Then follow the instructions in Section 2.2.1 ii) to iv) above
MITSUBISHI
FX1S/FX1N/FX2N
+ 232-BD
mode
RD
CD
CS
1
2
O
VO
DA
RS
log
LI
MODEM-FX2-CAB
OR
MODEM-PC9-CAB
AnS/QnS/A
MITSUBISHI
FX0S/FX1S
FX0N/FX1N/FX2N
MITSUBISHI
FX
MAC 40+ CAB
MAC 40+ CAB
FX-20P-CAB
MODEM-
MAC-CAB
RD
S
CD
T
CS
O
VOICE
DATA
RS232
24V
OV
LINE
Modem-A2S
mod
RD
CD
CS
1
2
O
V
D
R
lo
LI

5
2.2.4 Connection to FX-232AW / FX0N-232ADP
i) Connect the 9-pin to 25-pin cable, type MODEM-R2A-CAB, between the
Data RS232 port on the front of the MODEM and the RS232C Connector
on the FX232AW / FX0N-232ADP module.
ii) Then follow the instructions in Section 2.2.1 ii) to iv) above
2.2.5 Connection to DESK Version
i) Connect the PC to Modem Data cable, type MODEM-PC9-CAB, between
the Data RS232 port at the rear of the MODEM and a spare
communication port on your PC.
ii) Then follow the instructions in Section 2.2.1 ii) to iv) above.
MITSUBISHI
FX1S/FX1N/FX2N
+ FX2N-CNV-BD +
FX0N-232-ADP
mode
RD
CD
CS
1
2
O
VOI
DA
RS
logi
LI
MODEM-R2A-CAB
MITSUBISHI
FX + FX-232AW
RDSDCDTRCSOH
logilink
336
MODEM-PC9-CAB

6
2.2.6 Wiring
24V dc Supply A2S and DIN Versions
i) Wire 24 dc from a suitable supply, usually from terminals on a nearby
module to the miniature screw terminal plug provided.
ii) Check the specification for the 24V supply before making connection.
However, reversing the polarity of the dc will cause no harm.
12V dc Supply DESK Version
i) Plug the 12V dc power supply provided into a mains supply and connect
the jack plug into the connector at the rear of the MODEM.
2.3 Initial configuration
i) Set the Modem to the correct local protocol (see 5.9 for a list of codes),
with the command:
AT%ADP=x (where x = protocol setting)
ii) Read section 3.1 for more details.
