Zoovaa 10-OFB-001B User manual

Maximum Weight:
28lbs (13kg)
Maximum Weight:
5lbs (2kg)
A+B Maximum Weight:
33lbs (15kg)
ASSEMBLY INSTRUCTIONS
ADJUSTABLE HEIGHT STANDING DESK RISER
Item No.: 10-OFB-001B
D E F GCBA
1
Components
Tools required not included
Features & Specifications
1 pc1 pc 2 pcs2 pcs 1 pc
S=4mm
A
B
CAUTION: DO NOT EXCEED
MAXIMUM LISTED WEIGHT
CAPACITY. SERIOUS INJURY
OR PROPERTY DAMAGE MAY
OCCUR!
6 pcs
35.4INCHES(900MM)
23.2INCHES(590MM)
21.9INCHES(557MM)
6.7-19.7INCHES
(145-500MM)
7.48INCHES(190MM)
35.4INCHES(900MM)
Note: The illustrations below are for reference only and may differ slightly from actual parts. If you
have trouble with installation or if there are missing parts, please contact customer service so we
can assist and remedy the problem quickly.
CAUTION: Please read all instructions carefully and thoroughly
before using this product. Keep this manual and all instructions
for future reference.
For customer service, please contact [email protected]

1
2
Warning: Impact Hazard! Moving
parts can crush and cut.
C
D
B
Attach the Brackets (B) to the Keyboard Tray (C) with
Screws (D) using a Philips head screwdriver.
CAUTION: Ensure the desktop riser is
centered on a flat, level surface before
operating.
CAUTION: Heavy object.
Two person lift required.

CAUTION: Keep monitor and laptop base fully on the
desktop surface. Allowing any parts of the monitor
and laptop base or the stand to hang off the edge
may result in property damage and/or personal injury.
CAUTION: Raise the desktop slowly. Raising the
desktop too fast may create an unstable situation
resulting in property damage and/or personal injury.
③Insert the Brackets (B) with the Keyboard
Tray (C) on to the thumb screws then
tighten the thumb screws with Allen Wrench (E).
①Press the handles
on each side and
lift the desktop.
3
4
5
E
To operate the desktop riser, press the two handle
grips on each side simultaneously and raise or
lower the desktop to the desired height.
CAUTION: Please keep hands away from the
supporting bars during operation as pinching
could result.
②Loosen the pre-attached thumb screws on the frame

Use the Cable Tie (G) to organize cables,
wires, and cords and avoid a tangled mess.
WARNING: Leave enough slack in cable to allow for full
range of vertical motion (15”/38 cm). Failure to heed
this warning may result in property damage and/or
personal injury.
DO NOT place hands on or near support bars. Pinch points are
created during lifting and lowering the worksurface. Failure to
follow these instructions may result in serious personal injury.
7
G
6
F
Use Self Adhesive Tie (F) for clean cable management.
Limited Warranty Terms and Conditions:
All ZOOVAA products are guaranteed to the original purchaser and are subject to the terms and conditions as
stated in this Limited Warranty. This Warranty only applies to the United States domestic market.
Our products are warranted to be free from defects in materials and workmanship by a limited 90 day parts
and 3 year frame Warranty. The Warranty applies for the purposes intended, under normal conditions only.
This Warranty excludes but is not limited to damage caused by normal and typical wear, accidents, unreason-
able use, negligence, improper care, damage from abuse, or unauthorized repair.
WARNING: This product can expose you to one or more chemicals known to the State of California to cause
cancer and birth defects or reproductive harm. For more information, go to www.P65Warnings.ca.gov/prod-
uct.
WARNING: To avoid potential to pinch
cables, it is important to follow the cable
routing instructions in this manual. Failure to
follow these instructions may result in equip-
ment damage and/or personal injury.
