Zte AD8000 User manual

1
Precautions
zDo not subject the device to severe impact or drop it from high position.
zDo not use the player in extreme hot or cold, dusty or damp field. Do not
expose it to direct sunshine.
zExcessive sound pressure from earphones and headphones can cause
hearing loss.
zAvoid using the player in strong magnetic field.
zKeep the device away from water or other liquids. In the event that water or
other liquids enter the device, power off the product immediately, and clean
the device.
zDo not use chemical solution to clean the device in order to avoid corrosion.
Clean it with a dry cloth.
zWe are not responsible for the damages or lost data caused by malfunction,
misusing, repairing the device or battery replacement.
zDo not attempt to disassemble, repair or modify the product. This will
invalidate guarantee.
zWhen not using the device for an extended period of time, please charge
the battery at least once per month to extend the battery life.
zDo not use the device in extremely hot, cold, dusty or damp environments.
zAvoid dropping or striking the unit .This may cause external and internal
physical damage to the player.
zCharge the battery if:
a) The battery level icon displays (An empty battery)
b) The device powers off automatically and off again when restarted.
c) No response when pressing keys with keys unlocked and battery
installed.
zTo prevent damage from static shock, never use the device in very dry
conditions.
zWhen the device is being formatted or transferring a file, do not interrupt
the connection. Otherwise, data may be corrupt of lost.
zWhen the device is used as a portable HD, please use only per instructions.
Otherwise, permanent data loss could occur.
zThis manual may not reflect the actual device’s operation since it is subject
to change without prior notification. Please comply with your actual
device’s operations always.

2
Table of Content
Introduction..........................................................................................................3
Feature Summary................................................................................................3
Package Content.................................................................................................3
Buttons & Ports....................................................................................................3
Charging Battery..................................................................................................4
Installing Memory card ........................................................................................4
Transferring Files.................................................................................................5
Turning On/Off .....................................................................................................5
Home Screen.......................................................................................................6
Using the Touch Screen ......................................................................................8
Using the Virtual Keyboard..................................................................................9
Access Internet....................................................................................................9
Playing Music ....................................................................................................12
Playing Video.....................................................................................................16
Viewing Photos..................................................................................................17
Using the Camcorder.........................................................................................18
Using the Camera..............................................................................................19
File Explorer ...................................................................................................... 19
E-mail ................................................................................................................20
Manage Applications .........................................................................................22
System Settings.................................................................................................23
Troubleshooting.................................................................................................24
Specifications ....................................................................................................25
Listening Cautions.............................................................................................27

3
Introduction
MID is a mobile device that gives you an amazing Internet experience --
allowing you to communicate with others, enjoy your favorite entertainment, and
access information on the Internet at anytime and anywhere. This latest
generation of small, powerful, highly portable Internet-connected devices
combines many great capabilities with the convenience of a pocket-sized
solution for your life on-the-go.
Feature Summary
zBuilt-in Android Operating System
With the built-in Android OS, your MID supports most of popular
applications. You can install or uninstall applications such as MSN,
YouTube, g-email etc. on your MID.
zWi-Fi / 3G Connectivity
With the latest Wi-Fi and 3G technology, your MID can connect you to the
Internet wherever you are.
z7-inch Touch Screen
Touch or slide your finger in the screen, the screen responds instantly.
zEntertainment
Allows you to enjoy music, movie or pictures any time and any where.
Package Content
zMain Unit
zStereo earphones
zUSB cable
Buttons & Ports
Front View
zAC Adaptor
zUser Manual
zWarranty Card
a
b c
d
e
f
a. LCD Display
b. Camera Lens
c. Home: Go to the Home
Screen.
d. Menu: Display an overlay
menu.
e. SCROLL button: roll in all
ways to make selection; press
to confirm selection.
f. ESC: Return

4
TopView
Bottom View
Side View
Charging Battery
The device has built-in rechargeable battery. No extra battery installation is
required. Just charge the device when it indicates low battery.
To charge the battery, connect the device to any standard wall outlet through
the AC adaptor via the DC-IN port. It takes about 3 hours to fully charge the
battery.
Note:
a. You can operate the device even when it is being charged. But for extending the battery
life, you are suggested NOT to use the device when it is in charge.
b. You are recommended to charge the battery when you use the device for the first time.
c. For maximum performance, lithium-ion batteries need to be used often. If you don’t use
the device often, be sure to recharge the battery at least once per month.
Installing Memory card
In addition to the built-in memory, your MID features a memory card slot to
extend its memory space. You can read e-book, music, image or video files
from a SD card directly.
To install a memory card, find the card slot at the bottom of the machine, and
gh
i
j
k
l
g. USB Port: connect to computer, USB flash drive, mouse or keyboard
through USB cable.
h. Power button: press and hold to turn on or off the device; briefly
press to turn on or off the screen.
i. Micro-SD Card Slot
j. Earphone Jack
k. DC-IN Port: connect to
any standard electronic
outlet through AC
adaptor.
l. Reset pin hole
m. Built-in microphone
n. 3G Card Slot: open to
insert a 3G network
card.
m
n

5
then insert a Micro-SD card into the slot with the correct direction.
To access the memory card, enter the Explorer mode and then select the
“SDCard”directory.
Transferring Files
Before reading or playing files, make sure your MID’s internal memory or the
external memory card has media files. If not, transfer files from computer to
your MID.
(1) Connect your MID to a computer with the supplied USB cable.
(2) Once connected, two removable disk drives appear in your computer. One
represents the internal memory of your MID, and the other represents the
memory card inserted into your MID. Now you can copy files from or to these
disk drives.
(3) Once the data transfer completes, drag from the top bar downwards to
display the USB notification message. Choose “Turn off USB Storage” and
then tap on “Turn Off” to disconnect the device from computer.
(4) Remove the player from the PC safely.
a) Left-click the icon at the right bottom corner of the computer
desktop.
b) Click the pop-up mini-window with message of “Stop the USB Mass
Storage Device – Drive (X)”.
c) Remove the player from the computer.
Turning On/Off
To turn on the device, press and hold the Power button on the unit until you see
the boot-up screen. It may take a few minutes to start up the system, please
Drag downwards

6
wait before you proceed.
You should see the following locked screen once the device turns on. Before you
start using the device, you need to unlock the screen first. To unlock the screen, drag
the lock icon upward.
To turn off the device, press and hold the Power button until you see the option
“Power Off”, tap on “Power Off” and then tap on “OK”.
Tip: Your MID will sleep with the screen off if it stays inactive for a few seconds. You can
briefly press the Power button to turn on the screen and wake it up.
Home Screen
Indications
a. Home: Go back to the Home Screen wherever you are in the interface.
b. Memory Card: the exclamation mark indicates no available memory card,
and it should disappear once a memory card is available.
c. Wi-Fi Network
d. 3G Network
e. Battery Charge
f. Current Time
g. Volume Down: Tap briefly or continuously to decrease the volume.
h. Volume Up: Tap briefly or continuously to increase the volume.
a b cdef g h i j
k
l
m

7
i. Return: Return to the previous directory.
j. Menu: Tap to display an overlay setting menu.
k. Address Inputting Area. You can input the website address by tapping
this field. A virtual keyboard should appear. Use the keyboard to type in
letters. Tapping will hide the keyboard.
l. Applications Tab: Tap on this icon to reveal all applications installed on
your MID (alarm clock, calculator, GlobalTime etc.).
- You can copy the applications onto the Home screen by pressing and
holding on their icons.
- You can delete the application from the Home Screen by dragging
their icons to the Application Tab. To delete a Home screen item, hold
your finger onto it until it is highlighted, then drag it to the Application
Tab which has become a trash icon.
m. Default shortcuts (“Browser”, “Video Player”, “Audio Player”, etc.)
- Tap on an icon to open the corresponding application.
- Roll the SCROLL button on the unit to select an item.
- You can customize the Home Screen by adding/removing shortcuts
and widgets, changing the wallpaper, etc.
zCustomizing the Home screen items
- To add a Home screen item (shortcuts, widgets, folders etc.), tap on the
Menu icon and then select “Add” , or hold your tap on the Home
Screen until a pop-up menu displays.
- To move a Home screen item, hold your finger onto it until it is highlighted,
then drag it to the desired location, and release it.
zChanging the wallpaper
Tap on the Menu icon , and then tap on “Wallpaper”. Tap on one picture
and then tap on “Set Wallpaper” to confirm.

8
zGo to the extended Home Screen
Slide your finger horizontally on the screen OR roll the SCROLL button to go to
the left or right panel of the extended Home Screen.
You may see the following extended Home Screen in which you have some
useful shorcuts. Tapping on these shorcuts can activate their function.
zChanging the System Settings
Tap on the Menu icon , and then tap on “Settings” . Choose a category:
“Wireless& networks”, “Sound & Display”, “Date & Time”, etc. For more
information on the different settings, see the System Settings section.
Using the Touch Screen
Your MID is equipped with a touch-screen. Below are a few tips on how to use
the touch screen.
Main Touch Screen Actions
yIn different applications, you can go back one level in the interface by
tapping on the Back icon (at the top right corner of the screen).
yWherever you are in the interface, you can go back directly to the Home
Screen by tapping on the Home icon (in the top left corner of the
screen).
Other Touch Screen Actions
yWhen watching a video or listening to music,
you can tap on the progression bar to go
directly to a different location in the video or
a b c a. Connect to available Wi-Fi
network
b. Refresh the media library
c. Adjust the screen brightness

9
song. You can also use your finger to
drag the cursor in the progression bar to
another location in the video or song.
yIn the different browsers (File, Music,
Video, Photo, etc.), you can drag your
finger up and down to scroll the file list up
and down.
yIn the Web browser, you can scroll up and down by tapping on the page and
dragging it up or down (be careful however not to tap on a link!).
yTap on the link to open the page.
Using the Virtual Keyboard
Tapping on any text input field can show up the virtual board. With the virtual
keyboard, you can enter website address or any text if required.
Indications
Selecting Input Method
If you have installed more than one input method on your MID, you can select one
method by a) holding your tap on the button until the Android keyboard settings
appear; b) choosing “Input Method” and then choosing your desired one.
Access Internet
You can surf on the Internet with your slim MID.
You MID features built-in Wi-Fi technology and 3G card slot so that you can
access the internet via Wi-Fi and 3G network.
First of all, you need to configure a Wi-Fi or 3G network. For the Wi-Fi
configuration procedure to work, you need to be in a Wi-Fi zone that will allow
you to connect to it. Every time Your MID is in range of a network that you have
already configured once, it will attempt to make a connection. For the 3G
network configuration to work, you need to insert a 3G card into the device.
a. Caps Lock
b. Backspace.
c. Number and Characters
/Letter keyboard.
d. Space
e. Enter
cb
d
a
e

10
Making WIFI Connection
(1) Go on the Home screen, tap on the Menu icon and then select
“Settings”.
(2) In the “Settings” screen, select “Wireless & Networks”.
(3) If the WiFi is off, tap on the “Wi-Fi” setting to turn it on. Then select “Wi-Fi
settings”. Your MID will scan automatically for available WiFi networks
and display them. The list of available networks shows all the wireless
networks in range of your device.
- The list is constantly refreshed automatically.
- When the WiFi is enabled, Your MID will connect automatically to your
configured networks when they are in range.
- If Your MID finds a network that has never been configured, it will display
a notification icon.
(4) Tap on the network you want to connect to, enter the required network
information (password) and then tap on “Connect”. Your MID will now
attempt to establish a connection to that WiFi hot spot with the network
parameters you entered. If the connection is successful, the message
Connected to XXX will appear under the WIFI setting.
Note:
a) The available network list is constantly refreshed automatically.
b) When the Wi-Fi is enabled, Your MID will connect automatically to your configured
networks when they are in range.
c) If Your MID finds a network that has never been configured, it will display a notification
icon.
Advanced Connection
To manually scan for available Wi-Fi networks,
(1) In the “Wi-Fi settings” screen, tap on the Menu icon , and then tap on
“Scan”.
(2) If the Wi-Fi network you want to connect to does not appear in the list, scroll
down the screen, then tap on “Add a Wi-Fi network”. Enter the required
settings, then tap on “Save”.
To access the advanced network parameters (“Regulatory domain”, “IP
address”, etc), tap on the Menu icon , and then tap on “Advanced”. Other
parameters will appear. The required information can be obtained from the
person who manages the network.
