ZTV Electron ZT-850T User manual

MODEL
ZT-850T
PAGE:
1OF4
PRODUCT
INSTRUCTION DESCRIPTION
Wireless Camera
ZT-850T
WIRELESS CAMERAUSER SMANUAL
REVISIONS DESCRIPTION DATE DESIGN
SHENZHENZHONGWANG ELECTRONCO., LTD
APPROVAL
PAGES
TOTAL
FILE
NUMBER ISSUEDATE CHECK
4 DESIGN
FCCInformation
Thisdevicecomplieswithpart15oftheFCCRules,Operationissubjecttothefollowingtwoconditions:(1)Thisdevicemay
not causeharmfulinterference,and (2)Thisdevicemustacceptanyinterference
received,includinginterferencethat maycause
undesiredoperation.
CAUTION:
ChangesormodificationsnotexpresslyapprovedbySummerinfantmayvoidtheusersauthoritytooperatethis
equipment.
NOTE:Thisequipme
nthasbeentestedand found tocomplywiththelimitsforaClass Bdigitaldevice,pursuanttopart15of
theFCCRules.
Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterferenceinaresidentialinstallation.This
equipment
generates,usesand canradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe
instructions,maycauseharmfulinterference toradiocommunications,However,thereisnoguarantee thatinterference
will not
occurinaparticul
arinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcan
bedeterminedbyturningtheequipmentoffand on,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreof
thefollowingmeasures:
l Reorientorrelocatethereceivingantenna
l Increasetheseparationbetweentheequipmentandthereceiver
l Consult thedealeroranexperiencedradio/ TVtechnicianforhelp.

-2-
FILENUMBER MODEL ZT-850T PAGES:2OF4
Operationinstruction
1.Connectingthe receiverantenna.(Figure1)
2.Connectingthe 9Vdirect current stabilizer(Figure2), pilot lamplighting(Figure3).
3.Connectingthe audioandvideo (figure4)outputwiththe inputtothe monitor,the television
shouldbeseton A/Vmodel.
4.Connectingthe audioandvideo output withthe inputofthe transmitter.
5.Plugpowerjack ofDCpowersupply(8V,300mA)intothepowersocketofthe CMOScamera
(figure6). (Batteryofthe samevoltageisacceptable.)
6.Turningthemicro-adjustmentknob(figure5)on the receivertill receivingthe pictureofthe
wireless camera.
7.Fine tunetothe desireposition till the imageofCMOScameraisreceived.
8.Adjust thelensoftheCMOScamera(figure7)tobest position.
Notice
1.Themachine issupplied withmanydifferenttypes,pleaseprovide withelectricpoweraccording
the value on the label.
2.Obstructsbythe buildingand soon will causeattenuation.
3.Normallythat themachine will slightlywarmupduringoperation.
4.Shouldanyothermalfunctionsoccur, pleasecontactlocaldistributor.
5.Undernormaloperationalconditions,oneyear swarrantyisgranted.iftherearequalityproblems
within3months, thiscompanywillunconditionallyreplacewithanewcamera.
6.Pleasepowerdownwhen charge.
Waning
Thisproductisforthe solepurposeofsecurityandapplicableformonitoringinresidential
houses,shopsand companies.Theusershall observelocalrules,regulationsand laws,and
shall besolelyliableinthisregard.Thiscompanyshall not beliableforanyillegalitiestherein.
SHENZHENZHONGWANG ELECTRONCO., LTD TEL [phone]
FAX [phone]
http://www.ztv.cc

-3-
FILENUMBER MODEL ZT-850T PAGES:3OF4
TechnicalData
ITEM TYPE
Transmission
Frequency 2.414~2.468GHz4cH
Electricpower:DC 8V
Output power <10mW
Video input: 1.0VP-P(MAX)
Powerconsumption current<300mA
Audioinput: 2VP-P (Max.)
Effectiverange (no obstacles) 30m
CMOS
IMAGESENSOR 1/3-inchCMOSImageSensor
CMOSTOTALPIXELS 628*582
SYNC SYSTEM INTEMAL
MINIMUMILLUMINATION 1LμxF1.25600°K
RESOLUTION 330TVLine
Mode:AWB(Zerocolorrolling)
WHITEBALANCE
Range:3200~10000°K
GAINCONTROL AGC
S/NRATIO 48dB(Min)/60dB(TYP)(AGCOFF)
ELECTRONICSHUTTER 1/60~1/15,000sec
CAMMACORRECTION 0.45
OPERATIONTEMPERATURE -10℃~50℃
OPERATIONHUMIDITY 85%RH
SHENZHENZHONGWANG ELECTRONCO.,LTD TEL [phone]
FAX [phone]
http://www.ztv.cc

-4-
FILENUMBER MODEL ZT-850T PAGES:4OF4
.
SHENZHENZHONGWANG ELECTRONCO.,LTD TEL [phone]
FAX [phone]
http://www.ztv.cc
:
ReceiverAntenna
:②ReceiverPowerSocket
:③ReceiverIndicator
:A④udio&VideoJack
:⑤Monitor
:⑦Flip-typeChannelController
⑧:AdjustableLens
