Zummo Z40 Assembly instructions

MAINTENANCE INSTRUCTIONS
Maintenance and
cleaning tips
We advise using protective gloves to handle our juicers.
Cleaning the juice extraction system and front cover at least once a day is advisable.
Do not forget to regularly check the peel containers.
It is not necessary to use specialized products.
All parts can be washed in the dishwasher (it is advisable to clean the front cover by hand).
The front covers of our juicers are
comprised of polycarbonate and
ABS models.
For this reason, we advise not
cleaning them in the dishwasher to
prevent scratches or defects.
Z40 NATURE ONE

The machines must be cleaned and disinfected as frequently as indicated above. In this
process, first remove all the solid waste, and then clean and disinfect. The following
types of products can be used to disinfect the machines:
Descaling detergents/disinfectants for food use: Used either by immersion (small parts) or
sprayed (large parts and stainless-steel front of machine) in the concentration recommended
by the manufacturer. Each product must be left to act for the time indicated, and then rinsed
well to avoid contact of the juice with the product. These products usually have a very high
pH, which, with time, may degrade the polycarbonate, so it is advisable not to exceed the
product action times on transparent plastic parts.
Chlorinated disinfectant detergents for food use: Same use as the previous products. They
can be used by immersion or sprayed, bearing in mind the time recommendations given by
the manufacturer. Thoroughly rinse the parts treated before they come in contact with the
juice again.
Another option can be solutions with domestic use (4% chlorine) or industrial use (10%
chlorine) bleach. The necessary concentration for it to be eective at room temperature is
100 ppm, which means 2.5 ml of domestic bleach for every litre of water, or 1 ml of industrial
bleach per litre of water.
Juice extraction area:
oJuice extraction tray
oBlade
oCups
oAdapt tray
oTap*
oFront cover sides
oFront cover
oChutes/containers
oStainless steel machine front
Clean the following components at
least once a day:
Feeder:
oInterior basket and separators
oHopper track**
Cabinet:
oBody and interior of cabinet
oWaste containers
Clean weekly or twice a
week when required:
*These parts are handled by customers, so special attention is recommended. Keeping
a spare part is advisable, so that it can be changed half-way through the day.
** These parts are in contact with the fruit, so it is advisable to increase washing
frequency in spring and summer.
MAINTENANCE INSTRUCTIONS
Z40 NATURE ONE

Unplug the machine
from the mains.
With the machine stopped
press the o button.
Turn the flange upwards and
remove the side of the front cover.
.
Now remove the other side of the
front cover, turning the flange.
Do not forget to fit
the blade protector.
Extract the Adapt tray.Unscrew the nuts. Unscrew the cups.
Extract the Simpleclick balls.
To remove the juice extraction
system, pull it outwards.
Separate the two chutes. Turn the locking flange
1.
2.
4.
5.
6.
8.7.
9.
10. 11.
14. 15.
13.
12.
DISASSEMBLY INSTRUCTIONS
C/ Cádiz, 4 - 46113 Moncada - Valencia (Spain) - ([phone] - [e-mail] - www.zummocorp.com
Z40 NATURE ONE
Extract the front cover.
3.
Separate the filter from the tray.
Remove the scraper
from the tray.

DISASSEMBLY INSTRUCTIONS
C/ Cádiz, 4 - 46113 Moncada - Valencia (Spain) - ([phone] - [e-mail] - www.zummocorp.com
Z40 NATURE ONE
Press the side flanges.
1. Extract the tap from the tray. You can change the tap mode
by rotating the wheel,
2. 3.
Instructions to dismount the Adapt tray.
Extract the advanced lower basket.
17.
Remove the basket turning it in
anti-clockwise direction.
16.

Turn the lower flange and fit one
side of the front cover.
Remove the blade protector.
Fit the advanced lower basket. Insert the basket. Activate the locking flange.
Place the Simpleclick balls. Fit the juice extraction system
together with the cups.
Screw the nuts.
Fit the sweeper and insert
it into the Adapt tray.
Insert the filter into
the Adapt tray.
Screw the nuts of the Adapt tray.
Insert the Adapt tray.
1.
2. 3.
4.
6.
7. 9.
10. 11. 12.
8.
ASSEMBLY AND CLEANING INSTRUCTIONS
Z40 NATURE ONE
C/ Cádiz, 4 - 46113 Moncada - Valencia (Spain) - ([phone] - [e-mail] - www.zummocorp.com
5.
Insert the front cover. Turn the lower flange and fit the
other side of the front cover.
Fit the chutes.
13. 14. 15.

Clean all parts with water
and liquid detergent.
Also suitable for dishwashers
(Except front cover).
1.
ASSEMBLY AND CLEANING INSTRUCTIONS
Z40 NATURE ONE
Plug the machine into the mains. Press the on button.
C/ Cádiz, 4 - 46113 Moncada - Valencia (Spain) - ([phone] - [e-mail] - www.zummocorp.com
2.
16. 1 7.
D100822/21-1.
