ZYLIA ZR-1 User manual

Zylia sp. z o. o.
Uniwersytetu Poznańskiego 2,
61-614 Poznań, Poland
[email protected]
tel.:[phone]
www.zylia.co
KRS: 0000270693
REGON: 140778047
NIP: 5252380826

Zylia sp. z o. o.
Uniwersytetu Poznańskiego 2,
61-614 Poznań, Poland
[email protected]
tel.:[phone]
www.zylia.co
KRS: 0000270693
REGON: 140778047
NIP: 5252380826

Zylia sp. z o. o.
Uniwersytetu Poznańskiego 2,
61-614 Poznań, Poland
[email protected]
tel.:[phone]
www.zylia.co
KRS: 0000270693
REGON: 140778047
NIP: 5252380826
.......................................................................................................................................... 4
................................................................................................................. 4
................................................................................................................................... 5
................................................................................................................................. 5
...................................................................................................................... 5
........................................................................................................................ 7
................................................................................................................. 7
........................................................................................................ 8
............................................................................................................................ 9
.......................................................................................................................... 9
........................................................................................................................................ 9
...................................................................................................................................... 9
............................................................................................................................................. 9
.................................................................................................................. 9
.................................................................................................... 10
................................................................................................................. 11
.............................................................................................................................................. 11
........................................................................................................................................ 12
......................................................................................................................... 12
........................................................................................................................ 12
.................................................................................................... 12
............................................................................................................ 12

Zylia sp. z o. o.
Uniwersytetu Poznańskiego 2,
61-614 Poznań, Poland
[email protected]
tel.:[phone]
www.zylia.co
KRS: 0000270693
REGON: 140778047
NIP: 5252380826

Zylia sp. z o. o.
Uniwersytetu Poznańskiego 2,
61-614 Poznań, Poland
[email protected]
tel.:[phone]
www.zylia.co
KRS: 0000270693
REGON: 140778047
NIP: 5252380826
Button name
State of the
device
Action
Result
ON/OFF
Turned off
Push for 3 seconds
Device is being turned on
Turned on, idle
Push f
or 3 seconds
Device is being turned off
Recording in
progress
Push for 3 seconds
Device stops recording and turns off
REC
Device turned
on, idle
Push
Recording is started

Zylia sp. z o. o.
Uniwersytetu Poznańskiego 2,
61-614 Poznań, Poland
[email protected]
tel.:[phone]
www.zylia.co
KRS: 0000270693
REGON: 140778047
NIP: 5252380826
Button name
State of the
device
Action
Result
Recording in
progress
Push
Recording is finished
LED
ZM
-
1
connected, LED
Ring on
Push
The ZM
-
1 LED Ring is dimmed by 25%
every time and turned off eventually
ZM
-
1
connected, LED
Ring off
Push
The ZM
-
1 LED Ring is turned on
RC
(remote
control)
No paired
device
Push
ZR-1 device becomes visible and ready
to pair
Paired device
Push
No event action
Paired device
Push for 3 seconds
ZR-1 disconnects from remote control
application
Backward
No playback
Push
No event action
Playback on
Push
Skip to the previous recording
Playback on
Push & hold
Rewind – fast-backward
Play
Device
turned
on
Push
Play last recorded file
Playing
Push
Pause played file
Paused
Push
Continue playing the recorded file
Recording in
progress
Push
No event action
Forward
No playback
Push
No event action
Playback on
Push
Skip to next recording

Zylia sp. z o. o.
Uniwersytetu Poznańskiego 2,
61-614 Poznań, Poland
[email protected]
tel.:[phone]
www.zylia.co
KRS: 0000270693
REGON: 140778047
NIP: 5252380826
Button name
State of the
device
Action
Result
Play
back on
Push & hold
Fast forward

Zylia sp. z o. o.
Uniwersytetu Poznańskiego 2,
61-614 Poznań, Poland
[email protected]
tel.:[phone]
www.zylia.co
KRS: 0000270693
REGON: 140778047
NIP: 5252380826

Zylia sp. z o. o.
Uniwersytetu Poznańskiego 2,
61-614 Poznań, Poland
[email protected]
tel.:[phone]
www.zylia.co
KRS: 0000270693
REGON: 140778047
NIP: 5252380826
1. Download the bin from the link provided by ZYLIA.
2. Upload the provided file to a USB flash drive with FAT32 file system and at least 4GB of
free space.
3. It is recommended that during the update procedure the ZR-1 should be connected to the
external power adapter supplying 5V at 2,5A. The device should be turned off.
4. Remove the SD Card from the slot and connect the USB flash drive to the ZR-1 USB socket.
5. Turn on the device while simultaneous pressing and holding PLAY and REC buttons.
Release the buttons after around 5 seconds and wait until REC, SD CARD and GAIN LEDs
light up. After the three LEDs turn off, ON/OFF LED will change the color to purple
indicating that the firmware update process has started.
6. The process may last around 5 minutes. When the update ends, the ZR-1 will power off by
itself.
