ZyXEL Communications AG-225H V2 User manual

Smart Auto-detection for Instant Connection
802.11a/g Wi-Fi Finder &
USB Adapter
ag-225h v2
Benefits
Hotspot Finder
ZyXEL AG-225H v2 makes it easy to find a wireless hotspot when you are on the
road.The dual-band tri-mode USB adapter is equipped with a high contrast LCD
screen with backlight and built-in LiON battery,which allows you to scan the
environment for hotspots without being attached to your notebook computer.
LCD Status Display
The LCD screen displays detailed site survey information for easy reading.
In addition, users can scroll through the screens to view network SSID,
encryption requirements, signal strength, band used, and channels used.
Dual-Band Wireless Client
Due to the dual-band tri-mode nature of the AG-225H v2,you can easily add
support for 802.11a, 802.11b, and 802.11g wireless networking standards to your
desktop or laptop computer. Support for World Wide Radio (WWR) ensures no
matter where you are, you will be able to interoperate with the local Wi-Fi
networks. In dual-band environments,intelligent software constantly monitors
the wireless connection and will change bands to avoid interference and
maintain high throughput levels.
Enhanced Wireless Security
In addition to the basic 64/128/256-bit WEP encryption, the AG-225H v2 features
the latest wireless security mechanisms to protect your network with 802.1x
authentication and WPA/WPA2. These enhanced security functions allow only
authorized users to access the network,thus further protecting your data from
being tapped during wireless transmission.
Turn Your Laptop into an Access Point
Not only does the AG-225H v2 act as a hotspot finder and a client adapter, it can
also turn your computer into an instant wireless access point.Perfect for
conference rooms, meeting rooms,and hotels where you have one wired
network connection, but multiple computer users.
ł
IEEE 802.11a/b/g compliance (2.4GHz and 5GHz
radio bands)
ł
Supports software AP mode for Internet
connection sharing
ł
Displays detailed wireless site survey information
(SSID, channel, and security) on the LCD
ł
Supports LCD backlight
ł
Enhanced wireless security with WEP,WPA and WPA2
ł
Built-in rechargeable LiON battery charged via
the USB port
wire
l
ess

802.11a/g Wi-Fi Finder &
USB Adapter
ag-225h v2
Standard Compliance
• IEEE 802.11a, 802.11b, 802.11g
Application
• Wireless access for Desktop/Notebook PC
• Wi-Fi finder for road warriors and hotspot users
• Wireless Internet sharing as software Access Point
Frequency Range
• 802.11b/g: 2.4 ~ 2.4835GHz
• 802.11a: 5.15 ~ 5.25GHz
• 5.25 ~ 5.35GHz
• 5.470 ~ 5.725GHz (CE only)
• 5.725 ~ 5.825GHz (FCC only)
Data Rate (Automatic Fallback)
• 802.11b: 11M/5.5M/2M/1Mbps
• 802.11g: 54M/48M/36M/24M/18M/12M/9M/6M
• 802.11a: 54M/48M/36M/24M/18M/12M/9M/6M
RF Output Power
• 802.11b: 18dBm @11Mbps
• 802.11g: 15dBm @54Mbps
• 802.11a: 14dBm @54Mbps
Modulation Technique
• DBPSK/DQPSK/CCK/OFDM
Network Architecture
• Infrastructure
• Ad-Hoc (FCC only)
Security
• 64/128/256-bit WEP Encryption,WPA and WPA2
Hardware Specifications
• Host Interface: USB 2.0
• Antenna: Internal Antenna
Physical Specifications
• Dimensions: 99 (W) x 32 (D) x 16 (H) mm
• Weight: 36g
Environmental Specifications
• Temperature: 0ºC ~ 50ºC
• Humidity: 10% ~ 70%, non-condensing
System Requirements
• Intel-compatible Pentium II 300 MHz or higher
• 32 MB RAM (64MB Recommended)
• A minimum of 20MB available hard disk space
• A CD-ROM drive
• A USB port (V2.0/V1.1)
• Microsoft Windows XP/2000
Specifications
Application Diagram
Internet
TMTM
Us
e AG-22
5
H v2
to
d
e
t
e
ct
W
i-Fi Hots
p
ot
s
1.Wi-Fi Finder Mode
Allo
w
oth
er
s
to
sha
re
I
nternet connection
H
otspo
t
2. Client Adapter Mode 3. Software AP Mode
Plu
g
-
i
n AG-225H v2 to laptop
f
or Internet access W
i
-F
i
VoI
P
P
-2
000W
Wireless Laptop
S
o
f
tware AP Mode
TMTM
Internet
65-100-022202G 05/06
