Prestige 2002 Series
Benefits
Models:
P-2002, VoIP ATA
P-2002L, VoIP ATA with PSTN Lifeline
ZyXEL’s P-2002 is an Analog Telephone Adapter (ATA) that
provides customers with an easy-to-use solution for Voice over IP
service deployment. Connecting a traditional phone set to the
POTS phone port of the P-2002 series instantly establishes an IP
phone device, allowing users to place VoIP calls without the use of
a PC. Based on industry standard SIP (Session Initiation protocol,
RFC 3261) call control protocol and sophisticated voice
compression technology, the P-2002 series offers smooth IP-based
voice communication with superb sound quality.
ZyXEL’s P-2002 series Analog Telephone Adapter is an ideal
solution for IP Telephony service deployment as well as SOHO
and Home VoIP applications.
Application Diagram
VoIP Analog Telephone Adapter
Supports Open Standard
ZyXEL’s P-2002 series supports standard SIP (RFC 3261), which is
suitable for IP telephony service deployment and addresses the
needs of users who are connecting to emerging SIP-based
communication networks.
Easy to Deploy
ZyXEL’s P-2002 series supports multiple methods of configuration
including Web-based configuration, Telnet management, and TFTP
Auto-Provisioning. It eliminates the time and effort associated with
complicated installation procedures.
Multiple SIP and Voice Channels
Based on ZyXEL’s flexible VoIP technology platform, one or more
SIP phone number may be configured with the P-2002 ATA. Each
SIP phone number can be freely assigned to either phone port
individually, or to both ports at the same time.
By using the P-2002 ATA to deploy VoIP service, service providers
need only provide a minimum of one SIP number to each
subscriber. Billing and service deployment are simplified by
allowing subscribers to use two phones with the same SIP number.
If one telephone is in use, users may use a secondary telephone to
place a call while using the same SIP number. Additionally, users
may also receive incoming calls even when the SIP number is in use.
The advantages of the P- 2002 ATA include increased traffic and
service revenue.
Cost Effective
ZyXEL’s P-2002 series turns a traditional phone into an IP phone
device at a very low cost. Not only does the Prestige 2002 series
deliver VoIP service at a low per-port cost but the built-in two-port
Ethernet switch also allows user to connect their PC to the reserve
Ethernet port without adding an extra Ethernet switch or hub.
Lifeline Support (Option, P-2002L)
ZyXEL’s P-2002L allows users to maintain PSTN phone service and
VoIP service at the same time. When ATA power down occurs or
VoIP service is not available, outgoing phone calls will be relayed
to PSTN automatically. When VoIP service is active, users can
place calls to a PSTN phone by dialing pre-fix numbers. Emergency
calls or important calls can be relayed to PSTN automatically.
IP Telephony Service
Provider Application
Trunking
Gateway
VoIP
Call
Server
IP Telephony Service Provider
PSTN Phone
Cable/DSL Modem
PSTN
Network
PSTN
Network
Home
Cable/DSL Modem
P-2002
FXS
FXS
Home
FXS
FXS
P-2002L
Internet
RJ-45 Ethernet
RJ-45 Ethernet
Life Line Relay
IP-PBX based Corporate
VoIP Application
IP Network
PSTN Phone
Headquarters
IP-PBX
Branch Office
FXS
FXS
P-2002
P-2002
Traditional
Phone
Network
RJ-45 Ethernet
RJ-45 Ethernet
PSTN
Network

Copyright© 2004 ZyXEL Communications Corporation. All rights reserved. The ZyXEL and ZyNOS logo are registered trademarks of ZyXEL Communications Corp. Other trademarks and service names referenced are properties of their respective holders. All specifications are subject to change without notice. 65-100-200303
Features
Voice Functionality
• SIP (RFC 3261) version 2
• SDP (RFC 2327)
• RTP (RFC1889)
• RTCP (RFC1890)
• Echo Cancellation: G.168
• VAD (Voice Activity Detection)
• Silence Suppression
• CNG (Comfort Noise Generation)
• Dynamic Jitter Buffer (Adaptive)
• QoS Supports TOS, DiffServ
• VLAN Tagging
• 3 REN per RJ-11 FXS ports
• DTMF Detection and Generation
• DTMF: In-Band and Out-of-Band
(RFC 2833), (SIP INFO)
• SIP NAT Traversal Support STUN
(RFC 3489)
• Fax Tone Detection and Pass-through
• Modem Tone Detection and Pass-through*
• T.38 FAX Relay*
• Speed Dial Phonebook
• Telephony Features: Caller ID, Call
Waiting, Message Waiting, Three Way
Conference (Depends on IP Telephony
Service Provider)*
• Flash Hook Timer*
• Multiple SIP Accounts/Phone Numbers —
Freely assignable to Each Phone Port
• Multiple Channel Technology
Voice Codecs
• G.711
• G.729
• GSM (Option)*
• G.726 (Option)*
• G.723 (Option)*
PSTN Lifeline Support
(Option, P-2002L with PSTN Line Port)
• Send Emergency Call to PSTN
• Make a PSTN Call by Dialing
Pre-fix Number
• PSTN Relay when Device Power Down
• PSTN Relay when VoIP Service is
Not Available
• Receive Incoming PSTN Phone Call
Network Functionality
• PPPoE
• DHCP Client
• Friendly Web-based Configuration Tool
• Telnet Management
• FTP/TFTP Firmware Upgrade and
Configuration Backup/restore
• Support TFTP Auto-Provisioning
Specifications
Real Panel
Hardware Specification
• LAN: Two 10M/100M Auto MDI/MDIX
Ethernet Ports
• Phone: Two RJ-11 ports for Analog
Telephone sevice
• Lifeline Port: One RJ-11 Port for PSTN
Lifeline (P-2002L)
• Reset Button
• Status LEDs Indicator: PWR/VoIP, LAN,
PC, Phone1, Phone2
• Power: 12V AC input
Physical Specification
• Dimensions:
180(L) x 128(D) x 36.5(H) mm
• Weight: 312g
Operating Environment
• Temperature: 0°C ~ 40°C
• Humidity: 20% ~ 85% (Non-condensing)
