ZyXEL Communications WPA-1000 User manual

Make Your Next Presentation Move
Benefits
High-Speed Wireless Connection
ZyXEL WPA-1000 seamlessly integrates a high-speed wireless hardware
solution and a unique compression software module to provide 54 Mbps
data throughput via wireless connections.With its friendly Web-based user
interface, users can control the presentation with just one button on the
PC utility software; while WPA-1000 replicates the image on the computer
screen to the remote display device, such as a projector, simultaneously.
Auto-Search VGA Signal Support
With ZyXEL WPA-1000, conventional wired projectors/monitors can be
upgraded to fancy wireless counterparts immediately. Since WPA-1000
searches virtually all projector/monitor signals automatically and eases the
setup efforts, just click a button and your professional presentation is
ready to roll.
No VGA Cable or User Swapping Hassle
With ZyXEL WPA-1000, speakers do not have to swap VGA cable for their
turn, and you have greater control over the presentations.The WPA-1000
administrator can designate a logged-in user to display his or her material,
and queue all others on a waiting list with handy stop/play/kick
functionalities on the control panel.
ł
802.11b/g Wireless Connectivity
ł
Advanced Wireless Security Transmission with
WEP Encryption
ł
Install Built-in Projecting Software from the Product,
not CD
ł
Plug and Show (PnS) technology: allows installation
free by using PnS dongle (included)
ł
Presentation from Multiple Users
ł
Web-based Management Tools with Conference Control
ł
Compatible with Virtually All Projectors with
VGA Connectivity
ł
Vista Compatible
DIGITAL MEDIA
Wireless Projector Adapter
WPA-1000

Wireless Projector Adapter
WPA-1000
Standard Compliance
• Comply to 802.11b/g w onnectionwireleeless co
•Standard VGA output
Software Features
•on)tioAP mode (as as a server in connectin wireless c
•Auto-searcrch for avaA rsvailable projectors
System Requirements
•III 800MHz orputinComputing powwer: Intel Pentium I
er profaster rocessor
•Memory SizMe ize: 256 MBMB RAM
••10MB free harard-disk spspace
•soft Windows 2000 ServiceOperating Systetem: Microoso
s XP Service Pack 2 or later,Pack 4 or later,WiWindows
bitor Windows Vista 32 b32 b
•Explorer 6.0 or 7.0Browser:Microsoft Ex
Firefox 1.5 or 2.0(recommended), F
•11b/g Wireless adapter or EthernetNetworks: 802.11
connection
•pports display resolutions up toDisplay: Supp
00 with 32-bit color depth1280 x 800
Hardware Specifications
Networks
•One 10/100 Ethernet LAN port
• 802.11b/g wireless connection with antenna
Output Connectors
• D-Sub 15-pin VGA Connector
Power
• DC 5V, 2A
Others
• Reset button
Physical Specifications
• Dimensions: 190 (W) x 130 (D) x 32 (H) mm
•Weight: 0.4 Kg
Environmental Specifications
Temperature
• Operating: 0ºC ~ 45ºC
• Storage: -40ºC ~ 70ºC
Humidity
• Operating: 5% ~ 90% RH
• Storage: 0% ~ 95% RH
Regulation
Safety
• UL1950
• CSA C22.2 No.950
• EN60950, EN41003
EMC
• FCC Part 15 Class A
• EN55022 Class A
Specifications
Application Diagram
WPA-1000
Wireless Projector Adapter
U
ser
r 1
U
ser 2
r 2
U
ser 3
r 3
U
ser 4
r 4
Projector
ADSL ModemADSL Gateway
Internet
For more product information, visit us on the web at www.ZyXEL.com
65-100-102602B 01/08
Copyright © 2008 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of ZyXEL Communications Corp. All other brands,
product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.
