ZyXEL Communications FiberHome AN5516-06 Guide

AN5516-06
Optical Line Terminal Equipment
Hardware Description
Version: A
Code: MN000000814
ZyXEL FiberHome
May 2011

I
Preface
Related Documentation
Document Description
AN5516-06 Optical Line
Terminal Equipment
Documentation Guide
Introduces the retrieval method, contents, releasing,
reading approach, and suggestion feedback method for
the complete manual set for the AN5516-06.
AN5516-06 Optical Line
Terminal Equipment Product
Description
Introduces the AN5516-06's network location, functional
features, hardware structure, FTTx application model,
equipment configuration, network management system
and technical specifications. It is the foundation of the
complete manual set. The other manuals extend and
enrich the concepts introduced in the Product Description.
AN5516-06 Optical Line
Terminal Equipment Feature
Description
Introduces the key features supported by the AN5516-06,
including GPON / EPON access, GPON / EPON terminal
management, VLAN, broadcast, voice and safety; and
introduces these functions in details in terms of definition,
characteristic, specification, principle description,
references and so on.
AN5516-06 Optical Line
Terminal Equipment Hardware
Description
Introduces the appearance, structure, functions, technical
specifications, and usage method for the AN5516-06’s
cabinet, PDP, subrack, cards, cables and wires, facilitating
users’ mastery of the hardware features of the equipment.
AN5516-06 Optical Line
Terminal Equipment Installation
Guide
Introduces the overall installation and verifying procedure
from unpacking inspection to power-on examination after
the equipment is delivered on site, and provides reference
information (e.g. safety principles and wiring scheme of a
variety of interfaces) to guide users to install the
equipment.

II
Document Description
AN5516-06 Optical Line
Terminal Equipment EPON
Configuration Guide
Introduces the method for configuring the EPON services
supported by the equipment via ANM2000 Network
Management System, such as basic configuration, voice
service configuration, data service configuration, multicast
service configuration, and software upgrading
configuration, to guide users on start-up for various
services and software upgrading.
AN5516-06 Optical Line
Terminal Equipment GUI
Reference
Introduces the shortcut menu for every card of the
AN5516-06 inside ANM2000 Network Management
System, including the function, parameter explanation,
precautions and configuration example of every command
in the shortcut menu of each card, to help users master
the operation of the AN5516-06 inside ANM2000.
AN5516-06 Optical Line
Terminal Equipment Component
Replacement
Introduces the operation procedures of replacing the
AN5516-06’s components, including preparations,
precautions, early operations, operation process and
subsequent operations, so as to guide users with the
completion of component replacement on the hardware.
AN5516-06 Optical Line
Terminal Equipment Routine
Maintenance
Introduces routine maintenance operations of the
AN5516-06, including remote maintenance and on-site
maintenance.
AN5516-06 Optical Line
Terminal Alarm and Event
Reference
Introduces the AN5516-06’s alarm information and event
reference, including alarm / event names, alarm / event
levels, possible reasons, effects on the system, and
processing procedure.
AN5516-06 Optical Line
Terminal Equipment
Troubleshooting Guide
Introduces the fault processing principles and methods of
fault diagnosis and locating for the AN5516-06. Also
discusses the typical fault cases of various services. If the
trouble is too complicated to process, users can refer to
ZyXEL for technical support according to the
instructions in this document.
AN5516-06 Optical Line
Terminal Equipment Quick
Installation Guide
Introduces the AN5516-06 installation and cable
connection and layout using diagrams to guide a quick
installation for users.

III
Version
Version Description
A Initial version.
Intended Readers
This manual is intended for the following readers:
Planning and designing engineers
Commissioning engineers
Operation and maintenance engineers
To utilize this manual, these prerequisite skills are necessary:
Electrical safety knowledge
Related mechanical engineering knowledge

IV
Conventions
Terminology Conventions
Terminology Convention
AN5516-06 AN5516-06 Optical Line Terminal Equipment
ANM2000 ZyXEL FiberHome e-Fim ANM2000 Broadband Access
Network Management System
EC4B 4×EPON-C Interface Card (type B)
EC8B 8×EPON-C Interface Card (type B)
GC4B 4×GPON-B Interface Card (type B)
GC8B 8×GPON-C Interface Card (type B)
C155A 1×STM-1 Optical Interface Card (CES Mode)
CE1B 32×E1 Optical Interface Card (CES mode) (type B)
PUBA Public Card (type A)
HSWA Core Switch Card (EPON) (card number: 2.115.334)
HU1A 4×GE +1×10GE Optical Interface Uplink Card
HU2A 2×GE +2×10GE Optical Interface Uplink Card
GU6F 6×GE Optical Interface Uplink Card
CIO Common Interface Card
PWR Power Supply Card
FAN Fan Control Card
Symbol Conventions
Symbol Convention Description
Note Important features or operation guide.
Caution Possible injury to persons or systems, or cause traffic
interruption or loss.
Warning May cause severe bodily injuries.

Contents
Preface .................................................................................................................... I
Related Documentation...................................................................... I
Version ....................................................................................... III
Intended Readers ............................................................................ III
Conventions .....................................................................................IV
1Cabinet......................................................................................................... 1-1
1.1Appearance.................................................................................... 1-2
1.2Size and Weight............................................................................. 1-5
1.3Structure ........................................................................................ 1-6
1.4Typical Layout .............................................................................. 1-12
1.5Ventilation Principle...................................................................... 1-14
2PDP.............................................................................................................. 2-1
2.1Function ......................................................................................... 2-2
2.2Structure ........................................................................................ 2-3
2.3Power Connector ........................................................................... 2-5
2.3.1Main and Branch Power Supply Connector Posts ........... 2-5
2.3.2Automatic Circuit Breaker ................................................ 2-6
2.4Alarm Terminal ............................................................................... 2-7
2.5Lightning Protection Module........................................................... 2-7
2.6Specifications ................................................................................. 2-8
3Subrack ........................................................................................................ 3-1
3.1Structure ........................................................................................ 3-2
3.2Size and Weight............................................................................. 3-2
3.3Subrack Configuration ................................................................... 3-3
3.4Fan Unit ......................................................................................... 3-4
3.4.1Function........................................................................... 3-4
3.4.2Appearance ..................................................................... 3-4
3.4.3Specifications................................................................... 3-5

4Card ............................................................................................................. 4-1
4.1Appearance and Structure ............................................................. 4-2
4.2Card Configuration Table ............................................................... 4-7
4.3HSWA Card.................................................................................... 4-8
4.4EC4B Card................................................................................... 4-12
4.5EC8B Card................................................................................... 4-16
4.6GC4B Card .................................................................................. 4-20
4.7GC8B Card .................................................................................. 4-24
4.8HU1A Card................................................................................... 4-28
4.9HU2A Card................................................................................... 4-30
4.10GU6F Card................................................................................... 4-32
4.11CE1B Card................................................................................... 4-34
4.12C155A Card ................................................................................. 4-37
4.13PUBA Card................................................................................... 4-40
4.14CIO Card...................................................................................... 4-42
4.15PWR Card.................................................................................... 4-44
5Cable and Connector ................................................................................... 5-1
5.1Power Cable .................................................................................. 5-2
5.1.1Cabinet Power Cable....................................................... 5-2
5.1.2Subrack Power Cable ...................................................... 5-4
5.2Protection Earth Ground Cable ...................................................... 5-6
5.2.1Subrack Protection Earth Ground Cable.......................... 5-6
5.2.2Cabinet Protection Earth Ground Cable .......................... 5-7
5.3Alarm Cable ................................................................................... 5-8
5.3.1Alarm Cable for the Head of Row Cabinet ....................... 5-8
5.3.2Subrack Alarm Cable ....................................................... 5-9
5.4Fiber Jumper................................................................................ 5-10
5.5Coaxial E1 Cable ......................................................................... 5-12
5.6Coaxial Clock Cable..................................................................... 5-15
5.7Network Cable ............................................................................. 5-16
5.8Serial Port Cable.......................................................................... 5-19
5.9Dry Contact Cable........................................................................ 5-21

Appendix A Abbreviation ...................................................................................A-1

Figures
Figure 1-1 An illustration of the 19-inch cabinet .............................................. 1-2
Figure 1-2 An illustration of the 21-inch cabinet .............................................. 1-3
Figure 1-3 An illustration of the 21-inch antidust cabinet................................. 1-4
Figure 1-4 The 19-inch cabinet ....................................................................... 1-6
Figure 1-5 The 21-inch cabinet ....................................................................... 1-8
Figure 1-6 The 21-inch antidust cabinet ........................................................ 1-10
Figure 1-7 Typical layoutof the 19-inch cabinet ............................................. 1-12
Figure 1-8 Typical layout of the 21-inch cabinet ............................................ 1-13
Figure 1-9 An illustration of ventilation principle for a 19-inch cabinet........... 1-15
Figure 1-10 An illustration of ventilation principle for a 21-inch cabinet........... 1-16
Figure 2-1 The PDP structure.......................................................................... 2-3
Figure 2-2 The PDP panel............................................................................... 2-4
Figure 2-3 The PDP front panel....................................................................... 2-6
Figure 3-1 Subrack structure........................................................................... 3-2
Figure 3-2 An illustration of subrack configuration ..........................................3-3
Figure 3-3 The appearance of the fan unit ...................................................... 3-4
Figure 4-1 Appearance and structure of the EC4B card.................................. 4-3
Figure 4-2 Appearance and structure of the HU1A card.................................. 4-4
Figure 4-3 Appearance and structure of the PWR card................................... 4-5
Figure 4-4 Appearance and structure of the CIO card..................................... 4-6
Figure 4-5 The location of the key on the HSWA card................................... 4-10
Figure 4-6 The location of the keys of the EC4B card................................... 4-14
Figure 4-7 Location of the key of the EC8B card........................................... 4-18
Figure 4-8 Location of the key of the GC4B card .......................................... 4-22
Figure 4-9 Location of the key of the GC8B card .......................................... 4-26
Figure 4-10 Location of the key of the CE1B card........................................... 4-35
Figure 4-11 Location of the key of the C155A card ......................................... 4-38
Figure 4-12 Location of the key of the PUBA card .......................................... 4-41
Figure 5-1 The DC -48V power cable.............................................................. 5-2

Figure 5-2 The ground cable ........................................................................... 5-3
Figure 5-3 The protection earth ground cable ................................................. 5-3
Figure 5-4 The end of the cabinet power cable connected with the PDP........ 5-3
Figure 5-5 The subrack power cable............................................................... 5-4
Figure 5-6 The subrack protection earth ground cable.................................... 5-6
Figure 5-7 The cabinet protection earth ground cable..................................... 5-7
Figure 5-8 The alarm cable for the head of row cabinet .................................. 5-8
Figure 5-9 The subrack alarm cable................................................................5-9
Figure 5-10 The LC / PC optical fiber connector ............................................. 5-11
Figure 5-11 The SC / PC optical fiber connector............................................. 5-11
Figure 5-12 The 75ΩE1 cable ........................................................................ 5-12
Figure 5-13 The DB-44P Plug ......................................................................... 5-13
Figure 5-14 The coaxial clock cable ................................................................ 5-15
Figure 5-15 The network cable........................................................................ 5-16
Figure 5-16 The RJ-45 connector ................................................................... 5-17
Figure 5-17 The serial port cable .................................................................... 5-19
Figure 5-18 The dry contact cable................................................................... 5-21

Tables
Table 1-1 The size and weight of the cabinets............................................... 1-5
Table 1-2 Descriptions of alarm indicator LEDs on the top of the 19-inch cabinet
....................................................................................................... 1-7
Table 1-3 Descriptions of alarm indicator LEDs on the top of the 21-inch cabinet
....................................................................................................... 1-9
Table 1-4 Descriptions of alarm indicator LEDs on the 21-inch antidust cabinet
..................................................................................................... 1-11
Table 2-1 Introduction to external power input connectors............................. 2-5
Table 2-2 Introduction to external power input connectors............................. 2-5
Table 2-3 The PDP parameter specifications................................................. 2-8
Table 3-1 The size and weight of the subrack................................................ 3-2
Table 3-2 Fan unit parameter table ................................................................3-5
Table 4-1 Classification of the AN5516-06 Cards .......................................... 4-2
Table 4-2 The AN5516-06card configuration table......................................... 4-7
Table 4-3 The HSWA card interfaces............................................................. 4-9
Table 4-4 The HSWA card indicator LEDs ..................................................... 4-9
Table 4-5 The HSWA card key..................................................................... 4-10
Table 4-6 The HSWA card technical specifications...................................... 4-11
Table 4-7 The EC4B card interfaces............................................................ 4-12
Table 4-8 The EC4B card indicator LEDs .................................................... 4-13
Table 4-9 The EC4B card keys .................................................................... 4-14
Table 4-10 The EC4B card technical specification......................................... 4-15
Table 4-11 The EC8B card interfaces ............................................................ 4-16
Table 4-12 The EC8B card indicator LEDs .................................................... 4-17
Table 4-13 The EC8B card key...................................................................... 4-17
Table 4-14 The EC8B card technical specification......................................... 4-18
Table 4-15 The GC4B card interfaces............................................................ 4-20
Table 4-16 The GC4B card indicator LEDs.................................................... 4-21
Table 4-17 The GC4B card key ..................................................................... 4-21

Table 4-18 The GC4B card technical specification ........................................ 4-22
Table 4-19 The GC8B card interfaces............................................................ 4-24
Table 4-20 The GC8B card indicator LEDs.................................................... 4-25
Table 4-21 The GC8B card key ..................................................................... 4-25
Table 4-22 The GC8B card technical specification ........................................ 4-26
Table 4-23 The HU1A card interfaces ............................................................ 4-28
Table 4-24 The HU1A card indicator LEDs .................................................... 4-28
Table 4-25 The HU1A card technical specification......................................... 4-29
Table 4-26 The HU2A card interfaces ............................................................ 4-30
Table 4-27 The HU2A card indicator LEDs .................................................... 4-30
Table 4-28 The HU2A card technical specification......................................... 4-31
Table 4-29 The GU6F card interface.............................................................. 4-32
Table 4-30 The GU6F card indicator LEDs .................................................... 4-32
Table 4-31 TheGU6F card technical specification ......................................... 4-33
Table 4-32 The CE1B card interfaces ............................................................ 4-34
Table 4-33 The CE1B card indicator LEDs .................................................... 4-34
Table 4-34 The CE1B card key...................................................................... 4-35
Table 4-35 The CE1B card technical specification......................................... 4-35
Table 4-36 The C155A card interfaces........................................................... 4-37
Table 4-37 The C155A card indicator LEDs................................................... 4-37
Table 4-38 The C155A card key .................................................................... 4-38
Table 4-39 The C155A card technical specification ....................................... 4-39
Table 4-40 The PUBA card interfaces............................................................ 4-40
Table 4-41 The PUBA card indicator LEDs .................................................... 4-40
Table 4-42 The PUBA card key...................................................................... 4-40
Table 4-43 The PUBA card technical specification ........................................ 4-41
Table 4-44 The CIO card interfaces............................................................... 4-42
Table 4-45 The CIO card indicator LEDs ....................................................... 4-42
Table 4-46 The CIO card technical specification............................................ 4-43
Table 4-47 The PWR card interfaces ............................................................. 4-44
Table 4-48 The PWR card indicator LEDs ..................................................... 4-44
Table 4-49 The PWR card technical specification.......................................... 4-44
Table 5-1 Purposes of fiber jumpers ............................................................ 5-10

Table 5-2 The corresponding relationship between the card and the fiber
jumper.......................................................................................... 5-11
Table 5-3 Signal description associated with the E1 interface pin ...............5-13
Table 5-4 The wiring scheme of the straight-through network cable ............ 5-17
Table 5-5 The wiring scheme of the cross-over network cable .................... 5-17
Table 5-6 Definition of the serial port cable pins .......................................... 5-20
Table 5-7 The wiring scheme of the dry contact cable ................................. 5-22

Version: A 1-1
1Cabinet
This chapter introduces the AN5516-06 cabinet and includes the following
contents:
Appearance
Size and weight
Structure
Typical layout
Ventilation principle

AN5516-06 Optical Line Terminal Equipment Hardware Description
1-2 Version: A
1.1 Appearance
The AN5516-06 can be mounted in a 19-inch cabinet or a 21-inch cabinet.
Figure 1-1 illustrates the appearance of the 19-inch cabinet.
Figure 1-1 An illustration of the 19-inch cabinet

1 Cabinet
Version: A 1-3
Figure 1-2 illustrates the appearance of the 21-inch cabinet.
Figure 1-2 An illustration of the 21-inch cabinet

AN5516-06 Optical Line Terminal Equipment Hardware Description
1-4 Version: A
Figure 1-3 illustrates the appearance of the 21-inch antidust cabinet.
Figure 1-3 An illustration of the 21-inch antidust cabinet

1 Cabinet
Version: A 1-5
1.2 Size and Weight
Table 1-1 provides the size and weight of each type of cabinet.
Table 1-1 The size and weight of the cabinets
Cabinet Type Size (H×W×D) Hardware Number Weight (Empty Cabinet)
19-inch cabinet
1600mm×600mm×600mm 4.102.596 94kg
2000mm×600mm×600mm 4.102.597 109kg
2200mm×600mm×600mm 4.102.598 117kg
2600mm×600mm×600mm 4.102.599 134kg
21-inch cabinet
1600mm×600mm×300mm 4.102.589 51kg
2000mm×600mm×300mm 4.102.590 61kg
2200mm×600mm×300mm 4.102.591 71kg
2600mm×600mm×300mm 4.102.592 76kg
21-inch antidust cabinet
1600mm×600mm×300mm 404000068 58 kg
2000mm×600mm×300mm 404000069 69 kg
2200mm×600mm×300mm 404000070 74 kg
2600mm×600mm×300mm 404000071 85 kg
