PoE12 Series
802.3af/802.3at
PoE Injector
PoE12 Series
802.3af/802.3at
PoE Injector
Ł
IEEE 802.3af and IEEE 802.3at
Power over Ethernet (PoE)
standards compliant
Ł
Install anywhere taking
advantage of PoE technology
Ł
Superior safety with
overloading and short-circuit
protection
Empower Easy Power over
Ethernet Connectivity
The ZyXEL PoE12 Series is a PoE injector designed to support the increasing power demands
of the latest-generation N wireless Access Points (APs) as well as the pan, tilt or zoom
functions of IP surveillance cameras.The PoE12 Series consists of two models: PoE-12 and
PoE12-HP.The PoE-12 and PoE12-HP are single-port PoE injectors that deliver both power
and data to other PoE devices via a single CAT-5 Ethernet cable without extra power supply.
The PoE-12 enables 100 Mbps data transmissions and provides power up to 15.4 W, while
the PoE12-HP allows data transmitted at 1000 Mbps and delivers power up to 30 W.
Benefits
Industry standard compliance and investment protection
PoE is a standard-based technology that specifies how power is distributed along with data on
standard Ethernet LAN cables.The standard specifies IEEE 802.3af providing up to 15.4 W of power
per device and IEEE 802.3at providing up to 30 W per device. Complying with the IEEE 802.3af and
IEEE 802.3at standards, the ZyXEL PoE12 Series offers interoperability and compatibility with other
standard-based PoE devices.
Trouble-free installation
With PoE technology, the PoE12 Series enables users to place devices such as wireless LAN APs,IP
surveillance cameras and IP phones exactly where they are needed. Since the devices are directly
powered through Ethernet cables, there is no need to have separate power supplies or to have
costly electrical engineers putting AC power sockets on ceilings or roof spaces.
Plug and Play—ease of use
The PoE12 Series is easy to use and needs no configuration. Since only simple inbound and
outbound cable plugs are required, the installation is very straightforward and can be performed
by users having no electrical wiring experience without spending extra cost.

5-100-01011004 06/11
For more product information, visit us on the web at www.ZyXEL.com
Copyright © 2011 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of
ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their
respective owners. All specifications are subject to change without notice.
ADSL/Cable
Modem
Non-PoE Switch
PoE AP
PoE IP Camera
Power Outlet
PoE-12
802.3af PoE
Injector
Power Outlet
PoE12-HP
802.3at PoE
Injector
Internet
CAT-5 Cable (Data)
Power Cable (Power)
PoE12 Series
802.3af/802.3at PoE Injector
PoE12 Series
802.3af/802.3at PoE Injector
Specifications
Application Diagram
Note: *1: 10/100 or 10/100/1000Base-T (Data),for connection to the passive hub or switch
*2: 10/100 or 10/100/1000Base-T (Power/Data),for connection to the PoE devices (PD)
Model PoE-12 PoE12-HP
802.3af PoE Injector 802.3at PoE Injector
Product Name
Ports
10/100Base-T (Data)*1 1 -
10/100Base-T (Power/Data)*2 1 -
10/100/1000Base-T (Data)*1 - 1
10/100/1000Base-T (Power/Data)*2 - 1
Standard Compliance
IEEE 802.3 10Base-T Ethernet IEEE 802.3 10Base-T Ethernet
Ethernet IEEE 802.3u 100Base-Tx Ethernet IEEE 802.3u 100Base-Tx Ethernet
IEEE 802.3ab 1000Base-T
PoE IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet
Certification
UL 60950-1 EN 60950-1
Safety EU RoHS Compliant CSA international
EU RoHS Compliant
Emission (EMC) FCC Part15 (Class B) FCC Part15 (Class B)
CE EMC (Class B) CE EMC (Class B)
Power Requirement
Input voltage 100 - 240 V AC, 50/60 Hz, 0.3 A 100 - 240 V AC, 50/60 Hz, 1.5 A max
Power consumption (Watt) 17.3 42.1
Physical Specifications
Item dimensions (WxDxH)(mm/in.) 117 x 60 x 35/4.61 x 2.36 x 1.38 155 x 74 x 36/6.10 x 2.91 x 1.42
Item weight (g/lb.) 177/0.26 396/0.87
Packing dimensions (WxDxH)(mm/in.) 201 x 133 x 54/7.91 x 5.24 x 2.13 202 x 155 x 69/7.95 x 6.10 x 2.72
Packing weight (g/lb.) 500/1.10 780/1.72
Environmental Specifications
Operating temperature 5°C to 45°C/41°F to 113°F 0°C to 50°C/32°F to 122°F
Operating humidity 10% to 90% (Non-condensing) 10% to 95% (Non-condensing)
Storage temperature -20°C to 55°C/-4°F to 131°F -40°C to 70°C/-40°F to 158°F
Storage humidity 5% to 95% (Non-condensing) 5% to 95% (Non-condensing)
