ZyXEL Communications P-2602H-D1A User manual

P-2602H-DxA Series
ADSL2+ VoIP IAD
Quick Start Guide
Version 3.40
5/2006
Edition 1

P-2602H-DxA Series Quick Start Guide
2
Overview
This Quick Start Guide is designed to help you set up the P-2602H-DxA series devices (“P-2602H-DxA”). The
P-2602H-DxA series is an ADSL2+ router with a built in 4-port switch and VoIP integrated access device
(IAD).
Note: The screens in this guide reflect the P-2602H-D1 model.
The following figure shows how your P-2602H-DxA (A) connects your network to the Internet and provides
firewall protection. It also shows how your device can make VoIP calls and calls to regular phones.
1 Requirements
Make sure you have the following things before you set up your P-2602H-DxA.
• Internet access - account information provided by your ISP, such as user name, password, and so on.
• VoIP account - You need the account information provided by your VoIP service provider (the company that lets
you make phone calls over the Internet). This information might include your URI, number, and so on.
• Internet Explorer 6.0 or later or Netscape Navigator 7.0 or later, with JavaScript enabled.

P-2602H-DxA Series Quick Start Guide
3
2 Hardware Connections
1DSL: Use the gray ADSL cable to connect the DSL (or MODEM) jack on a splitter to this port. If a splitter is
not provided connect the telephone jack to this port.
2ETHERNET1~4: Use Ethernet cables to connect computers to this port for initial configuration and/or
Internet access.
3 PHONE 1-2: Use a telephone cable (and any telephone adaptors provided with your P-2602H-DxA) to
connect your telephones to these ports. If you only have one telephone, you should use port 1.
4POWER:Use the power adaptor provided with your P-2602H-DxA to connect an appropriate power source
to this port.

P-2602H-DxA Series Quick Start Guide
4
Note: If you are using T-ISDN (UR-2), connect the green wire to a TAE connector before connecting it
to a telephone wall jack or the telephone splitter's TEL (or PHONE) jack.
5Push in the POWER button. Look at the lights on either side of the P-2602H-DxA.
•ThePOWER light blinks during start-up and is green once the P-2602H-DxA is ready.
• Each ETHERNET light turns on if the corresponding ETHERNET port is properly connected.
The lights blink when the P-2602H-DxA is sending or receiving data through the corre-
sponding ETHERNET port.
•TheDSL light stays on if a physical connection with the ISP is established. The INTERNET
light stays on when Internet access is available.
•ThePHONE lights stay on when your SIP account is registered and they blink if the receiver
is off the hook.
If the PHONE 1 or PHONE 2 light is on, go to Section 4 to see how to make calls through
the Internet.
If the INTERNET light comes on but the PHONE lights are off, go to Section 3.2 and use the
VOIP SETUP wizard.
If the INTERNET light is off but the DSL light is on, go to Section 3.1 and use the
INTERNET SETUP wizard to configure your Internet access settings.
If the lights are different than described, go to Troubleshooting.

P-2602H-DxA Series Quick Start Guide
5
3 Initial Configuration
3.1 Internet Setup
Note: You should have the information provided by your ISP.
1Open your browser, and go to http://192.168.1.1.2Enter the password 1234. Then, click Login.
If your browser cannot find this screen, make sure
your browser is configured correctly. See
Troubleshooting in the User’s Guide for details.
3Follow the directions in this screen. 4Click Go to Wizard setup. Then, click Apply.

P-2602H-DxA Series Quick Start Guide
6
1Click INTERNET SETUP.
2Wait while the P-2602H-DxA tries to detect your
Internet connection. If the P-2602H-DxA cannot
detect your Internet connection, follow the
directions. Enter the information provided by
your ISP. Keep the default settings if your ISP
did not provide some information.
3When your Internet connection is setup
correctly, the INTERNET light should be green.
When you are finished click Return to Wizard
Main Page.
3.2 VoIP Setup
1Click VOICE OVER INTERNET SETUP.
Note: You should have the information provided
by your VoIP service provider.
2Enter the information provided by your VoIP
service provider. Keep the default settings if your
VoIP service provider did not provide some
information. If you have a SIP account like
[e-mail], the SIP Number
is 1234567, and the SIP Service Domain is VoIP-
provider.com.
3When you are done, the PHONE light should be
on. Close the wizard and the main screen opens.

P-2602H-DxA Series Quick Start Guide
7
4 Phone Calls
When a PHONE light turns on, your SIP account is registered successfully. Dial a numerical SIP number (like
“12345” for example) on your phone’s keypad. Use your voice service provider’s dialing plan to make calls
through the Internet to regular telephone numbers. See your User’s Guide for other calling options.
Troubleshooting
If you cannot access the Internet, follow these steps.
1Check the device’s lights. If they are different than what is described in Section 2, turn off the device, make
sure the connections are correct, and inspect your cables for damage. Turn the device on again.
2Follow the steps in Section 3 again. Make sure you enter the correct information. For example, if your
account has a user name and password, make sure you type it correctly. In addition, if you are not sure
which encapsulation your ISP uses, contact your ISP.
3If you are using a new Internet account, contact your ISP to make sure it is active.
4If you still have problems, see Troubleshooting in the User’s Guide.
If you can access the Internet, but you cannot make calls through the Internet, follow these steps.
1Check the PHONE lights. If neither of them is on, make sure that your telephone is connected to the
corresponding PHONE port.
2Make sure the VOICE OVER INTERNET SETUP wizard screens are properly configured (see Section 3.2).
3You can also check the VoIP status in the Status screen. See the User’s Guide for more information about
this screen.
Viewing Your Product’s Certifications
1Go to www.zyxel.com.
2Select your product from the drop-down list box on the ZyXEL home page to go to that product's page.
3Select the certification you wish to view from this page.
