LAN Switches
Quick Sales Guide
coverback
For more product information, visit us on the web at www.ZyXEL.com
Copyright © 2010 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of ZyXEL Communications Corp. All other brands,
product names, or trademarks mentioned are the property of their respective owners. All specications are subject to change without notice.
65-100-000066B 02/10
Modular Switch Quick Finder
• Max. 384 Gbps non-blocking switching fabric, 286 Mpps forwarding rate
• 6 slots (two for management and four for I/O modules), 10U height hardware architecture
• Hot-swappable I/O modules, power supply and fan trays secure network reliability along with easy operation and maintenance
• Intelligent QoS and traffic control for enhanced availability
• Extended L3 routing and L2 switching functions for highest performance
MS-7206S
Switch chassis with 6 slots,
including fan module (MF-7201)
MI-7248PWR
48 x 1 Gbit-Base-T port I/O module
with Power over Ethernet support
for MS-7206S
MI-7248TF
24 x 1 Gbit-Base-T port and 24 x 1 Gbit
SFP slots I/O module for MS-7206S
MI-7248
48 x 1 Gbit-Base-T port I/O module
for MS-7206S
MM-7201
Switch fabric and management
module for MS-7206S
MP-7202
External PoE supply with 750 W,
for MS-7206S
MF-7201
Fan module for MS-7206S
MP-7201
Power supply module 600 W,
for MS-7206S
MPC-7202
Connecting module for
external PoE power supply
MI-7526F
20 x 1 Gbit SFP slots, 4 x Gbit dual
personality port (Base-T/SFP), and
1 x 2-port 10 Gbit open slot I/O
module for MS-7206S
EM-412
2 port CX4 module
MS-7206 PoE starter kit
consists of: 1x MS-7206S,
1 x MI-7248PWR, 1 x MM-7201,
1 x MP-7201, 1 x MP-7202
MS-7206 fibre starter kit
consisting of: 1 x MS-7206S,
1 x MI-7248TF, 1 x MM-7201,
1 x MP-7201
System Capacity
• Switch Fabric Slot: 2
• I/O Module Slot: 4
• Power Supply Unit Slot: 2
• Fan Module Slot: 1
Performance • Switching Fabric: 384 Gbps
• Forwarding Rate: 286 Mbps
Max Port Density
• 1000Base-T: 192
• 1000Base-T with PoE: 192 (4 x MI-7248PWR)
• 1000 SFP: 96
• 10G: 8 (4 x MI-7526F + 4 EM-412/EM-422)
Resilience and
Availability
• IEEE 802.1D STP/802.1w RSTP/802.1s MSTP
• Redundant Power supply support
• Switch Fabric High Availability
• VRRP
• MRSTP
• Dual Configuration Files
• Swappable Fan module
• IEEE 802.3ad LACP (max # trunks/links per trunk):
24/8
Traffic Control
• 4K static VLAN/4K dynamic VLAN
• 802.1ad VLAN Stacking (QinQ)
• BPDU Transparency
• GVRP
• VLAN Trunking
Security
• 802.1x
• Intrusion Lock
• MAC Filtering
• MAC Freeze
• Port Isolation
• Port Security
• SSH v1/v2
• SSL
• Static MAC Forwarding
• ACL (L2/L3/L4) Security Filtering
Management
• iStacking
• Web Interface
• CLI
• Syslog
• Daylight Saving
• RMON (1, 2, 3, 9)
• Port Mirroring
• NTP
• DHCP Relay per VLAN
• RJ-45 Out-of-band Management Port
• DHCP Option 82
• DHCP Client (Management)
• RS-232 Out-of-band Console Port
• SNMP v1, v2c, v3
• 802.3af PoE Support
• Jumbo Frame Support on Gigabit Ports
EM-422
2 port XFP module
Media Converter
MC1000-SFP-FP ■
1000Base-T RJ-45 to Gigabit fiber
■
Fiber protection mechanism
■
1 mini-GBIC SFP slot for flexible choice of SFP
■
Multimode and singlemode supported
■
Up to 80 km reach (depends on mini-GBIC SFP)
■
Max. power consumption: 9.6 watt
■
Dimensions: 194 (W) x 129 (D) x 25 (H) mm
MC100FX-SC30-A ■
10/100Base-TX RJ-45 to 100FX singlemode
■
For use with singlemode Fiber, SC connector
■
Up to 30 km reach
■
Max. power consumption: 2.4 watt
■
Dimensions: 74 (W) x 110 (D) x 24 (H) mm
MC100FX-SC2-A ■
10/100Base-TX RJ-45 to 100FX multimode
■
For use with multimode fiber, SC connector
■
Up to 2 km reach
■
Max. power consumption: 2.4 watt
■
Dimensions: 74 (W) x 110 (D) x 24 (H) mm
10G Module
■
2-slot XFP 10G fiber module
■
Extended 10G module of MI-7526F/XGS-4528F/XGS-4526
(requires purchase of 10G XFP transceivers)
EM-422
EM-412 ■
2-slot CX4 10G module
■
Extended 10G module of MI-7526F/XGS-4528F/XGS-4526
Accessories
PoE Injector
POE-12 ■
IEEE 802.3af 15.4 watt PoE injector
■
Fanless design, noiseless
■
Max. power consumption: 17.3 watt
Backup Power System
BPS-120 ■
Up to 6 switches from the 4500/4000/3000 series can be
connected to one BPS-120
■
Provides power to one switch without traffic or user
interruption or switch rebooting in the event of a switch
internal power supply failure
■
Temperature, power and fan speed monitoring
■
Max. power consumption: 180 watt/613 BTU/hr
■
Dimensions: 440 (W) x 270 (D) x 44.45 (H) mm
External PoE Power
SFP Transceiver
Specifications
Transceiver
Class
10 Gigabit XFP Gigabit SFP Fast Ethernet SFP
FTLX8511D3
(XFP-SR)
FTLX1611M3
(XFS-ER)
FTLX1412D3BCL
(XFP-LR)
SFP-
1000T
SFP-
SX-D
SFP-LX-
10-D
SFP-
BX1310-
10-D
SFP-
BX1490-
10-D
SFP-
LHX1310-
40-D
SFP-ZX-
80-D
SFP-
100FX-2
SFP-
100TX
SFP-
100LX-20
SFP-
100BX1310-
20-D
SFP-
100BX1550-
20-D
Connector LC LC LC RJ-45 LC LC LC LC LC LC LC RJ-45 LC LC LC
Wavelength 850
nm
1550
nm
1310
nm -850 nm
1310
nm
1310 nm
(TX)
1490 nm
(RX)
1490 nm
(TX)
1310 nm
(RX)
1310
nm
1550
nm
1550
nm -1310 nm
1310 nm
(TX)
1550 nm
(RX)
1550 nm
(TX)
1310 nm
(RX)
Max
Transmission
Distance
300 m 40 km 10 km 100 m 550 m 10 km 10 km 10 km 40 km 80 km 2 km - 20 km 20 km 20 km
Support
DDMI
Features
Yes Yes Yes - Yes Yes Yes Yes Yes Yes - - - Yes Yes
■
RoHS compliant, green product
■
Provision of more/external PoE power budget (225 W )
PPS250
■
Industry standard compliance
■
SFP MSA (Multi-Source Agreement) compliance
■
Hot-pluggable with maximum flexibility
■
Compact size, high port density
■
Low power dissipation
■
Support DDMI (Digital Diagnostics Monitoring Interface)
features

inside
Fixed-Port Switches Quick Finder
L3 Managed
4500 Series Gigabit Ethernet
with 10G Uplink
XGS-4526
XGS-4528F
4000 Series
Gigabit Ethernet GS-4024
Fast Ethernet ES-4124
L2 Managed
2200 Series Gigabit Ethernet
GS2200-24
GS2200-24P
GS2200-48
3000 Series Fast Ethernet
ES-3124
ES-3124PWR
ES-3148
2000 Series Fast Ethernet
ES-2024A
ES-2024PWR
ES-2108
ES-2108-G
ES-2108PWR
Web Managed
1500 Series—PoE Gigabit Ethernet GS1500-24P
1500 Series
Gigabit Ethernet
GS-1524
GS-1548
Fast Ethernet
ES-1528
ES-1552
Unmanaged
1100 Series Gigabit Ethernet
GS1100-16
GS1100-24
1000 Series
Gigabit Ethernet
GS-1116A
GS-1124A
GS-1124B
Fast Ethernet
ES-1024B
ES-1124
100 Series Fast Ethernet
ES-116P
ES-124P
Model Name Ports Key Features
XGS-4526
20-port 1000Base-T
4 dual personality GbE ports
1 optional 2-port 10G open slot
• Slot for 2-port 10 Gbit module
• Extended L3 routing and L2 switching functions for highest performance
• Multilayer-aware (L2/L3/L4) ACL for Security Protection and Traffic Optimization
• Port Security and Enhanced 802.1x Port Authentication
• 8 IEEE 802.1p hardware priority queues
• BPS support
XGS-4528F
24 dual personality GbE ports
2 12G stacking ports
1 optional 2-port 10G open slot
GS-4024 20-port 1000Base-T
4 dual personality GbE ports
• High-Performance wire-speed switching and IP routing
• High-security for business-critical applications
• Advanced routing protocol (OSPF, RIP, VRRP and DVMRP)
• High redundancy and resilience architecture with RSTP, VRRP and Port Trunking
ES-4124
24-port 10/100Base-TX
2-port 1000Base-T
2 dual personality GbE ports
• Empowering Converged Network for SME
• Secure Multi-Service Delivery Quality
• Enhanced Multi-layer Security Protection
• Advanced routing protocol (OSPF, RIP, VRRP and DVMRP)
GS2200-24 24-port 1000Base-T
4 dual personality GbE ports • Port security and enhanced 802.1x port authentication
• MAC freeze and intrusion lock
• 8 IEEE 802.1p hardware priority queues
• WFQ, WRR and SPQ queuing algorithms
• MVR and IGMP snooping for IP multicasting optimization
• Easy Web GUI for intelligent PoE management (only GS2200-24P)
GS2200-24P 24-port 1000Base-T PoE
4 dual personality GbE ports
GS2200-48
44-port 1000Base-T PoE
2 GbE SFP open slot
4 dual personality GbE ports
ES-3124
24-port 10/100Base-TX
2-port 1000Base-T
2 dual personality GbE ports • Robust High-Availability system design
• Strengthened service management and control
• IEEE 802.1s MSTP and IEEE 802.1w RSTP enable fast recovery networks
• Policy-based QoS empowered by (L2/L3/L4) ACL
• VLAN Stacking (Q-in-Q) support for L2VPN
• Backup Power System (BPS) extends network up time
• Easy Web GUI for intelligent PoE management (only ES-3124PWR)
ES-3124PWR
24-port 10/100Base-TX PoE
2-port 1000Base-T
2 dual personality GbE ports
ES-3148
48-port 10/100Base-TX
2-port 1000Base-T
2 dual personality GbE ports
ES-2024A 24-port 10/100Base-TX
2 dual personality GbE ports
• Port-based and 802.1Q-tagged VLAN (4K PVID)
• MAC filtering, freeze and specific MAC forwarding
• Port security and enhanced 802.1x port authentication
• WFQ Queuing Algorithms
• MVR and IGMP snooping for IP multicasting optimization
• Easy Web GUI for intelligent PoE management (only ES-2024PWR)
ES-2024PWR 24-port 10/100Base-TX PoE
2 dual personality GbE ports
ES-2108 8-port 10/100Base-TX
• Fan-less hardware design (ES-2108/ES-2108-G)
• Traffic prioritizing of Intelligent QoS and bandwidth increment of 64 Kbps optimize service quality of application
and utilization of bandwidth
• MVR enables IP multicasting applications across multiple VLANs environments
• Port-based and 802.1Q-tagged VLAN (4K PVID)
• MAC filtering/forwarding and MAC freeze
ES-2108-G 8-port 10/100Base-TX
1 dual personality GbE ports
ES-2108PWR 8-port 10/100Base-TX PoE
1 dual personality GbE ports
GS1500-24P 24-port 1000Base-T PoE
4 dual personality GbE ports
• Intuitive and Streamlined Web-based Management Interface
• 8 IEEE 802.1p hardware priority queues
• WRR, WFQ and SPQ Queuing Algorithms
• Easy Web GUI for intelligent PoE management
GS-1524 20-port 1000Base-T
4 dual personality GbE ports
• Robust system design
• Intuitive and Streamlined Web-based Management Interface
• Auto DoS attack prevention
• Auto VoIP optimization
• Port security
• 4 IEEE 802.1p hardware priority queues
• WRR and SPQ queuing algorithms
GS-1548 44-port 1000Base-T
4 dual personality GbE ports
ES-1528
24-port 10/100Base-TX
2-port 1000Base-T
2 GbE SFP open slot
ES-1552
48-port 10/100Base-TX
2-port 1000Base-T
2 GbE SFP open slot
GS1100-16 16-port 1000Base-T • Non-blocking, wire-speed transmission
• Supports auto-MDI/MDI-X
• EEE standards complied
GS1100-24 24-port 1000Base-T
2 GbE SFP open slot
GS-1116A 14-port 1000Base-T
2 dual personality GbE ports
• Non-blocking full wire speed forwarding
• Data flow control for better transmission reliability
• Forwards and filters packets at non-blocking, full wire-speed
• Auto MDI/MDI-X support
GS-1124A 22-port 1000Base-T
2 dual personality GbE ports
GS-1124B 24-port 1000Base-T
ES-1024B 24-port 10/100Base-TX
ES-1124 24-port 10/100Base-TX
2 dual personality GbE ports
ES-116P 16-port 10/100Base-TX • 3.2/4.8 Gbps non-blocking switching fabric; 2.4/3.6 Mpps forwarding rate
• 8K MAC address table
• Suitable for desktop and rack-mount installation
ES-124P 24-port 10/100Base-TX
Model No.
Switch 4500 Series Switch 4000 Series Switch 3000 Series Switch 2200 Series Switch 2000 Series
XGS-4526 XGS-
4528F GS-4024 ES-4124 ES-3124 ES-3124
PWR ES-3148 GS2200-
24 GS2200- 24P GS2200- 48 ES-2024A ES-2024
PWR ES-2108 ES-
2108-G ES-2108 PWR
Switch Class Layer 3 Layer 3 Layer 3 Layer 3 Layer 2 Layer 2 Layer 2 Layer 2 Layer 2 Layer 2 Layer 2 Layer 2 Layer 2 Layer 2 Layer 2
Hardware
100 Mbit
RJ45 Ports - - - 24 24 - 48 - - - 24 - 8 8 -
100 Mbit
RJ45 PoE Ports -----24-----24--8
1 Gigabit
RJ45 Ports 20 - 20 2 2 2 2 24 - 44 - - - - -
1 Gigabit
RJ45 PoE Ports --------24------
1 Gigabit
SFP Slots ---------2-----
Dual Personality
Gigabit Ports
(RJ45/SFP)
4244222244422- 11
12 Gigabit
CX4 Ports -2-------------
10 Gigabit
Open Slots 11-------------
Wire-speed Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Backplane
Bandwidth
(Gbps)
96 144 48 12.8 12.8 12.8 17.6 56 56 100 8.8 8.8 1.6 3.6 3.6
Forwarding Rate
(Mbps) 71.4 100 35.7 9.6 9.6 9.6 13.1 41.7 41.7 74.4 6.6 6.6 1.3 2.7 2.7
MAC Addresses 8000 8000 16000 16000 16000 16000 16000 16000 16000 8000 8000 8000 8000 8000 8000
Management
CLI, Web, GUI Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
iStacking (Single
IP Management) Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Out-of-band
Management
Port
Yes Yes Yes Yes Yes Yes Yes - - Yes - - - - -
Routing/Redundancy
OSPF Yes Yes Yes Yes - - - - - - - - - - -
RIP v1, v2 Yes Yes Yes Yes - - - - - Yes - - - - -
Static IP Routing Yes Yes Yes Yes - - - - - Yes - - - - -
VRRP Yes Yes Yes Yes - - - - - Yes - - - - -
Spanning Tree
(STP/MSTP/RSTP)
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Backup Power
Support Yes Yes Yes Yes Yes Yes Yes - - Yes - - - - -
Quality of Service
Priority Queues 888888888844444
Data
Prioritisation
(SPQ/WRR/WFQ)
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes Yes/Yes/- Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes
Yes/Yes/
Yes Yes/Yes/- Yes/Yes/- Yes/Yes/- Yes/Yes/- Yes/Yes/-
ACL Data
Prioritization
(L2/L3/L4)
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes - - - - -
IGMP Snooping
(v1/v2/v3) Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
MVR Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Jumbo Frame
Forwarding Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes - - - - -
DVMRP Yes Yes Yes Yes - - - - - - - - - - -
802.1p Class
of Service Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Security
MAC Freeze/
Intrusion Lock Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
802.1x
Authentication Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
TACACS+ Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
ACL Security
Filter L2/L3/L4 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes - - - - -
RADIUS
MAC Login Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
VLAN Stacking
(Q-in-Q) Yes Yes Yes Yes Yes Yes Yes - - Yes - - - - -
LAN Switches Features Matrix
Model No.
Switch 1500 Series Switch 1500 Series
— PoE Switch 1100 Series Switch 1000 Series
GS-1524 GS -1548 ES-1528 ES-1552 GS1500-24P GS1100-16 GS1100-24 GS-1116A GS-1124A GS-1124B ES-1024B ES-1124
Switch Class Web-
managed
Web-
managed
Web-
managed
Web-
managed Web-managed Unmanaged Unmanaged Unmanaged Unmanaged Unmanaged Unmanaged Unmanaged
Hardware
100 Mbit
RJ45 Ports - - 24 48 - - - - - - 24 24
1 Gigabit
RJ45 Ports 20 44 2 2 - 16 24 14 22 24 - -
1 Gigabit
RJ45 PoE Ports - - - - 24 - - - - - - -
1 Gigabit
SFP Slots - - 2 2 - - 2 - - - - -
Dual Personality
Gigabit Ports
(RJ45/SFP)
4 4 - - 4 - - 2 2 - - 2
Wire-speed Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Backplane
Bandwidth (Gbps) 48 96 12.8 17.6 56 32 52 32 48 48 4.8 8.8
Forwarding Rate
(Mbps) 35.7 71.4 9.6 13.1 41.67 23.8 38.7 23.8 35.7 35.7 3.6 6.6
MAC Addresses 8000 8000 8000 8000 16000 8000 8000 8000 8000 8000 8000 8000
Management
CLI, Web, GUI GUI GUI GUI GUI GUI - - - - - - -
SNMP SNMPv1, v2c SNMPv1, v2c SNMPv1, v2c SNMPv1, v2c SNMPv1, v2c, v3 - - - - - - -
RMON (1, 2, 3, 9) RMON_Lite RMON_Lite RMON_Lite RMON_Lite RMON - - - - - - -
Routing/Redundancy
Spanning Tree
(STP/MSTP/RSTP) - - - - Yes/-/Yes - - - - - - -
Quality of Service
Priority Queues 4 4 4 4 8 - - - - - - -
Data Prioritisation
(SPQ/WRR/WFQ) Yes/Yes/- Yes/Yes/- Yes/Yes/- Yes/Yes/- Yes/Yes/Yes - - - - - - -
Jumbo Frame
Forwarding Yes Yes - - Yes Yes Yes Yes Yes Yes - -
802.1p Class
of Service Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes - -
Broadcast Storm
Control Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes -
Security
802.1x
Authentication - - - - Yes - - - - - - -
Special Features
AutoDoS
Prevention Yes Yes Yes Yes - - - - - - - -
AutoVoIP Yes Yes Yes Yes - - - - - - - -
Fanless - - Yes Yes - Yes Yes - - Yes Yes Yes
EEE - - - - - Yes Yes - - - - -
