ZyXEL Communications PoE-80 User manual

PoE-80
Eight-port Power over Ethernet Hub
User’s Guide
Version 1.06
April 2004

PoE-80 User’s Guide
2
Table of Contents
Copyright ............................................................................................................................................ 3
Federal Communications Commission (FCC) Interference Statement.............................................. 3
Information for Canadian Users.......................................................................................................... 4
ZyXEL Limited Warranty..................................................................................................................... 5
Syntax Conventions in this Guide ...................................................................................................... 6
Customer Support .............................................................................................................................. 6
1 About Your PoE-80.......................................................................................................................... 9
1.1 Key Features............................................................................................................................. 9
1.2 Packaging List........................................................................................................................... 9
2 Hardware and Installation.............................................................................................................. 10
2.1 Desktop Installation................................................................................................................. 10
2.2 Rack-mounted Installation ...................................................................................................... 10
2.3 Rear Panel Connections ......................................................................................................... 11
2.4 Front Panel Connections ........................................................................................................ 12
2.5 Front Panel LEDs.................................................................................................................... 12
3 Software Utility Installation ............................................................................................................ 12
3.1 Starting the Utility.................................................................................................................... 15
4 Removing the Utility....................................................................................................................... 15
5 Managing the PoE-80.................................................................................................................... 17
5.1 System Setup & Control.......................................................................................................... 17
5.2 System Information ................................................................................................................. 18
5.3 Port Specific Control ............................................................................................................... 19
5.4 Parametric Information............................................................................................................ 21
6 Troubleshooting............................................................................................................................. 21
7 Specifications ................................................................................................................................ 22
7.1 DATA OUT PoE Injector RJ-45 Port Pin Assignments........................................................... 23

PoE-80 User’s Guide
3
Copyright
Copyright © 2004 by ZyXEL Communications Corporation.
The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a
retrieval system, translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without the prior written
permission of ZyXEL Communications Corporation.
Published by ZyXEL Communications Corporation. All rights reserved.
Disclaimer
ZyXEL does not assume any liability arising out of the application or use of any products, or software
described herein. Neither does it convey any license under its patent rights nor the patent rights of others.
ZyXEL further reserves the right to make changes in any products described herein without notice.
This publication is subject to change without notice.
Trademarks
Trademarks mentioned in this publication are used for identification purposes only and may be properties of
their respective owners.
Federal Communications Commission (FCC)
Interference Statement
This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired
operations.
This equipment has been tested and found to comply with the limits for a CLASS B digital device pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.

PoE-80 User’s Guide
4
If this equipment does cause harmful interference to radio/television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice 1
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Certifications
1. Go to www.zyxel.com.
2. Select your product from the drop-down list box on the ZyXEL home page to go to that product's page.
3. Select the certification you wish to view from this page.
Information for Canadian Users
The Industry Canada label identifies certified equipment. This certification means that the equipment meets
certain telecommunications network protective, operation, and safety requirements. The Industry Canada
does not guarantee that the equipment will operate to a user's satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of
the local telecommunications company. The equipment must also be installed using an acceptable method of
connection. In some cases, the company's inside wiring associated with a single line individual service may
be extended by means of a certified connector assembly. The customer should be aware that the compliance
with the above conditions may not prevent degradation of service in some situations.

PoE-80 User’s Guide
5
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by
the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may
give the telecommunications company cause to request the user to disconnect the equipment.
For their own protection, users should ensure that the electrical ground connections of the power utility,
telephone lines, and internal metallic water pipe system, if present, are connected together. This precaution
may be particularly important in rural areas.
Caution
Users should not attempt to make such connections themselves, but should contact the appropriate electrical
inspection authority, or electrician, as appropriate.
Note
This digital apparatus does not exceed the class A limits for radio noise emissions from digital apparatus set
out in the radio interference regulations of Industry Canada.
ZyXEL Limited Warranty
ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or
workmanship for a period of up to two years from the date of purchase. During the warranty period, and upon
proof of purchase, should the product have indications of failure due to faulty workmanship and/or materials,
ZyXEL will, at its discretion, repair or replace the defective products or components without charge for
either parts or labor, and to whatever extent it shall deem necessary to restore the product or components to
proper operating condition. Any replacement will consist of a new or re-manufactured functionally
equivalent product of equal value, and will be solely at the discretion of ZyXEL. This warranty shall not
apply if the product is modified, misused, tampered with, damaged by an act of God, or subjected to
abnormal working conditions.
NOTE
Repair or replacement, as provided under this warranty, is the exclusive remedy of the purchaser. This
warranty is in lieu of all other warranties, express or implied, including any implied warranty of
merchantability or fitness for a particular use or purpose. ZyXEL shall in no event be held liable for indirect
or consequential damages of any kind of character to the purchaser.
To obtain the services of this warranty, contact ZyXEL's Service Center for your Return Material
Authorization number (RMA). Products must be returned Postage Prepaid. It is recommended that the unit be
insured when shipped. Any returned products without proof of purchase or those with an out-dated warranty
will be repaired or replaced (at the discretion of ZyXEL) and the customer will be billed for parts and labor.
All repaired or replaced products will be shipped by ZyXEL to the corresponding return address, Postage
Paid. This warranty gives you specific legal rights, and you may also have other rights that vary from country
to country.

PoE-80 User’s Guide
6
Online Registration
Register your product online to receive e-mail notices of firmware upgrades and information at
www.zyxel.com for global products, or at www.us.zyxel.com for North American products.
Syntax Conventions in this Guide
The PoE-80 Eight-port Power over Ethernet Hub may be called the “PoE-80”, “the power injector” or “the
system” in this guide.
Customer Support
When you contact your customer support representative please have the following information ready:
Please have the following information ready when you contact customer support (see the next page for
contact information).
• Product model and serial number.
• Warranty Information.
• Date that you received your device.
• Brief description of the problem and the steps you took to solve it.

PoE-80 User’s Guide
7
SUPPORT E-MAIL TELEPHONE1WEB SITEMETHOD
LOCATION
SALES E-MAIL FAX1FTP SITE
REGULAR MAIL
[email protected]m.tw [phone] www.zyxel.com
www.europe.zyxel.com
ftp.zyxel.com
WORLDWIDE
[e-mail] [phone] ftp.europe.zyxel.com
ZyXEL Communications Corp.
6 Innovation Road II
Science Park
Hsinchu 300
Taiwan
[email protected]m [phone]
[phone]
www.us.zyxel.comNORTH
AMERICA
[e-mail] [phone] ftp.us.zyxel.com
ZyXEL Communications Inc.
1130 N. Miller St.
Anaheim
CA 92806-2001
U.S.A.
[email protected] [phone] www.zyxel.deGERMANY
[e-mail] [phone]
ZyXEL Deutschland GmbH.
Adenauerstr. 20/A2 D-52146
Wuerselen
Germany
[phone]FRANCE [email protected]
[phone]
www.zyxel.fr ZyXEL France
1 rue des Vergers
Bat. 1 / C
69760 Limonest
France
[email protected] [phone]SPAIN
[e-mail] [phone]
www.zyxel.es ZyXEL Communications
Alejandro Villegas 33
1º, 28043 Madrid
Spain
[email protected] [phone] www.zyxel.dkDENMARK
[e-mail] [phone]
ZyXEL Communications A/S
Columbusvej 5
2860 Soeborg
Denmark
[email protected] [phone] www.zyxel.noNORWAY
[e-mail] [phone]
ZyXEL Communications A/S
Nils Hansens vei 13
0667 Oslo
Norway
[email protected] [phone] www.zyxel.seSWEDEN
[e-mail] [phone]
ZyXEL Communications A/S
Sjöporten 4, 41764 Göteborg
Sweden
[email protected] [phone] www.zyxel.fiFINLAND
[e-mail] [phone]
ZyXEL Communications Oy
Malminkaari 10
00700 Helsinki
Finland
1“+” is the (prefix) number you enter to make an international telephone call.

PoE-80 User’s Guide
9
1 About Your PoE-80
The PoE-80 Eight-port Power over Ethernet Hub is an eight-port power injector, designed for use
with 10/100 BaseT Ethernet networks. The PoE-80 injects DC power through the unused twisted-
wires (pairs 4/5 and 7/8) of a standard 8-pin CAT 5 cable. This allows increased flexibility in the
locating of power over Ethernet (PoE) enabled devices by eliminating the need for a nearby power
source.
1.1 Key Features
 Eight RJ-45, 10/100 Mbps PoE-enabled ports
 Ensures a constant power supply to PoE-enabled devices.
 Automatically detects if connected devices are PoE-enabled to avoid sending power to non-
PoE devices.
 Supports power management
 Control, status, and parameters manageable per port
 Remote power feeding up to 100 meters
 Centralized power distribution
 Protection against short circuits
 Accepts a wide range of AC power input
 Automatically updates management information.
1.2 Packaging List
The following items come with your PoE-80.
 This User’s Guide
 One power cord
 One console cable
 One Ethernet cable
 Rack mount kit

PoE-80 User’s Guide
10
2 Hardware and Installation
Do not block the device’s rear panel fans or the side panel ventilation
holes. Leave space between devices when stacking.
2.1 Desktop Installation
Step 1. Set the PoE-80 upside-down on a sturdy level space with a power outlet nearby.
Step 2. Make sure there is enough clearance around the PoE-80 to allow air circulation and the
attachment of cables and the power cord.
Step 3. Remove the adhesive backing from the supplied rubber feet.
Step 4. Attach the rubber feet to each corner on the bottom of the PoE-80. These rubber feet help
protect the PoE-80 from shock or vibration and ensure space between devices when
stacking.
Step 5. Turn the PoE-80 right-side up after you attach the rubber feet.
2.2 Rack-mounted Installation
The PoE-80 can be mounted on an EIA standard size, 19-inch rack or in a wiring closet with other
equipment. Follow the steps below to mount your PoE-80 on a standard EIA rack using the included
rack-mounting kit.
Step 1. Align one bracket with the holes on one side of the PoE-80 and secure it with the bracket
screws. Similarly, attach the other bracket.
