1 BY ONE OUS00-0568 User manual

Amplied Digital Indoor HDTV Antenna
Window Antenna Transparent Series – 50 Miles
Model OUS00-0568
Congratulations!You have just purchased the nest, technologically advanced,
easy-to-install HD digital antenna for indoor use. 1byone® products have been
rated“best sellers.”We hope your investment in this quality antenna will give you
and your family years of enjoyment. Thank you for your purchase and your
support. We invite you to visit our website at www.1byone.com for other high-qual-
ity products.
Package Contents -
Antenna with attached amplier and 20ft coaxial cable
5ft USB Power Cable
Optional USB Adapter 5V 100mA
Two Suction Cups
Instruction Manual
Warranty Card
www.1byone.com
2. Mount the Antenna
Find a convenient indoor location to mount your antenna, then scan for channels using the
instructions below.
Note: Before nal mounting, rst test your selected antenna location by scanning for channels. In
some instances, you may decide to relocated the antenna for better reception. See below for addition
tips for optimal antenna placement.
3. Scan the TV for Channels
A. In the TV’s setup menu, set the mode to 'Antenna' or 'Air.' Refer to theTV manual for detailed
instructions.
B. While in the TV’s setup menu, set TV to scan for channels.This can sometimes be listed as
'auto-program,' 'channel search,' or 'channel scan.' Refer to your TV manual for detailed instructions.
C. If you are about 25-35 miles away from the tower, we recommend to switch o the inline
amplier (when yellow light is on).
If you are about 35-50 miles away from the tower, we recommend to switch on the inline
amplier (when green light is on).
Note: If you want to know how many channels you can expect to receive, please refer to "How many
channels can I receive?"in FAQ below.
Antenna Placement Options and Tips
Signal reception and quality depends on the distance from the broadcast tower to your home.
Surrounding geography and environment may also aect signal strength and reception.
If your reception is sporadic or needs to be improved, try the helpful tips below:
1. Place the antenna in a higher location.
2. Face the antenna towards the nearest broadcast tower.
3. Place the antenna close to or on a window.
4. If you nd the channels are less than expected, please switch the amplier to the "on" and "o"
position separately, and do remember to do a channel scan every time you switched. Please do
remember to connect the power adapter to the inline amplier no matter the amplier is in the
"on" or "o" position, otherwise the antenna won't work properly.
Important:
Always re-scan for channels whenever you move your antenna.
Frequently Asked Questions
How many channels can I receive?
The number of channels you can receive will be determined by what is being broadcast in your area.
Channel reception will vary from location to location based on terrain (including trees, buildings,
hills and mountains). The fewer obstructions, the better your chance of receiving strong digital
signals. Go to http://dtv.gov/maps. Enter your address for a listing of likely channels available in
your area.
Copyright ©2015 1byone Products, Inc. All rights reserved
Will all the channels I receive be High Denition (HD)?
Not all digital signals are High Denition (HD). Make sure you are using a High Denition Television
(HDTV) with built in ATSC tuner. When connecting the antenna to a third-party receiver, make sure it is
capable of receiving HD. Otherwise no HD channels can be picked up.
Will the picture be better than cable?
All cable companies compress their HD signals. The result is a degraded signal that is usually inferior to
ATSC broadcast. Many factors determine whether your picture quality will be better in every instance.
However, your picture quality should greatly improve using your 1byone® ATSC compatible digital antenna.
Can I connect the antenna to multiple televisions?
Yes. However, the signal should only be split between multiple HDTVs if using an amplied antenna.
Troubleshooting
What if I can’t receive a signal with my 1byone® antenna?
1. Check to make sure you have correctly connected the antenna to your HDTV or third-party HD receiver.
See the Setup Guide under,“Connect the Antenna to TV or convertor box”in this manual.
2. Re-Scan for Channels. See the Setup Guide under,“Scan for Channels”in this manual.
3. Reposition the antenna in a dierent location. Maybe higher on a wall or close to a window?
Facing the direction of the broadcast tower is usually best. Signal strength will vary based
on certain conditions. Distance from the tower, hills, buildings and even tall trees can impact
reception. Always re-scan for channels after moving the antenna.
One channel is missing.
1. Something may be obstructing the signal. Move the antenna, then re-scan for channels.
2. Try turning the antenna 10 or 20 degrees in either direction to avoid reection, then re-scan for channels.
The picture or sound freezes while I am watching a channel, or there are boxes in the picture.
This is often caused by a weak or intermittent signal. Try moving the antenna to a dierent location or
aiming it in the direction of the broadcast tower for that channel.
For Optimal Performance
Place your 1byone® antenna in the location with the strongest reception. Typically this will be on a
window and facing the broadcaster’s tower. A television signal can become weak or intermittent by trying
to pass through walls that are exceptionally thick or contain large amounts of metal. Your 1byone®
antenna can usually pick up the stronger signals from almost any direction. Experiment with dierent
walls and even dierent rooms to nd the best location to mount your antenna. To check the exact
distance from your residence to the nearest tower, go to - http://dtv.gov/maps and type in your zip
code.You will then have a better idea of what you should expect in the way of reception. If there are
multiple tower locations, optimize the position of your 1byone antenna by pointing it in the direction of
the weakest signal (usually the farthest away from you).
Distributed by
1byone® Products, Inc.
2313 E Philadelphia St, Ontario, CA 91761
www.1byone.com
®
50 mile maximum range possible. Individual experiences may vary.
尺寸：355.5X216mm说明书形式为三折页 材质：铜版纸120g
正面背面
On/Off
Antenna
TO TV DC
+
-

1
Power Option
For USB
Power Cable
For use when no
USB port is available
on the TV.
Supplied USB
100-240V Power Adapter
5’USB Power Cable
3
5’USB Power Cable
20’Coaxial Cable To ANT/IN or CABLE IN
on back of TV
Detailed
View
To USB
on back of TV*
A. Before your connection, please read the below names and use for the antenna
parts(as shown in gure 1).
B. Connect the coaxial cable from the antenna to the ANT/IN or CABLE IN port on
the back of your TV (as shown in gure 2). Note: For TV's that require a tuner box,
connect the coaxial cable from the antenna to the tuner box's ANT/IN or CABLE IN
port. See the“Final Conguration”Illustrations below for both connection options.
C. The amplier requires power to operate properly. Plug the round end of the
amplier’s 5ft long USB power cable into the amplier (as shown in gure 1).
Then insert the USB plug into an open USB port on the back of your TV (see
gure 2). If no USB port is available, use the supplied power adapter to power
the amplier through any standard 110V outlet (see this option in gure 3).
Back of TV
2
From 20’
Coaxial Cable
From
5’USB Power Cable
ANT/IN
CABLE IN
ANT/IN
USB
Final conguration when connected to
the HDTV with built in digital tuner
Digital
Antenna
USB adapter
5V 100mA
HDTV
Inline Amplier
Inline Amplier
Inline Amplier
Final conguration when connected
through a digital set-top box
Set-top Box
Digital
Antenna
USB adapter
5V 100mA
Traditional TV
1. Connect Antenna to TV or Set-top box
USB Power Cable shown using optional 100-240V power adapter*
*USB Power Cable may also be plugged into any available USB port on HDTV as well.
On/Off
Antenna
TO TV DC
+
-
On/Off
Antenna
TO TV DC
+
-
On/Off
Antenna
TO TV DC
+
-
Antenna
Inline Amplier
*Switch-on: Green light
Switch-o: Yellow light
On/Off
Antenna
TO TV DC
+
-
