SimpleSpec 250.02tm Installation Manual
Ready To Go

Contents Overview
(2) =+
M8 × 25mm
Threaded Rod
3151754
(2)
Coupler with
Cover Plate
3151639
(2)
Cable Coupler with
Cover Plate KIT
3151639K
(2)
3mm Cable with
Terminal End
3-15-723
(1)
Varia
Panel ½"
=
(2)
Fixed Surface Bracket
for M8 KIT
3-15-179-K
+ + + +
Fixed Surface
Bracket for M8
315179
(2)
M8 × 14mm
SHCS
3157778
(2)
M6 × 12mm
Set Screw
315-776
(2)
M6 × 2mm
Set Screw
315-777
(2)
M8 × 4mm
SHCS
3156363
(2)
(2) =
1" Top Gripper KIT
315-749K
+
1" Top Gripper
315-749
(2)
M6 × 12mm
Set Screw
315-776
(4)
(1) =
1" Shelf Holder
315-754K
+
Shelf Holder
315-754
(1) (1)
M6 × 12mm
Set Screw
315-776
For Each Additional Panel
(×2) 3mm cable with Terminal End 315-723
(×2) Cable Coupler with Cover Plate 3151639K
(×1) 1" Top Gripper 315-749K
(×4) Suspend Anchoring KIT 3157-K
(×2) 1" Shelf Holder 315-754K
(×2) Fixed Surface Bracket for M8 315179-K
(4) =
Suspend Anchoring KIT
3-15-7-K
+ +
M8 Threaded
Wood Insert
315-791
(4)
M8 Concrete
Anchor
315311A
(4)
M8 Threaded
Rod, 5mm
315332A
(4) +
M8 Thread
Rod, 25mm
3151754
(4)
M8 Toggle
Bolt Anchor
315-734
(4) +
2
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG25002 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 250.02tm Installation Manual
Ready To Go

Overview
Create luid motion and dynamic presence with this 25.2 column feature. Design intimate or expansive installations with
formed panels. It can be used as a standalone accent feature or create a light scale partition with a run of the 25.2.
96"
(2439mm)
16"
(407mm)
Cable Coupler with
Cover Plate KIT
3-15-1639-K
1" Top Gripper KIT
3-15-0749-K
3mm Cable with
Terminal End
3-15-0723
Varia Panel ½"
Suspend
Anchoring KIT
3-15-7000-K
+
Fixed Surface Bracket
for M8 KIT
3-15-1790-K
Suspend
Anchoring KIT
3-15-7000-K
+
3
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG25002 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 250.02tm Installation Manual
Ready To Go

Installation
Required Tools
Metric Allen
Wrenches
*If anchoring in concrete follow Steps 1a-f, if anchoring in drywall follow Steps 1g-l, if anchoring in wood follow Steps 1m-n.
Then move on to Step 1o.
Anchor Cable Couplers1
Drill Drill Bits Hammer Drill Hammer
Drill Ø1mm hole, minimum 65mm
deep.
Remove drilling debris with a blowout
bulb or with compressed air.
With screw in anchor (315311A), use a
hammer to insert anchor.
b ca Concrete Installation
4
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG25002 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 250.02tm Installation Manual
Ready To Go

Anchor Cable Couplers cont...1
Installation
e fd
Place a washer under the screw head. Torque the screw to 15 Nm. Remove screw.
Metal
Studs
Metal
Studs
h ig
Drill ؾ" (19mm) hole. Minimum
clearance behind wall = 1⅞" (48mm)
Position the metal channel parallel
with the plastic legs. Insert the metal
channel through the drilled hole into
the wall cavity.
Pull the metal channel irmly against the
inner wall cavity by tugging the plastic
pull ring.
Hollow Substrate Installation
5
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG25002 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 250.02tm Installation Manual
Ready To Go

Installation
1Anchor Cable Couplers cont...
o
3-15-1754
Anchor appropriate
for substrate
3-15-1639
k lj
Slide the plastic cap forward along the
legs until it is seated lush to the work
surface.
Snap the plastic legs o lush at the
plastic cap by pushing outward.
Note: Maximum torque on screw or rod
is 5 ft-lb.
nm
Drill Ø⁄" (Ø11.1mm) hole, minimum
2mm deep.
Use an Allen wrench to install the M8
Threaded Insert (315-791).
Wood Installation
6
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG25002 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 250.02tm Installation Manual
Ready To Go

Installation
2Attach Cable Assembly
a b
3-15-0723
3-15-1639
3-15-1639
3-15-1639
Complete this step for both cable assemblies.
3Attach Top Grippers
a
3-15-0749
3-15-0749
3-15-0723
3-15-0723
b
3-15-0776
3-15-0749
7
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG25002 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 250.02tm Installation Manual
Ready To Go

Installation
4Loosely Attach Panel to Top Grippers
3-15-0776
5Mark Floor for Anchoring
8
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG25002 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 250.02tm Installation Manual
Ready To Go

Installation
6Remove Panel 7Anchor Surface Brackets
Install loor anchors in concrete following Steps 1a-f.
a
b
3-15-0777 (×2)
3-15-1790 (×2)
3-15-3011A (×2)
9
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG25002 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 250.02tm Installation Manual
Ready To Go

Installation
8Mount Panel
3-15-0776
3-15-1790
10
For more information, please visit 3-form.com or call 800.726.0126
APRIL 2018 | MANRTG25002 | REV 002 © 2018 3form, Inc. All rights reserved.
SimpleSpec 250.02tm Installation Manual
Ready To Go

Installation
9Attach Shelf Holder - For Drop Ceilings Only
3-15-0754
3-15-0776
11
