3COM SWITCH 4200G FAMILY
QUICK REFERENCE GUIDE
Overview
This Command Reference applies to the following Switch 4200G models:
About the Command Line Interface
To use and navigate the command line interface of your unit, please refer to the following points for assistance:
■When initially accessing the command line interface, press Enter when prompted. The User View menu for the unit
displays. This is indicated by the chevron brackets around the name of the unit at the prompt, for example,
<sw4200G>.
■When in the System View menu, square brackets appear around the name of the unit at the prompt, for example,
[sw4200G].
■You must be in the System View menu to access the configurable CLI commands.
■Some commands can be entered directly at any prompt from anywhere in the interface.
■If you enter part of a command followed by a ? (with no space between), the CLI will show you all the commands
that begin in that way.
■The term ‘view’ may be used interchangeably with the term ‘menu’.
■The undo command is placed before the command you wish to undo, for example, undo setauthentication password.
■<CTRL-A> places the cursor back to the start of the command line.
■Enter the first few characters of a command and press TAB to enter the full command without having to input the
entire command (where there is only one command that starts with the entered characters).
■Use the Up Arrow key at the prompt to repeat the previous command string.
■Use the Delete key to delete the character after the cursor; the Backspace key deletes the character before the cursor.
■When entering physical port numbers, Enter the port number as x/0/z, where x is the unit number and z is the
physical port number.
Switch 4200G 12-Port (3CR17660-91)
Switch 4200G 24-Port (3CR17661-91)
Switch 4200G 48-Port FX (3CR17662-91)
Switch 4200G 1-Port 10Gigabit Module (XFP) (3C17666)

23Com Switch 4200G Family
Command Reference
Displaying Command Parameters
At the prompt, enter the name of the command followed by a space and ?. For example:
<sw4200G>boot ?
The following parameters are displayed:
attribute-switch Exchange the file main-attribute and backup-attribute.
boot-loader Select a file to boot at the next time
bootrom Update Bootrom
web-package Set web resource package
To specify boot loader, enter the command as follows:
<sw4200G>boot boot-loader ?
You only need to enter ? if parameters exist for the command.
Displaying Parent Menus
At the prompt, enter quit.
Displaying the User View Menu
Press <CTRL-Z>.
Obtaining Help
At the prompt, enter ?.
Further Information
For further information about how to use the command line interface, refer to the Command Reference Guide and
the Configuration Guide, which are both available as PDF documents on the CD that accompanied the unit.
Commands
access-limit
Use the access-limit command to set the maximum number of access users that can be contained in
current ISP domain.
ISP Domain view
accounting
Use the accounting command to configure an accounting scheme for the current ISP domain.
ISP Domain view
accounting domain
Use the accounting domain command to enable the DHCP accounting function.
DHCP Address Pool view
accounting-on enable
Use the accounting-on enable command to enable user re-authentication upon device restart function.
RADIUS Scheme view
accounting optional
Use the accounting optional command to open the accounting-optional switch.
ISP Domain view
RADIUS Scheme view

3Com Switch 4200G Family 3
Command Reference
acl
Use the acl command to reference ACL and implement the ACL control to the TELNET users.
User Interface view
acl
Use the acl command to define an ACL identified by a number, and enter the corresponding ACL View.
System view
active region-configuration
Use the active region-configuration command to activate the settings of an MST (multiple spanning
tree) region.
MST Region view
add-member
Use the add-member command to add a candidate device to a cluster.
Cluster view
address-check
Use the address-check command to enable or disable DHCP relay security on a VLAN interface, so as to
start or stop the validity check on user addresses under the VLAN interface.
VLAN Interface view
administrator-address
Use the administrator-address command to store the MAC address of the management device on a
member device.
Cluster view
am user-bind
Use the am user-bind command to bind the MAC and IP addresses of a legal user to a specified port.
System view
Ethernet Port view
apply qos-profile
Use the apply qos-profile command to manually apply the QoS profile to the current port.
Ethernet Port view
apply qos-profile interface
Use the apply qos-profile interface command to manually apply a QoS profile to one or more
consecutive ports.
System view
arp check enable
Use the arp check enable command to enable the ARP entry checking function, that is, to disable a switch
from creating multicast MAC address ARP entries for MAC addresses learned.
System view
arp static
Use the arp static command to configure the static ARP mapping entries in the ARP mapping table.
System view
arp timer aging
Use the arp timer aging command to configure the aging time for dynamic ARP mapping entries.
System view
ascii
Use the ascii command to configure data transmission mode as ASCII mode.
FTP Client view
attribute
Use the attribute command to configure attributes of a user whose service type is lan-access.
Local User view
authentication
Use the authentication command to configure an authentication scheme for the current ISP domain.
ISP Domain view
authentication-mode
Use the command authentication-mode to specify the authentication mode.
User Interface view
authorization
Use the authorization none command to allow users in the current ISP domain to use network services
without being authorized.
ISP Domain view

43Com Switch 4200G Family
Command Reference
auto-build
Use the auto-build command to create a cluster automatically.
Cluster view
auto-execute command
Use the auto-execute command command to set the command that is executed automatically after a user
logs in.
User Interface view
binary
Use the binary command to specify that files be transferred in binary mode. That is, data is transferred in
binary streams.
FTP Client view
black-list add-mac
Use the black-list add-mac command to add a device into the blacklist.
Cluster view
black-list delete-mac
Use the black-list delete-mac command to delete a device from the blacklist.
Cluster view
boot attribute-switch
Use the boot attribute-switch command to switch between the main and backup attribute for all the files
or a specified type of files. This changes a file with the main attribute to one with the backup attribute, or
vice versa.
User view
boot boot-loader
Use the boot boot-loader command to configure an app file to be of the main attribute. The app file
specified by this command becomes the main startup file when the device starts the next time.
User view
boot boot-loader
Use the boot boot-loader command to specify the host software that will be adopted when the current
switch or a specified switch in the fabric reboots next time.
User view
boot boot-loader backup-attribute
Use the boot boot-loader backup-attribute command to configure an app file to be of the backup
attribute.
User view
boot bootrom
Use the boot bootrom command to update the BootROM.
User view
boot web-package
Use the boot web-package command to configure a Web file to be of the main or backup attribute.
User view
broadcast-suppression
Use the broadcast-suppression command to define the broadcast traffic ratio allowed on one port or each
of the ports.
System view
build
Use the build command to configure a cluster with the current switch as the management device. Argument
name specifies the name of the cluster.
Cluster view
bye
Use the bye command to terminate the connection to the remote SFTP server and return to system view.
SFTP Client view
bye
Use the bye command to terminate the control connection and data connection with the remote FTP server
and quit to user view.
FTP Client view
cd
Use the cd command to change the current path on the remote SFTP server.
SFTP Client view

3Com Switch 4200G Family 5
Command Reference
cd
Use the cd command to enter a specified directory on the Ethernet switch.
User view
cd
Use the cd command to change the work path on the remote FTP server.
FTP Client view
cdup
Use the cdup command to return to the upper directory.
SFTP Client view
cdup
Use the cdup command to enter the parent directory.
FTP Client view
check region-configuration
Use the check region-configuration command to display the configurations of the MST regions that are
not activated.
MST Region view
clock datetime
Use the clock datetime command to set the current system time and date.
User view
clock summer-time
Use the clock summer-time command to set the name, time range, and offset of the daylight saving time.
User view
clock timezone
Use the clock timezone command to set local time zone information.
User view
close
Use the close command to terminate an FTP connection without quitting FTP client view.
FTP Client view
cluster
Use the cluster command to enter cluster view.
System view
cluster enable
Use the cluster enable command to enable the cluster function on a switch.
System view
cluster-local-user
Use the cluster-local-user command to configure a Web username and password for all cluster
members.
Cluster view
cluster-mac
Use the cluster-mac command to configure a multicast MAC address for cluster management. Run this
command only on the management device only.
Cluster view
cluster-mac syn-interval
Use the cluster-mac syn-interval command to set the interval for the management device to send
multicast packets. This command can be executed on the management device only.
Cluster view
cluster-snmp-agent community
Use the cluster-snmp-agent community command to configure a SNMP community for a cluster to enable
SNMP access.
Cluster view
cluster-snmp-agent group v3
Use the cluster-snmp-agent group command to configure a SNMP group for a cluster to map SNMP
users to the SNMP view.
Cluster view
cluster-snmp-agent mib-view included
Use the cluster-snmp-agent mib-view command to create or update the information about the MIB view
configured for a cluster.
Cluster view

63Com Switch 4200G Family
Command Reference
cluster-snmp-agent usm-user v3
Use the cluster-snmp-agent usm-user v3 command to add an account to the SNMPV3 group configured
for a cluster.
Cluster view
cluster switch-to
Use the cluster switch-to command to switch between the management device and member devices
for configuration and management.
User view
cluster switch-to sysname
Use the cluster switch-to sysname command to switch between the master device and a member
device.
User view
command-privilege level
Use the command-privilege level command to set the level of the specified command in a specified view.
System view
copy
Use the copy command to copy a file.
User view
copy configuration
Use the copy configuration command to copy the configuration of a specific port to other ports, to ensure
consistent configuration.
System view
cut connection
Use the cut connection command to cut the connection a user or a category of users by force.
System view
data-flow-format
Use the data-flow-format command to set the units of measure for the data flow sent to the RADIUS
Server.
RADIUS Scheme view
databits
Use the databits command to set the databits for the user interface.
User Interface view
debugging
Use the debugging command to enable the system debugging.
User view
debugging
Use the debugging command to enable the system debugging.
User view
debugging arp packet
Use the debugging arp packet command to enable ARP debugging.
User view
debugging dhcp client
Use the debugging dhcp client command to enable debugging for the DHCP client/BOOTP client.
User view
debugging dhcp-relay
Use the debugging dhcp-relay command to enable DHCP relay debugging.
User view
debugging DLDP
Use the debugging dldp command to enable specific debugging for DLDP on all ports with DLDP enabled.
User view
debugging ntp-service
Use the debugging ntp-service command to debug different NTP (network time protocol) services.
User view
debugging radius
Use the debugging radius command to enable the debugging for RADIUS protocol.
User view
debugging snmp-agent
Use the debugging snmp-agent command to enable SNMP Agent debugging.
User view

3Com Switch 4200G Family 7
Command Reference
debugging udp-helper
Use the debugging udp-helper command to enable UDP Helper debugging.
User view
delete
Use the delete command to delete a specified file stored on a switch.
User view
delete
Use the delete command to delete the specified file from the server.
SFTP Client view
delete
Use the delete command to delete the specified remote file.
FTP Client view
delete-member
Use the delete-member command to remove a member device from the cluster.
Cluster view
delete static-routes all
Use the delete static-routes all command to delete all the static routes.
System view
description
Use the description command to enter a description of an Ethernet port.
Ethernet Port view
description
Use the description command to assign a description string for the VLAN.
Use the undo description command to restore the default description string.
VLAN view
description
Use the description command to assign a description string to a VLAN or a VLAN interface.
VLAN view
VLAN Interface view
description
Use the description command to define the description information of an ACL to describe the specific
purpose of the ACL.
Basic ACL view
Advanced ACL view
Layer 2 ACL view
dhcp relay information enable
Use the dhcp relay information enable command to enable option 82 supporting on a DHCP relay,
through which you can enable the DHCP relay to insert option 82 into DHCP request packets sent to a
DHCP server.
System view
dhcp relay information strategy
Use the dhcp relay information strategy command to instruct a DHCP relay to perform specified
operations to DHCP request packets that carry option 82.
System view
dhcp-security static
Use the dhcp-security static command to configure a static user address entry.
System view
dhcp-server
Use the dhcp-server command to map the current VLAN interface to a DHCP server group.
VLAN Interface view
dhcp-server ip
Use the dhcp-server ip command to configure the DHCP server IP address(es) in a specified DHCP
server group.
System view
dir
Use the dir command to display the information about the specified files or directories on a switch.
User view

83Com Switch 4200G Family
Command Reference
dir
Use the dir command to query specified files.
FTP Client view
dir
Use the dir command to display the files in the specified directory.
SFTP Client view
disconnect
Use the disconnect command to terminate a FTP connection without quitting FTP client view.
FTP Client view
display acl
Use the display acl command to view the detailed configuration information of an ACL, including each
rule and its number as well as the number and size in bytes of the data packets that match the statement.
Any view
display am user-bind
Use the display am command to view whether address management is enabled and to display IP address
pool configuration.
Any view
display arp
Use the display arp command to display the ARP mapping table entries by entry type, or by a specified
IP address.
Any view
display arp count
Use the display arp count command to display the number of the specified type of ARP mapping entries.
Any view
display arp timer aging
Use the display arp timer aging command to view the current setting of the dynamic ARP aging timer.
Any view
display boot-loader
Use the display boot-loader command to display the information about the app startup files of a switch,
including the current app startup file name, the main and backup app startup files to be used when the switch
starts the next time.
Any view
display boot-loader
Use the display boot-loader command to display the host software (.bin file) that will be adopted when
the switch reboots.
Any view
display bootp client
Use the display bootp client command to display BOOTP client-related information, including the MAC
address of the BOOTP client and the IP address obtained.
Any view
display brief interface
Use the display brief interface command to display the configuration information about one specific
or all ports in brief, including the port type, connection state, connection rate, duplex attribute, link type and
default VLAN ID.
Any view
display channel
Use the display channel command to display the details about the information channel.
Any view
display clock
Use the display clock command to display the current date and time of the system, so that you can adjust
them if they are wrong.
Any view
display cluster
Use the display cluster command to display the state and basic configuration information of the cluster
that contains the current switch.
Any view
display cluster base-topology
Use the display cluster topology command to display the standard topology view of the cluster.
Any view

3Com Switch 4200G Family 9
Command Reference
display cluster black-list
Use the display cluster black-list command to display the current blacklist of the cluster.
Any view
display cluster candidates
Use the display cluster candidates command to display candidate devices of a cluster.
Any view
display cluster current-topology
Use the display cluster current topology command to display the current topology view or the topology
path between two points.
Any view
display cluster members
Use the display cluster members command to display the information about cluster members.
Any view
display connection
Use the display connection command to view the information for a specified connection type.
Any view
display cpu
Use the display cpu command to display CPU usage of a specified switch.
Any view
display current-configuration
Use the display current-configuration command to display the current configuration of a switch.
Any view
display debugging
Use the display debugging command to display the enabled debugging on a specified device.
Any view
display debugging habp
Use the display debugging habp command to display the state of HABP debugging.
Any view
display device
Use the display device command to display the information, such as the module type and operating
status, about each board (main board and sub-board) of a specified switch.
Any view
display dhcp client
Use the display dhcp client command to display the DHCP client-related information.
Any view
display dhcp-security
Use the display dhcp-security command to display one or all user address entries, or a specified type
of user address entries in the valid user address table of a DHCP server group.
Any view
display dhcp-server
Use the display dhcp-server command to display information about a specified DHCP server group.
Any view
display dhcp-server interface vlan-interface
Use the display dhcp-server interface vlan-interface command to display information about the
DHCP server group to which a VLAN interface is mapped.
Any view
display dhcp-snooping
Use the display dhcp-snooping command to display the user IP-MAC address mapping entries recorded
by the DHCP snooping function.
Any view
display dhcp-snooping
Use the display dhcp-snooping command to display the correspondence between user IP addresses and
MAC addresses recorded by the DHCP snooping function.
Any view
display dhcp-snooping trust
Use the display dhcp-snooping trust command to display the (enabled/disabled) state of the DHCP
snooping function and the trusted ports.
Any view

10 3Com Switch 4200G Family
Command Reference
display dhcp-snooping trust
Use the display dhcp-snooping trust command to display the DHCP-Snooping state and information
on trusted ports.
Any view
display diagnostic-information
Use the display diagnostic-information command to display the system diagnostic information, or save
the system diagnostic information to a file (with a suffix of "diag") in the flash memory.
Any view
display domain
Use the display domain command to view the configuration information of a specified ISP domain or
display the summary information of all ISP domains.
Any view
display dot1x
Use the display dot1x command to view the relevant information of 802.1x.
Any view
display fib
Use the display fib command to view the summary of the forwarding information base.
Any view
display ftp-server
Use the display ftp-server command to display the FTP server-related settings of a switch when it
operates as an FTP server.
You can use this command to verify FTP server-related configurations.
Any view
display ftp-user
Use the display ftp-user command to display the settings of the current FTP user, including the user
name, host IP address, port number, connection idle time, and authorized directory.
Any view
display garp statistics
Use the display garp statistics command to display the GARP statistics on specified (or all) ports.
Any view
display garp timer
Use the display garp timer command to display the values of the GARP timers on specified or all ports.
Any view
display gvrp statistics
Use the display gvrp statistics command to display the GVRP statistics about specified (or all) Trunk
ports.
Any view
display gvrp status
Use the display gvrp status command to display the enable/disable status of global GVRP.
Any view
display habp
Use the display habp command to display HABP configuration and status information.
Any view
display habp table
Use the display habp table command to display the MAC address table maintained by HABP.
Any view
display habp traffic
Use the display habp traffic command to display statistics on HABP packets.
Any view
display history-command
Use the display history-command command to display history commands.
Any view
display icmp statistics
Use the display icmp statistics command to view the statistics information about ICMP packets.
Any view
display igmp-snooping configuration
Use the display igmp-snooping configuration command to display the configuration information about
IGMP Snooping.
Any view
